Pet Gear PG8500 Manuel utilisateur

INSTRUCTION MANUAL

Travel System Stroller

PG8500

To see our full line of products, visit us online at: www.petgearinc.com

CUSTOMER SERVICE HELP DESK

[email protected]

Toll-Free 877-752-9123 - Eastern Standard Time 8am-3pm, Monday through Friday

For The ON-THE-GO Pet™

For Pets

Only

Travel System Stroller PG8500

WARNING!

•For pets only.

•Do not carry additional bags, goods, or accessories in or on stroller except as recommended

in the manufacturer's instructions.

•Recommended use of an approved safety restraint correctly fitted and adjusted.

•Do not leave pet unsupervised in stroller.

•Before making adjustments to stroller ensure that pet’s body is clear of any moving parts.

•This stroller is designed for one pet only.

•Do not hang bags from handles as this may cause the product to become unstable.

•Do not use on escalator or stairs; fold stroller and carry.

•Put on brake whenever you park the stroller.

•Ensure stroller is completely erected and check that all locks are engaged before placing pet

in stroller.

•Do not overload as stroller may become unstable; maximum weight of pet using this stroller

should not exceed 15 lbs.

•Any goods carried in the basket not to exceed 6 lbs.

•Do not use near an open or exposed flame.

•To clean and lubricate front and rear wheels, push out locking lever under wheel housing

to release rear wheel.

•To ensure ease of maneuverability and to minimize wear and tear, keep all moving parts

clean and lubricated with WD40® or light machine oil.

•Push wheel sets back on until they click and lock in position;

pull on wheel housings to ensure they are secure.

•Push stroller back and forth and rotate swivels around to work in lubricant.

•Clean the rear wheel assembly and the rest of the frame with warm, soapy water;

clean off with warm water and dry thoroughly.

NOTE: Do not lubricate brake components.

WHEEL MAINTENANCE

For Pets Only. Not intended to be used as a restraining device for

aggressive or dangerous animals that dig, chew or paw aggressively.

Do not leave your pet unattended for long periods of time. Pet Gear is not liable for

any damage caused by aggressive, destructive, immature or untrained animals.

Failure to follow these warnings and the instructions could result in serious injury or death.

For Pets

Up To

15 lbs

Travel System Stroller PG8500

PARTS LIST

Check that you have all the parts shown BEFORE assembling your product.

If any parts are missing, call Customer Service.

STROLLER FRAME BACK TRAY

REAR AXLE ASSEMBLIES REAR WHEELS (2)

FRONT WHEEL

ASSEMBLY (2)

RETAINER WASHER RETAINER CAP HUB CAP

TO OPEN STROLLER

TO ASSEMBLE FRONT WHEELS

4Travel System Stroller PG8500

Step 1. Release locking latch.

Step 2. Unfold as shown. Make sure both

locks snap into place.

Step 1. Turn stroller over as shown.

Step 2. Push wheel assembly onto stroller

leg until it snaps into place. Tug firmly on

wheel assembly to be sure that wheel is

securely in place. Repeat for other wheel.

NOTE: To remove, squeeze tab and pull

wheel off.

Note Direction

of Arrow

TO ASSEMBLE REAR WHEELS

Travel System Stroller PG8500

Step 1. Remove and discard the protective sleeve

from the ends of the rear axle assembly and the

rear leg tubes.

Step 2. Position the rear axle assemblies onto the

rear leg tubes at the same time.

Step 3. Slide the wheel onto the axle.

Step 4. To Install Retainer Washer: Snap the

retainer washer onto the axle. Make sure that the

larger end of retainer washer is toward the wheel

and the slot in the washer lines up with the rib on

the axle. You may need to twist the washer until it

locks into place. (Figures A, B.)

Step 5. To Install Retainer Cap: Snap the retainer

cap over the retainer washer. (Figure C.)

NOTE: If Retainer Cap does not snap completely

over Retainer Washer, Wheel Assembly is NOT

secure and Wheel may come off.

Step 6. Repeat for other side.

Axel Retainer Washer Retainer Cap

Figure A

Figure B

Figure C

TO ATTACH CARRIER TO FRAME

TO USE IN VEHICLE

TO USE AS CARRIER

6Travel System Stroller PG8500

Attach with Velcro-2 places on each side.

Place seat belt through strap and adjust seat belt.

Attach with clips-2 places on

each side.

(Optional)

Attach accessory holder.

TO OPERATE BRAKES

TO FOLD STROLLER

Travel System Stroller PG8500

UNLOCK

LOCK

Step 1. Push levers on both rear wheels down to lock.

Step 2. Pull levers up to unlock.

Step 1. Before folding, Lock brakes and close canopy.

Step 2. Standing behind stroller, pull up on both side latches.

Step 3. Fold as shown.

NOTE: fold stroller so wheels straddle frame.

DO NOT allow wheels to press against frame as this

may damage tires.

Step 4. Engage locking latch.

8Travel System Stroller PG8500

PO Box 99

West Rutland, VT 05777

877-752-9123

www.petgearinc.com

•Always store product in a clean, dry place.

•Not recommended for use on the beach.

•Do not put heavy items on top of the stroller.

•Clean frame by wiping with a lightly oiled cloth.

•Do not use detergent or abrasives. Spot clean fabric with dry cleaning fluid or mild soap

and warm water.

•To ensure easy maneuverability and to minimize wear and tear, (especially wheels, axles,

and swivels), keep all moving parts clean and lubricated with WD40® or light machine oil.

•NOTE: Do not lubricate brake components or swivel locks.

•Regularly check stroller for loose parts. These should be tightened or replaced.

LOOKING AFTER YOUR STROLLER

REPLACEMENT PARTS

Please have your model number ready before calling. Use only Pet Gear replacement parts.
