No Butts Bin SR1601 Manuel utilisateur

Assembly Instructions

SR1601-08-14022019-USA

Shelter Type: SR1601

Email : [email protected]

Web : www.nobutts.com

Tel : 1-888-662-8887

511

EXPLODED VIEW

Spanner

Torx bit

Tools required:

Drill/Screwdriver

Mallet

Hack saw

ITEM

NO. PART NAME

DRG NUMBER

LENGTH

Default/QT

S1 Frame

S3 Frame

JF1 Bracket

JF1

Default

CB1 Bracket

CB1

Default

RB1 Bracket

RB1

Default

Rafter

FT1 Bracket

FT1

Default

FT3 Bracket

FT3

Default

L3 Bracket

Default

L1 Bracket

Default

Beam B1

Sealing Strip

PCE1

PCE1 Roof Sheet

RC1

RC1 Roof Strip

2MD

2MD Roof Edging

40x40 End cap

BOUGHT IN ITEM

40 x 40 x

20 5

PARTS LIST

Fittings

Bolt set M10

Nut

Washer

Black

Cap

T25 T38 AB1210

M10 x 60

25mm

Tech

screw

38mm

Tech

screw

M10 x 100

Concrete Bolt

Pack A

30 30 60 60 72 30 8

Required

22 22 49 49 32 18 5


ITEM NO.

PART NO.

DESCRIPTION

DIMENSION

(MM)

DIMENSION

(INCHES)


QTY.

FRAME

2000x1035

78.74 x 40.55

FRAME

2000x517

78.74 x 20.35

JF1

BRACKET

220x40

8.66 x 1.58

CB1

BRACKET

110x110

4.33 x 4.33

RB1

BRACKET

110x42x40

4.33 x 1.81

RAFTER

1035 x 1.57 x

1.57

40.75 x 1.57 x

1.57

FT1

FOOT

109x100x40

4.29 x 3.93 x

1.57

FT3

FOOT

109x100x80

4.29 x 3.93 x

3.27

BRACKET

73x38

2.87 x 1.50

BRACKET

95x45

3.74 x 1.77

BEAM

2100x40x40

82.68 x 1.57 x

1.57

Sealing Strip

TRIM TO 1035

TRIM TO 40.75

1 ROLL

PCE1

ROOF PANEL 1130 x 1050

44.49 x 41.34

RC1

ROOF STRIP

1130

44.49

2MD

ROOF EDGE

TRIM TO SUIT TRIM TO SUIT

EC40

END CAP

40x40

40 x 40

ENSURE CORRECT

ALIGNMENT ON

BOTH SIDES

ENSURE CORRECT

ALIGNMENT ON

BOTH SIDES

517

2110

557

20.35

83.07

21.93

Check dimensions to ensure

correct alignment

FT1

FT3

FT1

CB1

JF1

CB1

Step 1

Assemble main frame using

and

welded Frames. Join the frames

using

CB1

brackets in the corners and

JF1

brackets for the flat joints.

Then move the shelter to its final position, attach

FT1

and

FT3

foot brackets

and use the concrete bolts to secure it to the ground.

MEASUREMENTS IN BLUE - MM

MEASUREMENTS IN GREEN - INCHES

RB1

RB1RB1

RB1

RB1RB1

RB1

Step 2

Attach

rafters using

RB1

brackets at rear and

brackets in

the centre.

Step 3

Attach

brackets to

rafters. Then attach

tie bar.

L1L1

RC1

PCE1

2MD

PCE1

RC1

2MD

Step 4

Apply sealing strips to

rafters then put the

PCE1

Panels on top,

secure down with

RC1

strips and

38mm Tech screws

. Then attach the

2MD

edge trim.

NOTE: Sealing Strip

to be attached to

rafters as below.

2193 HOLE CENTERS ON FEET

477

2110

1035

86.34

20.73

526.50

18.78

40.75

83.07

44.90

1140.56

PLAN VIEW

Suggested size for concrete base: 200mm / 7.87in

oversized on all four sides

Notes:
