One Forall XSight Manuel utilisateur

User Manual

English

Unpacking and Setting Up Xsight .............................................................3

Using Xsight Keys and Touch screen ..........................................................3

Keys Xsight COLOUR .........................................................................4

Keys Xsight TOUCH ...........................................................................6

Initial Setup .................................................................................8

Favorites .....................................................................................9

Activities .....................................................................................9

Devices ......................................................................................9

Profiles .....................................................................................10

Settings ....................................................................................10

Device Setup ...............................................................................11

Add Device ............................................................................11

Delete Device ..........................................................................12

ViewCode .............................................................................12

Learning . ..................................................................................13

Volume Control .............................................................................14

Clock .......................................................................................15

Audio ......................................................................................15

Brightness ..................................................................................15

Timeout ....................................................................................16

Language ..................................................................................16

RF On/Off ..................................................................................16

Reset .......................................................................................16

2WWW.ONEFORALL.COM

English

Getting to Know Xsight ........................................3

Home Screen and Everyday Use ...........................9

Settings .............................................................11

PC Setup ............................................................17

The Xsight TOUCH /Xsight COLOUR is the latest fully-featured universal remote control from ONE FOR

ALL. It offers full control of all your infra-red controlled Audio Video devices, as well as high-end features

such as Learning, Profiles and Activity Control. You can set up your remote to control your devices by

following the simple on-screen instructions on the remote, or connect to a PC for adding advanced

features such as Activities and Favorites.

Inside the packaging you will find the following:

• Your “Xsight COLOUR” or “Xsight TOUCH”Universal Remote Control

• Charging Cradle (Xsight TOUCH)

• AC/DC Adaptor for Charging Cradle (Xsight TOUCH)

• Lithium Ion battery (Xsight TOUCH) or3xAABatteries (Xsight COLOUR)

• USB Cable

• CD-ROM with remote software and User Manual

• Quick Start Guide

Firstly, install the battery supplied in the packaging by matching the contacts + and – to the illustrations

in the battery compartment.

Only Xsight TOUCH: The supplied battery comes partially charged, but we recommend charging

the battery for approximately an hour before use.

To do this, connect the charging cradle to a power outlet using the supplied AC/DC Adaptor and place

the remote on the cradle. The display will show the “battery charging icon”. In order to fully charge

the remote, leave it in the cradle for approximately 4 hours.

To begin setting up your Xsight you have two options:

1) Follow the on-screen instructions on the remote while in front of the devices you wish to control.

This is the quickest method to set up the remote for basic control of your devices. For more

advanced setup, you can connect the remote to your PC once it is operating all your devices

correctly.

2) To use PC setup, including Activities (translation), Favorites (translation) etc, insert the CD-ROM into

your PC and follow the install wizard. Connect the remote when prompted by the software using the

included USB Cable.

To start using your remote at any time, simply touch it or press a key and it will respond and the backlight

will illuminate. You can adjust the amount of time the light is on for in the Settings Menu (see page 16).

Xsight features the following types of controls:

• hard keys on the remote’s front that let you control common device features.

• fully-interactive screen (Xsight TOUCH features a Touch Screen) that provides functions for your devices

appropriate to your pattern of use.

WWW.ONEFORALL.COM 3

Getting to Know Xsight

Unpacking and Setting Up

“Xsight TOUCH” or “Xsight COLOUR”

(See also the Xsight Quick Guide)

Using Xsight Keys and Touch screen

Charging Cradle

AC/DC Adaptor

for Charging Cradle

3x AA

Batteries

USB Cable

Lithium Ion battery

CD Rom

Quick Start Guide

4WWW.ONEFORALL.COM

Keys Xsight COLOUR

WWW.ONEFORALL.COM 5

Keys Xsight COLOUR

Power key

Turns device ON/OFF.

Screen keys

3 keys on either side of the screen give you direct access to the functions displayed on the

screen.

Scroll bar

Scrolls pages.

Home key

Shortcut key – One short press goes one back to the previous level in the Menu structure. Hold-

ing down for two seconds takes the remote to the Home screen.

Favorites

Shortcut key – In user mode accesses the Favorites screen directly. Disabled in Setup mode.

Activities

Shortcut key – In user mode accesses the Activities screen directly. Disabled in Setup mode.

Devices

Shortcut key – In user mode accesses the Devices screen directly. Disabled in Setup mode.

Guide key

Brings up device guide if your original remote has guide.

Menu key

Brings up device menu if your original remote has menu. In DVD, it brings up disc menu.

Info

Displays information about your video or audio feed.

Exit

Exit guide and menu.

Channel keys

Operates channel up/down functions in video devices and preset up/down in audio devices.

Volume keys

Controls volume and mute.

Navigation keys

Operates the navigation functions of your device if available.

Teletext keys

Accesses teletext functions if your device has text features.

Transport keys

Operates DVR functions and performs traditional Play/Pause/Fast Forward/Rewind/Record on all

other video and audio devices.

Digit 0-9

Direct digit entry or text entry for customizing labels.

AV key

Selects input function of your device. E.g. TV/SAT, TV/DVD.

Enter/ -/—

Operates channel enter and 10+ digit entry.

Touch screen

Your remote’s customizable touch screens can be set up via the remote or by connecting to your PC. To

use the functions displayed on the screen simply touch the buttons that appear on it. To move between

the pages, brush your thumb along the slider bar to the left or right. Multiple pages will wrap around, so

for example if you scroll right to the last page, scrolling right again will take you back to the first page.

8WWW.ONEFORALL.COM

Initial Setup

When you first power up your remote, it will enter Initial Setup Mode. In this mode, you will;

1) First choose which language you prefer to be displayed on the remote.

2) Next you will be asked to select the region you live in. This will help the remote when setting up

devices during the setup process.

3) Next you will be asked to select whether the remote will display the time in 12 hour or 24 hour

format, and then to set the time.

4) To set the time you can use the digit keys 0-9, or step through the hours and minutes using the Hour

and Min keys displayed on the screen.

5) Once ready, press “Finish”.

After this, a few Tutorial screens will be displayed in order to help you familiarize yourself with the remote.

Once the tutorial is complete, the remote will lead you through the steps to set up all the devices you

wish to control.

1) First, select the device type (e.g. TV) and then select the brand from the list of the top brands

for the selected device in your region.

If a certain device type or brand is not listed, set up all of you other devices, and then use the PC Setup (see page

17) to add that particular device type or brand. If a PC connection is not available, you can also Learn a Device

using the original remote. For Learning, see page 13.

2) Once the brand has been selected, you can then search through the available codes for that

brand by trying keys on the remote. If the keys respond correctly, you can accept the current code

by pressing “Works”, or test the next code by pressing “Next”. When the device has been set up,

you will have the option to set up another device.

TIP: To quickly step through and test multiple codes, alternately press “Power” and “Next”. Once the device

responds to Power, stop and test other keys to confirm the code is correct.

Once you have set up the remote to control your devices, you will be asked if you wish to set a device as

the Master Volume control. This feature is useful if you always change volume using the same device, say

for example an AV Receiver.

Once Initial Setup has taken place, the remote will display the Home Screen.

WWW.ONEFORALL.COM 9

Home Screen and Everyday Use

Favorites

To access the Home Screen at any time, you can hold down the “Home\Back” key for

2 seconds. Pressing this key once will take you back one screen.

The Home Screen of the remote will display the following options:

This key will give you access to your Favorite Channels. Each channel will have a key of its own and be

labeled with the name of the channel. It is also possible to upload your own custom pictures to use on

the key. When pressed, the key will send the necessary commands to select the chosen channel on the

device you use to select channels (for example it may send digit buttons 1, 2 and then 3 to your Cable

box). It is possible to have up to 72 Favorites set up on your remote.

“Favorites” can be set up using PC Setup only.

To access the Favorites Screen at any time, you can press the “Favorites” key underneath the

screen.

This key will give you access to all of your Activities.

An “Activity” is a special mode that your remote control can be set into, where groups of keys can

address different devices to suit what you are doing at the moment. For example, if you create an Activity

called “Watch DVD”, you could set transport keys (Play, Stop etc) to control your DVD Player, but the

Volume Keys to control your Surround Sound Amp.

When you have set up your Activity, it will appear as a key on your touch screen. When this key is pressed,

as well as changing the function of the keys, the remote will send a series of commands to your AV

Devices to make sure they are in the right state for your Activity. For example, it would turn on the TV,

DVD Player and Surround Amp, and then select the correct input on the TV and Amp so the correct

picture and sound are seen and heard. A series of commands such as this is called a Macro, and you can

define this at the end of setting up an Activity.

Activities can be set up using PC Setup only.

To access the“Activities”Screen at any time, you can press the “Activities” key underneath

the screen.

Devices

This key will give you direct access to all the devices that your remote is set up to control. Once pressed,

you will see a list of devices to control (e.g. TV, Sat, Amp etc). Selecting a device will put the remote into

the correct mode to control the device selected. So if you selected TV, the remote will now act just as your

TV’s remote did.

The screen will also display a selection of keys appropriate to the current device.

Devices can be set up using the remote only (via Device Setup or Learning), or using PC Setup.

To access the Devices Screen at any time, you can press the “Devices” key underneath the

screen.

Activities

10 WWW.ONEFORALL.COM

Home Screen and Everyday Use

Proﬁles

A“Profile” is a collection of Favorites that could be grouped by User (e.g. Mom, Dad, Kids etc) or Genre

(e.g. Movies, News, Sport etc). Once the initial group of Favorites (up to 70) has been set up, you can then

choose sub-sets of Favorites to be Profiles.

Profiles can be set up using PC Setup only.

To access Profiles at any time, you can press the “Favorites” key underneath the screen and you

will then be able to choose between All or individual Profiles.

Settings

The “Settings” key will take you to a menu allowing you to change options on the remote, as well as

adding or deleting devices, and learning commands from your original remote control(s). See the next

section for more details.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels One Forall Télécommande

One Forall

One Forall URC-10820 Manuel utilisateur

One Forall

One Forall URC-3435 Manuel utilisateur

One Forall

One Forall URC 1921 Manuel utilisateur

One Forall

One Forall ONE FOR ALL URC3110 Manuel utilisateur

One Forall

One Forall URC-6410 Manuel utilisateur

One Forall

One Forall SAMSUNG URC-4910 Manuel utilisateur

One Forall

One Forall KAMELEON 6 Manuel utilisateur

One Forall

One Forall URC-1669 Manuel utilisateur

One Forall

One Forall URC1913-2 Manuel utilisateur

One Forall

One Forall URC-7140 Manuel utilisateur

One Forall

One Forall URC1280 Manuel utilisateur

One Forall

One Forall URC 7115 Manuel utilisateur

One Forall

One Forall URC 7120 Manuel utilisateur

One Forall

One Forall SMART STREAMER URC 7945 Manuel utilisateur

One Forall

One Forall URC7125 Manuel utilisateur

One Forall

One Forall DVD Expert Manuel utilisateur

One Forall

One Forall URC1030 Manuel de la liste des pièces

One Forall

One Forall URC-1030 Manuel utilisateur

One Forall

One Forall URC-8550 Manuel utilisateur

One Forall

One Forall Essence 4 Manuel utilisateur

One Forall

One Forall Contour TV URC1210 Manuel utilisateur

One Forall

One Forall URC 1910 Manuel utilisateur

One Forall

One Forall URC-4220 Manuel utilisateur

One Forall

One Forall URC 1913 Manuel utilisateur

Manuels Télécommande populaires d'autres marques

Panasonic

Panasonic EUR7622KB0 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation
