TT-455 OPERATION MANUAL

the knowledge is in our hands

LAST PAGE

RETURN TO MENU

TWINTEC 455

TT 455 OPERATION - INFORMATION INDEX

1. Part Identification Diagram

2. Basic Operation Instructions

3. Dos and Donts

4. Fitting The Brush / Dri e Board

5. Filling The Clean Water Tank

6. Water Release Controls

7. Adjusting The Handle Height

8. Handle Controls

9. Emptying The Top Tank

10. Emptying The Bottom Tank

11. Cleaning The Separator Filter

12. Cleaning The Top Tank Filter

13. Cleaning The Bottom Tank Filter

14. Daily Maintenance Routine

15. Changing The Squeegee Blades

16. Problem Sol ing

TWINTEC 455

TT 455 OPERATION - PART IDENTIFICATION

HANDLE TOP (DIRTY

WATER) TANK

BOTTOM (CLEAN

WATER) TANK

SEPARATOR

SQUEEGEE TOOL

BRUSH

CHASSIS

TWINTEC 455

TT 455 OPERATION - OPERATING INSTRUCTIONS

1. Ensure that power lead is plugged into appropriate mains scoket

2. Ensure that the red power indicator light is illuminated

3. Fit pad & drive board / scrubbing brush

4. Unclip deck so that the pad / brush is positioned flat to the floor

5. Lower the squeegee blade so that it is positioned flat to the floor

6. Fill bottom tank with clean water and detergent

7. Ensure that water on/off control is set at appropriate position

8. Ensure that top tank(s) are empt

9. Ensure that separator is fitted correctl

10. Adjust handle height to suit

11. Stand behind the machine

12. Press both of the green switches on the front of the handle

13. Press and hold in the ellow button on the rear of the handle and at the same

time squeeze the triggers on the handle. Release the ellow button

14. Push the machine in the direction in which ou want to clean, holding in the black

triggers

15. When ou want the machine to stop, release triggers

TWINTEC 455

TT 455 OPERATION - DOS AND DONTS

DO ensure onl competent persons unpack and assemble the machine

DO keep the machine clean

DO keep the brushes in good condition

DO replace an worn or damaged parts immediatel

DO ensure that the working area is clear of obstructions

DO ensure that the working are is well illuminated

DO follow all the instructions supplied

DO ensure that if using a pad, it is washed after each use

DONT use steam cleaners or pressure washers to clean the machine

DONT use the machine outdoors in the rain

DONT attempt machine maintenance or cleaning with the isolator pin intact

DONT allow an inexperienced repairs

DONT leave the brush or pad on the machine when not in use

DONT allow the machine to be used b inexperienced or unauthorised personnel

DONT lift or pull the machine b an of the operating triggers

DONT leave the machine running in one spot, turn off if not being used

DONT leave the brush or pad on the machine overnight, the will flatten

WARNING

It is essential that the equipment is correctl assembled and operated in accord

ance with current safet regulations. When using the equipment alwa s ensure

that all necessar precautions are taken to guarantee the safet of the operator

and an other persons who ma be affected. Wear non-slip footwear when

scrubbing. Alwa s use a respirator mask in dust environments. The use of

other accessories ma affect the safet of the scrubber dr er. A full range of

brushes and other accessories are available from Numatic International.

TWINTEC 455

TT 455 OPERATION - FITTING THE BRUSH / DRIVE BOARD

1. MACHINE SHOWN WITH

SCRUB RING AND BRUSH.

2. POSITION BRUSH ONTO

THE GEARBOX WITH THE 3

INDENTATIONS ALLIGNING

WITH THE 3 TABS. TURN

ANTI-CLOCKWISE TO LOCK

THE BRUSH IN PLACE.

3. THE BRUSH WILL NOW

BE LOCKED IN PLACE AND

READY FOR USE.

NOTE: WHEN USING A DRIVE BOARD FOLLOW THE SAME INSTRUCTIONS

TO FIT DRIVE BOARD AND THEN FIX PAD CENTRALLY ONTO BOARD.

TWINTEC 455

TT 455 OPERATION - FILLING THE CLEAN WATER TANK

1. SIMPLY POUR WATER

WITH A MIX OF YOUR CHO-

SEN DETERGENT INTO THE

SPOUT ON THE FRONT OF THE

BOTTOM TANK.

TWINTEC 455

TT 455 OPERATION - WATER RELEASE CONTROLS

1.THE WATER CONTROL IS

LOCATED AT THE REAR OF

THE MACHINE (BOTTOM LH)

2. WITH THE TAP IN ITS

HORIZONTAL POSITION

THERE WILL BE NO WATER

FLOW.

3.IN ORDER TO RELEASE

WATER, PUSH TAP TOWARDS

THE FLOOR.

NOTE:

FULL WATER FLOW IS 2.5

LITRES PER MINUTE. THIS

TAP CAN BE ADJUSTED ANY-

WHERE BETWEEN NO FLOW

AND FULL FLOW TO ACHIEVE

THE DESIRED FLOW FOR THE

TASK BEING UNDERTAKEN.

TWINTEC 455

TT 455 OPERATION - ADJUSTING THE HANDLE HEIGHT

1. SQUEEZE THE HANDLE

ADJUSTMENT LEVER ON

THE RIGHT HAND SIDE.

2. OPERATION IS EASIEST

WITH THE HANDLE AT WAIST

HEIGHT.

3. FOR TURNING IN TIGHT

SPACES OR FOR LESS FLOOR

PRESSURE, PUT THE HANDLE

INTO A HIGHER POSITION.

NOTE:

THE BEST WAY TO SCRUB IS

TO FIND A HANDLE LEVEL AT

WHICH YOU FEEL COMFORT-

ABLE AND CAN EASILY CON-

TROL THE MACHINE AROUND

CORNERS AND OBSTACLES

AS WELL AS IN A STRAIGHT

LINE.

THE HIGHER THE HANDLE

LEVEL, THE LESS FLOOR

PRESSURE AND VICE VERSA.

TWINTEC 455

TT 455 OPERATION - HANDLE CONTROLS

WATER ON / OFF VACUUM ON / OFF

POWER

INDICATOR

OPERATION

LEVERS

RESET BUTTON

HANDLE ADJUST

LEVER
