Perle IDS-409-SFP Manuel
IDS-409-SFP Hardware Installation Guide
Managed Industrial Ethernet Switches
Updated October 2016
Revision 1.10
Document Part# 5500377-10
www.perle.com
IDS-409-SFP Hardware Installation Guide
THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS GUIDE ARE SUBJECT TO CHANGE
WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS GUIDE ARE BELIEVED TO BE
ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE
FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.
This e uipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC
rules. These limits are designed to provide reasonable protection against harmful interference when the e uipment is operated in a
commercial environment. This e uipment generates, uses, and can radiate radio-fre uency energy and, if not installed and used in
accordance with this hardware guide may cause harmful interference to radio communications. Operation of this e uipment in a
residential area is likely to cause harmful interference, in which case users will be re uired to correct the interference at their own
expense.
Modifications to this product not authorized by Perle could void the FCC approval and negate your authority to operate the product.
Perle reserves the right to make changes without further notice, to any products to improve reliability, function, or design.
Perle, the Perle logo, and IDS Switch are trademarks of Perle Systems Limited.
©2016. Perle Systems Limited.
Table of Contents
Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Switch Model Views . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Port Status Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Terminal Block Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
DIP Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Cautions and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Terminal Block-Power Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Grounding the IDS switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Connecting Power to the IDS Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Wiring the Relay Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Wiring Digital Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Connecting the Console Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Connecting Data Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
SFP Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Resetting the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Configuring the IDS Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Appendix A - Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Appendix B - Sample Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Appendix C - Mechanical Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Appendix D - DIN Rail and Wall Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Appendix E - IDS Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Appendix F - Cables and Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
2
IDS-409-SFP Hardware Installation Guide
Preface
Audience
This guide is for the network or computer technician responsible for installing Perle IDS-
409 series switches. amiliarity with the concepts and terminology of Ethernet and local
area networks is required.
Purpose
This document describes the hardware and physical characteristics of the Perle IDS
switch. It covers hardware features as well as installation and operation of the switch. This
document does not cover how to configure your Perle IDS switch. Information to config-
ure your Perle IDS switch can be found in the User’s Guide
Package Contents
• IDS switch with attached DIN rail mounting bracket
• Quick Start Guide
Document Conventions
This document contains the following conventions:
Most text is presented in the typeface used in this paragraph. Other typefaces are used to
help you identify certain types of information. The other typefaces are:
Note: Means reader take note: notes contain helpful suggestions.
Caution: Means reader be careful. In this situation, you might perform an action that
could result in equipment damage or loss of data.
Warning: IMPORTANT SAFETY INSTRUCTIONS
Means danger. You are in a situation that could cause bodily injury. Before you work on
any equipment, be aware of the hazards involved with electrical circuitry and be familiar
with standard practices for preventing accidents. Only qualified personnel should connect
power to this unit.
Overview 3
IDS-409-SFP Hardware Installation Guide
Overview
This chapter discusses the following topics:
• LED Indicators
• Switch Model View
• Ports
• Port Status Indicators
The table below gives a brief overview of the models covered in this guide. or more
details and for the most up-to-date list of models, please refer to the product pages at
www.perle.com.
Standard
Models
10/100/1000Base-T
Ports SFP Temp
IDS-409-SFP 8 1 Standard
IDS-409-2SFP 7 2 Standard
IDS-409-3SFP 6 3 Standard
IDS-409-5SFP 4 5 Standard
IDS-409-SFP-XT 8 1 Industrial
IDS-409-2SFP-XT 7 2 Industrial
IDS-409-3SFP-XT 6 3 Industrial
IDS-409-5SFP-XT 4 5 Industrial
Overview 4
IDS-409-SFP Hardware Installation Guide
Switch Model Views
IDS-409-SFP
IDS-409-SFP-XT
1 – Terminal Block for Power 1, 2 8 – Terminal Block – Relay, I/O
2 – Status L Ds 9 – SFP Status L D
3 – Console Port – serial 10 - SFP Slot
4 – Console Port – USB 11 - Reset / FS (Fast Setup)
5 – DIP switches 12 - Wall Mount Bracket Screw Holes
6 – 10/100/10100 Base-T Ports 13 - DIN Rail Clip
7 – SD Card Slot
Overview 5
IDS-409-SFP Hardware Installation Guide
IDS-409-2SFP
IDS-409-2SFP-XT
1 – Terminal Block for Power 1, 2 8 - SD Card Slot
2 – Status L Ds 9 – Terminal Block – Relay, I/O
3 – Console Port – serial 10 – 10/100/1000 Base-T Port
4 – Console Port – USB 11 - SFP Slots
5 – DIP switches 12 - Reset / FS (Fast Setup)
6 – SFP Status L Ds 13 - Wall Mount Bracket Screw Holes
7 – 10/100/1000 Base-T Ports 14 - DIN Rail Clip
Overview 6
IDS-409-SFP Hardware Installation Guide
IDS-409-3SFP
IDS-409-3SFP-XT
1 – Terminal Block for Power 1, 2 8 - SD Card Slot
2 – Status L Ds 9 – Terminal Block – Relay, I/O
3 – Console Port – serial 10 – SFP Slots
4 – Console Port – USB 11 - Reset / FS (Fast Setup)
5 – DIP switches 12 - Wall Mount Bracket Screw Holes
6 – SFP Status L Ds 13 - DIN Rail Clip
7 – 10/100/1000 Base-T Ports
Overview 7
IDS-409-SFP Hardware Installation Guide
IDS-409-5SFP
IDS-409-5SFP-XT
1 – Terminal Block for Power 1, 2 8 - SD Card Slot
2 – Status L Ds 9 – Terminal Block – Relay, I/O
3 – Console Port – serial 10 – SFP Slots
4 – Console Port – USB 11 - Reset / FS (Fast Setup)
5 – DIP switches 12 - Wall Mount Bracket Screw Holes
6 – SFP Status L Ds 13 - DIN Rail Clip
7 – 10/100/1000 Base-T Ports
Overview 8
IDS-409-SFP Hardware Installation Guide
LED Indicators
P (Power Inputs)
Sys (System Status)
Alr (Alarm)
BC (Backup Coupling)
State Description
Green
P1 and P2 Power in uts within s ecifications
Yellow
P1 or P2 Providing ower within s ecifications
Red
Neither P1 or P2 roviding ower within s ecifications
State Description
Green - blinking (after power on)
System booting
Green - solid
System ready/o erating normally
Green - blinking slowly
Fast Setu Mode activated/ ort available
Green - blinking fast
Fast Setu Mode activated/no ort avail-
able
Red
Hardware fault or firmware load error
State Description
Off
No alarms configured
Green - solid
Alarms configured, but no alarms detected
Red - solid
Alarm condition detected
Red - blinking
Alarm condition detected and Alarm Relay activated
State Description
Off
Backu Cou ling not enabled
Green - solid
Backu Cou ling Link enabled
