SPEC FILE

Product Number : PT-DS8500U

Product Name : 3-Chip DLP®Projector

As of July 2010. Specifications subject to change without notice.

SFD10M002

1/17

SPEC FILE PT-DS8500U

3-Chip DLP®Projector

As of July 2010

SFD10M002

2/17

Specifications

Main unit

Power supply

Power consumption

DLP®chip Panel size

Display method

Pixels

Lens

Lamp

Screen size

Brightness*2

Center-to-corner uniformity*2

Contrast*2

Resolution

Scanning frequency SDI

HDMI/DVI-D/RGB

YPBPR(YCBCR)

S-Video/Video

Optical axis shift

Keystone correction range

Installation

120 V AC, 10 A, 60 Hz

920 W (970 VA) (0.2 W with standby mode set to ECO*1.6Wwith

standby mode set to NORMAL. Both with fan stopped.)

24.1 mm (0.95 inches) diagonal (4:3 aspect ratio)

DLP®chip × 3 (R, G, B), DLP®projection system

1,470,000 (1,400 × 1,050) × 3, total of 4,410,000 pixels

Optional powered zoom/focus lenses

355 W UHM lamps (× 2) (dual lamp system)

70–600 inches (70–300 inches with the ET-D75LE5), 4:3 aspect ratio

10,600 lumens (dual lamp, high mode)

90%

10,000:1 (full on/full off, in dynamic iris 3 mode)

1,400 × 1,050 pixels (Input signals that exceed this resolution will be

converted to .)

SD-SDI signal: SMPTE 259M compliant: 480i, 576i

Single-link HD-SDI signal: SMPTE 292M compliant:

720/50p, 720/60p, 1035/60i, 1080/50i, 1080/60i, 1080/25p,

1080/24p, 1080/24sF, 1080/30p

Horizontal: 15–100 kHz, vertical: 24–120 Hz,

Dot clock: 162 MHz or lower

525i (480i): fH15.75 kHz; fV60 Hz,

625i (576i): fH15.63 kHz; fV50 Hz,

525p (480p): fH31.50 kHz; fV60 Hz,

625p (576p): fH31.25 kHz; fV50 Hz,

750 (720)/60p: fH45.00 kHz; fV60 Hz,

750 (720)/50p: fH37.50 kHz; fV50 Hz,

1035/60i: fH33.75 kHz; fV60 Hz,

1125 (1080)/60i: fH33.75 kHz; fV60 Hz,

1125 (1080)/50i: fH28.13 kHz; fV50 Hz,

1080/25p: fH28.13 kHz; fV25 Hz,

1080/24p: fH27.00 kHz; fV24 Hz

1080/24sF: fH27.00 kHz; fV48 Hz,

1080/30p: fH33.75 kHz; fV30 Hz

1080/60p: fH67.50 kHz; fV60 Hz,

1080/50p: fH56.25 kHz; fV50 Hz

Horizontal: 15.75/15.63 kHz, vertical: 50/60 Hz,

(NTSC, NTSC4.43, PAL, PAL60, PAL-N, PAL-M, SECAM)

±50% (±40% with the ET-D75LE6) from center of screen, powered

±30% (±20% with the ET-D75LE6) from center of screen, powered

Vertical: ±40° (±22° with the ET-D75LE5, ±28° with the ET-D75LE6)

When using only the KEYSTONE correction of the Geometric

Adjustment function: Vertical ±40°, horizontal ±15°

(vertical ±22° and horizontal ±15° with the ET-D75LE5,

vertical ±28° and horizontal ±10° with the ET-D75LE5)

When using both the KEYSTONE and CURVED corrections of the

Geometric Adjustment function: Vertical ±5°, horizontal ±5°

(vertical ±10° and horizontal ±10° with the ET-D75LE3,

vertical ±10° and horizontal ±15° with the ET-D75LE4/D75LE8)

Ceiling/floor, front/rear

SPEC FILE PT-DS8500U

3-Chip DLP®Projector

As of July 2010

SFD10M002

3/17

Terminals*3SDI IN

HDMI IN

DVI-D IN

RGB 1 IN

RGB

YPBPR(YCBCR)

RGB 2 IN

R, G, B

YPBPR(YCBCR)

VIDEO IN

S-VIDEO IN

SERIAL IN

SERIAL OUT

REMOTE 1 IN

REMOTE 1 OUT

REMOTE 2 IN

LAN

Power cord length

Cabinet materials

Dimensions (W × H × D):

Weight

Operating temperature

Operating humidity

BNC × 1,

SD-SDI signal (YCBCR4:2:2 10-bit):

SMPTE 259M compliant: 480i, 576i

Single-link HD-SDI signal (YCBCR4:2:2 10-bit):

SMPTE 292M compliant: 720/50p, 720/60p, 1035/60i, 1080/50i,

1080/60i, 1080/25p, 1080/24p, 1080/24sF, 1080/30p

HDMI 19-pin × 1, Deep Color, compatible with HDCP,

480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24p,

1080/24sF, 1080/25p, 1080/30p, 1080/60p, 1080/50p

(non-interlaced signals only),

VGA (640 × 480)–WUXGA*2(1,920 × 1,200),

dot clock: 25–162 MHz

NOTE: Compatible with non-interlaced signals only.

DVI-D 24-pin × 1, DVI 1.0 compliant, HDCP compatible,

for single link only

480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24p,

1080/24sF, 1080/25p, 1080/30p, 1080/60p, 1080/50p,

VGA (640 × 480)–WUXGA*2(1,920 × 1,200),

dot clock: 25–162 MHz

NOTE: Compatible with non-interlaced signals only.

BNC × 5

R: 0.7 Vp-p, 75 ohms,

G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75 ohms,

B: 0.7 Vp-p, 75 ohms

HD/VD, SYNC: High impedance, TTL (positive/negative), 75 ohms

Y: 1.0 Vp-p (including sync signal), PB/PR(CB/CR): 0.7 Vp-p, 75 ohms

NOTE: SYNC/HD and VD terminals do not accept tri-level sync signals.

D-sub HD 15-pin (female) × 1

R: 0.7 Vp-p, 75 ohms,

G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75 ohms,

B: 0.7 Vp-p, 75 ohms

HD/VD, SYNC: High impedance, TTL (positive/negative), 75 ohms

Y: 1.0 Vp-p (including sync signal), PB/PR(CB/CR): 0.7 Vp-p, 75 ohms

NOTE: SYNC/HD and VD terminals do not accept tri-level sync signals.

BNC × 1, 1.0 Vp-p, 75 ohms

Mini DIN 4-pin × 1, Y: 1.0 Vp-p, C: 0.286 Vp-p, 75 ohms

D-sub 9-pin × 1 (RS-232C compliant) for external controller

D-sub 9-pin × 1 for link control

M3 jack × 1 for wired remote control

M3 jack × 1 for link control

D-sub 9-pin × 1 for external control (parallel)

RJ-45 × 1 for network connection, 100Base-TX/10Base-T, compliant

with PJLink™ (class 1)

3.0 m (9 ft 10 in)

Molded plastic

530 mm × 200 mm*5× 548.5 mm*6

(20-7/8˝ × 7-7/8˝ *5× 21-19/32˝ *6) (without lens)

Approx. 24 kg (52.9 lbs)*7(without lens)

0°–45°C (32°–113°F)*8

10%–80% (no condensation)

SPEC FILE PT-DS8500U

3-Chip DLP®Projector

As of July 2010

SFD10M002

4/17

Remote control unit

Power supply

Operation range*9

Dimensions (W × H × D)

Weight

Supplied accessories

Optional accessories

Zoom lens (1.0–1.2:1)

Zoom lens (1.4–1.8:1)

Zoom lens (1.8–2.6:1)

Zoom lens (2.6–5.1:1)

Zoom lens (5.0–8.0:1)

Zoom lens (7.9–15.0:1)

Fixed-focus lens (0.8:1)

Lens motor cover

High-ceiling mount bracket

Low-ceiling mount bracket

Attachment for ceiling mount bracket

Frame

Smoke cut filter

Replacement lamp (one bulb)

Replacement lamp (a set of two bulbs)

Replacement filter unit

3 V DC (AA type battery × 2)

Approx. 30 m (98 ft 5 in) when operated from directly signal receptor

51 × 176 × 28 mm (2˝ × 6-15/16˝ × 1-3/32˝)

Approx. 134 g (4.7 oz) (including batteries)

Power cord with security lock (× 1)

Wireless/wired remote control unit (× 1)

Batteries for remote control (AA type × 2)

Safety wire rope (× 1)

ET-D75LE6

ET-D75LE10

ET-D75LE20

ET-D75LE30

ET-D75LE4

ET-D75LE8

ET-D75LE5

ET-D75MC1

ET-PKD310H

ET-PKD310S

ET-PAD310

ET-PFD310

ET-SFD310

ET-LAD310

ET-LAD310W

ET-ACF310

Weights and dimensions shown are approximate. Specifications subject to change without notice.

*1 When the standby mode is set to ECO, LAN-based network functions such as the standby ON function will not operate.

*2 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.

*3 The SYNC/HD and VD inputs do not accept the tri-level sync signal.

*4 WUXGA resolution is supported only when the signals are compliant with VESA CVT-RB (Coordinated Video Timing-Reduced Blanking).

*5 With legs at shortest position.

*6 Excluding the optional lens.

*7 Average value (excluding the optional lens). May differ depending on models.

*8 The operating temperature range is 0°C (32°F) to 40°C (104°F) when used in High-Altitude mode (1,400 m (4,593 ft) to 2,700 m (8,858 ft)).

*9 Operation range differs depending on environments.

540 (21-1/4)

548.5 (21-19/32)

8.5 (11/32)

530 (20-7/8)

462 (18-3/16) 468 (18-7/16)26 (1-1/32)

100 (3-15/16)

200 (7-7/8)

Dimensions

SPEC FILE PT-DS8500U

3-Chip DLP®Projector

As of July 2010

SFD10M002

5/17

Terminals

6 7 8 9 10 11 12 13

23 4 5

8 Video input

9 S-Video input

10 RGB 1 input

11 RGB 2 Input

12 DVI-D input

13 LAN connector

1 Remote 1 input

2 Remote 1 output

3 Remote 2 input

4 Serial input

5 Serial output

6 SDI input

7 HDMI input

unit : mm (inch)

NOTE: This illustration is not drawn to scale.

SPEC FILE PT-DS8500U

3-Chip DLP®Projector

As of July 2010

SFD10M002

6/17

Standard setting-up position (when installed using the ET-PKD310H)

Upper edge of projected image

342

(13-15/32)

∅60.5

(2-3/8)

198

(7-25/32)

Lower edge of projected image

Projected image

340–420

(13-3/8–

16-17/32)

436–516

(17-5/32–

20-5/16)

100

(3-15/16)

100

(3-15/16)

100

(3-15/16)

100

(3-15/16)

Projected image

unit : mm (inch)

*1 When the lens protrudes to the

maximum.

212 mm (8-11/32˝) with the ET-D75LE6

125 mm (4-29/32˝) with the ET-D75LE10

114 mm (4-1/2˝) with the ET-D75LE1

121 mm (4-3/4˝) with the ET-D75LE20

99 mm (3-29/32˝) with the ET-D75LE2

121 mm (4-3/4˝) with the ET-D75LE30

102 mm (4-1/32˝) with the ET-D75LE3

126 mm (4-31/32˝) with the ET-D75LE4

254 mm (10˝) with the ET-D75LE8

202 mm (7-15/16˝) with the ET-D75LE5

*2 Adjustable in 40 mm (1-9/16˝) steps.

Caution:

• All construction work should be done by a qualified technician.

• When mounting to the ceiling, use the special mounting bracket. To prevent the projector from swaying or drop-

ping, attach the wire that is included with the projector between the mounting bracket and the ceiling.

SPEC FILE PT-DS8500U

3-Chip DLP®Projector

As of July 2010

SFD10M002

7/17

100

120

150

200

250

300

400

500

600

Screen

size

(inch,

diagonal)

Zoom

Zoom lenses

Fixed-focus

Fixed-

focus

lens*

Distance to screen (L) Height from the edge of screen

to center of lens (H)

ET-D75LE10

Zoom lens

min. max. min. max. min. max. min. max. min. max. min. max.

ET-D75LE6

Zoom lens

ET-D75LE20

Zoom lens

ET-D75LE30

Zoom lens

ET-D75LE4

Zoom lens

ET-D75LE8

Zoom lens

ET-D75LE5

Fixed-focus

lens

Except

ET-D75LE6

–

107

122

137

152

183

229

305

381

457

610

762

914

960

1097

1234

1372

1646

2057

2743

3429

4,115

5,486

6,858

8,230

–

1,067

1,219

1,372

1,524

1,829

2,286

3,048

3,810

4,572

6,096

7,620

9,144

1,022

1,180

1,338

1,496

1,812

2,286

3,076

3,866

4,656

–

533

610

686

762

914

1143

1524

1905

2,286

–

1,662

1,910

2,158

2,406

2,902

3,646

4,886

6,126

7,366

9,846

12,326

14,806

2,517

2,892

3,267

3,642

4,393

5,518

7,393

9,269

11,144

14,895

18,646

22,397

3,660

4,200

4,739

5,279

6,358

7,976

10,674

13,372

16,069

21,464

26,859

32,254

7,095

8,134

9,173

10,212

12,290

15,406

20,600

25,795

30,989

41,377

51,766

62,154

11,374

13,013

14,653

16,292

19,571

24,489

32,686

40,882

49,079

65,472

81,866

98,259

21,143

24,215

27,286

30,358

36,502

45,717

61,076

76,435

91,794

122,512

153,230

183,948

1,392

1,599

1,806

2,013

2,427

3,048

4,083

5,118

6,153

8,223

10,293

12,363

1,946

2,236

2,526

2,816

3,397

4,267

5,718

7,169

8,620

11,522

14,424

17,326

2,516

2,887

3,259

3,630

4,372

5,486

7,343

9,199

11,056

14,769

18,482

22,195

3,636

4,172

4,708

5,243

6,315

7,922

10,600

13,278

15,957

21,313

26,670

32,026

7,101

8,132

9,163

10,194

12,255

15,348

20,503

25,657

30,812

41,121

51,431

61,740

11,090

12,730

14,369

16,009

19,288

24,206

32,404

40,601

48,799

65,194

81,589

97,984

100

120

150

200

250

300

400

500

600

Screen

size

(inch,

diagonal)

Zoom

Zoom lenses

Fixed-focus

Fixed-

focus

lens*

Distance to screen (L) Height from the edge of screen

to center of lens (H)

ET-D75LE10

Zoom lens

min. max. min. max. min. max. min. max. min. max. min. max.

ET-D75LE6

Zoom lens

ET-D75LE20

Zoom lens

ET-D75LE30

Zoom lens

ET-D75LE4

Zoom lens

ET-D75LE8

Zoom lens

ET-D75LE5

Fixed-focus

lens

Except

ET-D75LE6

–

0.4

0.5

0.7

0.8

1.1

1.3

1.5

2.1

2.5

3.0

3.2

3.6

4.1

4.6

5.5

6.8

9.0

11.3

13.6

18.0

22.5

27.1

–

0.0

3.2

3.6

4.1

4.5

5.4

6.8

9.0

11.3

13.5

18.0

22.5

27.0

3.4

3.9

4.4

5.0

6.0

7.5

10.1

12.7

15.3

–

1.4

1.7

1.9

2.1

2.5

3.1

4.1

5.2

6.2

–

5.5

6.3

7.1

7.9

9.6

12.0

16.1

20.1

24.2

32.4

40.5

48.6

8.3

9.5

10.8

12.0

14.5

18.2

24.3

30.5

36.6

48.9

61.2

73.5

12.1

13.8

15.6

17.4

20.9

26.2

35.1

43.9

52.8

70.5

88.2

105.9

23.3

26.7

30.1

33.6

40.4

50.6

67.6

84.7

101.7

135.8

169.9

204.0

37.4

42.7

48.1

53.5

64.3

80.4

107.3

134.2

161.1

214.9

268.6

322.4

69.4

79.5

89.6

99.6

119.8

150.0

200.4

250.8

301.2

402.0

502.8

603.6

4.6

5.3

6.0

6.7

8.0

10.0

13.4

16.8

20.2

27.0

33.8

40.6

6.4

7.4

8.3

9.3

11.2

14.0

18.8

23.6

28.3

37.9

47.4

56.9

8.3

9.5

10.7

12.0

14.4

18.0

24.1

30.2

36.3

48.5

60.7

72.9

12.0

13.7

15.5

17.3

20.8

26.0

34.8

43.6

52.4

70.0

87.5

105.1

23.3

26.7

30.1

33.5

40.3

50.4

67.3

84.2

101.1

135.0

168.8

202.6

36.4

41.8

47.2

52.6

63.3

79.5

106.4

133.3

160.2

213.9

267.7

321.5

Projection distance for 4:3 aspect ratio screen

(ET-D75LE6/D75LE10/D75LE20/D75LE30/D75LE4/D75LE8/D75LE5)

Unit: feet

Unit: millimeters

• The value for L (distance to screen) varies slightly depending on the zoom lens characteristics.

• At the shortest projection distance, the zoom lens characteristics may cause slight image distortion.

• When vertical keystone correction is used, the image is corrected in the direction that reduces its projected size.

NOTE: When the fixed-focus lens is mounted, the optical lens shift function cannot be used.

SPEC FILE PT-DS8500U

3-Chip DLP®Projector

As of July 2010

SFD10M002

8/17

100

120

150

200

250

300

400

500

600

Screen

size

(inch,

diagonal)

Distance to screen (L) Height from the

edge of screen

to center of lens

(H)

ET-D75LE2

Zoom lens

min. max. min. max. min. max.

ET-D75LE1

Zoom lens

ET-D75LE3

Zoom lens

–

1,067

1,219

1,372

1,524

1,829

2,286

3,048

3,810

4,572

6,096

7,620

9,144

2,768

3,178

3,588

3,998

4,818

6,047

8,096

10,145

12,195

16,293

20,391

24,490

4,215

4,832

5,449

6,066

7,301

9,153

12,239

15,326

18,412

24,585

30,758

36,931

7,095

8,126

9,157

10,188

12,250

15,342

20,497

25,652

30,806

41,116

51,425

61,734

2,071

2,378

2,685

2,991

3,605

4,525

6,059

7,593

9,126

12,194

15,261

18,329

2,801

3,213

3,624

4,036

4,859

6,093

8,151

10,209

12,266

16,381

20,497

24,612

4,225

4,842

5,460

6,077

7,312

9,163

12,250

15,336

18,423

24,596

30,768

36,941

100

120

150

200

250

300

400

500

600

Screen

size

(inch,

diagonal)

Distance to screen (L) Height from the

edge of screen

to center of lens

(H)

ET-D75LE2

Zoom lens

min. max. min. max. min. max.

ET-D75LE1

Zoom lens

ET-D75LE3

Zoom lens

–

0.0

3.5

4.0

4.6

5.0

6.1

7.5

10.0

12.5

15.0

20.0

25.0

30.0

9.1

10.5

11.8

13.2

15.9

19.9

26.6

33.3

40.1

53.5

66.9

80.4

13.9

15.9

17.9

20.0

24.0

30.1

40.2

50.3

60.5

80.7

101.0

121.2

23.3

26.7

30.1

33.5

40.2

50.4

67.3

84.2

101.1

134.9

168.8

202.6

6.8

7.9

8.9

9.9

11.9

14.9

19.9

25.0

30.0

40.1

50.1

60.2

9.2

10.6

11.9

13.3

16.0

20.0

26.8

33.5

40.3

53.8

67.3

80.8

13.9

15.9

18.0

20.0

24.0

30.1

40.2

50.4

60.5

80.7

101.0

121.2

Projection distance for 4:3 aspect ratio screen

(ET-D75LE1/D75LE2/D75LE3)

Unit: feet

Unit: millimeters

• The value for L (distance to screen) varies slightly depending on the zoom lens characteristics.

• At the shortest projection distance, the zoom lens characteristics may cause slight image distortion.

• When vertical keystone correction is used, the image is corrected in the direction that reduces its projected size.

NOTE: When the fixed-focus lens is mounted, the optical lens shift function cannot be used.

SPEC FILE PT-DS8500U

3-Chip DLP®Projector

As of July 2010

SFD10M002

9/17

Calculation of the projection distance

For a screen size different from the above, use the equation below to calculate the projection distance.

Aspect ratio 4:3

minimum L (mm) = (diagonal screen size in inches) × 20.7 – 56.6

maximum L (mm) = (diagonal screen size in inches) × 24.8 – 73.6

minimum L (mm) = (diagonal screen size in inches) × 29.0 – 85.7

maximum L (mm) = (diagonal screen size in inches) × 37.5 – 108.5

minimum L (mm) = (diagonal screen size in inches) × 30.7 – 76.0

maximum L (mm) = (diagonal screen size in inches) × 41.0 – 100.4

minimum L (mm) = (diagonal screen size in inches) × 37.1 – 83.2

maximum L (mm) = (diagonal screen size in inches) × 54.0 – 116.2

minimum L (mm) = (diagonal screen size in inches) × 41.2 – 79.5

maximum L (mm) = (diagonal screen size in inches) × 61.7 – 106.4

minimum L (mm) = (diagonal screen size in inches) × 53.6 – 113.1

maximum L (mm) = (diagonal screen size in inches) × 103.9 – 176.5

minimum L (mm) = (diagonal screen size in inches) × 61.7 – 95.8

maximum L (mm) = (diagonal screen size in inches) × 103.1 – 121.6

minimum L (mm) = (diagonal screen size in inches) × 103.1 – 115.8

maximum L (mm) = (diagonal screen size in inches) × 163.9 – 101.3

minimum L (mm) = (diagonal screen size in inches) × 164.0 – 386.2

maximum L (mm) = (diagonal screen size in inches) × 307.2 – 359.8

L (mm) = (diagonal screen size in inches) × 15.8 – 83.5

Zoom lenses

ET-D75LE6

ET-D75LE10

ET-D75LE1

ET-D75LE20

ET-D75LE2

ET-D75LE30

ET-D75LE3

ET-D75LE4

ET-D75LE8

Fixed-focus lens

ET-D75LE5

• Distances calculated with the above equations will include slight deviations.

SPEC FILE PT-DS8500U

3-Chip DLP®Projector

As of July 2010

SFD10M002

10/17

(Width of

projected image)

(Height of

projected image)

0.1V

0.5V

0.1V

0.3H0.3H

Standard postition of projected image

360°

-15°

+15°

Shift range

Optical axis shift function allows to shift the position of a projected image as shown below.

Installable angle

Install the projector at an angle within the range shown below.

• Vertical direction

The projector may be installed at a vertical

angle of 360°.

• Horizontal direction

The projector may be installed at a horizontal

angle of ±15°.

• When the lens except the ET-D75LE6 is mounted

(Width of

projected image)

(Height of

projected image)

0.12V

0.4V

0.12V

0.2H0.2H

Standard postition of projected image

• When the ET-D75LE6 is mounted

• Because the ET-D75LE5 is a fixed short-throw lens, the lens shift function cannot be used with it.

Table des matières

Autres manuels Panasonic Projecteur

Panasonic

Panasonic PT-LB3U Manuel utilisateur

Panasonic

Panasonic PT-AH1000 Manuel utilisateur

Panasonic

Panasonic PT-AE1000E Manuel utilisateur

Panasonic

Panasonic WE160 - VIDEO IMAGER Manuel utilisateur

Panasonic

Panasonic PT-F200NTE/PT-FW100NTE Manuel utilisateur

Panasonic

Panasonic PT-LM2E Manuel utilisateur

Panasonic

Panasonic PT-EW630UL Manuel utilisateur

Panasonic

Panasonic PT-DW5100E Guide de configuration rapide

Panasonic

Panasonic PTL780NTU - LCD PROJECTOR Manuel utilisateur

Panasonic

Panasonic AE3000U - LCD Projector - HD 1080p Manuel utilisateur

Panasonic

Panasonic PT-DZ6700U - DLP Projector 1080p Manuel utilisateur

Panasonic

Panasonic PT-DZ12000U - WUXGA DLP Projector Manuel utilisateur

Panasonic

Panasonic Tentative PT-LB50SU Manuel du système

Panasonic

Panasonic PT-JX200FWE Mode d'emploi

Panasonic

Panasonic PTL390U - LCD PROJECTOR Manuel utilisateur

Panasonic

Panasonic PTL759VU - LCD PROJECTOR Manuel utilisateur

Panasonic

Panasonic TQBJ0223 Manuel utilisateur

Panasonic

Panasonic PT-L6600UL Manuel utilisateur

Panasonic

Panasonic PTL595U - LCD PROJECTOR Manuel utilisateur

Panasonic

Panasonic PTLB10SU - LCD PROJECTOR Manuel utilisateur

Panasonic

Panasonic PTL797U - LCD PROJECTOR Manuel utilisateur

Panasonic

Panasonic L711U - XGA LCD Projector Manuel utilisateur

Panasonic

Panasonic PT-LB55NT Manuel utilisateur

Panasonic

Panasonic Tentative PT-LB50NTU Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur

Asus

Asus ZenBeam Latte Manuel utilisateur
