Perrot ZX30 Series Manuel utilisateur



TDP079eRev.26.03.2019Page1/8



PerrotREGNERBAUCALWGmbHIndustriestraße19‐29/D‐75382Althengstett/Germany

Phone:0049‐7051‐162‐0/E‐mail:[email protected]

Operationmanual



forPERROTagriculturalimpactsprinkler



ZX30

ZA7

ZA22

ZS30

ZB22

ZE30

ZK30

ZM22



TDP079eRev.26.03.2019Page2/8



PerrotREGNERBAUCALWGmbHIndustriestraße19‐29/D‐75382Althengstett/Germany

1. Introduction



Thisoperationmanualshowsonwhatyoushouldpayattentionduringinstallation,

operationandmaintenanceofsolidsetsprinklerirrigationsystems.Inspitethat

maintenanceandoperatingofimpactsprinklersrequirelessattention,therearesome

detailsyoushouldpayattentionto,sothattheinstallationfulfilsitsfunctionandworks

toyourcompletesatisfactionduringalongperiod.



TDP079eRev.26.03.2019Page3/8



PerrotREGNERBAUCALWGmbHIndustriestraße19‐29/D‐75382Althengstett/Germany

2.Typeofsprinklersandinletsizes



number  =trajectoryangle

Withoutletter=fullcirclesprinkler

D   =with2nozzles(backnozzle)

W    =partcirclesprinkler(30‐360°)

WR   =partcirclesprinklerflipupcontrollever

F   =fullcirclesprinklerwithtripod

WF   =partcirclesprinklerwithtripod



TypeofsprinklerAvailabletypesInletsize

ZX30



ZX30WR½“MBSP

ZA7



ZA7/ZA7D/ZA7W½“MBSP

ZA22



ZA22/ZA22D/ZA22W/ZA22WF½“MBSP

ZS30



ZS30¾“MBSP

ZB22



ZB22/ZB22D/ZB22W¾“MBSP

ZE30



ZE30/ZE30W/ZE30F/ZE30WF1“MBSP

ZK30



ZK30/ZK30W1“MBSP

ZM22



ZM22/ZM22W1½“ MBSP

Example:

ZX  30   WR

Typeof  trajectoryangle  partcirclesprinkler

sprinklerflipupcontrollever



TDP079eRev.26.03.2019Page4/8



PerrotREGNERBAUCALWGmbHIndustriestraße19‐29/D‐75382Althengstett/Germany

2.1Installation



Whenconnectingtothepublicsupplynetwork,observethelocalregulations

Pipesaretobelaidinasandbedonstonyground.Thesandbedshould

surroundthepipe10cmonallsides

Wheninstallingthesprinkler,e.g.onastandpipe,makesurethatthesprinkler

headcaneasilybeturnedbyhand.



 



Flushthepipesproperbeforeinstallationofthesprinklers



3.Commissioning



Pipesmustalwaysbefilledslowly,thatmeansyoumustopenthegatevalvegradually,

underobservanceoftheassignedoperatingpressure.Despiteofathoroughlyflushingit

mayhappenthatthesprinklernozzlemayclog.Tocleanthenozzle,youmustunscrew

thenozzleandflushthesprinkler.(Usesocketwrench)

Sprinkler

PE‐pipe

Riserpipe

Sprinkler



Riserpipe



Perrot

Cardan

Quick

couplingpipe



TDP079eRev.26.03.2019Page5/8



PerrotREGNERBAUCALWGmbHIndustriestraße19‐29/D‐75382Althengstett/Germany

4.Adjustments



4.1Wateringarc(settingrange30‐360°)

Thearcofthepartcirclesprinklersisadjustedbypressingagainstthespringstopper,

whichwidensthespring.Aroughalignmentispossiblebeforeinstallation,thefine

adjustmentshouldbemadewiththesprinklerrunning



4.2Radiusrange

Theradiusrangeissetusingdifferentnozzlesandpressures.Forfurtherinformation

seedatasheet



4.3Jetdeflectorscrew(notavailableforallsprinklermodels)

Thejetdeflectorscrewisforadjustmentoftheirrigationnearthesprinkler.Ifthe

screwisturnedfurtherintothewaterjet,theprecipitationclosetoofthesprinkleris

increasedandtheradiuswillbereduced



5.Maintenance/Cleaning/Repair



Checkthesprinklerfunctionatregularintervals



Ifthesprinklerortheturningdevicegetsdirty,itshouldonlyberinsedwithclear

water.Donotuselubricantsorgrease,asthiswilldamagetheslidingdiscsinthe

sprinkler!!!



Removeandrepairdefectivepartsimmediatelyorreturnforrepair



TDP079eRev.26.03.2019Page6/8



PerrotREGNERBAUCALWGmbHIndustriestraße19‐29/D‐75382Althengstett/Germany

6.Winterizing



Beforeshuttingdowntheirrigationsystemforwinter,drainthepipesystemandif

necessary,thepumpingstation.Leavedrainvalveopenuntilrestart.

Withthesprinklers,makesurethatthereisnowaterinthesprinkler.



Assurethatthereremainsnowaterinthesprinklers.



7.TroubleshootingandSolutions



Attention!!!

Beforecarryingoutthefollowingtask,itmustbeensuredthatthepiping

systemisdepressurised.



Iftheradiusofindividualsprinklersistooshort,dirtparticlesmaybepresentinthe

nozzleorinthesprinklerbody.Removeandcleanthesprinklernozzle.Ifnecessary,

thesprinklermustbedismantledtocleanthesprinklerbody.



Ifthesprinklerdoesnotturn,thereareusuallydirtparticlesinthenozzle.Unscrew

nozzleandclean!



Ifthesprinkleronlyturnsinonedirectionandthenstops,eithertheturningdevice

isblocked,orthepressureistoolow.Cleantheturningdevicewithcleanwateror

compressedair(onlyforpartcirclesprinklers).





Subjecttochangewithoutpriornotice.



TDP079eRev.26.03.2019Page7/8



PerrotREGNERBAUCALWGmbHIndustriestraße19‐29/D‐75382Althengstett/Germany

Notes



TDP079eRev.26.03.2019Page8/8



PerrotREGNERBAUCALWGmbHIndustriestraße19‐29/D‐75382Althengstett/Germany



Weremainatyourfulldisposalforanyfurtherinformationyoumayrequire!



REGNERBAUCALWGmbH

Industriestrasse19‐29

75382Althengstett/Germany

Tel.+49/7051/162‐0

Email:[email protected]

http://www.perrot.de
