NovaStar VX4 Manuel utilisateur

User's Manual

LED Video Controller VX4S/VX4

Rev1.1.2 NS160110080

Xi’an NovaStar Tech Co., Ltd.

Statement

You are welcome to use the products from Xi’an NovaStar Tech Co., Ltd. (hereinafter

referred to as Novastar). It is our great pleasure to offer this manual to help you

understand and use the product. We strive for precision and reliability during the

compilation of this manual, and the contents of this manual are subject to change

without notice. If you have any problem in use or you have any suggestion, please

feel free to contact us according to the contact information provided in this manual.

We will do our utmost to satisfy your needs. Also, we would like to express our

sincere thanks to your suggestions and make assessment as soon as possible for

adoption.

No part of this manual may be reproduced or transmitted in any form or by any

means without prior written consent of Xi’an NovaStar Tech Co., Ltd.

Trademark

is a registered trademark of NovaStar Tech Co., Ltd.

Safety Statement

To avoid potential hazards, please use this equipment according to the regulations.

In case of damages, non-professionals should not disassemble it for maintenance

without permission. Please contact the after-sales department of the company.

High voltage danger: The operating voltage of this product is 100-240V

AC.

Grounding: This production is connected to ground via the ground

wire of power supply. Please ensure good grounding of grounding

conductor.

Electromagnetic interference: The device should be kept far away from

magnets, motors and transformers.

Moisture proof: Keep the equipment in a dry and clean environment. In

case of liquid immersion, please pull the plug immediately.

Keep away from flammable and explosive dangerous goods.

Prevent liquids or metal fragments from being immersed into the

machine to avoid safety accidents.

Xi’an NovaStar Tech Co., Ltd.

Contents

1 Model description ��1

2 Appearance��1

Front Panel ............................................................................................................................ 1

Rear Panel.............................................................................................................................. 2

3 Signal connection ��3

4 Dimension��3

5 Operating motion instruction��3

6 Main Interface��4

7 Operation instruction��5

Step1: Input Settings ......................................................................................................... 5

Step2: Screen Settings....................................................................................................... 5

Setp3: Brightness ................................................................................................................ 7

Setp4: Output Settings...................................................................................................... 7

Image Mosaic....................................................................................................................... 8

Advanced Settings.............................................................................................................. 9

Factory Reset......................................................................................................................15

Communication Settings................................................................................................15

Language.............................................................................................................................15

8 Specications��16

9 FAQ ��17

Xi’an NovaStar Tech Co., Ltd.

VX4S/VX4 User's Manual

-1-

1 Model description

Model Description (input interface type)

VX4 DVI×2, VGA×3, CVBS×3, HDMI×1, DP×1

VX4S DVI×1, VGA×2, CVBS×2, HDMI×1, DP×1, SDI×1

Tips: VX4 has different type and number of interface with VX4S, but their functions and

specifications are basically the same. In this manual, VX4 is described as the example.

2 Appearance

Front Panel

OFF

LEDDisplayVideo Controller

MENU CONTROL

ESC

PIP SCALE

MODE TEST

INPUTS FUNCTION

HDMI

DVI1

DVI2

VGA1

VGA2

CVBS3

CVBS2

CVBS1

VGA3

USB

TAKE

① ② ③ ④ ⑤ ⑥ ⑦ ⑧

①:

Power switch�

②:

Operation screen (Please see the section-Main Interface for detail).

③:

Knob� To press knob means Enter or OK, rotating knob represents selection or

adjustment.

④:

ESC� Escape current operation or selection.

⑤:

Four control keyboard shortcuts�

PIP: PIP Turn-on/off. The lighting of this key represents the turn-on of PIP;

otherwise, PIP is turned off.

SCALE: Picture zoom turn-on/turn-off. The lighting of this key represents the turn-

on of zoom function; otherwise, zoom function is unavailable.

MODE: Shortcut menu of loading or storage of display model. The key is light when

entering the model or shortcut menu, in case of exiting, the key is not bright.

TEST: Shortcut of turn-on/off of testing picture. In case of entering testing picture,

the key is bright; otherwise, the key is not bright.

⑥:

Shortcut keys for switching of 10 signal input source. Short press to set as the main

screen input source, and long press to set as PIP input source. The key is bright

after press when the video source has signal; the key flashes when the input of

video source has no signal. The setting result can be checked while setting on the

display screen and OLED screen.

Xi’an NovaStar Tech Co., Ltd.

VX4S/VX4 User's Manual

-2-

⑦:

Function keys�

TAKE: Display switching shortcut key. After short pressing TAKE key, PIP will

be opened; if it has been opened, the switching between MAIN and PIP will be

realized. Fn: Custom shortcut key.

⑧:

Flat mouth (Type A, female USB) is USB interface, which connects U disk;

Square mouth (Type B female USB) is USB controlling interface, communication with

PC.

Rear Panel

Input Source

Audio Audio Input

DP DP Input

HDMI HDMI Input

CVBS1~CVBS3 3-Channel PAL/NTSC TV composite video Inputs

DVI -1~DVI-2 2-Channel DVI Inputs

VGA1~VGA3 3-Channel VGA Inputs

Output Interface

DVI LOOP DVI LOOP Output

Monitor -VGA OUT VGA Monitoring Interface

Monitor -DVI OUT DVI Monitoring Interface

LED Out 1、2、3、4 4-Channel LED Outputs

Controlling Interface

ETHERNET Network Control (Communication with PC, or Access

Network)

Type B, female USB USB Control (Communication with PC, or Cascade IN)

Type A, female USB USB Cascade OUT

Power

AC 100-240V ～ 50/60HZ AC Power Interface

Tips:The two USB interfaces ( typeA) on front panel and rear panel are both forbidden to

connect with PC directly.

Xi’an NovaStar Tech Co., Ltd.

VX4S/VX4 User's Manual

-3-

3 Signal connection

Connect the required hardware equipment reference with the interface descriptions

of the previous chapters.

If it is required to control more than one set of VX4, please connect them according

to the following figure.

4 Dimension

2.5

482.6

440

251.5

VX4 's dimension (Unit:mm)

5 Operating motion instruction

Xi’an NovaStar Tech Co., Ltd.

VX4S/VX4 User's Manual

-4-

Knob:

Press the knob under the main interface to enter the operation interface menu;

Rotate the knob to select menu or press the knob under the operation interface

of menu to select current menu or enter submenu;

Rotate the knob to adjust the parameter after selecting the menu with

parameter; press the knob again for confirmation after adjustment.

ESC: Return key, exit current menu or operation.

Key lock/unlock: long press knob and ESC key simultaneously.

6 Main Interface

After starting the controller, the main interface of OLED display is as follows:

1VGA1

2HDMI

1024x768@60Hz

NovaStar 192�168�0�10

25%

First row: Company name; the name and IP of the product are shown alternately;

Second row: Main screen 1; signal source; input source signal format;

Third row: PIP 2; signal source; input source signal format;

Forth row: Status bar. the meanings of all icons are shown below.

LED Output (it is output Port 2 in primary mode currently, and

the backup status is displayed as )

PIP is turned off

PIP is turned on

The current effect is point-to-point display

It is “scale down” mode

It is “scale up” mode

Image Mosaic is not enabled;

Image Mosaic is enabled;

It is USB control currently

It is network port control currently

The current brightness is 25%

Sign of press key lock. When this icon appears at the main

interface, it is in locking state for key and knob functions.

Xi’an NovaStar Tech Co., Ltd.

VX4S/VX4 User's Manual

-5-

7 Operation instruction

The functions of VX4 are powerful with very simple operation, and multiple

operations can be completed with a knob and a return key. The design of more than

one shortcut keys makes operations more efficient.

Generally, the LED display can be used normally, and the brightness is moderate after

conducting the following four steps: Input settings → Screen settings → Brightness →

Output settings. Other menus such as screen control and senior setting can help users

better control LED display.

See the following section for details of operations.

Step1: Input Settings

Set resolution of input source signal. Resolution can be directly set and changed

for digital input interfaces DVI, HDMI and DP. Resolution can only be modified with

other input methods on input devices.

Input resolution can be set in two methods:

Method one: Preset Resolution.

Selection is made in preset resolution of the controller. If there is no preset

resolution, you can select the second method and customize resolution.

Brightness

Output Settings

25%

Screen Settings

Input Settings

1024x768

1280x1024

1366x768

1440x900

Preset Resolution

Custom Resolution

Method two: Custom Resolution.

Set Horizontal Res, Vertical Res and Custom· refresh rate and then select "Apply" and

press the knob for application. If the application is not confirmed, custom resolution

is invalid.

Width (H)

Height(V)

Custom Refresh Rate

Apply

1920

1080

60Hz

59.94Hz

50Hz

30Hz

Preset Resolution

Custom Resolution

Step2: Screen Settings

The precondition of Screen setting in shortcut is that the screen must be regular

rectangle (not special-shaped), cabinet must be regular rectangle and the size of

each cabinet are identical.

Step 1 The screen being power-on, if the cabinet is in normal display, enter into

Step 2; if the cabinet is in abnormal display, first, load the cabinet file, and

save it to the receiving card; see detailed operation in Advanced Settings ;

Xi’an NovaStar Tech Co., Ltd.

VX4S/VX4 User's Manual

-6-

Step 2 Return to the “Screen Settings” submenu. Rotate the button to switch to

submenus of other options respectively to perform configurations, as shown

in the following figures:

Brightness

25%

Input Settings

Cabinet Row Qty

Cabinet Column Qty

Port 1 Cabinet Qty

Data Flow（Front View）

Screen Settings

Output Settings

Step 3 Set Cabinet Row Qty and Cabinet Column Qty according to the actual

situation of the screen;

Step 4 Set Port1 Cabinet Qty. The device has some limitations on the cabinet

quantity of ports. For details, see precautions for screen settings;

Step 5 Set the Data Flow (Front View). Pay attention to precautions for screen

settings c), d) and e) below.

Precautions for screen settings:

（a）If the number of ports

with loads is n (n≤4), the first

n-1 ports must load the same

number of cabinets, which must

also be an integral multiple of

the number of cabinet rows or

columns and be greater than or

equal to the number of cabinets

for the nth ports.

Example:

For example, if port 1, port 2, port 3 have loads,

port 1 and port 2 must have the same number of

cabinets, which must also be an integral multiple

of the number of cabinet rows or columns.

Therefore, you only need to set port 1 cabinet Qty

according to the actual situation when setting the

screen. The number of receiving cards port 3 loads

must be smaller than or equal to port 1.

（b）In the case of special-shaped cabinets, different cabinet sizes and special-

shaped screen, the NovaLCT-Mars software is required to be connected to configure

the screen.

（c）During Data Flow setting, you can rotate the button to see the effects of

different data flow on the screen in real time. If you are satisfied with the effect of

current data flow, you must press the button to save the setting. You can press the ESC

to exit from the current operation.

（d）During Data Flow setting, you must ensure that the data flow of each port is

downward in the same direction.

（e）During Data Flow setting, you must ensure that Port 1 is the start position of

the whole data flow connection.

VX4 can load 2.3 million (2048x1152@60Hz) pixels in maximum. The width of lateral

load can reach to 3840 pixels in maximum (3840x600@60Hz); the longitudinal load

can reach to 1920 pixels in maximum (1920 x1200@60Hz).

Xi’an NovaStar Tech Co., Ltd.

VX4S/VX4 User's Manual

-7-

Setp3: Brightness

Return to the main menu interface. Press the Knob to select the corresponding value

of Brightness. You can rotate the Knob to adjust the value at this time.

Brightness

Screen Settings

Input Settings

Output Settings

25%

Brightness

Screen Settings

Input Settings

Output Settings

25%

Setp4: Output Settings

Output settings are divided into three cases:

First one: disable Scaling, i.e., the sizes of output image and input image are the

same, and original scale output is used. If the input resolution is smaller than the LED

display in one direction, LED display may not become bright in this direction; if the

input resolution is greater than the LED display in one direction, the input contents

may not be displayed completely in this direction. This option is applicable to the

application scenarios requiring point-to-point display. Horizontal offset and vertical

offset of images can be set according to the needs, and at this time the displayed

contents may move to the left or top at the LED display.

At this point [Scaling] is disabled.

Second one: Auto Fit� At this point [Scaling] is enabled, and [Auto Fit] is enabled.

When enabling [Auto Fit], the input contents will be fully zoomed to the size of LED

display, and the input contents will be adaptive to the size of LED display. This mode

is suitable for full-screen playback of the contents.

Xi’an NovaStar Tech Co., Ltd.

Autres manuels pour VX4

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels NovaStar Contrôleurs

NovaStar

NovaStar MCTRL660 PRO Manuel utilisateur

NovaStar

NovaStar NovaPro HD Manuel utilisateur

NovaStar

NovaStar VX1000 Manuel utilisateur

NovaStar

NovaStar NovaPro UHD Jr Manuel utilisateur

NovaStar

NovaStar VX400 Manuel utilisateur

NovaStar

NovaStar C1 Manuel utilisateur

NovaStar

NovaStar MCTRL R5 Manuel utilisateur

NovaStar

NovaStar MCTRL4K Manuel utilisateur

NovaStar

NovaStar NovaPro UHD Manuel utilisateur

NovaStar

NovaStar MCTRL R5 Manuel utilisateur

NovaStar

NovaStar VX600 Manuel utilisateur

NovaStar

NovaStar MCTRL300 Manuel utilisateur

NovaStar

NovaStar VX6s Manuel utilisateur

NovaStar

NovaStar CX40 Pro Manuel utilisateur

NovaStar

NovaStar MX40 Pro Manuel utilisateur

NovaStar

NovaStar NovaPro UHD Manuel utilisateur

NovaStar

NovaStar MBOX600 Manuel utilisateur

NovaStar

NovaStar NovaPro UHD Manuel utilisateur

NovaStar

NovaStar MCTRL 4K Manuel utilisateur

NovaStar

NovaStar MX Series Manuel utilisateur

NovaStar

NovaStar MX40 Pro Manuel utilisateur

NovaStar

NovaStar VX16s Manuel utilisateur

NovaStar

NovaStar VX4 Manuel utilisateur

NovaStar

NovaStar MCTRL660 PRO Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
