Product Model 1058 Standalone and Rack Card

Product Name VDSL Modem

Product Manager

John Grant Contact [email protected]

Who are the customers for the Model 1058?

The Patton Model 1058DV enables the

utilization of existing copper

infrastructure for the delivery of

symmetrical broadband and POTS/ISDN

services over a single twisted pair of

voice-grade wire. The Model 1058DV

solution is targeted to any user or

provider who needs high-speed data

links. These organizations include but

are not limited to CLEC’s, ISP’s,

Educational Facilities (Campus),

MTU/MDU’s, and corporate/government

offices. Popular applications for

symmetrical VDSL include medical

imaging, always on high-speed Internet

access, and real time bi-directional video streaming.

Typical applications include:

LAN-to-LAN Bridging: The Model 1058 connects remote LANs over a high-speed, symmetrical

12.5Mbps line. The 1058 CP is placed at a remote location and a 1058 CO is placed at the

central site to provide a LAN-to-LAN connection over a voice-grade wire.

Ethernet Extension: Enables the customer to overcome the 328 ft (100m) limitations of

Ethernet with a symmetrical 12.5 Mbps link at distances up to 4,656 ft (1.42 km).

Dedicated Internet and Voice Services: VDSL enables ISP’s to deliver dedicated high-speed

Internet access and voice services from a Point-of-Presence (POP) to a customer premise. A

1058CO is used at the POP and a 1058CP is used at the customer premise. The Model 1058DV’s

built-in POTS/ISDN splitter allows users to simultaneously use the phone or fax machine, while

surfing the web, downloading files or receiving e-mails.

MTU/MDU Services: Using broadband VDSL, data and voice services can be extended to the

hotel guest, apartment resident, and housing resident, etc. Patton’s VDSL modems allow service

providers to avoid the cost and trouble of wiring the individual hotel rooms with 4-wire twisted

pair or Ethernet cabling by using the existing voice-grade 2-wire infrastructure. The service

provider would place the 1001R rack system with multiple 1058RCDV/CO rack cards in the

basement or closet and the standalone 1058DV/CP in the individual hotel rooms. Once

connected, the Model 1058’s will automatically establish a high-speed Point-to-Point voice and

data link.

GGoCardoCard

Model 1058DV

and

1058DVRC

Related Patton xDSL Products:

Patton provides a complete line of xDSL products. Whether it’s VDSL for ultra-high speed

connections, mSDSL for high-speed long distance connections, or iDSL for standard U-interface

connections over long distances, Patton has the solutions to fit all types of networks. Patton's xDSL

solutions include compact cross connects, rack-card based solutions, and CPE units for your last

mile networking needs. Patton’s complete line of high-speed xDSL modems, include interfaces for

10Base-T Ethernet, T1/E1, G.703/G.704, voice, and serial (X.21, V.35, EIA-530, and V.24).

DSL Type Max Data

Rate Quick

Connect Compact

(Rocket) Rack Card

Cross Connect

iDSL 128 Kbps 1092A 1082 1092ARC 3092/3192

HDSL 1.152 Mbps 1094A 1089 1094ARC 3095

mSDSL 2.034 Mbps 1095 1088 1095RC 3095

VDSL 12.5 Mbps -1058 1058RC -

Model 1058 Features and Benefits

High-Speed Symmetrical 12.5Mbps

communications link. Fast and reliable data transmission.

Extends Ethernet beyond its current 328 ft

(100m) limitation. Inexpensively links remote devices or

extends LANs up to 4,652 ft (1,418 m).

Built-in POTS/ISDN Splitter (1058DV only) Provides “life-line” telephone link.

Full service integration (voice, video, and

data) services over existing voice-grade

telephone wire.

Eliminates the need to install new LAN-

grade cable or expensive fiber.

Operation transparent to high-layer

protocols. Lets higher-layer broadcast, multi-cast, and

data frames pass through. Supports VLAN

tagged frames.

Auto-sensing 10 or 100Base-T and full or

half-duplex Ethernet. No configuration necessary, just Plug &

Play.

Five status LEDs. Monitoring your connection and operational

status is made simple.

GGooCCardard

Model 1095 and 1095RC (Quick Connect)

Model 1088 (Rocket)

Model 3095 (Cross Connect)

Primary Application: Service Integration and LAN Extension

Used in pairs (Central Office and Customer Premise), the Model 1058 establishes a high-

speed, line sharing, symmetrical 12.5 Mbps voice and data link. The Model 1058 inter-

connects two geographically separated LANs over a voice-grade twisted pair wire.

Operation is simple: packets destined for the remote LAN are sent transparently, at full

line rate, to the peered LAN. The Model 1058DVs built-in splitter allows users to

simultaneously talk on the phone while surfing the web, downloading files or receiving e-

mails.

Optional parts for the Model 1058D and the Model 1058DV

•DC Power Supplies

•Rack cards are compatible with Patton’s Model 1001R High-Density Telco Rack System.

Optional DC Power Supplies for Standalone Units

Part

Number Description

48V-PSM -48 VDC power supply, 5VDC, 1A (optional)

24V-PSM -24 VDC power supply, 5VDC, 1A (optional)

12V-PSM -12 VDC power supply, 5VDC, 1A (optional)

GGooCCardard

Shipping/Export Information

ECCN export number: 8517.50.1000

Country of origin: United States of America, NAFTA

Total weight boxed: .96lbs (.44kg) without power supply

Individual unit: .4lbs (.18kg); without power supply

MTBF/ Repair Information

MTBF: 126,000 Hrs. Calculation based on MIL-HDBK-217F, Notice 2 -"Parts Count Reliability

Prediction"

Mean time to repair: 7–10 days

Warranty: 1-year parts and labor

Out of warranty repair rate: $150, flat rate –contact Patton’s Tech Support for details.

Physical Specifications

Dimensions: Standalone: 1.5” H x 4.13” W x 3.75” D (3.81 H x 10.5 W x 9.53 D cm)

Rack Card: 3.00” H x 0.83” W x 7.84” D (7.6 H x 2.1 W x 19.9 D cm)

Color: Standalone: Case: Black Front and Back Panel: Black with white letters

Rack Card: Front and Back Panel: White with black letters

Case material: Standalone: Plastic, Fire retardant

Rack Card: Iridite Aluminum

Environmental

Operating Temp: 32 to 122°F (0 to 50°C)

Storage Temp: -40 to 185°F (-40 to +85°C)

Relative Humidity: Up to 90% RH, non-condensing

Altitude: 0–15,000 feet (3,048 meters)

Ventilation requirements: None, units do not require cooling fans.

GGooCCardard

Approvals

Safety Emissions Telecommunications

FCC part 15, Class A FCC Part 68 A & B (1058DV only)CE Marked per EMC

directive 89/336/EEC and

low voltage directive

72/23/EEC.

ESD EN61000-4-2

EN55022 Class A,

conducted and radiated

emissions

Power Supplies

Standalone Units Only

AC: 120VAC, 50-60Hz, external or Universal input, 100-240VAC, 50-60Hz, external

DC: -48VDC, -24VDC, or -12VDC external (optional)

GGooCCardard

•When ordering standalone units, it is recommended that the 1058D be ordered in sets: one

1058D/CO (Local) and one 1058D/CP (Remote).

•* =You must specify a country specific power cord

Ordering Information-1058D (Data Only)

Model Description

1058D/CO Central Office VDSL Modem, Data Only; RJ-45 and Terminal Block; No

Power Supply

1058D/CP Customer Premise VDSL Modem, Data Only; RJ-45 and Terminal Block;

No Power Supply

1058D/CO/120 Central Office VDSL Modem, Data Only; RJ-45 and Terminal Block;

120VAC

1058D/CP/120 Customer Premise VDSL Modem, Data Only; RJ-45 and Terminal Block;

120VAC

1058D/CO/UI* Central Office VDSL Modem, Data Only; RJ-45 and Terminal Block; (UI)

100-240VAC

1058D/CP/UI* Customer Premise VDSL Modem, Data Only; RJ-45 and Terminal Block;

(UI) 100-240VAC

1058D-2PK VDSL Modem Set, Data Only; (Central Office and Customer Premise

Unit); No Power Supply

1058D/120-2PK

VDSL Modem Set, Data Only; (Central Office and Customer Premise

Unit); 120VAC

1058D/UI-2PK* VDSL Modem Set, Data Only; (Central Office and Customer Premise

Unit); (UI) 100-240VAC

Available Soon –Call for availability

1058DRC/CO Central Office VDSL Modem Rack Card, Data Only; RJ-45 and Terminal

Block

1058DRC/CP Customer Premise VDSL Modem Rack Card, Data Only; RJ-45 and Terminal

Block

GGooCCardard

•When ordering standalone units, it is recommended that the 1058D be ordered in sets: one

1058DV/CO (Local) and one 1058DV/CP (Remote).

•* =You must specify a country specific power cord

Ordering Information-1058DV (Data and Voice)

Model Description

1058DV/CO Central Office VDSL Modem, Data and Voice; RJ-45 and Terminal

Block; No Power Supply

1058DV/CP Customer Premise VDSL Modem, Data and Voice; RJ-45 and Terminal

Block; No Power Supply

1058DV/CO/120 Central Office VDSL Modem, Data and Voice; RJ-45 and Terminal

Block; 120VAC

1058DV/CP/120 Customer Premise VDSL Modem, Data and Voice; RJ-45 and Terminal

Block; 120VAC

1058DV/CO/UI* Central Office VDSL Modem, Data and Voice; RJ-45 and Terminal

Block; (UI) 100-240VAC

1058DV/CP/UI* Customer Premise VDSL Modem, Data and Voice; RJ-45 and Terminal

Block; (UI) 100-240VAC

1058DV-2PK VDSL Modem Set, Data and Voice; (Central Office and Customer

Premise Unit); No Power Supply

1058DV/120-2PK VDSL Modem Set, Data and Voice; (Central Office and Customer

Premise Unit); 120VAC

1058DV/UI-2PK* VDSL Modem Set, Data and Voice; (Central Office and Customer

Premise Unit); (UI) 100-240VAC

Available Soon –Call for availability

1058DVRC/CO Central Office VDSL Modem Rack Card, Data and Voice; RJ-45 and

Terminal Block

1058DVRC/CP Customer Premise VDSL Modem Rack Card, Data and Voice; RJ-45 and

Terminal Block
