Panasonic PTDW8300U - DLP PROJECTOR Manuel utilisateur

SPEC FILE

Product Number : PT-DW8300U

Product Name : 3-Chip DLP®Projector

As of July 2010. Specifications subject to change without notice.

SFD10M003

1/17

SPEC FILE PT-DW8300U

3-Chip DLP®Projector

As of July 2010

SFD10M003

2/17

Specifications

Main unit

Power supply

Power consumption

DLP®chip Panel size

Display method

Pixels

Lens

Lamp

Screen size

Brightness*2

Center-to-corner uniformity*2

Contrast*2

Resolution

Scanning frequency HDMI/DVI-D/RGB

YPBPR(YCBCR)

S-Video/Video

Optical axis shift

Keystone correction range

Installation

120 V AC, 10 A, 60 Hz

920 W (970 VA) (0.2 W with standby mode set to ECO*1.6Wwith

standby mode set to NORMAL. Both with fan stopped.)

21.6 mm (0.85 inches) diagonal (16:9 aspect ratio)

DLP®chip × 3 (R, G, B), DLP®projection system

1,049,088 (1,366 × 768) × 3, total of 3,147,264 pixels

Optional powered zoom/focus lenses

355 W UHM lamps (× 2) (dual lamp system)

70–600 inches (70–300 inches with the ET-D75LE5), 16:9 aspect ratio

9,600 lumens (dual lamp, high mode)

90%

10,000:1 (full on/full off, in dynamic iris 3 mode)

1,366 × 768 pixels (Input signals that exceed this resolution will be

converted to 1,366 × 768 pixels.)

Horizontal: 15–100 kHz, vertical: 24–120 Hz,

Dot clock: 162 MHz or lower

525i (480i): fH15.75 kHz; fV60 Hz,

625i (576i): fH15.63 kHz; fV50 Hz,

525p (480p): fH31.50 kHz; fV60 Hz,

625p (576p): fH31.25 kHz; fV50 Hz,

750 (720)/60p: fH45.00 kHz; fV60 Hz,

750 (720)/50p: fH37.50 kHz; fV50 Hz,

1035/60i: fH33.75 kHz; fV60 Hz,

1125 (1080)/60i: fH33.75 kHz; fV60 Hz,

1125 (1080)/50i: fH28.13 kHz; fV50 Hz,

1080/25p: fH28.13 kHz; fV25 Hz,

1080/24p: fH27.00 kHz; fV24 Hz

1080/24sF: fH27.00 kHz; fV48 Hz,

1080/30p: fH33.75 kHz; fV30 Hz

1080/60p: fH67.50 kHz; fV60 Hz,

1080/50p: fH56.25 kHz; fV50 Hz

Horizontal: 15.75/15.63 kHz, vertical: 50/60 Hz,

(NTSC, NTSC4.43, PAL, PAL60, PAL-N, PAL-M, SECAM)

±70% (±60% with the ET-D75LE6) from center of screen, powered

±30% (±20% with the ET-D75LE6) from center of screen, powered

Vertical: ±40° (±22° with the ET-D75LE5, ±28° with the ET-D75LE6)

Ceiling/floor, front/rear

SPEC FILE PT-DW8300U

3-Chip DLP®Projector

As of July 2010

SFD10M003

3/17

Terminals*3HDMI IN

DVI-D IN

RGB 1 IN

RGB

YPBPR(YCBCR)

RGB 2 IN

R, G, B

YPBPR(YCBCR)

VIDEO IN

S-VIDEO IN

SERIAL IN

SERIAL OUT

REMOTE 1 IN

REMOTE 1 OUT

REMOTE 2 IN

LAN

Power cord length

Cabinet materials

Dimensions (W × H × D):

Weight

Operating temperature

Operating humidity

Remote control unit

Power supply

Operation range*9

Dimensions (W × H × D)

Weight

HDMI 19-pin × 1, Deep Color, compatible with HDCP,

480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24p,

1080/24sF, 1080/25p, 1080/30p, 1080/60p, 1080/50p

(non-interlaced signals only),

VGA (640 × 480)–WUXGA*2(1,920 × 1,200),

dot clock: 25–162 MHz

NOTE: Compatible with non-interlaced signals only.

DVI-D 24-pin × 1, DVI 1.0 compliant, HDCP compatible,

for single link only

480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24p,

1080/24sF, 1080/25p, 1080/30p, 1080/60p, 1080/50p,

VGA (640 × 480)–WUXGA*2(1,920 × 1,200),

dot clock: 25–162 MHz

NOTE: Compatible with non-interlaced signals only.

BNC × 5

R: 0.7 Vp-p, 75 ohms,

G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75 ohms,

B: 0.7 Vp-p, 75 ohms

HD/VD, SYNC: High impedance, TTL (positive/negative), 75 ohms

Y: 1.0 Vp-p (including sync signal), PB/PR(CB/CR): 0.7 Vp-p, 75 ohms

NOTE: SYNC/HD and VD terminals do not accept tri-level sync signals.

D-sub HD 15-pin (female) × 1

R: 0.7 Vp-p, 75 ohms,

G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75 ohms,

B: 0.7 Vp-p, 75 ohms

HD/VD, SYNC: High impedance, TTL (positive/negative), 75 ohms

Y: 1.0 Vp-p (including sync signal), PB/PR(CB/CR): 0.7 Vp-p, 75 ohms

NOTE: SYNC/HD and VD terminals do not accept tri-level sync signals.

BNC × 1, 1.0 Vp-p, 75 ohms

Mini DIN 4-pin × 1, Y: 1.0 Vp-p, C: 0.286 Vp-p, 75 ohms

D-sub 9-pin × 1 (RS-232C compliant) for external controller

D-sub 9-pin × 1 for link control

M3 jack × 1 for wired remote control

M3 jack × 1 for link control

D-sub 9-pin × 1 for external control (parallel)

RJ-45 × 1 for network connection, 100Base-TX/10Base-T, compliant

with PJLink™ (class 1)

3.0 m (9 ft 10 in)

Molded plastic

530 mm × 200 mm*5× 548.5 mm*6

(20-7/8˝ × 7-7/8˝ *5× 21-19/32˝ *6) (without lens)

Approx. 24 kg (52.9 lbs)*7(without lens)

0°–45°C (32°–113°F)*8

10%–80% (no condensation)

3 V DC (AA type battery × 2)

Approx. 30 m (98 ft 5 in) when operated from directly signal receptor

51 × 176 × 28 mm (2˝ × 6-15/16˝ × 1-3/32˝)

Approx. 134 g (4.7 oz) (including batteries)

SPEC FILE PT-DW8300U

3-Chip DLP®Projector

As of July 2010

SFD10M003

4/17

Supplied accessories

Optional accessories

Zoom lens (1.0–1.2:1)

Zoom lens (1.4–1.9:1)

Zoom lens (1.8–2.7:1)

Zoom lens (2.7–5.2:1)

Zoom lens (5.2–8.2:1)

Zoom lens (8.2–15.4:1)

Fixed-focus lens (0.8:1)

Lens motor cover

High-ceiling mount bracket

Low-ceiling mount bracket

Attachment for ceiling mount bracket

Frame

Smoke cut filter

Replacement lamp (one bulb)

Replacement lamp (a set of two bulbs)

Replacement filter unit

Power cord with security lock (× 1)

Wireless/wired remote control unit (× 1)

Batteries for remote control (AA type × 2)

Safety wire rope (× 1)

ET-D75LE6

ET-D75LE10

ET-D75LE20

ET-D75LE30

ET-D75LE4

ET-D75LE8

ET-D75LE5

ET-D75MC1

ET-PKD310H

ET-PKD310S

ET-PAD310

ET-PFD310

ET-SFD310

ET-LAD310

ET-LAD310W

ET-ACF310

Weights and dimensions shown are approximate. Specifications subject to change without notice.

*1 When the standby mode is set to ECO, LAN-based network functions such as the standby ON function will not operate.

*2 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.

*3 The SYNC/HD and VD inputs do not accept the tri-level sync signal.

*4 WUXGA resolution is supported only when the signals are compliant with VESA CVT-RB (Coordinated Video Timing-Reduced Blanking).

*5 With legs at shortest position.

*6 Excluding the optional lens.

*7 Average value (excluding the optional lens). May differ depending on models.

*8 The operating temperature range is 0°C (32°F) to 40°C (104°F) when used in High-Altitude mode (1,400 m (4,593 ft) to 2,700 m (8,858 ft)).

*9 Operation range differs depending on environments.

540 (21-1/4)

548.5 (21-19/32)

8.5 (11/32)

530 (20-7/8)

462 (18-3/16) 468 (18-7/16)26 (1-1/32)

100 (3-15/16)

200 (7-7/8)

Dimensions

SPEC FILE PT-DW8300U

3-Chip DLP®Projector

As of July 2010

SFD10M003

5/17

Terminals

6 7 8 9 10 11 12

23 4 5

7 Video input

8 S-Video input

9 RGB 1 input

10 RGB 2 Input

11 DVI-D input

12 LAN connector

1 Remote 1 input

2 Remote 1 output

3 Remote 2 input

4 Serial input

5 Serial output

6 HDMI input

unit : mm (inch)

NOTE: This illustration is not drawn to scale.

SPEC FILE PT-DW8300U

3-Chip DLP®Projector

As of July 2010

SFD10M003

6/17

Standard setting-up position (when installed using the ET-PKD310H)

Upper edge of projected image

342

(13-15/32)

∅60.5

(2-3/8)

198

(7-25/32)

Lower edge of projected image

Projected image

340–420

(13-3/8–

16-17/32)

436–516

(17-5/32–

20-5/16)

100

(3-15/16)

100

(3-15/16)

100

(3-15/16)

100

(3-15/16)

Projected image

unit : mm (inch)

*1 When the lens protrudes to the

maximum.

212 mm (8-11/32˝) with the ET-D75LE6

125 mm (4-29/32˝) with the ET-D75LE10

114 mm (4-1/2˝) with the ET-D75LE1

121 mm (4-3/4˝) with the ET-D75LE20

99 mm (3-29/32˝) with the ET-D75LE2

121 mm (4-3/4˝) with the ET-D75LE30

102 mm (4-1/32˝) with the ET-D75LE3

126 mm (4-31/32˝) with the ET-D75LE4

254 mm (10˝) with the ET-D75LE8

202 mm (7-15/16˝) with the ET-D75LE5

*2 Adjustable in 40 mm (1-9/16˝) steps.

Caution:

• All construction work should be done by a qualified technician.

• When mounting to the ceiling, use the special mounting bracket. To prevent the projector from swaying or drop-

ping, attach the wire that is included with the projector between the mounting bracket and the ceiling.

SPEC FILE PT-DW8300U

3-Chip DLP®Projector

As of July 2010

SFD10M003

7/17

100

120

150

200

250

300

400

500

600

Screen

size

(inch,

diagonal)

Zoom

Zoom lenses

Fixed-focus

Fixed-

focus

lens*

Distance to screen (L) Height from the edge of screen

to center of lens (H)

ET-D75LE10

Zoom lens

min. max. min. max. min. max. min. max. min. max. min. max.

ET-D75LE6

Zoom lens

ET-D75LE20

Zoom lens

ET-D75LE30

Zoom lens

ET-D75LE4

Zoom lens

ET-D75LE8

Zoom lens

ET-D75LE5

Fixed-focus

lens

Except

ET-D75LE6

–

-87

-100

-112

-125

-149

-187

-249

-311

-374

-498

-623

-747

959

1,096

1,233

1,370

1,644

2,055

2,740

3,424

4,109

5,479

6,849

8,219

–

-174

-199

-224

-249

-299

-374

-498

-623

-747

-995

-1,245

-1,494

1,046

1,195

1,345

1,494

1,793

2,241

2,989

3,736

4,483

5,977

7,472

8,966

1,151

1,328

1,504

1,681

2,033

2,563

3,445

4,327

5,209

–

436

498

560

623

747

934

1,245

1,556

1,868

–

1,865

2,142

2,419

2,696

3,250

4,081

5,466

6,851

8,236

11,006

13,776

16,546

2,824

3,242

3,661

4,080

4,918

6,175

8,269

10,363

12,458

16,646

20,835

25,024

4,101

4,704

5,306

5,909

7,114

8,921

11,933

14,946

17,958

23,983

30,008

36,033

7,944

9,104

10,264

11,424

13,745

17,225

23,025

28,826

34,626

46,227

57,828

69,429

12,713

14,544

16,375

18,206

21,867

27,359

36,512

45,666

54,819

73,126

91,433

109,740

23,652

27,083

30,513

33,943

40,804

51,095

68,246

85,398

102,549

136,852

171,157

205,458

1,560

1,791

2,022

2,253

2,715

3,408

4,563

5,718

6,873

9,183

11,493

13,803

2,183

2,507

2,831

3,155

3,803

4,775

6,396

8,016

9,636

12,877

16,118

19,359

2,819

3,234

3,649

4,063

4,892

6,136

8,210

10,283

12,356

16,502

20,649

24,795

4,074

4,672

5,270

5,869

7,065

8,860

11,850

14,841

17,832

23,814

29,796

35,778

7,943

9,094

10,246

11,397

13,699

17,153

22,909

28,666

34,422

45,934

57,447

68,960

12,430

14,261

16,092

17,923

21,585

27,077

36,232

45,386

54,541

72,850

91,159

109,468

100

120

150

200

250

300

400

500

600

Screen

size

(inch,

diagonal)

Zoom

Zoom lenses

Fixed-focus

Fixed-

focus

lens*

Distance to screen (L) Height from the edge of screen

to center of lens (H)

ET-D75LE10

Zoom lens

min. max. min. max. min. max. min. max. min. max. min. max.

ET-D75LE6

Zoom lens

ET-D75LE20

Zoom lens

ET-D75LE30

Zoom lens

ET-D75LE4

Zoom lens

ET-D75LE8

Zoom lens

ET-D75LE5

Fixed-focus

lens

–

-0.3

-0.4

-0.5

-0.7

-0.9

-1.1

-1.3

-1.7

-2.1

-2.5

3.2

3.6

4.1

4.5

5.4

6.8

9.0

11.3

13.5

18.0

22.5

27.0

–

-0.6

-0.7

-0.8

-0.9

-1.0

-1.3

-1.7

-2.1

-2.5

-3.3

-4.1

-5.0

3.4

4.0

4.5

5.0

5.9

7.4

9.9

12.3

14.8

19.7

24.6

29.5

3.8

4.4

5.0

5.6

6.7

8.5

11.4

14.2

17.1

–

1.4

1.7

1.9

2.1

2.5

3.1

4.1

5.2

6.2

–

6.2

7.1

8.0

8.9

10.7

13.4

18.0

22.5

27.1

36.2

45.2

54.3

9.3

10.7

12.1

13.4

16.2

20.3

27.2

34.0

40.9

54.7

68.4

82.1

13.5

15.5

17.5

19.4

23.4

29.3

39.2

49.1

59.0

78.7

98.5

118.3

26.1

29.9

33.7

37.5

45.1

56.6

75.6

94.6

113.7

151.7

189.8

227.8

41.8

47.8

53.8

59.8

71.8

89.8

119.8

149.9

179.9

240.0

300.0

360.1

77.6

88.9

100.2

111.4

133.9

167.7

224.0

280.2

336.5

449.0

561.6

674.1

5.2

5.9

6.7

7.4

9.0

11.2

15.0

18.8

22.6

30.2

37.8

45.3

7.2

8.3

9.3

10.4

12.5

15.7

21.0

26.3

31.7

42.3

52.9

63.6

9.3

10.7

12.0

13.4

16.1

20.2

27.0

33.8

40.6

54.2

67.8

81.4

13.4

15.4

17.3

19.3

23.2

29.1

38.9

48.7

58.6

78.2

97.8

117.4

26.1

29.9

33.7

37.4

45.0

56.3

75.2

94.1

113.0

150.8

188.5

226.3

40.8

46.8

52.8

58.9

70.9

88.9

118.9

149.0

179.0

239.1

299.1

359.2

Except

ET-D75LE6

Projection distance for 16:9 aspect ratio screen

(ET-D75LE6/D75LE10/D75LE20/D75LE30/D75LE4/D75LE8/D75LE5)

Unit: feet

Unit: millimeters

• The value for L (distance to screen) varies slightly depending on the zoom lens characteristics.

• At the shortest projection distance, the zoom lens characteristics may cause slight image distortion.

• When vertical keystone correction is used, the image is corrected in the direction that reduces its projected size.

NOTE: When the fixed-focus lens is mounted, the optical lens shift function cannot be used.

SPEC FILE PT-DW8300U

3-Chip DLP®Projector

As of July 2010

SFD10M003

8/17

100

120

150

200

250

300

400

500

600

Screen

size

(inch,

diagonal)

Distance to screen (L) Height from the

edge of screen

to center of lens

(H)

ET-D75LE2

Zoom lens

min. max. min. max. min. max.

ET-D75LE1

Zoom lens

ET-D75LE3

Zoom lens

–

-174

-199

-224

-249

-299

-374

-498

-623

-747

-995

-1,245

-1,494

1,046

1,195

1,345

1,494

1,793

2,241

2,989

3,736

4,483

5,977

7,472

8,966

3,103

3,561

4,019

4,476

5,392

6,765

9,053

11,341

13,630

18,206

22,783

27,360

4,719

5,408

6,098

6,787

8,166

10,234

13,680

17,127

20,574

27,467

34,360

41,254

7,937

9,088

10,240

11,391

13,693

17,147

22,904

28,660

34,416

45,929

57,441

68,954

2,322

2,664

3,007

3,349

4,035

5,062

6,775

8,488

10,201

13,626

17,052

20,477

3,137

3,597

4,056

4,516

5,435

6,814

9,112

11,409

13,707

18,303

22,898

27,494

4,730

5,419

6,108

6,798

8,176

10,244

13,691

17,137

20,584

27,477

34,371

41,264

100

120

150

200

250

300

400

500

600

Screen

size

(inch,

diagonal)

Distance to screen (L) Height from the

edge of screen

to center of lens

(H)

ET-D75LE2

Zoom lens

min. max. min. max. min. max.

ET-D75LE1

Zoom lens

ET-D75LE3

Zoom lens

–

-0.6

-0.7

-0.8

-0.9

-1.0

-1.3

-1.7

-2.1

-2.5

-3.3

-4.1

-5.0

3.4

4.0

4.5

5.0

5.9

7.4

9.9

12.3

14.8

19.7

24.6

29.5

10.2

11.7

13.2

14.7

17.7

22.2

29.8

37.3

44.8

59.8

74.8

89.8

15.5

17.8

20.1

22.3

26.8

33.6

44.9

56.2

67.5

90.2

112.8

135.4

26.1

29.9

33.6

37.4

45.0

56.3

75.2

94.1

113.0

150.7

188.5

226.3

7.7

8.8

9.9

11.0

13.3

16.7

22.3

27.9

33.5

44.8

56.0

67.2

10.3

11.9

13.4

14.9

17.9

22.4

29.9

37.5

45.0

60.1

75.2

90.3

15.6

17.8

20.1

22.4

26.9

33.7

45.0

56.3

67.6

90.2

112.8

135.4

Projection distance for 16:9 aspect ratio screen

(ET-D75LE1/D75LE2/D75LE3)

Unit: feet

Unit: millimeters

• The value for L (distance to screen) varies slightly depending on the zoom lens characteristics.

• At the shortest projection distance, the zoom lens characteristics may cause slight image distortion.

• When vertical keystone correction is used, the image is corrected in the direction that reduces its projected size.

NOTE: When the fixed-focus lens is mounted, the optical lens shift function cannot be used.

SPEC FILE PT-DW8300U

3-Chip DLP®Projector

As of July 2010

SFD10M003

9/17

Calculation of the projection distance

For a screen size different from the above, use the equation below to calculate the projection distance.

Aspect ratio 16:9

minimum L (mm) = (diagonal screen size in inches) × 23.1 – 56.6

maximum L (mm) = (diagonal screen size in inches) × 27.7 – 73.6

minimum L (mm) = (diagonal screen size in inches) × 32.4 – 85.7

maximum L (mm) = (diagonal screen size in inches) × 41.9 – 108.5

minimum L (mm) = (diagonal screen size in inches) × 34.3 – 76.0

maximum L (mm) = (diagonal screen size in inches) × 45.8 – 100.4

minimum L (mm) = (diagonal screen size in inches) × 41.5 – 83.2

maximum L (mm) = (diagonal screen size in inches) × 60.2 – 116.2

minimum L (mm) = (diagonal screen size in inches) × 46.0 – 79.5

maximum L (mm) = (diagonal screen size in inches) × 68.9 – 106.4

minimum L (mm) = (diagonal screen size in inches) × 59.8 – 113.1

maximum L (mm) = (diagonal screen size in inches) × 116.0 – 176.5

minimum L (mm) = (diagonal screen size in inches) × 68.9 – 95.8

maximum L (mm) = (diagonal screen size in inches) × 115.1 – 121.6

minimum L (mm) = (diagonal screen size in inches) × 115.1 – 115.8

maximum L (mm) = (diagonal screen size in inches) × 183.1 – 101.3

minimum L (mm) = (diagonal screen size in inches) × 183.1 – 386.2

maximum L (mm) = (diagonal screen size in inches) × 343.0 – 359.8

L (mm) = (diagonal screen size in inches) × 17.6 – 83.5

Zoom lenses

ET-D75LE6

ET-D75LE10

ET-D75LE1

ET-D75LE20

ET-D75LE2

ET-D75LE30

ET-D75LE3

ET-D75LE4

ET-D75LE8

Fixed-focus lens

ET-D75LE5

• Distances calculated with the above equations will include slight deviations.

SPEC FILE PT-DW8300U

3-Chip DLP®Projector

As of July 2010

SFD10M003

10/17

(Width of

projected image)

(Height of

projected image)

0.2V

0.7V

0.2V

0.3H0.3H

Standard postition of projected image

360°

-15°

+15°

Shift range

Optical axis shift function allows to shift the position of a projected image as shown below.

Installable angle

Install the projector at an angle within the range shown below.

• Vertical direction

The projector may be installed at a vertical

angle of 360°.

• Horizontal direction

The projector may be installed at a horizontal

angle of ±15°.

• When the lens except the ET-D75LE6 is mounted

(Width of

projected image)

(Height of

projected image)

0.2V

0.6V

0.2V

0.2H0.2H

Standard postition of projected image

• When the ET-D75LE6 is mounted

• Because the ET-D75LE5 is a fixed short-throw lens, the lens shift function cannot be used with it.

Table des matières

Autres manuels Panasonic Projecteur

Panasonic

Panasonic PT-LX26HE Manuel utilisateur

Panasonic

Panasonic PT-CMZ50 Manuel utilisateur

Panasonic

Panasonic PT-AE900 Manuel utilisateur

Panasonic

Panasonic PT-DZ21K Series Manuel utilisateur

Panasonic

Panasonic PT-D5500E Manuel utilisateur

Panasonic

Panasonic PT-TW330 Manuel utilisateur

Panasonic

Panasonic PT-D4000E Manuel utilisateur

Panasonic

Panasonic PTLB75U - LCD PROJECTOR Manuel utilisateur

Panasonic

Panasonic PT-VMZ40 Manuel utilisateur

Panasonic

Panasonic PT-VX400 Manuel utilisateur

Panasonic

Panasonic PT-D5000ELS Manuel utilisateur

Panasonic

Panasonic PT-LB10NTU - Mobile Proj XGA 2000 Lumens 4.9LBS Cross Platform... Manuel utilisateur

Panasonic

Panasonic PTLC50U - LCD PROJECTOR Manuel utilisateur

Panasonic

Panasonic TC-LT1 Series Manuel utilisateur

Panasonic

Panasonic PT-AE1000U - LCD Projector - HD 1080p Manuel utilisateur

Panasonic

Panasonic PT-L720E Manuel utilisateur

Panasonic

Panasonic PTL6600U - LCD PROJECTOR Manuel utilisateur

Panasonic

Panasonic PT-LB75VEA Manuel utilisateur

Panasonic

Panasonic PT-AE1000U - LCD Projector - HD 1080p Manuel utilisateur

Panasonic

Panasonic AE3000U - LCD Projector - HD 1080p Manuel utilisateur

Panasonic

Panasonic PTAE2000U-EC Operating Manuel utilisateur

Panasonic

Panasonic PT-FX400U Manuel utilisateur

Panasonic

Panasonic PT-RCQ80 Manuel utilisateur

Panasonic

Panasonic PT-DS20KU Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur

Asus

Asus ZenBeam Latte Manuel utilisateur
