Programmable Terminal NA-series

Practices Guide

Page Editing – Broken-line Graph

NA5-15□101□

NA5-12□101□

NA5-9□001□

NA5-7□001□

V424-E1-01

■Introduction

This guide provides reference information on editing pages of the NA. It does not provide safety

information.

Be sure to obtain the NA-series Programmable Terminal User's Manuals, read and understand the safety

points and other information required for use, and test sufficiently before actually using the equipment.

transmitted, in any form, or by any means, mechanical, electronic, photocopying, recording, or

otherwise, without the prior written permission of OMRON.

(2) No patent liability is assumed with respect to the use of the information contained herein. Moreover,

because OMRON is constantly striving to improve its high-quality products, the information contained

in this manual is subject to change without notice. Every precaution has been taken in the preparation

of this manual. Nevertheless, OMRON assumes no responsibility for errors or omissions. Neither is

any liability assumed for damages resulting from the use of the information contained in this

publication.

(3) Trademarks

• Sysmac and SYSMAC are trademarks or registered trademarks of OMRON Corporation in Japan

and other countries for OMRON factory automation products.

• Windows, Visual Basic, and Excel are either registered trademarks or trademarks of Microsoft

Corporation in the United States, Japan, and other countries.

• Other company names and product names in this document are the trademarks or registered

trademarks of their respective companies.

• Microsoft product screen shots reprinted with permission from Microsoft Corporation.

• The product pictures and drawings contained in this document are the graphical images, which may

be different from the actual articles.

Terms and Conditions Agreement

Warranty, Limitations of Liability

Warranties

Exclusive Warranty

Omron’s exclusive warranty is that the Products will be free from defects in materials and

workmanship for a period of twelve months from the date of sale by Omron (or such other period

expressed in writing by Omron). Omron disclaims all other warranties, express or implied.

Limitations

OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED,

ABOUT NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR

PURPOSE OF THE PRODUCTS. BUYER ACKNOWLEDGES THAT IT ALONE HAS

DETERMINED THAT THE PRODUCTS WILL SUITABLY MEET THE REQUIREMENTS OF

THEIR INTENDED USE.

Omron further disclaims all warranties and responsibility of any type for claims or expenses

based on infringement by the Products or otherwise of any intellectual property right.

Buyer Remedy

Omron’s sole obligation hereunder shall be, at Omron’s election, to (i) replace (in the form

originally shipped with Buyer responsible for labor charges for removal or replacement

thereof) the non-complying Product, (ii) repair the non-complying Product, or (iii) repay or

credit Buyer an amount equal to the purchase price of the non-complying Product; provided

that in no event shall Omron be responsible for warranty, repair, indemnity or any other

claims or expenses regarding the Products unless Omron’s analysis confirms that the

Products were properly handled, stored, installed and maintained and not subject to

contamination, abuse, misuse or inappropriate modification. Return of any Products by

Buyer must be approved in writing by Omron before shipment. Omron Companies shall not

be liable for the suitability or unsuitability or the results from the use of Products in

combination with any electrical or electronic components, circuits, system assemblies or any

other materials or substances or environments. Any advice, recommendations or

information given orally or in writing, are not to be construed as an amendment or addition to

the above warranty.

See http://www.omron.com/global/ or contact your Omron representative for published

information.

Limitation on Liability; Etc

OMRON COMPANIES SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL,

OR CONSEQUENTIAL DAMAGES, LOSS OF PROFITS OR PRODUCTION OR

COMMERCIAL LOSS IN ANY WAY CONNECTED WITH THE PRODUCTS, WHETHER

SUCH CLAIM IS BASED IN CONTRACT, WARRANTY, NEGLIGENCE OR STRICT

LIABILITY.

Further, in no event shall liability of Omron Companies exceed the individual price of the

Product on which liability is asserted.

Terms and Conditions Agreement

Application Considerations

Suitability of Use

Omron Companies shall not be responsible for conformity with any standards, codes or

regulations which apply to the combination of the Product in the Buyer’s application or use

of the Product. At Buyer’s request, Omron will provide applicable third party certification

documents identifying ratings and limitations of use which apply to the Product. This

information by itself is not sufficient for a complete determination of the suitability of the

Product in combination with the end product, machine, system, or other application or use.

Buyer shall be solely responsible for determining appropriateness of the particular Product

with respect to Buyer’s application, product or system. Buyer shall take application

responsibility in all cases.

NEVER USE THE PRODUCT FOR AN APPLICATION INVOLVING SERIOUS RISK TO

LIFE OR PROPERTY WITHOUT ENSURING THAT THE SYSTEM AS A WHOLE HAS

BEEN DESIGNED TO ADDRESS THE RISKS, AND THAT THE OMRON PRODUCT(S) IS

PROPERLY RATED AND INSTALLED FOR THE INTENDED USE WITHIN THE OVERALL

EQUIPMENT OR SYSTEM.

Programmable Products

Omron Companies shall not be responsible for the user’s programming of a programmable

Product, or any consequence thereof.

Disclaimers

Performance Data

Data presented in Omron Company websites, catalogs and other materials is provided as a

guide for the user in determining suitability and does not constitute a warranty. It may

represent the result of Omron’s test conditions, and the user must correlate it to actual

application requirements. Actual performance is subject to the Omron’s Warranty and

Limitations of Liability.

Change in Specifications

Product specifications and accessories may be changed at any time based on

improvements and other reasons. It is our practice to change part numbers when published

ratings or features are changed, or when significant construction changes are made.

However, some specifications of the Product may be changed without any notice. When in

doubt, special part numbers may be assigned to fix or establish key specifications for your

application. Please consult with your Omron’s representative at any time to confirm actual

specifications of purchased Product.

Errors and Omissions

Information presented by Omron Companies has been checked and is believed to be

accurate; however, no responsibility is assumed for clerical, typographical or proofreading

errors or omissions.

Terms and Conditions Agreement

Contents

Terms and Conditions Agreement........................................................................3

Warranty, Limitations of Liability .............................................................................................3

Application Considerations .....................................................................................................4

Disclaimers .............................................................................................................................4

１Broken-line Graphs........................................................................................7

１-１Broken-line Graph Basic Settings ............................................................................7

Revision History ...................................................................................................13

Related Manuals

The following manuals are related to this manual.

Cat.No. Model Manual Name

W504 SYSMAC-SE2□□□ Sysmac Studio Version 1 Operation Manual

V117 NA5-15W□□□□

NA5-12W□□□□

NA5-9W□□□□

NA5-7W□□□□

NA-series Programmable Terminal Hardware User’s

Manual

V118 NA5-15W□□□□

NA5-12W□□□□

NA5-9W□□□□

NA5-7W□□□□

NA-series Programmable Terminal Software User’s

Manual

V119 NA5-15W□□□□

NA5-12W□□□□

NA5-9W□□□□

NA5-7W□□□□

NA-series Programmable Terminal Device Connection

User’s Manual

V120 NA5-15W□□□□

NA5-12W□□□□

NA5-9W□□□□

NA5-7W□□□□

NA-series Programmable Terminal Startup Guide

１ Broken-line Graphs

１-１ Broken-line Graph Basic Settings

The Broken-line Graph objects display the graphs of the current value of array variables or multiple

variables of the same data type.

Beware that a Broken-line Graph object does not operate in the simulation function of Sysmac Studio.

You must transfer data to the NA unit and operate the actual unit to confirm operations.

１-１-１ Registering Data Group

The variables that are to be displayed in a Broken-line Graph should be registered in Data

Groups. This function is equivalent to the “Broken-line Graph Group Setting” of the NS

series.

1. In the Multiview Explorer, right-click

[HMI]-[Data Groups], and click

[Add]-[Data Group].

2. Double-click the added

[DataGroup0].

3. Create the data to be displayed as a

graph.

Right-click on the edit pane and

click “Add”, or click the [+] button.

4. Enter an arbitrary name in [Data

Series]. The name is used in the

Properties of the Broken-line Graph

object to be described later.

Under [Type], choose the type of

variables to be used in a graph from

either “Variable” or “Array”. If you

use multiple variables as a group,

choose “Variable”. To display the

data of the array variable as a

graph, select “Array”.

In [Data Type], specify the data type

of the variables to be used in the

graph. Make sure to unify the data

type of the variables that are to be

used in a single data series.

5. You can have different types of data

series such as “Variable” and

“Array” within a data group.

6. Following is the explanation of the

settings in cases where “Variable” is

specified as the graph type. To add

the variables to be displayed in the

graph, right-click and select “Add”,

or click the [+] button.

7. Enter as many variable names in

[Variable] as the points to be

displayed on a line. Make sure to

[Global Variables].

8. Following is the explanation of the

settings in cases where “Array” is

specified as the graph type. Set an

array variable to be used in the

graph. Make sure to register in

advance the variable in [Global

Variables]. You can use

one-dimensional or two-dimensional

arrays.

9. If the data type of the array variable

is Structure, specify in [Target

Member] the name of the member

targeted for display.

In the example shown on the right,

the following names appear in the

graph:

BrokenLineB3(0).Array1,

BrokenLineB3(1).Array1,

BrokenLineB3(2).Array1,

・・・

１-１-２ Setting the Properties of a Broken-line Graph Object

Perform settings for displaying as a graph the data group specified in the previous

subsection.

1. From [Toolbox], select [HMI

Controls]-[Broken-line Graph]

and drag and drop it to the page.

2. In [DataGroup] under [Data] in

the Properties, enter the name of

the data group created in the

previous subsection.

3. When you click the [+] of the

[Traces] cell, the setting fields

appear under [0]. Register in

[DataSeries] the name of the data

series to be displayed in the

graph.

4. Repeat Step 3 the number of

times of the data (i.e. the number

of lines) to be displayed in the

graph.

5. Specify the timing for the graph to

be updated. You can select from

among two options: to update at a

constant interval, or to update

when a variable condition is met.

If you select “Interval” in

[DisplayUpdateType] under

[Behavior] in the Properties, the

graph display is updated at the

interval specified in [UpdateRate]

(unit: msec.).

6. If you select “Condition” under

[DisplayUpdateType] under

[Behavior] in the Properties, the

graph display is updated when

the condition specified in

[Expression] is met. In the

example shown on the right, the

display is updated when

UpdateFlag is turned ON.

7. Edit the vertical axis of the graph

as below:

1. Specify whether to display the

axis, major grid lines, and minor

grid lines.

2. Specify the maximum and

minimum values of the axis.

3. Specify the number of decimal

places of the axis values and the

number of ticks of the axis.

The figure on the right shows the

fields for the left axis. There are

the same fields for the right axis.

8. Edit the horizontal axis of the

graph as below:

1. Specify whether to display the

values and grid lines.

2. Specify the maximum and

minimum values of the axis.

3. Specify how many traces are

to be displayed within a graph.

Autres manuels pour Sysmac NA Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Omron Instrument de mesure

Omron

Omron Z500-SW2T Guide de l'utilisateur

Omron

Omron K3HB-X Manuel utilisateur

Omron

Omron F3UV Series Manuel utilisateur

Omron

Omron OKA-450R Manuel utilisateur

Omron

Omron Sti G9SX-LM224-F10 Series Manuel utilisateur

Omron

Omron K6CM series Guide de l'utilisateur

Omron

Omron Sti G9SX-SM032 Series Manuel utilisateur

Omron

Omron E3NC-SH Series Manuel utilisateur

Omron

Omron K3HB-C Series Manuel utilisateur

Omron

Omron K6CM series Manuel utilisateur

Omron

Omron 11 685 Manuel utilisateur

Omron

Omron KM50 Manuel d'utilisation et d'entretien

Omron

Omron K35-2 Manuel utilisateur

Omron

Omron K3MA-J Series Manuel utilisateur

Omron

Omron H7CX-R11-N Manuel utilisateur

Omron

Omron ZN-DPX21-S Series Manuel utilisateur

Omron

Omron Sti G9SX-SM032 Series Manuel utilisateur

Omron

Omron ZN-KMX21 Series Manuel utilisateur

Omron

Omron K3NC Manuel utilisateur

Omron

Omron K3NR Manuel utilisateur

Omron

Omron H7CC-A Series Manuel utilisateur

Omron

Omron K3NH Manuel utilisateur

Omron

Omron SYSMAC Series Manuel d'utilisation et d'entretien

Omron

Omron EQUO Series Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
