PEERLESS PLA 60-UNL Mode d’emploi

Models: PLA 60-UNL, PLA 60-UNL-S,

PLA 60-UNLP, PLA 60-UNLP-S,

PLAV 60-UNL, PLAV 60-UNL-S,

PLAV 60-UNLP, PLAV 60-UNLP-S

RTPLA 60-S

Installation and Assembly - Universal Articulating

SwivelArm for 32" - 60" Plasma Screens

Maximum UL Load Capacity:175 lb (79 kg)

This product is UL Listed. It must be

installed by a qualified professional

installer.

3215 W. North Ave. • Melrose Park, IL 60160 • (800) 729-0307 or (708) 865-8870 • Fax: (708) 865-2941 • www.peerlessmounts.com

ISSUED: 06-05-06 SHEET #: 202-9141-3 08-17-06

2 of 13 ISSUED: 06-05-06 SHEET #: 202-9141-3 08-17-06

Read instruction sheet before you start installation and assembly.

Installations:

To Wood Stud Walls ...................................................................................................... page 6

To Concrete Walls .......................................................................................................... page 7

IMPORTANT! Turn to the appropriate page for your wall installation.

• DonotbegintoinstallyourPeerlessproductuntilyouhavereadandunderstoodtheinstructionsandwarnings

containedinthisInstallationSheet.Ifyouhaveanyquestionsregardinganyoftheinstructionsorwarnings,please

callPeerlesscustomercareat1-800-729-0307.

• Thisproduct should only be installed by a qualified professional.

• Makesure that the supporting surface will safely support the combined load of the equipment and all attached hard-

wareand components.

• Neverexceed the Maximum UL Load Capacity of 175 lb (79 kg).

• Never mount this product to metal studs.

• If mounting to wood wall studs, make sure that mounting screws are anchored into the center of the studs. Use of an

"edgeto edge" stud finder is highly recommended.

• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.

• Tightenscrewsand nutsfirmly, but do not overtighten. Overtightening can damage theitems,greatlyreducing their

holdingpower.

WARNING

WALLCONSTRUCTION ADDITIONAL HARDWARE REQUIRED

Wood Stud, Wood Beam none

Solid Concrete Contact Customer Care for accessory kit

Other or unsure? Contact Customer Care

IMPORTANT! Certain types of walls require additional mounting hardware...

Accessories

•concreteanchor 4-pack (ACC 224)

Tools Needed for Assembly

•studfinder ("edge to edge" stud finder is recommended)

•drill

•7/32" drill bit for wood studs

•5/16" drill bit for concrete

•7/16"socketwrenchwithextension(recommended)

•level

•phillipsscrewdriver

3 of 13 ISSUED: 06-05-06 SHEET #: 202-9141-3 08-17-06

PLA60-UNL PLA60-UNL-S PLAV60-UNL PLAV60-UNL-S

PLA60-UNLP PLA60-UNLP-S PLAV60-UNLP PLAV60-UNLP-S

DESCRIPTION QTY. PART# PART# PART# PART#

Awallplate 1 201-1040 201-4040 201-1040 201-4040

Btilt-roll assembly 1 201-1093 201-4093 201-1048 201-4048

Carmassembly 1 201-1072 201-4072 201-1049 201-4049

Dwallsupport arm axle 1 201-1041 201-1041 201-1041 201-1041

Evinyltrim 3 600-1012 600-1012 600-1012 600-1012

FM10 x 1.5 x 15 mm screw bolt 8 520-9262 520-9262 520-9262 520-9262

G.505 x .75 x .062" nylon washer 1 540-1074 540-1074 540-1074 540-1074

Htilt adjustment knob 1 560-0108 560-0108 560-0108 560-0108

Icarriage bolt 3/8"-16 x 3.25" 1 520-1315 520-1315 520-1315 520-1315

J1.525 x 2 x .062" delrin washer 2 540-1070 540-1070 540-1070 540-1070

K#8-32 x .375" socket cap screw 1 520-1210 520-1210 520-1210 520-1210

Lplastic finishing cap 8 590-1123 590-1123 590-1123 590-1123

Mholdingpin 1 580-1166 580-1166 580-1166 580-1166

Nretainerplug 1 590-1007 590-1007 590-1007 590-1007

O5/16 x 3" wood screw 8 520-1243 520-1243 520-1243 520-1243

P.250 x 1 x .068" washer 8 540-1063 540-1063 540-1063 540-1063

Q9/64"allenwrench 1 560-9728 560-9728 560-9728 560-9728

Rcablemanagementclips 4 590-1166 590-1166 590-1166 590-1166

Scable tie 4 590-1168 590-1168 590-1168 590-1168

T36"polyestermeshsleeve 1 600-1015 600-1015 600-1015 600-1015

U6 mm allen wrench 1 560-9716 560-9716 560-9716 560-9716

V10mmallenwrench 1 n/a n/a 560-9727 560-9727

Wall Mount Parts List

Some parts may appear slightly different than illustrated.

Before you start make sure all parts

listed are included with your product.

OPU

RTPLA60-S

4 of 13 ISSUED: 06-05-06 SHEET #: 202-9141-3 08-17-06

PLA 60-UNL PLA 60-UNL-S PLA 60-UNLP PLA 60-UNLP-S

PLAV 60-UNL PLAV 60-UNL-S PLAV 60-UNLP PLAV 60-UNLP-S

Description Qty Part # Part # Part # Part #

AA adapter bracket 1 201-1110 201-4110 201-1110 201-4110

BB shallow adapter bracket 2 200-0756 200-0757 200-0754 200-0755

CC deep adapter bracket 2 200-0752 200-0753 200-0750 200-0751

DD allen wrench 1 560-9646 560-9646 560-0072 560-0072

Before you begin, make sure all parts shown are included with your product.

Adapter Bracket Parts List

RTPLA60-S

5 of 13 ISSUED: 06-05-06 SHEET #: 202-9141-3 08-17-06

M5 x 25 mm (4)

520-1122

M4 x 12 mm (6)

510-1079

M4 x 25 mm (4)

510-1082

M5 x 12 mm (4)

520-1064 M6 x 12 mm (4)

520-1050

M6 x 25 mm (4)

520-1211

I.D. 5.6 mm (4)

540-1057

multi-washer(6)

580-1036

I.D. 8.7 mm (4)

540-1059

SecurityAdapter Bracket Fasteners

M6 x 20 mm (4)

520-9554

M6 x 30 mm (4)

520-1067

M8 x 15 mm (6)

520-1068

M8 x 40 mm (4)

520-1152

M8 x 25 mm (4)

520-1101

M6 x 20 mm (4)

520-9402

M6 x 30 mm (4)

510-9109 multi-washer(6)

580-1036

M8 x 16 mm (6)

520-9257

M8 x 40 mm (4)

520-1136

M4 x 12 mm (6)

504-9013

Phillips Adapter Bracket Fasteners

M4 x 25 mm (4)

504-1015

M5 x 12 mm (4)

520-1027 M5 x 25 mm (4)

520-9543

M6 x 12 mm (4)

520-1128

M6 x 25 mm (4)

520-1208

I.D. 5.6 mm (4)

540-1057

M8 x 25 mm (4)

520-1031

I.D. 8.7 mm (4)

540-1059

6 of 13 ISSUED: 06-05-06 SHEET #: 202-9141-3 08-17-06

• Installermust verify that the supporting surface will safely support the combined load of the equipmentandallattached

hardwareandcomponents.

• Tightenwood screws so that wall plate is firmly attached, but donotovertighten. Overtightening can damage the

screws,greatly reducing their holdingpower.

• Never tighten in excess of 80 in. • lb (9 N.M.).

• Never mount this product to metal studs.

• Make sure that mounting screws are anchored into the center of the stud. The use of an "edge to edge" stud finder is

highlyrecommended.

• Hardwareprovided is for attachment of mount throughstandardthickness drywall or plaster into woodstuds.Installers

areresponsible to providehardwarefor other types ofmounting situations.

• Neverexceed the Maximum UL Load Capacity of 175 lb (79 kg).

WARNING

Installation to Wood Stud Wall

Wall plate (A) can be mounted to two studs that are 16" apart. Use a stud finder to locate the edges of the

studs. Use of an edge-to-edge stud finder is highly recommended. Based on their edges, draw a vertical line

down each stud’s center. Place wall plate on wall as a template. The top mounting slots should be located .36"

abovethe desired screen center for PLA60-UNL, PLA60-UNL-S,PLA60-UNLP, PLA60-UNLP-SandRTPLA60-

S and .43" below the desired screen center for PLAV 60-UNL, PLAV 60-UNL-S, PLAV 60-UNLP and PLAV 60-

UNLP-S. Level plate, and mark the center of the eight mounting holes. Make sure that the mounting holes are on

the stud centerlines. Drill eight 7/32" dia. holes 3" deep. Make sure that the wall plate is level, secure it using

eight 5/16 x 3" wood screws (O) and washers (P).

Skip to step 2 on page 8.

7 of 13 ISSUED: 06-05-06 SHEET #: 202-9141-3 08-17-06

IMPORTANT!Concretemustbe 2000 psi densityminimum.

Note: Fasteners for concrete walls are not included,

orderTWO #ACC 224accessory kits forinstallation

on concrete walls.

Use wall plate (A), making sure that it is level, as a

template to mark holes. The top mounting slots should

be located .36" above the desired screen center for PLA

60-UNL,PLA60-UNL-S,PLA60-UNLP,PLA60-UNLP-S

andRTPLA60-S and.43" below thedesired screen

centerfor PLAV60-UNL,PLAV 60-UNL-S,PLAV60-

UNLP and PLAV 60-UNLP-S. Drill 5/16" (8 mm) dia.

holes to a minimum depth of 3" (76 mm). Insert anchors

in holes flush with wall as shown (right). Place wall plate

(A)overanchorsand secure with 5/16 x 3"wood screws

(O)andwashers(P).

• Concrete must be 2000 psi density minimum. Lighter density concrete may not hold concrete anchor.

• Make sure that the supporting surface will safely support the combined load of the equipment and all attached

hardwareandcomponents.

• Neverexceed the Maximum UL Load Capacity of 175 lb (79 kg).

• Never mount this product to metal studs.

WARNING

• Always attach concrete expansion anchors directly to

load-bearingconcrete.

• Neverattach concrete expansion anchors toconcrete

coveredwith plaster, drywall,or other finishing mate-

rial.If mounting to concrete surfaces covered witha

finishingsurface isunavoidable,the finishing surface

mustbe counterbored as shown below.If plaster/

drywall is thicker than 5/8", custom fasteners must be

suppliedby installer (Not evaluated byUL).

WARNING

• Tighten wood screws so that wall plate is firmly

attached,but do notovertighten. Overtightening can

damagescrews, greatly reducingtheirholding power.

• Never tighten in excess of 80 in • lb (9 N.M.).

WARNING

Installation to Concrete Wall

CUTAWAYVIEW

INCORRECT CORRECT

mounting

plate

plaster/

drywall

concrete mounting

plate concrete

plaster/

drywall

concrete

surface

Drill hole(s) and insert anchor(s)

mounting

plate

Place plate over anchor(s) and secure with screw(s)

Tighten all fasteners

concrete

anchor

concrete

anchor

concrete

anchor

8 of 13 ISSUED: 06-05-06 SHEET #: 202-9141-3 08-17-06

Snap four cable management clips(R)into top or bottom of arm assembly(C)as shown.Cable ties (S) are used

withclips for cord management.

Slide one mesh sleeve (T) over each cable. Use cable ties (S) to tighten mesh sleeves to cables.

3-1

DETAIL 3

Note: There are five mounting positions. The

center position is shown (right). Slidewasher (J)

over wall support arm axle (D). Next, insert plastic

cap (N) into axle. Then, insert holding pin (M) into

axle. See detail 1.

Note: Fit of axle (D) into wall plate (A) and arm

assembly (C) will be tight. Gently tap into place

with a hammer if necessary.

2-1

Insert socket cap screw (K) into hole at bottom of

wall support arm axle (D) as shown in detail 3.

Tightenscrew using 9/64" allen wrench(Q).

Place arm assembly (C) with washer (J) into wall

plate (A). Insert axle assembly shown in detail 1

throughwall plate (A), arm assembly (C),and

washer (J). Lock axle in place by aligning holding

pin (M) with notches shown in detail 2.

2-2

DETAIL 1

NOTCH

DETAIL 2

• If you are uncertain that product is properly installed, call customer care.

WARNING

9 of 13 ISSUED: 06-05-06 SHEET #: 202-9141-3 08-17-06

Insert and tape carriage bolt (I) into top hole of pitch-roll assembly (B).Attach tilt-roll assembly to adapter

bracket (AA) with four M10 socket screws (F). Tighten screws using 6 mm allen wrench (U).

• Donot overtightenscrews! Overtighteningmay hinder

rolloption.

CAUTION

Attach two pieces of vinyl trim (E) to wall plate (A). Next, attach one piece of vinyl trim to bottom of swivel box on arm

assembly(C).

4-1 Insertonefinishingcap(L)intoeachunusedholeof wall plate (A).

SWIVELBOX

10 of 13 ISSUED: 06-05-06 SHEET #: 202-9141-3 08-17-06

Insert two M10 screws (F) into swivel box on arm assembly (C) as shown. Leave approx. 1/4" of exposed thread.

.25"

• Use an assistant or mechanical lifting equipment to safely lift and position the plasma TV.

WARNING

• After tilt is adjusted, all fasteners must be tightened.

Failure to do so will result in damage to the mount.

CAUTION

6-1

6-2

fig 6.1 fig 6.2

SWIVELBOX

Hook tilt-roll assembly (B) onto M10 screws (F).

Insert carriage bolt (I) into slot of swivel box as

shown in figure 6.1. Install nylon washer (G) and tilt

adjustmentknob (H).

Install remaining two M10 screws (F) as shown in

figure6.2. HAND TIGHTENallfour M10 screwsto

allowfor tilt adjustment. Removetape from carriage

bolt (I). For tilt adjustment, push back on the top of

plasma to relieve pressure on knob.Adjust tilt to

desired position and tighten tilt adjustment knob (H),

then securely tighten all four M10 screws (F) using 6

mmallen wrench (U).

SWIVELBOX

Adapter bracket not shown for clarity. Adapter bracket not shown for clarity.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels PEERLESS Support et étagère

PEERLESS

PEERLESS SA761PU Mode d’emploi

PEERLESS

PEERLESS PARAMOUNT PP740 Manuel utilisateur

PEERLESS

PEERLESS MIS 213 Mode d’emploi

PEERLESS

PEERLESS DS495 Mode d’emploi

PEERLESS

PEERLESS LWB375 Mode d’emploi

PEERLESS

PEERLESS DS-VW660 and assembly Mode d’emploi

PEERLESS

PEERLESS JMWS 30 Mode d’emploi

PEERLESS

PEERLESS SmartMount RTFPA45 Mode d’emploi

PEERLESS

PEERLESS Smartmount ST670 Mode d’emploi

PEERLESS

PEERLESS WBK100-W Mode d’emploi

PEERLESS

PEERLESS HT642-002 Mode d’emploi

PEERLESS

PEERLESS HCW101 Manuel utilisateur

PEERLESS

PEERLESS ACC951 Mode d’emploi

PEERLESS

PEERLESS PARAMOUNT PSP2-S Mode d’emploi

PEERLESS

PEERLESS PARAMOUNT PRA2X2 Manuel utilisateur

PEERLESS

PEERLESS SmartMount SP740P Mode d’emploi

PEERLESS

PEERLESS Paramount PF660 Mode d’emploi

PEERLESS

PEERLESS Solid-Point PLCM UN1 Mode d’emploi

PEERLESS

PEERLESS ACC-V800X Mode d’emploi

PEERLESS

PEERLESS LCC 18 Mode d’emploi

PEERLESS

PEERLESS Smartmount SA752PU Mode d’emploi

PEERLESS

PEERLESS WSP820 Mode d’emploi

PEERLESS

PEERLESS SF630P-S and assembly Mode d’emploi

PEERLESS

PEERLESS IMC 18 Mode d’emploi

Manuels Support et étagère populaires d'autres marques

Salamander

Salamander Acadia AC/W/L400/WH Manuel utilisateur

Fohhn

Fohhn VAT-09 Guide de l'utilisateur

ricoo

ricoo FS0522 Manuel utilisateur

AMSOIL

AMSOIL BMK-22 Guide rapide

Kargo Master

Kargo Master 48220 Manuel utilisateur

Milestone AV Technologies

Milestone AV Technologies SIMPLICITY SLF2 Manuel utilisateur

ricoo

ricoo S1222 Manuel utilisateur

Ready-Set-Mount

Ready-Set-Mount RSMCM602 Manuel utilisateur

VidaBox

VidaBox VB MNT FFS2 Manuel utilisateur

Welch Allyn

Welch Allyn 48960 Manuel utilisateur

Arkon

Arkon CM035-ST-2 Manuel utilisateur

PROEL

PROEL PLWIN60C Manuel utilisateur

Agilent Technologies

Agilent Technologies E2609B Manuel utilisateur

Mustang

Mustang MV-ARM4 Manuel utilisateur

Mounting Solutions

Mounting Solutions WRM-320 Manuel utilisateur

Pyle

Pyle PMKSPAD1 Manuel utilisateur

ShelterIt

ShelterIt 21208 Manuel utilisateur

SPL

SPL RackPack?4 1040 Manuel utilisateur
