Panasonic PT-L759V Manuel du système

• 2400 ANSI Lumens High Brightness

• XGA (1024 x 768), Maximum UXGA (1600 x 1200) Resolution

• One-touch auto setup and digital keystone correction

• Wireless remote with mouse control, arrow key control and laser pointer

- 1 -

S P E C F I L E

PRODUCT NO.: PT-L759V

PRODUCT NAME: Portable LCD Projector

MAJOR FEATURES

PT-L759V

Portable LCD Projector

S P E C F I L E

Specifications

Main Unit

Power supply: 100–240 V AC, 50/60 Hz

Power consumption: 370 W (during standby mode with fan stopped: Max. 20 W)

Colour system: composite: PAL/PAL-M/PAL-N/SECAM/NTSC/M-NTSC

component: 1080i/720p/480p/480i/625i

LCD panel: Panel size: 1.3˝ (diagonal)

Display method: Transparent LCD panel (x 3, R/G/B)

Drive method: Active matrix

Pixels: 786,432 (1,024 x 768) x 3

Pixel configuration: Stripe

Screen aspect ratio: 4:3

Lens: Manual zoom/focus lens (1:1–1:1.3),

F 2.5–3.0, f 45–59 mm,

Lamp: AC type 220 W UHM lamps

Colours: Full colour (16,777,216 colours)

Brightness: 2400 ANSI lumens

Contrast ratio: 450:1

Centre-to-corner uniformity ratio: 95%

Resolution: RGB: 1024 x 768 pixels, Video: 650 TV lines

Screen size: 508–7,620 mm (20–300 inches) diagonally

Throw distance: 0.8–13.5 m

Optical axis shift: 6 : 1 (fixed)

Installation: Ceiling/desk, front/rear (menu selection)

Built-in speakers: Size: 7 x 4 cm (x 1)

Output power: 1.5 W

Terminals: RGB1/YPBPRIN: D-sub HD 15-pin

R, G, B/Y, PB, PR: 0.7 Vp-p (1.0 Vp-p for Sync on G), 75Ω

HD/SYNC: 2.0–5.0 Vp-p, high impedance (positive/negative polarity)

VD: 2.0–5.0 Vp-p, high impedance (positive/negative polarity)

RGB2 IN/RGB1 OUT: D-sub HD 15-pin

R, G, B: 0.7 Vp-p (1.0 Vp-p for Sync on G), 75Ω

HD/SYNC: 2.0–5.0 Vp-p, high impedance (positive/negative polarity)

VD: 2.0–5.0 Vp-p, high impedance (positive/negative polarity)

S-VIDEO IN: Mini DIN 4-pin, Y: 1.0 Vp-p, C: 0.286 Vp-p, 75Ω

VIDEO IN: RCA jack, 1.0 Vp-p, 75Ω

AUDIO IN: For RGB: stereo mini jack, 0.32 Vrms

For Video: stereo mini jack, 0.32 Vrms

AUDIO OUT: Stereo mini jack, 0.32 Vrms

RS-232C: Mini DIN 8-pin

MOUSE: Round 13-pin

USB: USB 4-pin

Dimensions (W x H x D): 263 x 124 x 336 mm

Weight: 6.3 kg

Operating environment:

Temperature: 5°–40°C (41°–104°F)

Humidity: 10%–80% (no condensation)

Safety regulation: UL (UL 1950), C-UL, FCC Class-B, IC Class-B, CE (IEC950), CE

Class-B (IEC950/EN60950), CB Certificate, C-Tick

Laser beam: Safety regulations: 21CFR Part 1040.10

Laser type: Class II

Wavelength: 650 nm

Max. output: 1 mW

as of August 2001

PT-L759V

Portable LCD Projector

S P E C F I L E

Specifications (continued)

Remote Control Unit

Power supply: 3 V DC (AA-size battery x 2)

Operation range: Approx. 7 m when operated from directly in front of the signal

receptor)

Weight: Approx. 108 g (including batteries)

Dimensions (W x H x D): 46 x 34 x 191 mm

Accessories

Supplied accessories: Remote control unit, Batteries for remote control unit, Power cord,

VGA cable, Macintosh adapter, Video cable, Video audio cable,

JPEG Viewer for Windows95/98 (floppy disk), PS/2 mouse cable,

Macintosh mouse cable, Carrying handle

Optional accessories: Replacement lamp unit: ET-LA059X

Wide conversion lens: ET-LEC059

Serial mouse cable: ET-MC02S

Component video cable: ET-ADBNC

Ceiling mount bracket: ET-PK057

Weights and dimensions shown are approximate. Specifications subject to change without notice.

Windows is a registered trademark of Microsoft Corporation.

as of August 2001

Dimensions

unit: mm

POWER

CAPTURE

MODE

INPUT

STATUS CODE

VOLUME

PC ADJUST

STANDARD

ON (G)

STANDBY(R)

124

68.5

263 1.5

33.5

193

305 17

338

336

Note: This illustration is not drawn to scale.

Portable LCD Projector

S P E C F I L E

PT-L759V

as of August 2001

Terminals

RGB IN/RGB OUT connector pin assignment

1 PC card slot

2 Mouse connector for RGB1 (round 13-pin)

3 RS-232C connector

4 RGB output connector (D-sub 15-pin)

5 Audio input jack for RGB (stereo mini)

6 RGB input connector (D-sub 15-pin)

7 Audio input jack for Video/S-Video (stereo mini)

8 Video input connector (RCA)

9 S-Video input connector (Mini DIN 4-pin)

10 Audio output jack (stereo mini)

11 156

1105

no. signal

6 GND (R)

7 GND (G)

8 GND (B)

9NC

10 GND

no. signal

11 NC

12 DCC data

13 HD/SYNC

14 VD

15 DCC clock

no. signal

4NC

5 SYNC (through)

PS/2, VGA and XGA are trademarks of International Business Machines Corporation. Macintosh is a

registered trademark of Apple Computer, Inc. SVGA is a registered trademark of the Video Electronics

Standards Association. All other trademarks are the property of the various tradmark owners.

MOUSE

RS-232C

USBDVD-I

RGB OUT AUDIO IN RGB IN

AUDIO OUT VIDEO IN

S-VIDEO

VIDEO AUDIO IN

23 456789

RGB signal compatibility (Tentative)

640 x 400

640 x 480

800 x 600

1024 x 768

VGA VESA

VGA480

VESA

SVGA

XGA

SXGA

Mac 13˝

Mac 16˝

Mac 19˝

Mac 21˝

31.5

37.9

31.5

37.9

37.5

43.3

32.1

35.2

37.9

46.9

48.1

53.7

48.4

56.5

60.0

68.7

70.1

85.1

59.9

72.8

75.0

85.0

51.0

56.3

60.3

75.0

72.2

85.1

60.0

70.1

75.0

85.0

60.1

70.0

75.0

85.0

60.0

75.0

60.0

75.0

66.7

74.6

74.9

75.1

54.1

63.9

67.5

77.1

60.0

75.0

64.0

80.0

35.0

49.7

60.2

68.7

1152 x 864

1280 x 960

1280 x 1024

640 x 480

832 x 624

1024 x 768

1152 x 870

Display mode Resolution

(dots) Horizontal

frequency

(kHz)

Vertical

frequency

(Hz)

Display mode Resolution

(dots) Horizontal

frequency

(kHz)

Vertical

frequency

(Hz)

NOTE:

The display resolution of the PT-L757E is 1024 x 768 dots. If the

display resolution indicated in the above data does not match this

resolution, the input signal will be converted to 1024 x 768 dots.

PT-L759V

Portable LCD Projector

S P E C F I L E

as of August 2001

Standard setting-up positions

109

176

351

33.5

151

302

116

Projected image

MOUSE

PC-CARD

RS-232C RGBOUT AUDIOIN RGBIN

AUDIOOUT VIDEOIN

S-VIDEO

VIDEOAUDIO IN

Edge of projected image

Projected image

166–170

563–863

Adjustable in

60 mm steps

unit: mm

NOTE:

Illustrations show the PT-L759V installed using optional celing bracket.

Screen size L H

(diagonal)

20˝0.8 m 4 cm

40˝1.3 –1.7 m 9 cm

60˝2.0 –2.7 m 13 cm

80˝2.7 –3.6 m 17 cm

100˝3.4 –4.5 m 22 cm

120˝4.1 –5.4 m 26 cm

150˝5.2 –6.7 m 33 cm

200˝6.9 –9.0 m 44 cm

250˝8.7 –11.2 m 54 cm

300˝10.4 –13.5 m 65 cm

The values for L and H may vary slightly depending on the zoom lens characteristics.

The zoom lens characteristics may cause a small degree of distortion in the image when

projecting at the shortest distance.
