rights reserved. Unauthorized copying and distribu-

tion is a violation of law.

Order Number PTD0708U39AE

F16

Cordless Impact Driver

Model No. EY7206

North America

TABLE OF CONTENTS

PAGE PAGE

1 Warning -------------------------------------------------------------- 2

2 Specifications ----------------------------------------------------- 2

3 Wiring Connection Diagram ---------------------------------- 2

4 Schematic Diagram ---------------------------------------------- 3

5 Exploded View and Replacement Parts List ------------ 4

Please file and use this manual together with the service manual for Model No. EY7202-U1, Order No.

PTD0503U33C1.

1Warning

Caution:

• Pb free solder has a higher melting point that standard solder; Typicall the melting point is 50 - 70°F (30 - 40°C) higher. Please

use a soldering iron with temperature control and adjust it to 750 ± 20°F (400 ± 10°C). In case of using high temperature solder-

ing iron, please be careful not to heat too long.

• Pb free solder will tend to splash when heated too high (about 1100°F / 600°C).

2 Specifications

3 Wiring Connection Diagram

4 Schematic Diagram

Model No. : EY7206 Exploded View

5 Exploded View and Replacement Parts List

Model No. : EY7206 Parts List

Safety

Ref.

No. Part No. Part Name & Description Q'ty Remarks

1 WEY7206K3078 HOUSING AB SET 1

2 WEY6481L0177 CLICK SPRING 1

3 WEY7206K3107 NOSE PROTECTOR 1

4 WEY7206S3117 PROTECTOR 1

5 WEY7206S4058 FIXATION COVER ASSEMBLY 1

6 WEY6507K1167 C-TYPE RING 1

7 WEY6507L0857 THRUST PLATE 1

8 WEY6507L0197 BIT HOLDER SPRING 1

9 WEY7540K3717 BIT HOLDER 1

10 WEYT611S3137 FIXATION COVER 1

11 WEY6505L0867 SLIDER 1

12 WEY6507L6977 STEEL BALL 2 (φ3.5), (2PCS/PK)

13 WEY7206L1128 ANVIL 1

14 WEY7205L1087 DRIVING SHAFT ASSEMBLY 1

15 WEY7201L6967 STEEL BALL 2 (2PCS/PK)

16 WEY7205L1377 HAMMER 1

17 WEY7205L6957 STEEL BALL 29 (29PCS/PK)

18 WEY6507L0907 THRUST PLATE 1

19 WEY7201L0157 HAMMER SPRING 1

20 WEY7300L0867 THRUST PLATE 1

21 WEY7205L1137 DRIVING SHAFT 1

22 WEY6506L1357 PLANET GEAR 2 (2PCS/PK)

23 WEY6506L1347 PIN 2 (2PCS/PK)

24 WEY7205L0027 MOTOR MOUNTING PLATE ASSEMBLY 1

25 WEY7201L4957 BEARING 1

26 WEYT611L0967 O-RING 1 (43.6*1.3)

27 WEY7205L0037 MOTOR MOUNTING PLATE 1

28 WEYT611L1187 STATOR 1

29 WEY7205L1467 MOTOR ROTOR ASSEMBLY 1

30 WEY7205L2307 BRUSH ASSEMBLY 1

31 WEY7205K2007 SWITCH 1

32 WEY7205L2157 BATTERY TERMINAL 1

33 WEY7201Y3267 BELT HOOK LOCK LEVER 1

34 WEY7201L0167 SPRING 1

35 WEY7205Y3187 BELT HOOK 1

36 WEY7205K0257 BELT HOOK BOLT 1

37 WEY7205Y3147 F/R SELECTOR HANDLE 1

38 WEYT611L0197 SELECT SWITCH LEVER 1

39 WEYT611Y3147 CHANGE HANDLE 1

40 WEY6230K9216 TORX TAPPING SCREW 9 (K3-20)

- WEY9598K7019 TOOL CASE 1 [SH]

- WEY7206K8108 OPERATING INSTRUCTIONS 1 [SH]
