Nokia Bluetooth Headset BH-703
User Guide
9207478
Issue 1 EN
HS-106W_UG_en1_with_FCC&IC_notice.fm Page 1 Monday, March 10, 2008 4:55 PM
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this HS-106W product is in
compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at
http://www.nokia.com/phones/declaration_of_conformity/.
© 2008 Nokia. All rights reserved.
Nokia, Nokia Connecting People and the Nokia Original Accessories logo are registered
trademarks of Nokia Corporation. Other product and company names mentioned herein may be
trademarks or tradenames of their respective owners.
Reproduction, transfer, distribution or storage of part or all of the contents in this document in
any form without the prior written permission of Nokia is prohibited.
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and
improvements to any of the products described in this document without prior notice.
To the maximum extent permitted by applicable law, under no circumstances shall Nokia or any
of its licensors be responsible for any loss of data or income or any special, incidental,
consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law, no
warranties of any kind, either express or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose, are made in relation to the
accuracy, reliability or contents of this document. Nokia reserves the right to revise this
document or withdraw it at any time without prior notice.
The availability of particular products may vary by region. Please check with your Nokia dealer
for details.
HS-106W_UG_en1_with_FCC&IC_notice.fm Page 2 Monday, March 10, 2008 4:55 PM
Export controls
This device may contain commodities, technology or software subject to export laws and
regulations from the US and other countries. Diversion contrary to law is prohibited.
9207478/Issue 1 EN
HS-106W_UG_en1_with_FCC&IC_notice.fm Page 3 Monday, March 10, 2008 4:55 PM
4
Contents
1. Introduction ......................... 5
Bluetooth wireless technology........... 5
2. Get started ........................... 7
Overview................................................... 7
Chargers.................................................... 7
Charge the battery ................................ 8
Switch the headset on or off.............. 9
Pair the headset ..................................... 9
Disconnect the headset ................. 10
Reconnect the headset .................. 10
Troubleshooting................................... 10
3. Basic use............................. 12
Change the earplug............................ 12
Place the headset on the ear........... 12
Carry the headset in the strap ........ 14
Calls ........................................................ 14
Adjust the headset volume............... 15
Mute or unmute the microphone... 15
Switch the call between
the headset and mobile device ....... 16
Clear pairings or reset the headset 16
4. Battery information........... 17
Care and maintenance........... 19
FCC/Industry Canada notice.. 21
HS-106W_UG_en1_with_FCC&IC_notice.fm Page 4 Monday, March 10, 2008 4:55 PM
Introduction
5
1. Introduction
With the Nokia Bluetooth Headset BH-703, you can make and receive
calls while on the move. You can use the headset with compatible devices
that support Bluetooth wireless technology.
Read this user guide carefully before using the headset. Also, read the
user guide for your mobile device that you connect to the headset. It
provides important safety and maintenance information. Check
www.nokia.com/support or your local Nokia website for additional
information related to your Nokia product.
This product may contain small parts. Keep them out of the reach of small
children.
■Bluetooth wireless technology
Bluetooth wireless technology allows you
to connect compatible devices without
cables. The mobile device and the headset
do not need to be in line of sight, but the
maximum distance between the devices
should be 10 metres (33 feet). The closer
the mobile device and the headset are to
each other, the better the performance.
The optimal operating range is shown in
dark grey in the picture. The connection is
<10m
HS-106W_UG_en1_with_FCC&IC_notice.fm Page 5 Monday, March 10, 2008 4:55 PM
Introduction
6
subject to interference from obstructions (shown in light grey) or other
electronic devices.
The headset is compliant with the Bluetooth Specification 2.1 + EDR
supporting the following profiles: Headset Profile 1.1 and Hands-Free
Profile 1.5. Check with the manufacturers of other devices to determine
their compatibility with this device.
HS-106W_UG_en1_with_FCC&IC_notice.fm Page 6 Monday, March 10, 2008 4:55 PM
Get started
7
2. Get started
■Overview
The headset contains the following parts:
1. Indicator light
2. Charger connector
3. Multifunction key
4. Touch-sensitive area for volume
adjustment
5. Earpiece with a changeable
earplug
6. Earloop
7. Microphone
Before you can start using the headset, you must charge the battery and
pair the headset with a compatible device.
Parts of the headset are magnetic. Metallic materials may be attracted to the
headset. Do not place credit cards or other magnetic storage media near the
headset, because information stored on them may be erased.
■Chargers
The headset is intended for use with the AC-6 and DC-6 chargers.
12
36
7
5
1
4
HS-106W_UG_en1_with_FCC&IC_notice.fm Page 7 Monday, March 10, 2008 4:55 PM
Get started
8
Warning: Use only chargers approved by Nokia for use with this
particular enhancement. The use of any other types may invalidate any
approval or warranty, and may be dangerous.
When you disconnect the power cord of any enhancement, grasp and pull the plug,
not the cord.
■Charge the battery
Before charging the battery, carefully read “Battery information,” p. 17.
1. Connect the charger to a wall outlet.
2. Connect the charger cable to the charger
connector. The indicator light is red while
charging. Charging the battery fully may
take up to 1 hour with the AC-6 or DC-6
charger.
3. When the battery is fully charged, the
indicator light turns green. Disconnect the charger from the headset
and the wall outlet.
You can also charge the battery through the USB port of a compatible PC
using the Nokia Connectivity Cable CA-101 (sold separately). Connect one
end of the cable to the charger connector and the other end to the USB
port on the PC.
The fully charged battery has power for up to 6 hours of talk time or up to
160 hours of standby time.
When battery power is low, the headset beeps at regular intervals, and the
indicator light slowly flashes red.
HS-106W_UG_en1_with_FCC&IC_notice.fm Page 8 Monday, March 10, 2008 4:55 PM
Get started
9
■Switch the headset on or off
To switch on, press and hold the multifunction key until the headset beeps
and the indicator light turns on. When the headset can be connected to a
paired device, the indicator light slowly flashes green. When the headset
is connected to a paired device and is ready for use, the indicator light
slowly flashes blue. If the headset has not been paired with a device, it
automatically enters the pairing mode (see “Pair the headset,” p. 9).
To switch off, press and hold the multifunction key for at least 4 seconds
until the headset beeps and the indicator light turns red. If the headset is
not connected to a paired device within about 30 minutes, it switches off
automatically.
■Pair the headset
1. Ensure that your mobile device is switched on.
2. To pair the headset if it has not been previously paired with a device,
switch on the headset. The headset enters the pairing mode, and the
indicator light starts to flash blue quickly.
To pair the headset if it has been previously paired with another
device, ensure that the headset is switched off, and press and hold the
multifunction key until the indicator light starts to flash blue quickly.
3. Activate the Bluetooth feature on the mobile device, and set it to
search for Bluetooth devices. See the user guide of your device for
instructions.
4. Select the headset (Nokia BH-703) from the list of found devices.
HS-106W_UG_en1_with_FCC&IC_notice.fm Page 9 Monday, March 10, 2008 4:55 PM
Get started
10
5. Enter the passcode 0000 to pair and connect the headset to your
device, if your device asks you to do so. In some mobile devices, you
may need to make the connection separately after pairing. See the
user guide of your device for details. You only need to pair the headset
with your device once.
If pairing is successful, the headset appears in the menu of the mobile
device where you can view the currently paired Bluetooth devices.
Disconnect the headset
To disconnect the headset from your mobile device, switch off the
headset, or disconnect it in the Bluetooth menu of your device.
You do not need to delete pairing with the headset to disconnect it.
Reconnect the headset
To connect the headset to your paired mobile device, switch on the
headset, and make the connection in the Bluetooth menu of your device,
or press and hold the multifunction key until you hear a short beep.
You may be able to set your mobile device so that the headset connects to
it automatically. To activate this feature in a Nokia device, change the
paired device settings in the Bluetooth menu.
■Troubleshooting
If you cannot connect the headset to your mobile device, do as follows:
