Outback Professional Range Pro 6 Manuel utilisateur

Gas Barbecues

WARNING

• For outdoor use only.

• Read instructions before using the appliance. Failure to follow instructions could

result in death, serious bodily injury, and/or propertyloss.

• Warning: accessible parts may be veryhot. Keep young children away.

• Do not move the appliance during use.

• Turn off the gas supply at the gas cylinder after use.

• Any modification of the appliance, misuse, or failure to follow the instructions

may be dangerous and will invalidate your warranty. This does not affect your

statutory rights.

• Retain these instructions for future reference.

• Leak test your barbecue annually. Check the hose connections are tight and leak

test themeach time you reconnect the gas bottle.

FOR YOUR SAFETY

If you smell gas:

1. Shut off gas to the appliance.

2. Extinguish any open flame.

3. Open barbecue lid or hood.

4. If odour continues, discontinue use and

contact your local dealer.

FOR YOUR SAFETY

1. Do not store or use petrol or other flammable

vapours or liquids in the vicinity of this or any

other appliance.

2. A gas cylinder not connected for use shall not

be stored in the vicinity of this or any other

appliance.

Photographs are not to scale.

Specifications subject to change

without prior notice.

Assembly and Operating Instructions for Outback®

Professional Range Pro 4 & 6 Burner Gas Barbecues

0359

Pre-Assembled Component

Quantity varies according to modelpurchased

 Appearance, size, and constructionmay differ according to modelpurchased

Parts List

Quantities vary according to model purchased. Specifications subject to change without prior notice.

For more details on hardware, please see ‘Hardware Reference Diagram’.

CODE PART QTY Professional Range Pro 4 Professional Range Pro 6

HOOD

A1 Hood Handle 1  

A2 Hood 1  

A3 Heat Indicator Assembly 1  

A4 Warming Basket 1  

BODY

B1 Barbecue Body 1  

B2 Burner 4 6

B3 Back Burner 1  

B4 Control Panel 1  

B5 Knob ( Included Back Burner Knob) 57

B6 Drip Tray 1  

B7 Drip Pan 1  

B8 FoilLiner 1  

B9 Flame Tamer 4 6

B10 Grill 3 

TROLLEY

C1 Side Burner 1  

C2 Side Burner Grid 1  

C3 Side Burner Valve 1  

C4 L/H Side Burner Shelf withLid 1  

C5 R/HSide Shelf 1  

C6 Hose 1  

C7 L/H Panel 1  

C8 R/H Panel 1  

C9 Back Panel 1  

C10 Bottom Panel 1  

C11 BodySupport 1  

C12 Cabinet Support 1  

C13 L/HDoor 1  

C14 R/H Door 1  

C15 Caster 2  

C16 Lockable Caster 2  

C17 Heat Shield 1  

C18 Mounting Bracket 1  

C19 IgnitionAssembly 1  

ROTISSERIE

D1 Rotisserie Handle 1  

D2 Fork 2  

D3 Spit Rod 1  

D4 Motor 1  

D5 L/H Bracket 1  

D6 R/H Bracket 1  

HARDWARE

E1 Screw, M6x15 50  

E2 Nut, M6 16  

E3 Screw, M4x10 8  

E4 Screw, ST4.0 x10 4  

C20 Side Burner Knob 1  

E5 Screw, M5 x 10 4  

E6 Nut, M5 4  

E7 Screw 2  

Parts Diagrams

Quantities vary according to model purchased. Specifications subject to change without prior notice.

For more details on hardware, please see ‘Hardware Reference Diagram’.

C17

C18

C19

B10

C7 C8

C10

C11

C12

C13 C14

C15 C16

D1 D2 D3 D4

D6D5

Back Burner Knob

C20

Hardware Reference Diagram

Specifications subject to change without prior notice.

E7 E5, E6 E3

E1, E2

Assembly

IMPORTANT!

• Tools Required: Medium size flat blade or Phillips/Crosspoint screwdriver, adjustable spanner or

metric spanner set

• The assembly of this barbecue requires 2 people.

• Carefully unpack the parts from the box and remove all internal packaging before commencing

assembly. All loose items including the grills, flame tamers and warming basket must be removed

from the body.

• Whilst every care is taken in the manufacture of this product, care must be taken during assembly

in case sharp edges are present.

Attach the L/HPanel (C7) to the Bottom Panel (C10) using the Screws (E1) and Nuts (E2).

Attach the R/HPanel (C8) to the Bottom Panel (C10) using the Screws (E1) and Nuts (E2).

* A sticker on the panels

indicates the position for

easy assembly.

L/H

R/H

Attach the Body Support (C11) to the L/H (C7) and R/H (C8) Panels using the Screws (E1).

Attach the Cabinet Support (C12) between the Body Support and Bottom Panel using

the Screws (E1).

L/H

R/H

IgnitionAssembly

L/H

Attach the Back Panel (C9) to the assembled portion of the cabinet using the Screws (E1,E4).

L/H R/H

Turn over the cabinet.

Attached the Casters (C15) and the Lockable Casters (C16) to the Bottom Panel

(C10) using the Screws(E1).

Lay the Barbecue Body (B1) onto the supports of the cabinet Carefully . WARNING: DO NOT

RELEASE THE BARBECUE BODY WHILE THE BARBECUE HAS NOT BEEN PROPERLY

SEATED. THIS MAY RESULT IN INJURY OR DAMAGE TO YOUR BARBECUE.

Open Hood(A2), Connect the Body to the cabinet using the Screws(E1).

Attach the Side Burner Shelf (C4) and side Shelf (C5) to side panel of Body using

the Screws(E1,E3).

Feed the venturi tube of the side burner (C1) through the hole in the side burner shelf, and slide

the end of the venturi tube over the tip of the valve, then connect the burner to side burner

bracket using the Screws (E3).

Attach the Valve (C3) to the Side Burner Shelf (C4) using the Screws(E3).

Then push the Side Burner Knob (C20) onto the Valve stem.

Valve Side Burner knob

Valve

Venturi tube of the side burner

2 3

side burner bracket

Connect the wires to the Ignition Assembly (C19) as shown on the next page.

Attach the Electronic Ignition Battery in to the Ignition.

Note: The Ignition Assembly were Assembled on the L/H Panel.

Open L/H side burner lid and place the Grid (C2) onto the burner.
