Page 5
When your pet is missing, you can start tracking your pet with the remote
unit within up to 500 meters in a open area like a large property, or park.
(Distance may vary)
1. On the remote unit, press the “Search”
button once to search for the missing
pet or tag. The Rhythm and signal
strength indicators will initiate.
When going the right direction the
remote will increase in rhythm and
signal strength.
2. You must first
calibrate the remote to
the current environment. Press the search
button, hold remote at chest level, and
scan the area slowly in a circular
direction, from right to left for 360° and
again from left to right (one 360° turn =
3-4 seconds).
Note
: If the “Direction Indicator”
illuminates green on the remote unit
during this calibration process, it does not
yet indicate a tag unit’s direction.
4. Next, slowly scan a third time from
left to right. The “Direction Indicator”
on the remote unit will illuminate (green)
when it establishes the direction of the
tag location.
Note:
Press and
release
Pressand
release
Page 6
360360
Press and
release
How to search for your missing pet or tag
3
It is vital the above steps are done
to get the best tracking accuracy
as it may mean the difference
between finding your pet or not.
Important: Before you start searching,
you must follow the steps below to
calibrate your Pet Tracker 227PA!
SEARCHING FOR YOUR LOST PET (continued)
5.Start moving at the directions where you
think your pet may have wandered off to.
If a certain direction triggers the green LED
and starts increasing rhythm and signal
that means you are going the right way.
If you are walking the wrong way or direction
the green LED will likely stay off while the
signal indicator and rhythm will decrease.
If signal decreases, immediately turn and walk
the other direction or opposite way.
If your pet is moving around you may have
to keep trying different directions.
6. If you get close to within 15-25 meters
the signal strength and rhythm will go on
full via having all LED lights lid up.
The Direction Green LED indicator may
become inaccurate at this stage due to
the strong strength, but you should have
sight of your pet by now. If not, press and
hold to activate the tag to chirp to allow
tracking by sound.
.
7. Once the Tag unit is found, turn off the
Remote unit to stop searching
In quiet areas (e.g. libraries), it is possible to conduct a silent search,
where both the Remote and Tag units are muted. To do this simply, turn on
the “Mute” button on the Remote unit before turning on.
Afterwards, just use the signal strength indicator to search.
The “Mute” button on the side of the Remote unit can be switched on at any
time to silence the Remote unit to avoid distraction in quiet areas (e.g.
libraries).
Press and
release
Press and
release
MUTE MODE (on the Remote unit)
SILENT SEARCH
Page 8
1. When the base unit’s battery is low, the first indicator light at the bottom
will flash continuously while giving a low beeping tone.
2. When the tag unit’s battery is low, the LED will flash once every second
when it’s connected to the base unit and will beep a few times every
twenty seconds.
Note: If you run your units on low batteries, operations may become
unpredictable or results may become innacurate.
The Remote and each of the Tag units are ”Paired” before shipment - that is,
each Remote to Tag combination must have it’s own unique communication
handshake, so that the Remote does not get confused between the Tag
units.The procedures below are used to re-establish the ”Pairing” in case a
Tag unit is replaced or a Tag unit cannot communicate with the Remote. For
this example we ”Pair” the Remote unit to Tag #2 (black) - follow the
instructions below:
1.Make sure the Remote unit and ALL the Tag units are turned off.
2. To enter ”Registration” mode, hold down the ”Set” button (on side of
the Remote unit) and the ”Search” button for Tag #2 on the remote unit
and then, at the same time, turn on the Remote unit - as soon as the red
light above the ”Search” button (for Tag #2) flashes exactly twice,
release the buttons (if you’ve already reached the 3rd flash, you have to
start again).
If you’ve entered the ”Registration” mode successfully, the light above
”Search” button and the light below the ”Dis-alarm” light on the Remote
unit will flash together.
3. Finally, bring Tag #2 to within 10 cm (4 inches) of the Remote unit and
turn it on. TheTag unit will chirp twice, indicating a successful ”Pairing”.
4
BASE UNIT and TAG UNIT PAIRING
5
Low Battery Alerts
Federal Communication Commission Interference Statement
This equipment has been tested and improved to comply with the limits of a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This FCC Certifications equipment generates,
uses and can radiate radio frequency energy, if installed and used not in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determinedly turning the equipment off and
on, the user is encouraged to try to correct the interference by one of the following measures:
■Reorient or relocate the receiving antenna.
■Increase the separation between the equipment and receiver.
■Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
■Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept an interference received, including interference that may cause undesired
operation.
FCC Caution: Any changes or modifications are not expressly approved by the party responsible for
compliance which could void the user's authority to operate this equipment.
EU / RCM Declaration Conformity
This product is carrying the RCM and CE-Mark in accordance with the related European / Australia /
New Zealand Directives.
1. The Tag units are water-repellent, but not waterproof! Keep the device dry. Precipitation,
humidity, and all types of liquids or moisture can contain minerals that may corrode
electronic circuits. If your unit gets wet, remove the battery, and allow the unit to dry
completely before replacing it.
2. If you want to use the device during air flight, please comply with the air safety
regulations for each respective country.
3. We reserve the right to change the hardware/software specifications and designs, as
well as the information in the manuals, at any time without prior notice.
4. Proper operating temperatures for this product are between 40˚F ~104˚F (5˚C~32˚C).
Proper storage Temperatures are between -4˚F~185˚F (-20˚C~85˚C). For operating
temperatures under 40°F (5°C) please use LIR2032 batteries only – Ask your Pet
Tracker agent.
6. The batteries provided in this product should be disposed of properly according to
national or regional recycling regulations - contact local authorities for more information.
Warning: Do not expose the batteries to fire or heat - this may result in danger
from explosions.
Warnings and Important Information
