One Forall Audio Zapper Manuel utilisateur

URC-6540

URC-6541

Retain For Future Reference

Sorgfältig aufbewahren

A conserver soigneusement

USERGUIDE&CODEBOOK.... . . . . .. . . . . .. . . . . .. . . . . . .. . . . . .p. 2

BEDIENUNGSANLEITUNG&EINSTELLCODES ....p. 22

MODED’EMPLOI& LISTEDES CODES ...... . . . . ... . . . . .p. 42

Universal Remote

Universal-Fernbedienung

Télécommande Universelle

2WWW.ONEFORALL.COM

Table of Contents

ABOUT YOUR AUDIO ZAPPER 3

FEATURES AND FUNCTIONS 5

INSTALLING THE BATTERIES 7

INSTALLATION 8

Direct Set-Up 8

Key Lock/Unlock 10

Input Select Toggle 11

Search Method 12

Quick Code Reference 15

ADVANCED FEATURES 16

Mode Reassignment 16

Learning Feature 17

TROUBLE SHOOTING 20

Helpful Hints 20

Consumer Help-Line 21

SET-UP CODES 62

WWW.ONEFORALL.COM 3

About your AUDIO ZAPPER

Thank you for purchasing the AUDIO ZAPPER

universal remote control (URC-6540 or URC-6541).

Your Zapper package contains:

• The AUDIO ZAPPER Remote Control

• The AUDIO ZAPPER User Guide and Codebook

The User Guide and Code Book explains in simple

steps how to set-up and operate your new

universal remote control. You may need this guide

again in the future, so please be sure to keep it.

Your AUDIO ZAPPER requires 2 new "AAA/LR03"

Alkaline batteries.

Your AUDIO ZAPPER is a perfect solution for

replacing the basic functions of your lost or broken

audio remote control. You can operate the basic

functions of your Amplifier/Tuner, CD Player, Mini

Disc Player, and Audio Cassette Player. The AUDIO

ZAPPER is also ideal for use in place of your

complicated audio remote. With the Learning

feature, you can easily customize the AUDIO

ZAPPER for your favorite functions.

The illustration and the chart on the following

pages describe the features and functions of the

AUDIO ZAPPER universal remote control.

4WWW.ONEFORALL.COM

About your AUDIO ZAPPER

Device

Keys

Volume

Volume +

Programme +/

Track +

Programme

Track

Mute

MAGIC Power

Transport

Keys

Features and Functions

WWW.ONEFORALL.COM 5

Function

LED

The LED (Light Emitting Diode)

flashes as soon as you press any

valid key. It is also used during

set-up for user feed back.

Magic Key

The MAGIC key is used to set-up

your AUDIO ZAPPER and to access

special features.

Power Key

The Power key will turn your

Amplifier/Tuner both on and off

when in the TUN mode. This key

may also open and close your CD

tray when in the CD mode.

Device Keys

The TUN, CD, TAPE, and MD keys

select the component of your

system to be controlled. Pressing

the TUN key allows the remote to

control the basic functions of your

Amplifier/Tuner. After pressing

the CD key, you can operate the

basic functions of your CD player.

After pressing the TAPE key, the

transport keys operate your Audio

Cassette Player. After pressing the

MD key, you can operate the basic

functions of your Mini-Disc player.

Mute Key

The Mute key operates the same

function as the Mute key on your

original remote control.

Volume +/-, Programme +/- Keys

The Volume keys control the

volume level of your HI-FI.

After pressing the TUN key, the

Programme +/ - keys change the

pre-set stations up and down on

your Tuner.

MAGIC

TUN

TAPE

Features and Functions

6WWW.ONEFORALL.COM

Function

If Magic is first pressed, the

programme +/ - keys will search

up and down for the next

available station of your tuner.

After pressing the CD key, the

Programme +/– keys change the

track of your CD player up and

down. If Magic is first pressed,

the Programme +/- change the

disc up and down if this function

is available for your CD player.

Transport Keys

The Play key will cause your CD,

MD, or Audio Cassette to begin to

play, depending upon what mode

key you have selected. If Magic is

first pressed, the Play key will

cause the device to begin to

record, when applicable.

The Stop and Pause keys operate

the same function as on your

original remote control.

After pressing the CD key, the FF

and REW keys will search forward

and reverse through the song that

is playing.

After pressing the TAPE key, the

FF and REW keys will operate as

fast forward and rewind.

F Key (Function Key)

The F key allows you to select the

input of your Amplifier/Tuner.

Even if your original remote

control has a separate key for

each output (Tuner, CD, Tape,

etc.), the AUDIO ZAPPER’s F key

will send a different output

selection with each key press.

Installing the Batteries

WWW.ONEFORALL.COM 7

The AUDIO ZAPPER needs 2 new "AAA/LRO3"

alkaline batteries.

Remove the battery cover from

the back of the AUDIO ZAPPER by

pressing down on the tab.

Match the batteries to the +/-

marks inside the battery case,

then insert the batteries.

Press the battery cover back into

place.

Important notes:

- It is best that you do not use rechargeable

batteries.

- On the inside of the battery compartment door

you will find a label on which to write your set-

up codes after your ZAPPER is set up for your

devices. Please write down your codes for easy,

future reference.

- Upon removing the batteries, your set-up codes

and advanced programming will be retained.

Direct Set-Up

8WWW.ONEFORALL.COM

Setting Up Your Amplifier/Tuner

The following instructions allow you to set-up your

Audio System whether it be a Micro-System, Mini-

System, or separate components.

Find your HI-FI code in the Set-Up code section

(starting on page 62). Codes are listed by brand

name. The most popular code is listed first. Make

sure that your HI-FI set is switched on.

Press and release the TUN key.

Press and hold down MAGIC

until the red light blinks twice (the

light will blink once then twice).

Enter your 6-digit code

according to the chart below.

The red light will blink twice.

Example: To enter Pioneer code 121312 you

would press: Vol+, Vol

, Vol+, Ch+, Vol+, Vol

Now, aim the AUDIO ZAPPER at your HI-FI set

and press POWER. If your HI-FI set switches

off, turn your HI-FI set back on manually and

try all the other keys on the AUDIO ZAPPER

Keypad and fill in the "Set-Up table".

If all functions do not work properly, you should

lock those functions that do work properly (refer

to page 10 for Key Lock instructions), then try the

next code in the list.

If all functions on the keypad work, except for

input select please refer to page 11 for the Input

Select Toggle.

Write the codes for your HI-FI in the boxes

inside the battery compartment and on

page 15 for easy future reference.

MAGIC

TUN

______

VOL (+) = 1

VOL ( -) = 2

CH (+) = 3

CH ( -) = 4

Direct Set-Up

WWW.ONEFORALL.COM 9

Example for setting up a Pioneer Mini-System

One Amplifier/Tuner Set up code 121312

programmed on the TUN device key controls four of

the function keys (Power, Volume +, Volume -, and

F). These keys should be locked according to the

instructions on page 10.

These functions will remain after locking each key.

A second Amplifier/Tuner code 111143 could then

also be programmed on the TUN device key to

control the Programme + and Programme – for the

Tuner.

Set-Up Table

Audio Zapper Key TUN code TUN code

121312 111143

POWER X

Programme (+) X

Programme (-) X

Volume (+) X

Volume (-) X

F (input) X

Audio Zapper Key

Code: Code: Code:

POWER

Programme (+)

Programme (-)

Volume (+)

Volume (-)

F (input)

Key Lock/Unlock

10 WWW.ONEFORALL.COM

The Key Lock feature allows you to retain a

function from the currently programmed code.

The locked keys remain even after another code

has been programmed on the same device key.

To Lock a function:

Press and release the device key

(TUN, CD, TAPE or MD).

Press and hold down MAGIC

until the red light blinks twice (the

light will blink once then twice).

Next, press Programme -,

Programme +, Programme -

(the LED will blink twice).

Now press the function that you

would like to lock (the LED will blink

twice). For example, Programme +.

To Unlock a function:

Press and release the device key.

Press and hold down MAGIC

until the red light blinks twice (the

light will blink once then twice).

Next, press Programme -,

Programme +, Programme -

(the LED will blink twice).

Now press the function that you

would like to unlock (the LED will

blink four times).

Please note that steps 1-4 must be

repeated for each function that you wish

to lock or unlock.

MAGIC

TUN

MAGIC
