One Forall ZAPPER URC-6010 Manuel utilisateur

Universal remote . . . . . . . . . . . . . . . . . . . P. 2

URC-6010

702501

WWW.ONEFORALL.COM 2

INSTALLING THE BATTERIES

PICTURE OF THE ONE FOR ALL ZAPPER REMOTE

FEATURES AND FUNCTIONS

SETTING UP THE ZAPPER

Direct Set-Up 5

Search Method 7

Code Blink Out 8

SET-UP CODES

Television 59

ADVANCED OPERATION

Controlling Colour & Brightness 9

Scan 9

TROUBLE-SHOOTING

Helpful Hints 10

Installing The Batteries

Table of Contents

The ZAPPER needs 2 new “AAA/LRO3” alkaline batteries.

1Remove the battery cover from the back of the ZAPPER by pres-

sing down on the tab.

2Match the batteries to the +/- marks inside the battery case, then

insert the batteries.

3Press the battery cover back into place.

Important notes:

- In order to avoid having to reprogram your ZAPPER after you remove

the batteries, you will need to insert new batteries within 5 minutes.

Also, it is best that you do not use rechargeable batteries.

- On the inside of the battery compartment door you will find a

label on which to write your set-up code after your ZAPPER is set

up for your television. Please write down your code for easy,

future reference.

WWW.ONEFORALL.COM 3

WWW.ONEFORALL.COM 4

Features and Functions

See picture of the ZAPPER remote on page 3.

1Power

The POWER key operates the same function it did on your orginal

remote control.

2SEARCH Key

Use this key within the ”Search Method” (see page 7).

3LED (red light)

The LED (Light Emitting Diode) flashes red whenever a key is

pressed.

4MAGIC

The MAGIC key is used to set up your ZAPPER and to access special

features.

5Mute

The Mute key operates the same function it did on your orginal

remote control. It is also used to activate the Scan feature (see page

9).

6Volume +/-, Programme +/-

The Volume and Programme keys operate just as those on your

original remote control. These keys are also used to program the

ZAPPER for your television and to control the Colour and Brightness

settings of your television (see page 9).

WWW.ONEFORALL.COM 5

Direct Set-Up

To set up the ZAPPER for your Television follow the instructions below. To

set up your Television:

1Find your Television code in the Set-Up Code section

(page 59-68). Codes are listed by brand name. The

most popular codes are listed first.

2Press and hold the MAGIC key until

the LED blinks twice (the LED will blink

once then twice).

3 Enter your 5-digit code according to the chart

below. The LED will blink twice.

4Now, aim the ZAPPER at your Television and press

POWER. If your Television switches off, your ZAPPER

should be ready to operate your device.

5Turn your device back on and try all the remote’s functions

to ensure they are working properly. If the functions do not

work properly, repeat steps 1-4 using another code listed

under your brand.

6 Write the code for your TV in the boxes provided on

page 6 and inside the battery compartment for easy

future reference.

Setting Up The ZAPPER

ONE FOR ALL

Acura

Admiral

Adyson

Agazi

AGB

Aiko

11132

122241224223313

14232

21131

31121

142311113211322

224141131412131

2233213444

Volume + = 1

Volume

Programme + = 3

Programme

TV Code

Example: To enter the Sony TV code 24432, you would press Volume(-),

Programme(-), Programme(-), Programme(+), Volume(-).

If your television does not respond to the ZAPPER after you have tried all

the codes listed for your brand, try the Search Method described

on page 7.

Make sure you write your correct 5 digit code in the boxes provi-

ded inside the battery compartment and in the boxes provided on

this page.

6WWW.ONEFORALL.COM

Important notes:

- Some codes are quite similar. If your television does not respond or is not

functioning properly with one of the codes, follow steps 1-4 with each

code listed for your brand.

- If none of the codes listed for your brand operate your television, follow

the Search Method described in the next section. The Search Method can

be used even if your brand is not listed at all.

- Write the code for your TV in the boxes provided below and

inside the battery compartment for easy future reference.

■■ ■■ ■■ ■■ ■■

Volume + = 1

Volume

= 2

Programme

= 4

Programme + = 3

WWW.ONEFORALL.COM 7

Search Method

If your Television does not respond to the ZAPPER after trying all the codes

listed for your brand, try searching for your code. To search for your TV code:

1Turn on your TV.

2Press and hold the MAGIC key until the LED

blinks twice (the LED will blink once

then twice).

3Next, press the Programme(-) key three times.

4Point the ZAPPER at your television. Next, alternate

between POWER and SEARCH until your Television turns

off. You may have to press these keys many times, so be

patient. Remember, you must aim the ZAPPER at your

device the entire time you are searching for your code.

5 When your device turns off, press and release MAGIC

to store the code.

The ZAPPER should now be ready to operate your Television. Turn your

device back on and try all the remote’s functions to ensure they are

working properly. If some of the ZAPPER’S commands are not operating

correctly, try the search method again, you may be using the wrong code.

Important note: During step 4, you may have to press these keys many

times (up to 150!), so be patient. Remember, you must aim the ZAPPER at

your device the entire time you are searching for your code.

8WWW.ONEFORALL.COM

Code Blink Out

After you have used the Search Method, you can find out which code

the ZAPPER responded to by blinking back the code. It’s handy to know

your Television code for future reference. Remember, you can only

blink back your code after the ZAPPER is operating your device.

To blink out your TV code:

1Press and hold the MAGIC key until the red LED

blinks twice (the red LED will blink once then

twice).

2Next, press Programme(-), Programme(-),

Programme(+).

3For the first digit of your 5-digit code,

press Volume + ( ) and count the red blinks.

4For the second digit, press Volume - ( )

and count the red blinks.

5For the third digit, press Programme(+)

and count the red blinks.

6For the fourth digit, press Programme(-)

and count the red blinks.

7For the fifth digit, press MUTE and count the red

blinks.

Write the code for your TV in the boxes provided on page 6 and inside the

battery compartment for easy future reference.

WWW.ONEFORALL.COM 9

Controlling Colour & Brightness

Depending on the functions of your original remote control, the ZAPPER

can operate the colour and brightness settings of your Television.

Scan

Your ZAPPER comes with a special Scan function which lets you “scan”

through every programme available on your TV.

To scan the programmes on your TV:

1Aim the ZAPPER at your TV. Press and release MAGIC

then press the MUTE key.

The ZAPPER will send the command to advance

through all the programmes available on your

Television stopping at each programme for about three

seconds. Remember, you must aim the ZAPPER at your

device the entire time you are using scan.

2When you find a programme you would like to watch,

simply press any key to stop the Scan feature.

Advanced Operation

then holdPressColour up =

then holdPressColour down =

then holdPressBrightness up =

then holdPressBrightness down =

Note: You have 5 seconds to press the Volume or Channel keys for colour or

brightness adjustment after pressing MAGIC.

Important note: Scan may not function with a television that did not have

a programme +/- key on the original remote.

10 WWW.ONEFORALL.COM

Trouble-Shooting

Helpful Hints

Solution:

Try the search method.

A) Try all the codes listed for your

brand.

B) Try the search method.

You may be using the wrong code.

Try Direct Set-Up again trying each

code listed under your brand or

start the search method over again

to locate the proper code.

Press MAGIC until the light blinks

twice. Then press:

(CH-), (CH+), (CH-).

If your original remote did not

have channel +/- keys, the ZAPPER

may not operate this function.

Make sure you are using new

batteries and are aiming the ONE

FOR ALL at your device.

Replace batteries with 2 new

“AAA/LR03” alkaline batteries.

Problem:

Your brand is not listed in

the ONE FOR ALL code section?

The ONE FOR ALL does not

operate your television?

The ONE FOR ALL is not

performing commands

properly?

Your TV switches to

programme 1 when you

press the Power key before

switching off OR you must

press Power twice to switch

on your TV?

You cannot reach channel 10

and above on your TV.

The ONE FOR ALL does not

respond after pressing a

key?

LED does not blink when you

press a key?
