FrameSaverSLV

Network Access Module (NAM)

Installation Instructions

Document Number 9000-A2-GN1J-30

May 1999

Product Documentation on the World Wide Web

We provide complete product documentation online. This lets you search the

documentation for specific topics and print only what you need, reducing the waste of

surplus printing. It also helps us maintain competitive prices for our products.

Complete documentation for this product is available at www.paradyne.com.

Select

Library

→

Technical Manuals

→

FrameSaver Frame Relay Devices.

Select the following document:

9128-A2-GB20

FrameSaver SLV

9126/9128

User’s Guide

To request a paper copy of a Paradyne document:

Within the U.S.A., call 1-800-PARADYNE (1-800-727-2396)

Outside the U.S.A., call 1-727-530-8623

Before You Begin

Make sure you have:

A small, flat-blade screwdriver.

A small, Phillips screwdriver if installing an ISDN PRI DBM.



FrameSaver SLV ISDN Dial Backup Module (DBM) Installation Instructions

(Document No. 9000-A2-GN19) if installing an ISDN PRI DBM.

If a FrameSaver NAM with DBM is being replaced, the DBM must be transferred to

the replacement NAM.

Configuration information for the FrameSaver unit being installed or replaced.

496-15149

Appropriate cables:

— DSX cable

— Data port cables

— COM port-to-terminal or COM port-to-PC cable

— Modem cable

See the User’s Guide for additional information on:



Troubleshooting



Cables, Connectors, and Pin Assignments



Technical Specifications



Equipment List

Package Checklist

Verify that your package contains the following:

FrameSaver SLV NAM

NAM I/O card

T1 network cable

ISDN PRI cable, if applicable



FrameSaver SLV 9126/9128 Quick Reference

(Document No. 9128-A2-GL10)

Visit the Paradyne World Wide Web site at www.paradyne.com to register your

warranty. Select

Service & Support

→

Warranty Registration.

Safety Instructions

Please refer to the

EMI Warnings

and

Important Safety Instructions

beginning on

page 24.

!HANDLING PRECAUTIONS FOR STATIC-SENSITIVE DEVICES

This product is designed to protect sensitive components from

damage due to electrostatic discharge (ESD) during normal

operation. When performing installation procedures,

however, take proper static control precautions to

prevent damage to equipment. If you are not sure

of the proper static control precautions, contact

your nearest sales or service representative.

98-16202

SINGLE

T1 NAM

Network

ISDN PRI DBM

Modem

DSX-1

Communications

Port

Port 1

Port 2

NAM

I/O Card

Installing the I/O Card

The NAM’s I/O card provides the network, DSX, DBM,

modem, DTE and COM port connections. The I/O card

inserts directly behind the NAM that it supports in the

access carrier.

1. Remove the I/O card from the shipping box.

To avoid damaging the card, handle by the top and

bottom edges only.

2. At the rear of the carrier, align the I/O card with the

upper and lower tracks of the slot.

Push gently toward the midplane until it stops and

the card cannot be pushed any further.

99-16203-02

RearView

Captive

Screws

3. Using a small, Phillips screwdriver, alternately tighten the

captive screws until they are all snug.

98-16209

Ejector

Latches

FrontView

Installing the NAM into a Multislot Housing

The illustration shows the 14-slot access carrier as the housing.

CAUTION:

Be sure that you install the NAM in the correct slot so that it mates with its

matching I/O card. Otherwise, you could damage your card.

1. Remove the NAM from the shipping

box. Handle only by the top and

bottom edges to avoid damaging

the card.

2. At the front of the carrier, align the

NAM with the upper and lower

tracks of the appropriate slot.

3. Slide the NAM into the tracks until it

seats with the midplane connectors.

Use care not to force the card or

bend any pins.

4. Close the carrier’s upper and lower

ejector latches to lock the card into

place, then tighten the captive

screws on the ejector latches.

Verification Check:

Did the OK LED light?

– If yes, the FrameSaver unit has power.

– If no, refer to

Troubleshooting

in the User’s Guide.

Connecting the COM Port to an Asynchronous Terminal

The FrameSaver unit must first be directly connected to a VT100-compatible

asynchronous terminal or a PC providing VT100 terminal emulation to set up access

and management of the unit.

1. Configure the VT100-compatible async terminal or PC to be compatible with the

FrameSaver unit:

– COM Port in use by your PC: COM1 or COM2

– COM Port Baud Rate is set to 19.2 kbps

– Character length is set to 8 data bits

– Parity is set to none

– Stop bit is set to 1

– Flow Control is set to None

2. Insert the 8-pin end of the cable into the COM port for the appropriate slot.

3. Insert the other end of the cable into the VT100-compatible asynchronous terminal,

PC, or async terminal providing VT100 terminal emulation to set up the unit.

COM

98-16208a

COM Port-to-Terminal/Printer

COM Port-to-PC Cable

4. Press Enter on the keyboard to display the Main Menu.

Verification Check:

Did the Main Menu appear on the async terminal?

– If yes, continue with the installation.

– If no, recheck terminal and FrameSaver unit compatibility (see settings in

Step 1), or press the Enter key.

Refer to

Troubleshooting

in the User’s Guide for additional information.

A Quick Guide to Configuration

The FrameSaver unit should operate using the default (factory-set) configuration

options, except for the changes specified in these installation instructions. Refer to the

following table for help to navigate through the menus.

Press the . . . To . . .

Esc key Go back one screen or menu level. To see a visual

representation of the menu levels, see

Menu Hierarchy

the Quick Reference.

Tab key, or

up (↑) and down (↓)

arrow keys

Move the cursor from one menu item to the next.

Enter or Return key Complete the menu or option selection.

Spacebar Display the next available setting when changing a

configuration option. All the available settings for an

option appears at the bottom of the screen.

As an example, follow these steps to go to the Configuration Edit/Display menu so you

can start setting up the unit. To load a configuration for editing:

1. From the Main Menu, press the down arrow key twice so the cursor is on

Configuration.

2. Press Enter to display the Configuration menu. The Load Configuration From

menu appears.

3. Press Enter to select Current Configuration. The cursor is already on this selection.

The Configuration Edit/Display menu appears.

This sequence of steps would be shown as the menu selection sequence:

Main Menu

→

Configuration

→

Load Configuration From:

→

Current Configuration

To save a configuration option change:

1. Press Ctrl-a to switch to the screen function keys area at the bottom of the screen.

2. Type sor S(Save) and press Enter. The Save Configuration To menu appears.

3. Press Enter again to save your changes to the Current Configuration.

4. Press Esc until the Configuration Edit/Display menu reappears to continue

configuring the unit.

Press Ctrl-a, type m(MainMenu), and press Enter to return to the Main Menu.

In the sections that follow, only the minimum option changes required are included so

you will have a quick and trouble-free installation.

See the configuration option tables in the User’s Guide for more information about

configuration options.

Installing and Setting Up the FrameSaver SLV

To complete the installation, you must:

Verify that self-test passed.

Configure the FrameSaver unit.

Connect to the network and continue configuration.

Connect to the modem.

Connect to the ISDN, if applicable.

Connect to the DSX, if applicable.

Connect to the DTE(s).

Check the connections.

NOTE:

Follow these instructions as they are presented. The system should be configured

first before connecting the cables. Otherwise, installation time will be increased.

Verifying that Self-Test Passed

Before starting to configure the FrameSaver unit, confirm that the unit passed the

self-test.

1. Follow this menu selection sequence from the Main Menu, pressing Enter after

each selection:

Main Menu

→

Status

→

System and Test Status

2. Check the Self-Test Results column (in the center of the System and Test Status

screen).

– If Passed appears, the FrameSaver unit successfully completed the self-test.

– If any failure messages appear, reset the unit by removing and reinserting the

NAM. The unit will perform the self-test again. If the failure reappears, call your

service representative for assistance.

Configuring the FrameSaver Unit

To configure the FrameSaver unit:

Set the system clock.

Assign the Node IP Address.

Set up Network physical interface, and DSX-1 physical interface, if applicable.

Enter time slot assignments, if applicable.

Set up Data Port physical interface(s).

Set up modem call directories if dial-out traps are desired.

Set up management.

Set up Automatic Frame Relay Discovery Configuration.

Set up Automatic Backup Configuration, if an ISDN DBM if installed.

Setting the System Clock

To set up the system clock:

1. Select Date & Time.

Main Menu

→

Control

→

Date & Time

2. Move the cursor to the first field and enter the:

– Date in mm/dd/yyyy format (month/day/year).

– Time in hh:mm format (hours:minutes).

3. Save the date and time.

Assigning the Node IP Address

1. Set up the node.

Main Menu

→

Configuration

→

Management and Communication

→

IP Node

2. Minimally, enter the following options:

– Node IP Address

– Node Subnet Mask

3. Save the configuration.

Setting Up the Network and DSX-1 Interfaces

1. Select the network interface’s physical configuration options.

Configuration

→

Network

→

Physical

2. Configure the interface to match the network provider’s settings.

3. Save the configuration and return to the Network menu.

4. Select Frame Relay.

5. Configure the frame relay characteristics to match the network provider’s settings.

6. Save the configuration and return to the Configuration Edit/Display menu.

7. If applicable, select DSX-1.

8. Enable the interface and configure the unit to match the service provider’s settings.

9. Save the configuration.

Entering Time Slot Assignments

Frame relay time slots are discovered automatically if Time Slot Discovery is enabled

on the Frame Relay Network 1 Assignments screen, which is the default setting).

Configuration

→

Time Slot Assignment

→

Frame Relay Network Assignments

This feature can be disabled, if desired, so that Frame Relay-to-Network Time Slot

Assignments can be manually configured.

Use the following procedure if additional network time slots need to be cross-connected

to the DSX-1 interface. See

Assigning Time Slots

Configuration Options

of the User’s

Guide to read more about assigning time slots for a FrameSaver 9124, 9126, or 9128.

1. For the DSX-1 interface, select DSX-1 from the Configuration Edit/Display menu

and enable Interface Status.

2. Return to the Configuration Edit/Display menu.

3. Select Time Slot Assignment, then Frame Relay Network Assignments.

4. For the DSX-1 interface, map the desired time slots to the DSX-1 interface.

– Press the Tab key to move the cursor to the desired network interface time slot.

– Press the spacebar until the appropriate DSX-1 channel is displayed, Frame

Relay (FrameRly1) or Available. Frame Relay is the default.

– Repeat the process until all the desired time slots have been assigned to a

DSX-1 channel.

5. Save the configuration and return to the Configuration Edit/Display menu if no

DSX-1 channels will be assigned to network time slots.

If configuring DSX-to-network time slots, proceed to Step 6.

6. Return to the Time Slot Assignment menu and select DSX-1 to Network

Assignments.

7. Map the DSX-1 time slots to the network time slots.

8. Save the configuration.

Setting Up Data Ports

1. Configure the physical characteristics of the port.

Configuration

→

Data Ports

→

Physical

2. For multiport FrameSaver units, select a port.

Helpful Hint:

Press the spacebar to display the port number and press Enter.

3. If Port-2 will be used on a multiport unit, enable Port Status.

4. Change any options that may be necessary for the port.

5. Save any changes and return to the Data Ports menu.

6. Select Frame Relay.

7. Configure the port to match the DTE’s settings, if necessary.

8. Save the configuration.

Setting Up the Modem

FrameSaver 9126 and 9128 units have an integral modem for remote management.

It is already set up for dial-in access to the unit, with Port Use set to Terminal.

If using the modem for dialed IP network connectivity (SNMP, Telnet, FTP, or trap

dial-out):

1. Select Modem Port.

Configuration

→

Management and Communication

→

Modem Port

2. Minimally, change Port Use to Net Link, Save the change, and return to the

Management and Communication menu.

– Change Port Use to Net Link.

– Assign the IP Address and Subnet Mask if it is different from the Node.

– Change Link Protocol to SLIP, if necessary. The default setting is PPP.

3. Save the configuration.

See

Setting Up the Internal Modem

Setup

of the User’s Guide for additional

information.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Paradyne Matériel réseau

Paradyne

Paradyne 12000E Manuel utilisateur

Paradyne

Paradyne Comsphere 3510 Manuel utilisateur

Paradyne

Paradyne 4929 DSLAM Manuel utilisateur

Paradyne

Paradyne HotWire 5246 Manuel utilisateur

Paradyne

Paradyne FrameSaver SLV 9124 Manuel d'utilisation et d'entretien

Paradyne

Paradyne MIM-4E1 Manuel utilisateur

Paradyne

Paradyne ACCULINK 3161 CSU Manuel utilisateur

Paradyne

Paradyne COMSPHERE 6700 Series Manuel utilisateur

Paradyne

Paradyne Dual DSU 7511 Manuel utilisateur

Paradyne

Paradyne Hotwire 8775 MSDSL Manuel utilisateur

Paradyne

Paradyne Comsphere 3510 Manuel utilisateur

Paradyne

Paradyne COMSPHERE 3610 Manuel d'exploitation et d'entretien

Paradyne

Paradyne HotWire 7924 Manuel utilisateur

Paradyne

Paradyne ACCULINK 3151 CSU Manuel utilisateur

Paradyne

Paradyne Hotwire 7996 Instructions d'utilisation d'origine

Paradyne

Paradyne Hotwire 5620 Manuel utilisateur

Paradyne

Paradyne BitStorm IP DSLAM 1900 Manuel du produit

Paradyne

Paradyne FrameSaver NP 110 Manuel utilisateur

Paradyne

Paradyne 4000E Manuel utilisateur

Paradyne

Paradyne Hotwire 5216 Manuel utilisateur

Paradyne

Paradyne COMSPHERE 3550 Series Manuel utilisateur

Paradyne

Paradyne ACCULINK 317x E1 Manuel

Paradyne

Paradyne COMSPHERE 3610 Guide de l'utilisateur

Paradyne

Paradyne 3172 Manuel utilisateur

Manuels Matériel réseau populaires d'autres marques

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manuel utilisateur

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manuel utilisateur

Yudor

Yudor YDS-16 Manuel utilisateur

D-Link

D-Link ShareCenter DNS-320L Manuel utilisateur

Samsung

Samsung ES1642dc Instructions d'utilisation

Honeywell Home

Honeywell Home LTEM-PV Instructions de montage

evertz

evertz 7700 Series Manuel utilisateur

D-Link

D-Link ShareCenter DNS-343 Manuel utilisateur

Asante

Asante AsanteBridge 1012 Manuel utilisateur

FireBrick

FireBrick FB2700 Manuel utilisateur

Audiovox Electronics

Audiovox Electronics ARWH2T Manuel utilisateur

ADC

ADC DSX-1 Manuel

NetComm

NetComm NF2 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 5620 Manuel utilisateur

Dell EMC

Dell EMC XC6420 Series Manuel utilisateur

Lanner

Lanner NCA-1020A Manuel utilisateur

Allied Telesis

Allied Telesis AT-TN121-A Manuel utilisateur

Arista

Arista CCA-ETM-Q12 Manuel utilisateur
