Assembly and Operating Instructions for Outback®

Party 6 Burner Gas BBQ

Drawings are not to scale.

Specifications subject to change

without prior notice.

WARNING

• For outdoor use only. Not for commercial use.

• Read instructions before using the appliance. Failure to follow instructions could

result in death, serious bodily injury, and/or property loss.

• Warning: accessible parts may be very hot. Keep young children and pets away.

• Do not move the appliance during use.

• Turn off the gas supply at the gas bottle after use.

• Any modification of the appliance, misuse, or failure to follow the instructions may

be dangerous and will invalidate your warranty. This does not affect your statutory

rights.

• Retain these instructions for future reference.

• Leak test annually, and whenever the gas bottle is removed or replaced. Check that

the hose connections are tight and leak test each time you reconnect the gas bottle.

• For Flare-up control please refer to the ‘OPERATION’ section of this manual.

FOR YOUR SAFETY

If you smell gas:

1. Shut off gas to the appliance.

2. Extinguish any open flame.

3. Open barbecue lid or hood.

4. If odour continues, discontinue use and

contact your local dealer.

FOR YOUR SAFETY

1. Do not store or use petrol or other flammable

vapours or liquids in the vicinity of this or any

other appliance.

2. A gas bottle not connected for use must not be

stored in the vicinity of this or any other

appliance.

FS5680

CODE PART QTY Outback® Party 6 Burner

Gas BBQ

BODY

B1 Barbecue Body 1 

B2 Burner 6 

B3 Control Panel 1 

B4 Knob 6 

B5 Ignition Button 1 

B6 Lava Rock 1 

B7 Lava Rock Basket 1 

B8 Cooking Grill 1 

B9 Cooking Griddle 1 

B10 Hose and Regulator Assembly 1 

B11 Left Wind Shield 1 

B12 Right Wind Shield 1 

B13 Rear W ind Shield 1 

TROLLEY

C1 Side Shelf Support 2 

C2 Left Side Shelf 1 

C3 Right Side Shelf 1 

C4 Drip Tray Handle 1 

C5 Drip Tray 1 

C6 Screen 1 

C7 Trolley Assembly 1 

C8 Axle 1 

C9 Wheel 2 

C10 Wheel Hubcap 2 

C11 Lockable Caster 2 

HARDWARE

D1 M6x12 Bolt 12 

D2 M6 Wing Bolt 2 

D3 Locknut 2 

Pre-Assembled Component

Quantity varies according to model purchased

 Appearance, size, and construction may differ according to model purchased

Parts List

Quantity varies according to model purchased. Specifications subject to change without prior notice. For

more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.

Parts Diagram

Quantity varies according to model purchased. Specifications subject to change without prior notice. For

more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.

C2 C3

B12

B11

B13

B1 B2

B10

C9C10 C11

Hardware Reference Diagram

Specifications subject to change without prior notice.

M6x12 Bolt

M6 Wing Bolt

Assembly

IMPORTANT!

• TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/Crosspoint screwdriver,

adjustable spanner or metric spanner set.

• Remove any internal component or packaging from the barbecue body.

• Whilst every care is taken in the manufacture of this product, care must be taken during assembly in

case sharp edges are present.

• Please read the Important Information section carefully before assembly and use of your

barbecue.

Open the four latches as shown.

Carefully lift the Barbecue Body (B1) away from the Trolley Assembly (C7). and remove any

internal components or packaging from the Barbecue Body.

Carefully turn the Trolley Assembly (C7) upside-down.

Unscrew the Locknuts (D3) from both ends of the Axle (C8). Slide the axle through the

corresponding holes in the left legs. Slide the Wheels (C9) over each end of the axle. Secure the

wheels into place with the locknuts. Place the wheel Hubcaps (C10) onto the outsides of the

wheels. Attach the Lockable Casters (C11) into the right legs as shown.

Latch

D3 C10

C11

Carefully turn the trolley assembly over right side-up. Unfold the trolley assembly as shown.

Attach one Side Shelf Support (C1) to the barbecue body using M6x12 Bolts (D1x6pcs) as

shown. Repeat above process for the other side shelf support.

Make sure the side shelf buffers face upward when attaching the side shelf support.





Carefully place the barbecue body assembly onto the trolley assembly, and fix with M6 Wing

Bolts (D2x2pcs). Then lock the four latches as shown.

Unlock the latch on the side shelves, and extend them to horizontal position.

Unfold the Wind Shields (B11, B12, B13) and secure them in position by in placing the locking

tabs on side wind shields into the slots in barbecue body.

Remove the plastic wrap from the Lava Rock (B6) and then distribute the Lava Rock evenly in the

Basket (B7). Lay the lava rock carefully into the body ensuring it lies level within the body. Lay the

Cooking Grill (B8) and Griddle (B9) into place.

NOTE: Ensure that the lava rock lies directly underneath the grills.

Remove the retaining bolts from Drip Tray Handle (C4), and then attach it onto the Drip Tray (C5)

using the retaining bolts.

Insert the drip tray by sliding it underneath the barbecue body.

Attach the Screen (C6) to the front left/right legs as shown.

Connect the Hose and Regulator Assembly (B10) to the barbecue.

Ensure the mating faces of the connection are clean and not damaged. Do not use any

sealing tape, paste, or liquid on the connection. The nut must be tightened with the use

of a spanner. Do not use force which may damage the assembly.

(Left view of the barbecue trolley)

B10

Leak Testing

Always perform a leak test in a well-ventilated area.

Step 1 - Confirm all control knobs are in the off position.

Step 2 - Turn the gas on / open the gas control valve on the gas bottle or regulator.

Step 3 - Check for leaks by brushing a solution of ½ water and ½ liquid detergent / soap over all

the gas system joints, including gas bottle valve connections, hose connections, and regulator

connections.

Step 4 -NEVER USE AN OPEN FLAME to test for leaks at any time.

Step 5 - If bubbles form over any of the joints there is a leak

• Turn off the gas supply at the gas bottle

• Retighten all joints

• Repeat test

• If bubbles form again do not use the barbecue and contact your local distributor for assistance.

Always wipe the mixed solution (½ water and ½ liquid detergent / soap) from all joints and

connections after leak testing.

ASSEMBLY IS NOW COMPLETE.

PROCEED TO THE NEXT PAGE FOR INSTRUCTIONS ON OPERATION AND

MAINTENANCE

ALL JOINTS AND CONNECTIONS MUST NOW BE LEAK TESTED BEFORE USING THE

BARBECUE.

Leak test annually, and whenever the gas bottle is removed or replaced.

Leak Test Diagram

1. Maximum diameter or breadth is 320mm.

2. Maximum height (regulator included) is 700mm.
