P/N 5500339-10 (Rev E)

Perle IDS-108F(XT)

Unmanaged 10/100

Ethernet Switches

Installation Guide

- 2 - IDS-108F Installation Guide

Overview

This document contains instructions necessary for the installation

and operation of the Perle IDS-108F Ethernet switch. This

Ethernet switch can be ordered as an 8-port RJ-45 switch or as an

8-port RJ-45 switch with one or two SC or ST fiber ports. The fiber

ports can be either single mode (SM) or multimode (MM)

depending on the model selected and they can operate over

different wavelengths and distances. Visit the Perle website for the

most up to date installation guides, models and specifications.

http://www.perle.com/

Note: xxxxxxxx indicates models numbers for this product line.

TP = twisted pair

XT – Extended Temperature models

Features

•10/100Base-TX, one or two ST/SC fiber ports, multi/single

mode

•IEEE 802.3/802.3u/802.3x

•10/100, Full/Half duplex, MDI/MDIX with auto-sensing

•Auto-negotiation on copper ports

•Redundant DC power inputs

•Rugged high-strength case

•Industrial temperature models

•Din-rail or wall/panel mounting

Note – In this guide the various models will be referred to as the IDS-108F

Model

Port 1-8

Port 9 and 10

IDS-108F TP (RJ-45) empty

IDS-108F-xxxxxxxx TP (RJ-45) 1 or 2 fiber

ports

IDS-108F-XT

(Industrial Temperature Model) TP (RJ-45) empty

IDS-108F-xxxxxxxx-XT

(Industrial Temperature Model) TP (RJ-45) 1 or 2 fiber

ports

IDS-108F installation Guide

-

3

-

Getting to know your IDS-108F Switch

Package Contents:

•IDS-108F

•DIN-rail mounting clip (pre-installed on the unit)

•This guide

Note – Optional panel/wall mounting kits may be ordered for the IDS-108F

Front View of IDS-108F

(8 port RJ-45)

- 4 - IDS-108F Installation Guide

Front View of IDS-108F

(with two Fiber ports)

IDS-108F installation Guide

-

5

-

Bottom view of the IDS-108F

(with two ST fiber

ports)

Top view of the IDS-108F

Specifications

Terminal block Header (J1) – Cat. No. 5EHDR-04P,

manufacturered by Dinkle Enterprise Co., Ltd. Rated 300 V, 15 A,

105°C, FW-1.

Terminal block Plug – Cat. No. 5ESDV-04P, manufacturing by

Dinkle Enterprise Co., Rated 300 V, 105°C, FW-2, suitable for 28-

12 AWG (0.0804-3.31 mm2), torque value 4.5 lb-in.

Power

The IDS-108F switch has two power inputs that can be connected

simultaneously to DC or AC power sources. If one power source

fails, the other acts as a backup, and automatically powers the

switch.

- 6 - IDS-108F Installation Guide

Reset Button

To reset the IDS-108F insert a paper clip into the air hole vent and

gently press the reset button. The LEDs on the IDS-108F will go

On and then momentarily Off when released to show that the unit

has been reset. All links will be dropped and the MAC tables will

be cleared.

Status LED

(with two fiber ports)

P1 / P2– Power (Green LED)

On: Power present

Off: No Power present

Fiber Port 9/10 (Green LED)

On: Link up

Flashing: Link up and Ethernet activity detected

Off: Link down

Ethernet Port Status

Port Link / Speed (Green and Yellow LEDs)

On: Link Up

o100 Mbps Yellow on

o10 Mbps Yellow off

Flashing: Link up and Ethernet activity detected

Off : Link down

IDS-108F installation Guide

-

7

-

Dimensions for the IDS-108F

- 8 - IDS-108F Installation Guide

IDS-108F installation Guide

-

9

-

Mounting the IDS-108F on a DIN-rail

1. The DIN-rail clip will be fixed to the back panel of the IDS-

108F switch when you receive the product.

2. Position the IDS-108F such that the top of the DIN rail fits into

the slot on the top of the DIN-rail clip, just below the DIN-rail

hook and behind the spring.

3. While pushing down on the unit to compress the spring, rotate

the bottom of the IDS-108F toward the rail. This will snap the

bottom of the rail into the bottom of the clip. See diagram

below.

Note: To remove the IDS-108F from the DIN-rail, push down slightly on the

IDS-108F unit while pulling the bottom out.

Wall Mounting the IDS-108F

1. Remove the DIN-rail clip from the rear panel on the IDS-108F.

2. Attach the wall mount plates to the IDS-108F as shown below

using the screws provided in the kit.

- 10 - IDS-108F Installation Guide

3. Use the wall mount plates as a guide to mark the spots where

the screws will be.

4. Drive the screws into the wall leaving about 2 mm of the screw

protruding from the wall to allow room for sliding the wall

mount panel between the wall and the screws.

5. Once the screws are fixed to the wall, insert the four screw

heads through the large parts of the keyhole shaped screw

openings.

6. Pull the IDS down to lock the IDS-108F to the wall mount.

7. Tighten the four screws securely to the wall.

Note: For the best results use screws that have the following attributes:

Head diameter .5 - .6 mm

Shaft diameter 3 - 3.5 mm

Note: the dimensions are in mm
