Norac Rogator 700 Series Manuel utilisateur







Rogator700Series

UC7BoomHeightControlSystem

InstallationManual



PrintedinCanada

ReorderP/N:UC7‐BC‐RG13‐INSTRevD(Rogator700Series)



NOTICE:NORACSystemsInternationalInc.reservestherighttoimproveproductsandtheirspecificationswithoutnoticeandwithouttherequirementtoupdate

productssoldpreviously.Everyefforthasbeenmadetoensuretheaccuracyoftheinformationcontainedinthismanual.Thetechnicalinformationinthismanual

wasreviewedatthetimeofapprovalforpublication.



WWW.NORAC.CA

PRECISIONDEFINED



Contents



Introduction..........................................................................................................................1



TechnicalSpecifications........................................................................................................2



PartsOverview......................................................................................................................3



Pre‐InstallationChecklist.......................................................................................................7



HydraulicInstallation.............................................................................................................8



UltrasonicSensorInstallation..............................................................................................12



ElectronicInstallation..........................................................................................................19



SoftwareSetup....................................................................................................................24



CableSchematics.................................................................................................................25





WWW.NORAC.CA

PRECISIONDEFINED





Page1

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

1Introduction

CongratulationsonyourpurchaseoftheNORACBoomHeightControlSystem.Thissystemismanufactured

withtopqualitycomponentsandisengineeredusingthelatesttechnologytoprovideoperatingreliability

unmatchedforyearstocome.

Whenproperlyusedthesystemcanprovideprotectionfromsprayerboomdamage,improvesprayerefficiency,

andensurechemicalsareappliedcorrectly.

Pleasetakethetimetoreadthismanualcompletelybeforeattemptingtoinstallthesystem.Athorough

understandingofthismanualwillensurethatyoureceivethemaximumbenefitfromthesystem.

Yourinputcanhelpmakeusbetter!Ifyoufindissuesorhavesuggestionsregardingthepartslistorthe

installationprocedure,pleasedon’thesitatetocontactus.



Everyefforthasbeenmadetoensuretheaccuracyoftheinformationcontainedinthismanual.Allparts

suppliedareselectedtospeciallyfitthesprayertofacilitateacompleteinstallation.However,NORACcannot

guaranteeallpartsfitasintendedduetothevariationsofthesprayerbythemanufacturer.

Pleasereadthismanualinitsentiretybeforeattemptinginstallation.

WWW.NORAC.CA

PRECISIONDEFINED





Page2

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

2TechnicalSpecifications

 

CANICES‐3(A)/NMB‐3(A)



ThisClassAdigitalapparatuscomplieswithCanadianICES‐003.

PursuanttoEMCDirective–Article9,thisproductisnotintendedforresidentialuse.

Table1:SystemSpecifications

SupplyVoltage(rated) 12VDC

SupplyCurrent(rated) 10A

HydraulicPressure(maximum) 3300psi

BaudRate 250kbps

OperatingTemperatureRange 0°Cto80°C



Donotusehighspeedpowertools/drillswheninstallinghardware.



TheuseofdielectricgreaseisnotrecommendedonanyNORACelectricalconnections.



ToensureallstainlesssteelhardwaredoesnotgallorseizeapplyalightcoatingofthesuppliedPermatex

Anti‐seizegreasetoallthreadedpartsuponinstallation.PermatexAnti‐seizelubricantispreferred,butother

similaranti‐seizeproductsmaybeused.

WWW.NORAC.CA

PRECISIONDEFINED





Page3

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

3PartsOverview

3.1. ElectronicInstallationOverview



Figure1:ElectronicInstallationOverview



WWW.NORAC.CA

PRECISIONDEFINED





Page4

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

3.2. HydraulicPlumbingSchematic



Figure2:HydraulicPlumbingSchematic



WWW.NORAC.CA

PRECISIONDEFINED





Page5

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

3.3. ListofParts

ItemPartNumberNameQuantity

B0544706‐01KITCABLETIEBLACK10PCS21IN150PCS7.5IN1

B1744972SENSORMOUNTINGBRACKETLOWPROFILERAINFLAP16GA2

B2044971SENSORMOUNTINGBRACKETLOWPROFILE16GA2

B2144973‐02SENSORMOUNTINGBRACKETLOWPROFILE16GALARGEFLANGETALLCLAMP1

C0143220‐0.5CABLENETWORK14AWG0.5M3

C0243220‐03CABLENETWORK14AWG3M2

C0543210‐15CABLENETWORK18AWG15M2

C1050130‐01CABLEVALVE4‐PINDTTO2‐PINDT2

C1150120‐01CABLETEMPERATUREPROBE1

C1250130‐09CABLEVALVE4‐PINDTTO2‐PINDT(96"[2440mm])1

E0150000HCM1MODULE1

E0750300MAXSENSOR3

E0850200CANBUSREPEATER1

E1043760NETWORKCOUPLER3‐WAY1

E1143765NETWORKCOUPLER8‐WAY1

E1243764NETWORKCOUPLER2‐WAY1

E2043764TNETWORKCOUPLER2‐WAYWITHTERMINATOR 4

H0144863‐61HOSEASSEMBLY122R2‐0632INL6FORX6FORX451

H0244864‐06HOSEASSEMBLY122R2‐0818INL8FORX8FORX451

H0344863‐62HOSEASSEMBLY122R2‐0612INL6FORX6FORX902

H1044865‐69HYDRAULICSFITTINGKIT‐RG131

H20106685ACCUMULATORLOCKINGCOIL2

H21106686ACCUMULATORLOCKINGSOLENOIDVALVE2

M02UC7‐BC‐RG13‐INSTMANUALINSTALLATIONUC7ROGATOR7001

M05106706MOUNTINGCLIPHCM12

P01106705NETWORK4PINCAVITYPLUG2

P02106602NETWORK12PINPLUG(A‐KEY)DT1

P03105882NETWORK6PINPLUG4

V0144963DVALVEBLOCKASSEMBLY2STATIONCC/LSPROPDT4BOLT1





WWW.NORAC.CA

PRECISIONDEFINED





Page6

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

3.3.1. HydraulicFittingKitDetails(P/N:44865‐69)

ItemPartNumberNameQuantityPicture

F01106617MALEADAPTER‐6MB6MOR451



F02104586TEEADAPTER‐6FORXR6MORT3



F03105151MALETOMALEADAPTER‐6MB8MOR1



F04106618MALETOFEMALEADAPTER‐8FORX8MOR451



F05104885TEEADAPTER‐8FORXR8MORT1



F0644917MALEADAPTER‐6MB6MOR2



F07104590ELBOWADAPTER‐6MOR6FORX901



F08104369PLUG‐6MBP2



F09106619MALETOFEMALEADAPTER‐6MOR6FORX451



F1044928ORIFICEINSERT.047INONEWAY2



6 M B - 6 M OR X 90

SIZE IN

1/16TH'S

GENDER: MALE

OR FEMALE

90° ANGLE

SWIVEL

TYPE

GENDER

SIZE

TYPE:

B - ORB

J - JIC

OR - FLAT

FACE

P - PIPE

Fitting Name

Example:

WWW.NORAC.CA

PRECISIONDEFINED





Page7

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

4Pre‐InstallationChecklist

Thepre‐installchecklistisnecessarytochecktheexistingsprayerfunctionalitybeforetheinstallation.

1. Unfoldthesprayeroveraflat,unobstructedarea(i.e.nopowerlines…etc.).

2. Ensureallboom‐foldoperationsarefunctional(placeacheckmarkinboxesbelow).

3. Bringenginetofield‐operationalRPMandrecordbelow.

4. Recordthetime(seconds)ittakesforafullstrokeforallboomfunctions.Toensurerepeatable

measurements,taketheaverageof3trials.

5. NotallsprayerswillhavethefunctionslistedbelowinFigure3.



Ensuretheboomhassufficienttravelsoitdoesnotcontactthegroundduringthesetests.



Figure3:Pre‐InstallBoomSpeeds




