ACCESSORIES

SP RELAYS

TERMINAL SOCKET

DIMENSIONS (Unit: mm inch)

SP2-Terminal socket

40.64±0.4

1.600±.016 19.5±0.6

.768±.024

23±1

.906±.039

20.32±0.4

.800±.016

67±1

2.638±.039 15.24±0.4

.600±.016

52±1

2.047±.039

30±0.6

1.181±.024

4.5±0.4

.177±.016

6.5±0.4

.256±.016

Part No.: SP2-SF

SP4-Terminal socket

General tolerance: ±0.5 ±.020

40.64±0.4

1.600±.016

20.32±0.4

.800±.016

97±1

3.819±.039

52±1

2.047±.039

30±0.6

1.181±.024

4.5±0.3

.177±.012

6.5±0.3

.256±.012

30.48±0.4

1.200±.016

15.24±0.4

.600±.016

23±1

.906±.039

32±0.6

1.260±.024

19.5±0.6

.768±.024

40.5±0.6

1.594±.024

70.5±1

2.776±.039

11±0.4

.433±.016 21±0.4

.827±.016

Part No.: SP4-SF

Note: Terminal number marking is on the socket body. Please refer together with the SP relay schematic.

RoHS Directive compatibility information

http://www.mew.co.jp/ac/e/environment/

Mounting hole diagram

Notes:

(1) Mounting screws and the fastening

bracket are included in the package.

(2) Mount the relay with the proper

mounting direction — i.e. with the

direction of the mark on top of the

relay case matching the direction of the

mark on the terminal block. (The

direction of the terminal block is the

upward direction of the relay.)

30±0.2

1.181±.008 2-DIA. HOLES 4.5±0.1

2-DIA. HOLES .177±.004

Fastening bracket mounting and removal

1. Mounting

Insert the A part of the fastening bracket

into the mounting groove of the terminal

block, and then ﬁt the B part into groove,

while pressing with the tip of a minus

screwdriver.

2. Removal

Slide the B part of the fastening bracket

from the groove in the terminal block,

while pressing with the tip of a minus

screwdriver. While the bracket is in this

position, keep pressing the C part of the

bracket to the relay side with your ﬁnger,

and lift up to the left side and remove

from the groove, as in the diagram at

right.

Minus screwdriver

Fastening

bracket

SP relay

Terminal block

ACCESSORIES

SP RELAYS

MOUNTING BOARD

DIMENSIONS (Unit: mm inch)

18.4

.724 25

.984

23.2

.913

57.2

2.252

Mounting hole diagram

Tolerance: ±0.1 ±.004

18.4

.724 2-DIA. HOLES 3.2

2-DIA. HOLES .126

Panel cutout

Part No.: SP-MA

Direct chassis mounting possible, and applicable to DIN rail.

Use method

1. Both the SP relay 2 Form C and

4 Form C can be mounted to the

mounting slats.

2. Use the mounting slats either by

attaching them directly to the chassis, or

by mounting with a DIN rail.

(A) When attaching directly to chassis

Use two M3 screws.

For the mounting pitch, refer to the

speciﬁcation diagram.

(B) When mounting on a DIN rail

Use a 35mm 1.378inch wide DIN rail

(DIN46277).

The mounting method should be as

indicated in the diagram at right.

Method for mounting on DIN rail

(1) First ﬁt the arc shaped claw of the

mounting slat into the DIN rail.

(2) Press on the side as shown in the

diagram below.

(3) Fit in the claw part on the opposite

side.

Precautions for use

When mounting to a DIN rail, use a

commercially available fastening bracket

if there is a need to stop sliding of the

mounting slat in the rail direction.

Press relay in

Fit into mounting

grooves.

Press

Mounting

slat

DIN rail

Fig. 3

Fig. 2

Fig. 1

Fit in

To remove the

relay, press down

the mounting slats

so the claws move

to the outside.
