Perfect Prime TC0301 Manuel utilisateur
Datalogger Thermometer
TC0301
Instruction Manual
CONTENTS
P. 1
1. Introduction
2. Specifications
3. Symbol Definition and Button
3.1 Location
4. Operation Instructions
4.1 Power-Up
4.2 Connecting the Thermocouples
4.3 Selecting the Temperature Scale
4.4 Data-Hold Operation
4.5 T1,T2,T1-T2 Display Control
4.6 Relative Operation
4.7 MAX/MIN/AVG Operation
4.8 Auto Power O
4.9 Low Battery Condition
4.10 Calibration Point
4.11 Digital Output
................................................................................................ 2
......................................................................................... 2 - 4
............................................................. 5 - 6
.................................................................................................. 6
........................................................................ 7 - 13
............................................................................................... 7
.............................................................. 7
............................................................. 7
............................................................................... 7
..................................................................... 7
.................................................................................. 7
........................................................................ 8
........................................................................................ 8
.......................................................................... 9
................................................................................. 9
............................................................................... 9 - 13
1. INTRODUCTION/
2. SPECIFICATIONS
P. 2
This instrument is a digital thermometer for use with any K-type thermo-
couple as temperature sensor. Temperature indication follows National
Bureau of Standards and IEC584 temperature/voltage table for K-type
thermocouples.
NUMERICAL DISPLAY:
4 digital liquid crystal display
MEASUREMENT RANGE:
-200°C ~ 1370°C -328°F ~ 2498°F
RESOLUTION:
-200°C~ 200°C 0.1°C; 800°C ~1370°C 1°C
-200°F~ 200°F 0.1°F; else 1°F
MAXIMUM VOLTAGE AT THERMOCOUPLE INPUT:
60V DC, or 24Vrms AC
ENVIRONMENTAL:
• Operating Temperature and Humidity: 0°C ~50°C (32°F ~ 122°F);
0 ~ 80% RH
• Storage Temperature and Humidity: -10°C to 60°C (14°F ~ 140°F);
0 ~ 80% RH
• Altitude up to 2000 meters.
SPECIFICATIONS
INTRODUCTION
2. SPECIFICATIONS
P. 3
Range
-200°C ~ 200°C
200°C ~ 400°C
400°C~1370°C
-328°F ~ -400°F
-200°F ~ 200°F
200°F ~ 400°F
400°F ~ 2498°F
Accuracy
±(0.3% reading + 1°C)
±(0.5% reading + 1°C)
±(0.3% reading + 1°C)
±(0.5% reading + 2°F)
±(0.3% reading + 2°F)
±(0.5% reading + 2°F)
±(0.3% reading + 2°F)
ACCURACY: AT 23 ± 5°C
For T1-T2 Measurement, the accuracy is
±( 0.5% T1-T2 reading + 2°C) or ±( 0.5% T1-T2 reading + 2°F)
TEMPERATURE COEFFICIENT:
For ambient temperatures from 0°C ~ 18°C and 28°C ~ 50°C, for each
°C ambient below 18°C or above 28°C add the following tolerance
into the accuracy spec.
0.01% of reading + 0.03°C ( 0.01% of reading + 0.06°F )
NOTE:
The basic accuracy Specication does not include the error of the
probe please refer to the probe accuracy specication for additional
details.
SAMPLE RATE:
0.6 times per second
DIMENSION:
184×64×30mm
WEIGHT:
210g Approx.(7.4oz)
ACCESSORY:
K Type Bead Probe, Battery, Carrying Case, Instruction Menu.
OPTION:
Soft Ware Package ( Program, RS232 Connection Cable) , AC Adapter.
POWER REQUIREMENT:
9 Volt Battery, NEDA 1604 or JIS 006P or IEC6F22
BATTERY LIFE:
Approx. 100hrs with alkaline battery
AC ADAPTER:
9VDC ±15% 100mA ; Plug Diameter: 3.5×1.35mm
P. 4
2. SPECIFICATIONS
: This indicates that the minus temperature is sensed.
: Centigrade and Fahrenheit indication.
: Thermocouple Type Indication
: This indicates that the display data is being hold.
: The Maximum value is now being displayed.
: The Minimum value is now being displayed.
: The Average value is now being displayed.
: The reading is now under Relative Mode.
: The Battery is not sucient for proper operation.
-
°C °F
K
HOLD
MAX
MIN
AVG
REL
3. SYMBOL DEFINITION AND BUTTON
LOCATION
P. 5
Main Display Second Display
3. SYMBOL DEFINITION AND BUTTON
LOCATION
P. 6
T1 K type temperature
sensor connector
T2 K type temperature
sensor connector
LCD display
ON/OFF button
HOLD button
T1,T2,T1-T2 control button
Relative readout button
MAX MIN Average control
button
°C, °F control button
Oset calibration screw
11 Digital output connector
AC power adapter connector
Tripod connector
Battery cabinet cover
2
3
4
5
6
7
1
9
10
11
12
13
14
8
4.1 POWERUP
Press the key to turn the thermometer On or OFF.
4.2 CONNECTING THE THERMOCOUPLES
For measurement, plug the thermocouple into the input connectors.
4.3 SELECTING THE TEMPERATURE SCALE
When the meter was rst powered on, the default scale setting is set
at Celsius (°C) scale. The user may change it to Fahrenheit (°F) by
pressing “ °C/°F ” button and vice versa to Celsius.
4.4 DATAHOLD OPERATION
The user may hold the present reading and keep it on the display by
pressing the“HOLD”button. When the held data is no longer needed,
one may release the data-hold operation by pressing “HOLD” button
again. When the meter is under Data Hold operation, the “▲REL”
, and “ °C/°F ” button are disabled.
4.5 T1,T2,T1T2 DISPLAY CONTROL
One may select T1,T2 or T1-T2 to show on the main display by
pressing button. When T1 or T2 is select to show on the main
display, the other temperature will be shown on the second display.
When one select T1-T2 to show on the main display, T1 and T2 will be
shown on the second display alternately.
4.6 RELATIVE OPERATION FOR MAIN DISPLAY
When one press the “▲REL” button, the meter will memorize the
present reading and the dierence between the new reading and
the memorized data will be shown on the display. Press the “▲REL”
button again to exit the Relative operation.
4. OPERATION INSTRUCTIONS
P. 7
4.7 MAX/MIN/AVG OPERATION FOR MAIN DISPLAY
When one presses the button the meter will enter the
MAX/MIN mode. Under this mode the maximum value, minimum
value and average value of latest 8 data is kept in the memory
simultaneously and updated with every new data.
When the MAX symbol is display, the Maximum is shown on the
display.
Press again, then the MIN symbol is on the display and also the
minimum reading.
Press again, the AVG symbol is on the display and also the
average reading.
Press again, MAX, MIN and AVG will blink together. This means
that all these data is updated in the memory and the reading is the
present temperature.
One may press to circulate the display mode among these
options.
When the meter is under operation, “▲REL” and “ °C/°F ” are
disabled.
To exit the MAX/MIN mode, one may press and hold for two
seconds.
4.8 AUTO POWER OFF
By default, when the meter is powered on, it is under auto power o
mode. The meter will power itself o after 30 minutes if no key
operation or RS232 communication. Key combination at power on
or RS232 communication can disable auto power o. One may press
and hold “HOLD” button and then power on the meter and there will
be two successive beeps to indicate that auto power o is disabled.
4. OPERATION INSTRUCTIONS
P. 8
4.9 LOW BATTERY CONDITION
When the battery voltage is under proper operation requirement,
the symbol will show on the LCD and the battery need to be
replaced with new one.
4.10 CALIBRATION POINT
Room Temperature 23 ± 3°C
Normally, performing oset Calibration with thermal stabled ice
water through VR1 will give a very good calibration result.
4.11 DIGITAL OUTPUT
The Digital Output is a 9600bps N 81 serial interface.
The RX is a 5V normal high input port.
The TX is a 5V normal high output port.
The command of Digital Output is list below.
input
0 °C
190 °C
1000 °C
1900 °F
Adjust VR
VR1
VR2
VR3
VR4
Tolerance
± 0.1 °C
± 0.1 °C
± 1 °C
± 1 °F
TX
RX
GND
4. OPERATION INSTRUCTIONS
P. 9
