VISERA UHD 4K Camera System Quick Reference Guide

Disclaimer: Information provided in this guide is not exhaustive. Please refer to the complete Instructions For Use for each

item of equipment which should be thoroughlyread and understoodprior to handling, use and storage of the equipment.

Light SourceCamera HeadSwitch On

Switch on the camera system using the workstation master

switch which will then turn from white to green.

There is a secondary power switch on the transformer

under the workstation. This should remain switched on.

Insert the camera head into the camera processor,

ensuring the connector is the correct way up.

The colour bars on the monitor will now be replaced with

an image from the camera head.

Optical connecting part

UP mark

Video connector

Electrical contacts

Video connector socket

Video connector

UP mark

If required, place the lamp onto standby by pressing and

holding the lamp button.

Press the brightness mode button to select Auto.

Warning: When turning ON the light source, never allow

the distal end of an endoscope or a light guide cable to

come in contact with the patient and/or other ﬂammable

materials, such as operating room drapes. Patient injury

and/or a ﬁre can result.

Connect the light guide cable to the output.

Output socket

Brightness mode

indicators

Brightness mode

button

Lamp indicators

Lamp button

Emergency

lamp

Control panel

Issue 1

05/02/2021

KMF-08930

NCDR 02868

VISERA UHD 4K Camera System Quick Reference Guide

Disclaimer: Information provided in this guide is not exhaustive. Please refer to the complete Instructions For Use for each

item of equipment which should be thoroughlyread and understoodprior to handling, use and storage of the equipment.

High Intensity ModeWhite BalancingCamera Head

Attach the camera head to the telescope by rotating

the endoscope mount as below.

Releasing the camera head mount secures the telescope

in place.

Rotate

Endoscope

lock ring

Eyepiece Endoscope mount

Once the camera head, telescope and light guide cable

are connected, a white balance must be performed.

Perform a white balance by surrounding the tip of the

telescope in a white swab, ensuring it is fully enclosed.

Press and hold the white balance button on the

processor until ‘White Balance Complete’ appears

on the monitor.

The white balance status changes to completed.

White balance window

Warning: Do not use the high intensity mode when

connecting to an endoscope that has an insertion tube

outer diameter of 4.1 mm or less. The endoscope

becomes hot while the lamp is lit up and could

cause operator burn.

Caution: Do not touch the endoscope’s distal end and

light guide connector while the examination lamp is lit up.

The endoscope becomes hot while the examination lamp

is lit up and could cause operator burn.

Brighter examination light is available when connecting an

endoscope that has an insertion tube outer diameter of

4.1 mm or greater and a compatible Olympus light guide

cable by pressing the intensity mode button.

High intensity mode

indicator

Intensity mode button

Issue 1

05/02/2021

KMF-08930

NCDR 02868

VISERA UHD 4K Camera System Quick Reference Guide

Disclaimer: Information provided in this guide is not exhaustive. Please refer to the complete Instructions For Use for each

item of equipment which should be thoroughlyread and understoodprior to handling, use and storage of the equipment.

Title 1 Title 2 Title 3

VISERA UHD 4K Camera System Quick Reference Guide

Disclaimer: Information provided in this guide is not exhaustive. Please refer to the complete Instructions For Use for each

item of equipment which should be thoroughlyread and understoodprior to handling, use and storage of the equipment.

Camera Head Camera Head Troubleshooting

Adjust the image focus using the one touch auto focus

switch on the camera head. For an optimal auto focus:

Ensure telescope lens is clean from debris or liquid.

Hold the telescope stationary for three seconds after

pressing the one touch auto focus switch.

The image will focus on objects in the central 5% area of

the monitor.

No power

• Ensure everything is powered on.

• Check the isolation switch on the transformer is

turned on.

No image

• Ensure everything is switched on including the

monitor which can be switched off by accident.

• Ensure monitor input is set to (SDI 1) by using the

monitor input buttons.

• Unplug camera head, colour bars should appear. If no

colours appear, contact Olympus Service Helpdesk.

Dark image

• Check condition of telescope.

• Check condition of light lead.

High Intensity Mode Doesn’t light up

• Check a compatible Olympus light lead is being used.

Main examination lamp doesn’t come on

• Check the lamp meter on the light source has

not exceeded 500 hours and seek replacement

if necessary.

For telescopes of diameter 2.7 mm the auto focus may

not work. In this instance use the manual focus ring.

The three programmable buttons are assigned as follows:

1. Insert action 1

2. Insert action 2

3. Insert action 3

Press info and then scope information

Focus ring

One touch auto

focus switch

Info Dialog

Scope information

No. Nomenclature Description

1 User preset name Displays the user preset name

2 Scope model Displays the model name of the camera head

3 Serial number Displays the serial number of the camera head

4 Remote switch 1 Displays the function assigned to the remote switch 1

5 Remote switch 2 Displays the function assigned to the remote switch 2

6 Remote switch 3 Displays the function assigned to the remote switch 3

Issue 1

05/02/2021

KMF-08930

NCDR 02868

eyMed House, Stock Road, Southend-on-Sea, Essex, SS2 5QH, UK

Olympus Medical UKIE Olympus Medical Europe @OlympusMedUKIE

KeyMed House, Stock Road, Southend-on-Sea, Essex, SS2 5QH, UK

Olympus Medical UKIE Olympus Medical Europe

@OlympusMedUKIE

For further information, please contact

Olympus Customer Services on 01702 616 333

or visit www.olympus.co.uk
