SmartNode 4960 Series

T1/E1 PRI VoIP Router

Quick Start Guide

Document Number: 13223U7-001 Rev. A

Part Number: 07MSN4960-QS

Revised: June 30, 2006

Sales Ofﬁce: +1 (301) 975-1000

Technical Support: +1 (301) 975-1007

E-mail: [email protected]

WWW: www.patton.com

VoIPon www.voipon.co.uk [email protected] Tel: +44 (0)1245 808195 Fax: +44 (0)1245 600030

SmartNode 4960 Series Quick Start Guide

1.0 Power up the SmartNode

Connect the SmartNode to the mains (AC) power source with the power cable.

Wait until the

Power

LED stops blinking and remains constantly lit. Now the SmartNode is ready

to conﬁgure.

2.0 Connecting the SmartNode to your laptop PC

•

The SmartNode contains no user serviceable parts. The equipment shall

be returned to Patton Electronics for repairs, or repaired by qualiﬁed

service personnel.

•

Mains Voltage: Do not open the case when the power cord is attached.

For systems without a power switch, line voltages are present within

the power supply when the power cords are connected. The mains out-

let that is utilized to power the device shall be within 10 feet (3

meters) of the device, shall be easily accessible, and protected by a cir-

cuit breaker.

•

Ensure that the power cable used with this device meets all applicable

standards for the country in which it is to be installed, and that it is con-

nected to a wall outlet which has earth ground.

•

Hazardous network voltages are present in WAN ports regardless of

whether power to the SmartNode is ON or OFF. To avoid electric shock,

use caution when near WAN ports. when detaching the cables, detach

the end away from the SmartNode ﬁrst.

•

Do not work on the system or connect or disconnect cables during peri-

ods of lightning activity.

The interconnecting cables shall be acceptable for external use and shall be rated for

the proper application with respect to voltage, current, anticipated temperature, ﬂam-

mability, and mechanical serviceability.

WARNING

CAUTION

VoIPon www.voipon.co.uk [email protected] Tel: +44 (0)1245 808195 Fax: +44 (0)1245 600030

SmartNode 4960 Series Quick Start Guide

Figure 1.

Connecting to the PC

Connect the PC’s Ethernet port to

LAN (ETH

0/1)

port of the SmartNode 4960. The SmartNode 4960

Series is equipped with Auto-MDX Ethernet ports, so you can use straight-through or cross-over Ethernet

cables for host or hub/switch connections. (See

ﬁgure 1

The SmartNode comes with a built-in DHCP server to simplify conﬁguration. Therefore, to automatically

conﬁgure the PC for IP connectivity to the SmartNode, conﬁgure the laptop PC for DHCP. The SmartNode

will provide the PC with an IP address. Note that only Full Duplex operation is supported. Use auto nego-

tiation for best results.

Check the connection to the SmartNode by executing the

ping

command from the PC command window

as follows:

ping 192.168.1.1

3.0 Conﬁguring the desired IP address

3.1 Factory-default IP settings

The factory default conﬁguration for the Ethernet interface IP addresses and netmasks are listed in

table 1

Both Ethernet interfaces are activated upon power-up. LAN interface

ETH 0/1 (LAN)

provides a default DHCP

server. The WAN interface uses DHCP client to get the IP address and netmask automatically from the

service provider.

If these addresses match with those of your network, go to section

4.0 “Connecting the SmartNode to the

network”

on page 4. Otherwise, continue with the following sections to change the addresses and

network masks.

Table 1.

Factory default IP address and network mask conﬁguration

Item IP Addresss Network Mask

WAN interface Ethernet 0 (ETH 0/0) DHCP DHCP

LAN interface Ethernet 1 (ETH 0/1) 192.168.1.1 255.255.255.0

DHCP server address range (LAN) 192.168.1.10-192.168.1.99 255.255.255.0

LAN (connect to ETH 0/1)

Laptop PC

Ethernet

RS-232

Console

ETH 0/0

ETH 0/1

Reset

0/0

0/1

0/2

0/3

T1/E1

120-240V,50/60 Hz, 1A

Power

VoIPon www.voipon.co.uk [email protected] Tel: +44 (0)1245 808195 Fax: +44 (0)1245 600030

SmartNode 4960 Series Quick Start Guide

3.2 Login

To access the SmartNode, start the Telnet application on your PC. Type the default IP address into the

address ﬁeld:

192.168.1.1

. Accessing your SmartNode via a Telnet session displays the login screen.

Type the factory default login:

administrator

and leave the password empty. Press the

Enter

key after the

password prompt.

administrator

password:<Enter>

192.168.1.1>

After you log in, your SmartNode will be running in operator execution mode (indicated by > character

in the command line prompt). To enter conﬁguration mode, use the commands

enable

and

conﬁgure

192.168.1.1>

enable

192.168.1.1#

configure

192.168.1.1(cfg)#

3.3 Changing the WAN IP address

To modify IP conﬁguration settings, you must enter

context IP

mode. Enter the following command:

192.168.1.1(cfg)#

context ip router

192.168.1.1(ctx-ip)[router]#

Now you can set your IP address and network mask for the interface

ETH 0/0(WAN)

. In this example a

network 172.16.1.0/24 is assumed. The IP address in example is set to

172.16.1.99

. (You should set it

to the IP address that the network provider has given you.)

Note

The examples in this guide use a private IP network with the network address

172.16.1.0/24

192.168.1.1(ctx-ip)[router]#

interface WAN

192.168.1.1(if-ip)[WAN]#

ipaddress 172.16.1.99 255.255.255.0

2002-10-29T00:09:40 : LOGINFO : Link down on interface WAN.

2002-10-29T00:09:40 : LOGINFO : Link up on interface WAN.

172.16.1.99(if-ip)[WAN]#

Copy this modiﬁed conﬁguration to your new start-up conﬁguration. This will store your changes in non-

volatile memory. On the next start-up the system will initialize itself using the modiﬁed conﬁguration.

172.16.1.99 (if-ip)[WAN]#

copy running-config startup-config

172.16.1.99 (if-ip)[WAN]#

The SmartNode can now be connected to your network.

4.0 Connecting the SmartNode to the network

The interconnecting cables shall be acceptable for external use and shall be rated for

the proper application with respect to voltage, current, anticipated temperature, ﬂam-

mability, and mechanical serviceability.

CAUTION

VoIPon www.voipon.co.uk [email protected] Tel: +44 (0)1245 808195 Fax: +44 (0)1245 600030

SmartNode 4960 Series Quick Start Guide

In general, the SmartNode will connect to the network via the

WAN (ETH 0/0)

port. This enables the SmartNode

to offer routing services to the PC hosts on

LAN (ETH 0/1)

port. The SmartNode 4960 Series provides an auto-

MDX feature for both Ethernet ports, so you can use a straight-through or cross-over cable to connect to a host or

a switch (see

ﬁgure 2

Figure 2.

Connecting the SmartNode to the network

You can check the connection with the ping command from the SmartNode to another host on the

local LAN.

172.16.1.99(if-ip)[WAN]#ping <IP Address of the host>

Note

If the WAN address is

not

set to DHCP, to ping a device outside your local LAN you must ﬁrst conﬁgure

the default gateway. (For information on conﬁguring the default gateway, refer to section “Set IP

addresses” in Appendix C, “Command Summary” of the

SmartNode Series SmartWare Software Conﬁg-

uration Guide

5.0 Loading the conﬁguration (optional)

Patton provides a collection of conﬁguration templates on the CD-ROM shipped with your SmartNode device—

and also on the support page at

www.patton.com/voip

—one of which may be similar enough to your

application that you can use it to speed up conﬁguring the SmartNode. Simply download the conﬁguration note

that matches your application to your PC. Adapt the conﬁguration as described in the conﬁguration note to your

network (remember to modify the IP address) and copy the modiﬁed conﬁguration to a TFTP server. The Smart-

Node can now load its conﬁguration from this server.

RS-232

Console

ETH 0/0

ETH 0/1

Reset

0/0

0/1

0/2

0/3

T1/E1

120-240V, 50/60 Hz, 1A

Power

Straight-through wired or crossover cable

LAN (ETH 0/1)

LAN

WAN (ETH 0/0) Network

VoIPon www.voipon.co.uk [email protected] Tel: +44 (0)1245 808195 Fax: +44 (0)1245 600030

SmartNode 4960 Series Quick Start Guide

Note

Patton regularly adds new conﬁguration templates to the collection at

www.patton.com/voip

, so

if you do not see your application on the CD-ROM, it may have been added to the website.

Note

If your application is unique and not covered by any of Patton’s conﬁguration templates, you can man-

ually conﬁgure the SmartNode instead of loading a conﬁguration ﬁle template. In that case, refer to

the

SmartNode Series SmartWare Software Conﬁguration Guide

for information on conﬁguring the Smart-

Node device.

In this example we assume an TFTP server resides on the host with the IP address 172.16.1.11 and the conﬁgu-

ration ﬁle named

SN.cfg

resides in the root directory of the TFTP server.

172.16.1.99(if-ip)[WAN]#

copy tftp://172.16.1.11/SN.cfg startup-

config

Download...100%

172.16.1.99(if-ip)[WAN]#

After you reboot the SmartNode the new startup conﬁguration will become active.

172.16.1.99(if-ip)[WAN]#

reload

Running configuration has been changed.

Do you want to copy the 'running-config' to the 'startup-config'?

Press 'yes' to store, 'no' to drop changes :

Press 'yes' to restart, 'no' to cancel :

yes

The system is going down

6.0 Additional Information

Refer to the

SmartNode Series SmartWare Software Conﬁguration Guide

and the

SmartNode Getting Started Guide

located on the CD-ROM shipped with your SmartNode device and available online at

www.patton.com/

manuals.

For detailed information about:

•

Installing, conﬁguring, operating, and troubleshooting.

•

Warranty, trademark & compliance

The CD-ROM also includes many freeware and shareware tools, including TFTP servers, and Telnet clients.

A.0 Customer and Technical Support

Toll-Free VoIP support: call

sip:[email protected]

with a VoIP SIP client

Online support: www

.patton.com

E-mail support:

[email protected]

—answered within 1 business day

When you issue the reload command, the SmartNode will ask if you want to copy the

running conﬁguration to the startup conﬁguration. Since you just downloaded a con-

ﬁguration ﬁle to the startup conﬁguration you must answer this question with

Otherwise, the downloaded conﬁguration will be overwritten and lost!

IMPORTANT

VoIPon www.voipon.co.uk [email protected] Tel: +44 (0)1245 808195 Fax: +44 (0)1245 600030

SmartNode 4960 Series Quick Start Guide

Telephone support:

•

Standard: +1 (301) 975-1007 (USA), Monday–Friday: 8:00 am to 5:00 pm EST (1300 to

2200 UTC/GMT)

•

Alternate: +41 (0)31 985 25 55 (Switzerland), Monday–Friday: 8:00 am to 5:00 pm CET (0900 to 1800

UTC/GMT)

Fax:

+1 (253) 663-5693

(USA)

or +41 (0)31 985 25 26 (

Switzerland)

B.0 Compliance Information

B.1 Compliance

EMC Compliance:

•FCC Part 15, Class A

•EN55022, Class A

•EN55024

Safety Compliance:

•UL60950-1/CSA C22.2 No. 60950-1

•IEC/EN 60950-1

•AS/NZS 60950-1

PSTN Regulatory Compliance:

•FCC Part 68

•CS-03

•TBR 12 & 13 (E1)

•AS/ACIF S016:2001 (E1)

•AS/ACIF S043:2003

B.2 Radio and TV interference

The SmartNode router generates and uses radio frequency energy, and if not installed and used properly—that

is, in strict accordance with the manufacturer’s instructions—may cause interference to radio and television

reception. The SmartNode router have been tested and found to comply with the limits for a Class A computing

device in accordance with speciﬁcations in Subpart B of Part 15 of FCC rules, which are designed to provide rea-

sonable protection from such interference in a commercial installation. However, there is no guarantee that

interference will not occur in a particular installation. If the SmartNode router does cause interference to radio or

television reception, which can be determined by disconnecting the unit, the user is encouraged to try to correct

the interference by one or more of the following measures: moving the computing equipment away from the

VoIPon www.voipon.co.uk [email protected] Tel: +44 (0)1245 808195 Fax: +44 (0)1245 600030

8SmartNode 4960 Series Quick Start Guide

receiver, re-orienting the receiving antenna and/or plugging the receiving equipment into a different AC outlet

(such that the computing equipment and receiver are on different branches).

B.3 FCC Part 68 (ACTA) Statement

This equipment complies with Part 68 of FCC rules and the requirements adopted by ACTA. On the bottom side of

this equipment is a label that contains—among other information—a product identiﬁer in the format US:

AAAEQ##TXXXX. If requested, this number must be provided to the telephone company.

The method used to connect this equipment to the premises wiring and telephone network must comply with the

applicable FCC Part 68 rules and requirements adopted by the ACTA.

If this equipment causes harm to the telephone network, the telephone company will notify you in advance that

temporary discontinuance of service may be required. But if advance notice isn’t practical, the telephone com-

pany will notify the customer as soon as possible. Also, you will be advised of your right to ﬁle a complaint with

the FCC if you believe it is necessary.

The telephone company may make changes in its facilities, equipment, operations or procedures that could

affect the operation of the equipment. If this happens the telephone company will provide advance notice in

order for you to make necessary modiﬁcations to maintain uninterrupted service.

If trouble is experienced with this equipment, for repair or warranty information, please contact our company. If

the equipment is causing harm to the telephone network, the telephone company may request that you discon-

nect the equipment until the problem is resolved.

Connection to party line service is subject to state tariffs. Contact the state public utility commission, public ser-

vice commission or corporation commission for information.

B.4 Industry Canada Notice

This equipment meets the applicable Industry Canada Terminal Equipment Technical Speciﬁcations. This is con-

ﬁrmed by the registration number. The abbreviation, IC, before the registration number signiﬁes that registra-

tion was performed based on a Declaration of Conformity indicating that Industry Canada technical speci-

ﬁcations were met. It does not imply that Industry Canada approved the equipment.

This Declaration of Conformity means that the equipment meets certain telecommunications network protective,

operational and safety requirements. The Department does not guarantee the equipment will operate to the

user's satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to

the facilities of the local telecommunications company. The equipment must also be installed using an acceptable

method of connection. In some cases, the company’s inside wiring associated with a single line individual service

may be extended by means of a certiﬁed connector assembly (telephone extension cord). The customer should

be aware that compliance with the above condition may not prevent degradation of service in some situations.

Repairs to some certiﬁed equipment should be made by an authorized maintenance facility designated by the

supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give

the telecommunications company cause to request the user to disconnect the equipment. Users should ensure for

their own protection that the ground connections of the power utility, telephone lines and internal metallic water

pipe system, are connected together. This protection may be particularly important in rural areas.

VoIPon www.voipon.co.uk [email protected] Tel: +44 (0)1245 808195 Fax: +44 (0)1245 600030

SmartNode 4960 Series Quick Start Guide 9

B.5 EC Declaration of Conformity

(See section B.6 “EG-Konformitätserklärung” for German version.)

Product Description: SmartNode 4960 Series

This equipment conforms to the requirements of Council Directive 1999/5/EC on the approximation of the laws

of the member states relating to Radio and Telecommunication Terminal Equipment and the mutual recognition

of their conformity.

The signed Declaration of Conformity can be downloaded from www.patton.com/certiﬁcations/.

B.6 EG-Konformitätserklärung

(see section B.5 “EC Declaration of Conformity” for English version)

Produktbezeichnung: SmartNode 4960 Baureihe

Die bezeichneten Produkte stimmen in der von uns in Verkehr gebrachten Ausführung mit den Vorschriften fol-

gender Richtlinie überein:

R&TTE 1999/5/EG

Richtlinie des europäischen Parlaments und des Rates zur Angleichung der Rechtsvorschriften der

Mitgliedstaaten über Funkanlagen und Telekommunikations-Endeinrichtungen und die gegenseitige

Anerkennung ihrer Konformität.

Die unterzeichnete Konformitätserklärung kann heruntergeladen werden von: www.patton.com/

certiﬁcations/.

The safety advice in the documentation accompanying the products shall be obeyed.

The conformity to the above directive is indicated by the CE sign on the device.

Die Sicherheitshinweise in der mitgelieferten Produktdokumentation sind zu beachten.

Die Konformität mit der oben erwähnten Richtlinie wird durch das CE-Zeichen auf dem

Gerät bestätigt.

VoIPon www.voipon.co.uk [email protected] Tel: +44 (0)1245 808195 Fax: +44 (0)1245 600030

10 SmartNode 4960 Series Quick Start Guide

The information in this document is subject to change without notice. Patton Electronics assumes no

liability for errors that may appear in this document.

Trademarks statement

The term

SmartNode

is a trademark of Patton Electronics Company. All other trademarks presented in this docu-

ment are the property of their respective owners.

Warranty, Trademark, & Compliance Information

For warranty, trademark and compliance information, refer to the

Models SN4960 Series Getting Started Guide

located on the CD-ROM that came with your VoIP Gateway Router or available online at www.patton.com.

In accordance with the requirements of council directive 2002/96/EC on Waste of

Electrical and Electronic Equipment (WEEE), ensure that at end-of-life you separate

this product from other waste and scrap and deliver to the WEEE collection system in

your country for recycling.

VoIPon www.voipon.co.uk [email protected] Tel: +44 (0)1245 808195 Fax: +44 (0)1245 600030

Autres manuels pour SmartNode 4960 Series

Table des matières

Autres manuels Patton electronics Routeur réseau

Patton electronics

Patton electronics ENVIRONET EHA3201 Manuel utilisateur

Patton electronics

Patton electronics ONSITE 2603 Manuel utilisateur

Patton electronics

Patton electronics IM2RC/I-100B Manuel utilisateur

Patton electronics

Patton electronics SL4020 Manuel utilisateur

Patton electronics

Patton electronics 3224 Diamond Edge Manuel utilisateur

Patton electronics

Patton electronics SmartNode 07MSN5200-QS Manuel utilisateur

Patton electronics

Patton electronics DIAMONDLINK 3201 Manuel utilisateur

Patton electronics

Patton electronics SMARTNODE 5400 Manuel utilisateur

Patton electronics

Patton electronics SMART NODE 4950-NCE Manuel utilisateur

Patton electronics

Patton electronics IPLink 2821 Manuel utilisateur

Patton electronics

Patton electronics OnSite 2800 Series Manuel utilisateur

Patton electronics

Patton electronics 4110 Series Manuel utilisateur

Patton electronics

Patton electronics 2124 Manuel utilisateur

Patton electronics

Patton electronics DIAMONDLINK 3201 Manuel utilisateur

Patton electronics

Patton electronics IPROCKETLINK 3101 Manuel utilisateur

Patton electronics

Patton electronics Patton IPLink 2635 Manuel utilisateur

Patton electronics

Patton electronics OnSite 1052 Series Manuel utilisateur

Patton electronics

Patton electronics SmartNode 4830 Series Manuel utilisateur

Patton electronics

Patton electronics 2121 Manuel utilisateur

Patton electronics

Patton electronics Patton IPLink 2603 Manuel utilisateur

Patton electronics

Patton electronics IPLink 2802 Manuel utilisateur

Patton electronics

Patton electronics SmartLink 4020 Series Manuel utilisateur

Patton electronics

Patton electronics IpLink 2884 Manuel utilisateur

Patton electronics

Patton electronics SmartNode 4520 Series Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
