READ AND SAVE THESE INSTRUCTIONS.R

Please read these instructions carefully

before

attempting to install,

operate or service the Panasonic Ventilating Fan. Failure to comply

with instructions could result in personal injury and/or property

damage. Please retain this booklet for future reference.

Specifications

Dimensions

Description

11-12

13-14

6-8

4-5

Table of Contents

Supplied Accessories

Unpacking

General Safety Information

Installation

( Wooden Header )

III

( -Joist Mounting )I

10-11

Installation ( Between Joist Mounting )

Installation

( In Existing Construction )

Installation ( Joist Mounting- )I

Installation

Maintenance

Practical Guide to Installation

Product Service

FV-05VFL2

FV-08VFL2

FV-11VFL2

8-9

( Joist Mounting- )II

Installation

FV-05VFL2

FV-08VFL2

FV-11VFL2

Quantity

Appearance

Part name

Screw

M4X8

Grille

Suspension

bracket I

Suspension

bracket II

Screw

M4X12

Screw

M4X16

III

Machine screw

M4X8

Quantity

Appearance

Part name

18W

Fluorescent

lamp

Incandescent

lamp

Light unit

These Panasonic ceiling mount ventilating fan models use a sirocco fan with dolphin-shaped blades driven by

a capacitor motor.

The motor is designed to have an extended service life with reduced energy consumption.

It also incorporates a thermal-cutoff for safety.The grille can be quickly detached from the main unit. A damper

for preventing air counterflow is provided. The blower uses a high-capacity sirocco fan developed to reduce the

noise level.

The light unit is an energy-saving, lighting device which uses two 18W fluorescent lamps and produces almost

the same illumination as a standard 100W incandescent lamp.

Suspension

bracket III

Thumb screw

Long screw

M4X30

3 inch adaptor

connector

(optional part)

(For 16 inches on center joists,only use suspension bracket , for 19.2 inches on center joists, only use

suspension bracket , If more than 19.2 inches on center,use suspension bracket & .)

III II III

Junction box cover

Junction box

Lighting unit assy

Fluorescent lamp

Night lamp

Adaptor connector

Part nameNo. Part nameNo.

Damper

Body

Adaptor

Grille

Suspension bracket

Bracket cover

Unit: ( )inches mm

11 10

10 1/4 259()

11 7/8 (301)

43/8 110()

5 1/2 (141)

13/4 45()126()

27/873()

3 1/4 (81)

13 330()

10 1/4 261()

16 1/8 (410)

FV-05VFL2

FV-08VFL2

FV-11VFL2

37/898()

2 15/16 (74)

3 1/2 (90) 1 (25)

13 1/4~15 1/2 ( 336~394 )

16 1/2~18 3/4 ( 419~480 )

21 1/4~23 1/2 ( 540~597 )

Specifications are based on HVI standard.

Unpack and carefully remove unit from carton.

Refer to the Supplied Accessories list to verify that all parts are present.

1. Do not install this ventilating fan where air temperature may exceed 40 C (104 F).

2. Make certain that the electric service supply voltage is 120V, 60 Hz.

3. Follow all local electrical and safety codes, as well as the National Electrical Code (NEC) and

the Occupation Safety and Health Act (OSHA).

4. Always disconnect the power source before working on or near the fan, motor or light fixture.

5. Protect the power cord from sharp edges, oil, grease, hot surfaces, chemicals or other objects.

6. Do not kink the power cord.

7. Do not install the unit where ducts are configured as shown in Fig. A.

8. Provide suction parts with proper ventilation.

9. This unit is approved for use over a bathtub or shower when installed in a GFCI protected

branch circuit.

Adaptor

Fig. A

Noise

(sone)

Duct

diameter

(inches)

11.0 .0

11.0 (5.0)

(5 )

FV-05VFL2

FV-08VFL2

FV-11VFL2

<0.3

0.5

0.6

1.3

1.5

700

760

830

940

910

1050

110

(cfm)

CAUTION:

1. For general ventilating use only. Do not use to exhaust hazardous or explosive materials and vapors.

2. Not for use in cooking area. (Fig .B)

3. This product must be properly grounded.

Floor

Do not install above or

(Cooking area)

inside this area

45o

equipment

Cooking

Fig. B

WARNING:

To reduce the risk of fire, electric shock or injury to persons, observe the following;

A. Use this unit only in the manner intended by the manufacturer. If you have any questions, contact

the manufacturer.

B. Installation work and electrical wiring must be done by qualified person(s) in accordance with all

applicable codes and standards, including fire-rated construction.

C. Sufficient air is needed for proper combustion and exhausting of gases through the flue (chimney)

of fuel burning equipment to prevent backdrafting. Follow the heating equipment manufacturer's

guideline and safety standards such as those published by the National Fire Protection Association

(NFPA), and the American Society for Heating Refrigeration and Air Conditioning Engineers

(ASHRAE) and the local code authorities.

D. When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities.

E. Ducted fans must always be vented to the outdoors.

F. These models are UL listed for tub and shower enclosures.

G. Solid state controls may cause harmonic distortion which can cause motor humming noise. Do not use

this unit with any solid-state control device.

H. Before servicing or cleaning unit, switch power off at service panel and lock the service disconnecting

means to prevent power from being switched on accidentally. When the service disconnecting means

cannot be locked, securely fasten a prominent warning device, such as a tag, to the service panel.

I. NEVER place a switch where it can be reached from a tub or shower.

J. Not to be installed in a ceiling thermally insulated to a value greater than R40.

Fig.1

Suspension

bracket I

Suspension

bracket III

Suspension

bracket I

Suspension

bracket III

Fig.2-1

Fig.2-2

Fig.2-3

Fig.2-4

Fan body

Suspension

bracket I

Suspension

bracket III

Suspension

bracket II

Fan body

Thumb screw

Screw (M4X8)I

Suspension bracket III

Suspension bracket II

2. Insert the supension bracket into the fan body and

adaptor. (select the suspension bracket as show below)

Spacing A on center Joists Insert Suspension bracket

12 inches

16 inches

19.2 inches vertical joists

24 inches

Refer to Fig. 2-1

Refer to Fig. 2-2

Refer to Fig. 2-3

Refer to Fig. 2-4

If spacing A on center joists is 24 inches, connect

suspension bracket and (C4 mark to C4 mark)

as show below :

II III

Joists

1. Before installation, secure the fan body to adaptor

by using thumb screw.(Fig.1)

Duct tape

Connection method for 3 inches adaptor connector

3 inches adaptor connector

Remove the tape

Adaptor

IMPORTANT:

Damper

Remove the tape from damper and adaptor

before installation. As show below:

Suspension

bracket I

Fan body

Fig.3-2

Fig.4

4. Install the suspension bracket to joists by using long

screws (M4X30) and secure it to the fan body by

using screw (M4X12) (Fig.4)II

Fan body

Joist

4-Long screws(M4X30)

Joist

Fan body

2-Long screws

(M4X30)

2-Long screws

(M4X30)

screw (M4X12)II

5. Remove junction box cover and secure conduit or

stress relief to junction box knock-out hole. (Fig.5)

6. Refer to wiring diagram below.

Using wire nuts, connect house power wires to

ventilating fan wires:

black to black; white to white; green to green;

Replace the junction box cover.

CAUTION:

Mount junction box cover carefully so that lead

wires are not pinched.

7. Install a circular duct (using 4 inches duct or 3 inches

duct) and secure it with duct tape or clamps.

Fig.3-1

3. Install the suspension bracket and the flange of fan body

to joists by using long screws (M4X30) ( If spacing A

between joists is 10 1/4~12 inches, install the flange of

fan body according to Fig.3-2, others according to

Fig.3-1 install the product)

Wiring diagram

Motor

Moteur

Fan unit

Red

Black

Witeh

Green

Capacitor

Junction box

Green

Black

witeh

Lamp

Light unit

Power Supply

AC120V 60Hz

Earth ground

Black

White

Night Lamp Power Supply

AC120V 60Hz

Current Fuse

Electronic

Ballast

Witeh

Junction box cover

Fig. 5

Conduit

Circular duct

Wire nut

Conduit

Junction box

Green wires

Lead wires

Duct tape

or clamps

3. Follow steps 5 to 7 of the installation (page 7) to

complete the duct work and wiring.

9. Insert the plug connector and plug connector

into the receptacle and receptacle respectively,

and secure the light unit to the fan unit with 2 screw

(M4X16) and 1 machine screw (M4X8). (Fig.6)

II III

III

10. Insert the fluorescent lamps and screw the night

lamp into the light unit.(Fig.6)

11. Insert mouting springs into slots as shown

and mount grille to fan body.(Fig.7)

Slot

Grille

Mounting spring

Fig.7

Light unit

1. Disconnect plug connector from receptacle and

remove adaptor from fan body before starting

installation.

2. Insert the suspension bracket into the adaptor and

secure it to joists by using long screws(M4X30) (Fig.8)

Keep the distance B (7/8 inch, 21.6mm) for the

thickness of ceiling board.

If spacing A between joists is 21 1/4 to 23 1/2

inches (540mm~597mm), connect suspension

bracket and (C4 mark to C4 mark) according

to page. 8 Select the suspension bracket according

to spacing A as show below.

II III

suspension

bracket

suspension

bracket I

suspension

bracket III

suspension

bracket &II III

8. Finish ceiling work. Ceiling hole should be aligned

with the edge of the flange. (Fig.6)

Ceiling

Joists

2-Long screws

(M4X30)

2-Long screws(M4X30)

Adaptor

inches mm()

Fig.8

13 1/4~15 1/2 ( 336~394 )

16 1/2~18 3/4 ( 419~480 )

21 1/4~23 1/2 ( 540~597 )

Suspension bracket

Fig.6

10 7/8 (275)

Machine screw

(M4X8)

screw (M4X16)III

Light unit

Plug connector III

Plug connector II

Ceiling

10 7/8 (275)

inches (mm)

Plug connector III

Plug connector II

Receptacle III

Receptacle II

4 W Night Lamp

Fluorescent lamps

Spacing A

between Joists

inches (mm)

13 1/4~15 1/2

( 336~394 )

16 1/2~18 3/4

( 419~480 )

21 1/4~23 1/2

( 540~597 )

Make sure that adaptor claws are properly inserted

into body slots.

IMPORTANT:

5. Insert the fan body into joists. (Fig.9)

6. Secure the fan body to adaptor by using thumb

screw and plug connector to receptacle(Fig.10)

Fig. 9

When mounting

body and blower

separately

1. Loosen 4 screws (but

do not remove them

from blower). (Fig.12-1)

2. Remove blower section.

(Fig.12-2)

4. Insert fan body (without

blower section) into joists

(Fig.9)

5. Secure the adaptor to

fan body by using thumb

screw. (Fig.10)

7. Insert the blower into the

fan body. (Fig.12-3)

8. Secure the blower.

(Fig.12-4) and plug

connector to receptacle

(Fig.10)

3. Remove adaptor from

fan body and secure it

to joists as in Fig.8 of

page 8.

Fig.12-2

Fig.12-3

Fig.12-1

Fig.12-4

Slots

Adaptor

claws

Fan body

Joist

7. Secure to joists by using

long screws(M4X30) and secure it to fan body by

using screw (M4X12) in vertical direction (Fig.11)

the suspension bracket

8. Follow steps 8 to 11 of Installation (page 8) to

complete the installation work.

Conduit

Junction box cover

Circular duct

4. Insert to fan body (refering

to step 2 of installation , page 6)

the suspension bracket in

6. Secure the fan body

to joists by using long

screw(M4X30) (Fig.11)

Fig. 10

Thumb

screw Plug connector IReceptacle I

4-Screws Screw driver

Fan body

Adaptor

4-Screws

Fan body

Blower

Duct tape

or clamps

Fig. 11

2-Long screws

(M4X30)

screw (M4X12)II

1. Before installation, secure the to by

using thumb screw (Fig.13) Secure the lighting unit to

fan body (refering to Fig.6 of page 8).

fan body adaptor

Fig.13

Suspension bracket

The suspension can comply with

different kinds of joists.

III

I-

bracket

2. Connect the suspension to fan body. (Fig.14)

(Select the hole by checking -joist size and fix the

screw to the frame hole.)

bracket III

4 kinds of joist

inches (mm)

I-

9/16 ( )14.3

11/16 (17.5)

31/32 (24.6)

1 17/32 38.9()

Thumb screw

Fan body

3. Connect the ventilating fan to the joist. (Fig.15)I-

4. Follow steps 5 to 11 of installation (page 7, page 8) to

complete the installation work.

1. Before installation, secure the to by

using thumb screw (Fig.13) Secure the lighting unit

to fan body (refering to Fig.6 of page 8).

fan body adaptor

C4 C1

Fig.14

Fig.15

Fig.16

2. Insert the suspension bracket into bracket cover of

adaptor side and the back of the fan body. (Fig.16)

(select the suspension bracket according to spacing A

as show below)

Suspension bracket

[

Suspension bracket

[

III

16 inches and 19.2 inches

horizental joist]

19.2 inches vertical joist]

Suspension bracket

[

Suspension bracket

[

III

16 inches and 19.2 inches

horizental joist]

19.2 inches vertical joist]

Suspension bracket

[

Suspension bracket

[

16 inches and 19.2 inches

horizental joist]

19.2 inches vertical joist]

16 inches and 19.2 inches

horizental joist

19.2 inches vertical joist

4-Long screws

(M4X30)

Ijoist

Screw (M4X12)II

Suspension

bracket III

Autres manuels pour FV-05VFL2

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Panasonic Ventilateur

Panasonic

Panasonic FV-17CU8 Manuel utilisateur

Panasonic

Panasonic F-48DFL Manuel utilisateur

Panasonic

Panasonic RG-C1315LA Manuel utilisateur

Panasonic

Panasonic F-M14E8 Manuel utilisateur

Panasonic

Panasonic WhisperCeiling FV-05 Manuel utilisateur

Panasonic

Panasonic K14Y2 Manuel utilisateur

Panasonic

Panasonic FV-08VRL1 Manuel utilisateur

Panasonic

Panasonic Whisper Green FV-08VKM1 Guide de démarrage rapide

Panasonic

Panasonic Whisper Green-Lite FV-08VKL1 Manuel utilisateur

Panasonic

Panasonic WhisperGreen FV-08VKML3 Manuel utilisateur

Panasonic

Panasonic FV-08VSL3 Manuel utilisateur

Panasonic

Panasonic Whisper Green-Lite FV-08VKML2 Manuel utilisateur

Panasonic

Panasonic WhisperLite FV-05VQ5 Manuel utilisateur

Panasonic

Panasonic F-60XDN Manuel utilisateur

Panasonic

Panasonic FV-15TGUZ Manuel utilisateur

Panasonic

Panasonic FV-07VF1 Manuel d'exploitation et d'entretien

Panasonic

Panasonic FV-05VS1 Manuel utilisateur

Panasonic

Panasonic Whisper Value-Lite FV-08VSL1 Manuel utilisateur

Panasonic

Panasonic WhisperCeiling FV-15VQ4 Manuel d'exploitation et d'entretien

Panasonic

Panasonic FV-0510VS1 Manuel utilisateur

Panasonic

Panasonic WhisperCeiling FV-20VQ3 Manuel utilisateur

Panasonic

Panasonic F-70ZBR Manuel utilisateur

Panasonic

Panasonic FV-08VFL2 Manuel utilisateur

Panasonic

Panasonic ECONAVI F-M15H5VBSQH Manuel utilisateur

Manuels Ventilateur populaires d'autres marques

ELTA FANS

ELTA FANS H03VV-F Manuel utilisateur

Hunter

Hunter 20714 Manuel d'instructions

Emerson

Emerson CARRERA VERANDA CF542ORB00 Manuel utilisateur

Hunter

Hunter Caraway Manuel d'instructions

Kompernass

Kompernass KH 1150 Manuel utilisateur

VES

VES FALA100/12V/TR Manuel utilisateur

Vertiv

Vertiv Liebert DCD Manuel utilisateur

Westinghouse

Westinghouse GFP Series Manuel utilisateur

Venmar

Venmar KUBIX HRV PLUS Series Manuel utilisateur

Maico

Maico ECR 31 Manuel utilisateur

Sonnenkonig

Sonnenkonig Dinky Manuel utilisateur

S&P

S&P ECOWATT HXBR Manuel utilisateur

Wider

Wider IMP03369BH Manuel utilisateur

Hinkley

Hinkley HIGHLAND Manuel utilisateur

Broan

Broan 766BN Manuel utilisateur

Premium

Premium PFS16022 Instructions de montage

Litex Industries

Litex Industries E-CGL52CB5C1 Manuel utilisateur

Lindab

Lindab LTDF Manuel utilisateur
