LS-30 35 mm Film Scanner User’s Guide

Cautions

• The reproduction of this manual in whole or in part is prohibited

save in cases in which Nikon’s prior permission has been

obtained.

• The information contained in this manual is subject to change

without notice.

• Nikon has made every effort to produce a perfect manual, but

should you find any mistakes, we would be grateful if you would

kindly let us know. The address of Nikon’s representative in

your area is provided separately.

• Nikon is not liable for damages resulting from the use of this

product.

Symbol

The symbols in this manual signify important safety precau-

tions. All passages marked with this indication should be read prior

to installation to prevent injury to yourself or to others. These

indications are also placed in the table of contents to mark passages

that should be read before use.

✔Symbol

The ✔symbols in this manual signify the need for caution when

using the product. These indications are placed in sections that

should be read before operation to prevent damage to the product.

Warning!

The CD-ROMs on which the software and manuals are distributed

should not be played back on audio CD equipment. Playing CD-

ROMs on an audio CD player could cause hearing loss or damage

the equipment.

Trademark Information

Macintosh is a registered trademark of Apple Computer, Inc. Microsoft and

Windows are registered trademarks, and Windows NT a trademark, of Microsoft

corporation. IBM PC/AT is a trademark of International Business Machines

Corporation. i386, i486, Pentium, and Pentium II are trademarks of Intel Corpora-

tion, U.S.A. Adobe and Acrobat are registered trademarks, and Photoshop a

trademark, of Adobe Systems, Inc. The Clean Image function incorporated in the

LS-30 makes use of Digital ICE technology developed by Applied Science Fiction

Inc. Digital ICE and the Digital ICE logo are trademarks of Applied Science

Fiction Inc. All other trade-names mentioned in this manual are the trademarks or

registered trademarks of their respective holders.

iii

Nikon

LS-30 35 mm Film Scanner User’s Guide

Federal Communications Commission (FCC) Radio

Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio communica-

tions. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interfer-

ence by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/television technician for help.

CAUTIONS

Modifications

The FCC requires the user to be notified that any changes or modifications

made to this device that are not expressly approved by Nikon Corporation

may void the user’s authority to operate the equipment.

SCSI Cable

Depending on your region, a SCSI cable or ferrite core is provided with

your scanner. The SCSI cable used with your scanner must be that

provided or must have the provided ferrite core attached. Using other

interface cables may exceed the limits of the class B Part 15 of FCC rules.

Notice for customers in Canada

CAUTION

This class B digital apparatus meets all requirements of the Canadian

Interference Causing Equipment Regulations.

ATTENTION

Cet appareil numérique de la classe B respecte toutes les exigences du

Règlement sur le matériel brouilleur du Canada.

Notice for customers in European countries

ACHTUNG

Dieses Gerät entspricht den Bestimmungen der EG-Direktive 87/308/EEC

zur Störungsunterdrückung. Lärmemission kleiner 70 dBA

Nikon

LS-30 35 mm Film Scanner User’s Guide

Safety Precautions

Observe the following safety precautions when installing and

operating the LS-30:

•Do not allow your fingers, hair, or clothing into the film

insertion slot

Do not insert your fingers, hair, or clothing into the film inser-

tion slot on the front of the scanner when the power is on and a

film adaptor is in place. Doing so could result in injury.

•Do not disassemble

The interior of the scanner contains areas of high voltage.

Removing the scanner’s cover could result in fire or electric

shock. Contact your dealer or Nikon service office for inspec-

tion or repair.

•Do not modify

Do not modify the equipment. Doing so could cause fire or

electric shock.

•Do not place heavy objects on the scanner

•Place on a stable surface

Do not use the equipment on an unstable surface or on a surface

which is not horizontal. This could cause the equipment to fall,

resulting in injury.

•Do not drop

Do not subject the equipment to strong shocks, as this could

cause malfunction or breakage. Note that the scanning unit

contains glass parts; if the scanner is dropped, care should be

taken to avoid contact with broken glass.

•Keep clean

Use a dry cloth to remove any dirt from metal sections of the

scanner and their surroundings. Using the equipment when dirty

could cause fire.

Nikon

LS-30 35 mm Film Scanner User’s Guide

•Do not place foreign objects inside the scanner

Do not allow foreign objects of any kind into the unit. If

flammable objects, metal, or water come in contact with the

interior of the scanner, malfunction, fire, or electric shock could

result.

• Do not place vases, flowerpots, cups, cosmetics, vessels contain-

ing chemicals or water, or small metal articles on top of the

equipment. Should such articles or their contents fall into the

equipment, fire, electric shock or malfunction could result.

• Exposing the scanner to volatile substances such as alcohol,

benzine, thinner, or pesticides could cause malfunction, fire, or

electric shock.

• If foreign substances or water should find their way into the

equipment, turn off the power immediately, unplug the power

cord and contact your dealer or nearest Nikon service office.

Continued use could result in fire, electric shock or malfunction.

Particular care is advised in households with small children.

•When not using for an extended period

When not using the equipment for an extended period, remove

any film that may be in the adapters and take the adapters out of

the adapter slot. Turn off the equipment and unplug the power

cord. To prevent the accumulation of dust inside the equipment,

close the front cover.

•When performing routine maintenance

Before performing maintenance, turn the equipment off and

unplug the power cord.

•If you notice smoke or an unusual noise or smell from

the scanner, turn off the power immediately and then unplug

the power cord. Continued use could result in fire or electric

shock. After ensuring that the equipment has stopped smoking,

contact your dealer or Nikon service representative for informa-

tion on replacement or repair. DONOT attempt repairs yourself,

as this would be extremely dangerous.

Nikon

LS-30 35 mm Film Scanner User’s Guide

When transporting the scanner

The LS-30 is for use only in the country of sale. Nikon will not be

held responsible for consequences resulting from use overseas.

The scanning mechanism must be locked in its home position for

transport within the country. To return the scanning mechanism

its home position, remove any adapters from the adapter slot and

then turn the scanner on. The status LED will blink while the

scanning mechanism returns to the home position. Wait until the

status LED glows steadily, then turn off and unplug the scanner.

Place the guard in the adapter slot as shown below, sliding it in until

it contacts the back of the slot.

Remove the transport locking screws from the rear panel and screw

them into the holes provided in the side panel and the mouth of the

adapter slot (the hole in the mouth of the slot should align with the

hole in the guard). Close the front cover and pack the scanner and

adapters in the original packing material for transport.

✔Caution: Do not transport the scanner without first locking the

scanning mechanism with the transport lock screws. Moving the

scanner without the lock screws in place could damage the mecha-

nism.

vii

Nikon

LS-30 35 mm Film Scanner User’s Guide

Notice concerning prohibition of copying or repro-

duction

Note that simply being in possession of material which has been

copied or reproduced by means of a scanner may be punishable by

law.

• Items prohibited by law from being copied or reproduced

Do not copy or reproduce paper money, coins, securities,

government bonds, or local government bonds, even if such

copies or reproductions are stamped “Sample.”

The copying or reproduction of paper money, coins, or securities

which are circulated in a foreign country is prohibited.

Unless the prior permission of the government has been ob-

tained, the copying or reproduction of unused postage stamps or

post cards issued by the government is prohibited.

The copying or reproduction of stamps issued by the govern-

ment and certified documents stipulated by law is prohibited.

• Cautions on certain copies and reproductions

The government has issued cautions on copies or reproductions

of securities issued by private companies (shares, bills, checks,

gift certificates, etc.), commuter passes, or coupon tickets,

except when a minimum of necessary copies are to be provided

for business use by a company. Also, do not copy or reproduce

passports issued by the government, licenses issued by public

agencies and private groups, ID cards, and tickets, such as

passes and meal coupons.

• Comply with copyright notices

The copying or reproduction of copyrighted creative works such

as books, music, paintings, woodcut prints, maps, drawings,

movies, and photographs is prohibited except when it is done for

personal use at home or for similar restricted and non-commer-

cial use.

viii

Contents

Nikon

LS-30 35 mm Film Scanner User’s Guide

Contents

Safety Precautions.................................................................iv

1. Overview ............................................................... 1

2. Parts and Accessories......................................... 3

2.1 What’s in the Box..........................................................3

2.2 Parts of the LS-30.........................................................4

3. Setup ..................................................................... 5

3.1 Setting up the LS-30.....................................................5

3.2 Software Installation ...................................................16

4. Scanning ............................................................. 21

Appendix: Nikon Scan Controls ...................... 31

Menus, Tabs, and Information Displays ...............................31

Buttons..................................................................................32

Control Drawers....................................................................33

Preferences ..........................................................................35

1. Overview

Nikon

LS-30 35 mm Film Scanner User’s Guide

1. Overview

Thank you for your purchase of a Nikon LS-30 scanner for 35 mm

film. The LS-30 is a high-speed, high-resolution scanner capable of

producing images suited to a wide variety of tasks, including desk-

top publishing, design, and multi-media publishing. Its modular

design allows you to change from scanning 35 mm slides to scan-

ning 35 mm strip film “on the fly.” An adapter for scanning IX240

film is available separately. The LS-30 uses a high-speed SCSI

interface for connection to computers running Mac OS System

Software 7.1 or later, Windows 95 or later, or Windows NT 4.0 or

later.

The scanner driver software provided with your scanner, Nikon Scan

2.1, offers sophisticated pre-scan editing of images, including

precise color correction, contrast, and brightness adjustment. Nikon

Scan can be launched from any TWAIN-compliant application

under Windows or from any application that supports Adobe

Photoshop

plug-ins (version 4.0 or higher) on the Macintosh. Nikon

Scan can also be used as a “stand-alone” application, allowing you to

save scanned images to disk without the help of another application.

The user’s manuals for the LS-30 and Nikon Scan are divided into

three parts. This User’s Guide offers a brief introduction to setting

up the scanner and scanning images using Nikon Scan. More

detailed reference manuals for the scanner and for Nikon Scan are

provided on CD-ROM. To read these manuals you will need to

install the Adobe Acrobat Reader software included on the refer-

ence CD. In addition, a one-page Fast Track Guideis provided for

experienced users who want to get started with the minimum of

instruction. Where appropriate, this guide will refer readers to the

reference manuals or Fast Track Guidefor more information.

References to the manuals on CD are indicated by a icon in the

margin, references to the Fast Track Guideby a icon.

1. Overview

Nikon

LS-30 35 mm Film Scanner User’s Guide

The chapters that follow provide a step-by-step guide to installing

your scanner and using Nikon Scan to scan 35 mm slides or strip

film. The next chapter, Parts and Accessories, lists the things you

should find packaged with your LS-30 and names the parts of the

scanner. This is followed by “Setup,” which guides you through the

process of connecting your scanner to a computer and installing

Nikon Scan. “Scanning” outlines the steps involved in using Nikon

Scan to scan slides and strip film. A separate reference section lists

the controls available in Nikon Scan. We hope that you find this

manual useful.

Autres manuels pour Coolscan III LS-30

Table des matières

Autres manuels Nikon Scanner

Nikon

Nikon AX-210 Manuel utilisateur

Nikon

Nikon AF-S DX NIKKOR 35mm f/1.8G Manuel utilisateur

Nikon

Nikon Super Coolscan 900ED Manuel utilisateur

Nikon

Nikon AX-110 Manuel utilisateur

Nikon

Nikon LS8000 Manuel utilisateur

Nikon

Nikon Transparency Unit Manuel utilisateur

Nikon

Nikon COOLSCAN LS-10 Manuel utilisateur

Nikon

Nikon Scanners Instructions de montage

Nikon

Nikon Super Coolscan 5000 ED Manuel utilisateur

Nikon

Nikon CoolScan IV ED Manuel utilisateur

Nikon

Nikon SF-200 Manuel utilisateur

Nikon

Nikon Scan Manuel utilisateur

Nikon

Nikon Super Coolscan 5000 ED Manuel utilisateur

Nikon

Nikon LS4000 Manuel utilisateur

Nikon

Nikon Super Coolscan 4000 ED Manuel utilisateur

Nikon

Nikon Coolscan III LS-30 Manuel utilisateur

Nikon

Nikon Super Coolscan 9000 ED Manuel utilisateur

Nikon

Nikon COOLSCAN LS-10E Manuel utilisateur

Nikon

Nikon SUPER COOLSCAN 8000 ED Manuel utilisateur

Nikon

Nikon Super Coolscan 9000 ED Manuel utilisateur

Nikon

Nikon SuperCoolScan 5000ED Manuel utilisateur

Nikon

Nikon 9238 - Super Coolscan 5000 ED Manuel utilisateur

Nikon

Nikon LS-3510 Manuel utilisateur

Nikon

Nikon Super Coolscan 9000 ED Manuel utilisateur

Manuels Scanner populaires d'autres marques

Plustek

Plustek Scanner Manuel utilisateur

Z/I Imaging

Z/I Imaging PhotoScan 2001 Manuel utilisateur

Renkforce

Renkforce DS100-5M Manuel utilisateur

Image Access

Image Access WideTEK A2 Manuel utilisateur

Canon

Canon imageFORMULA CR-120N Manuel utilisateur

Fujitsu

Fujitsu FI-4860C2 Manuel utilisateur

GeoSlam

GeoSlam ZEB Horizon Instructions d'installation

Kodak

Kodak i5800 Scanner Manuel utilisateur

Kodak

Kodak i7300 Manuel utilisateur

Revopoint

Revopoint POP Manuel utilisateur

Fujitsu

Fujitsu fi-4860C Manuel utilisateur

Eddyfi Technologies

Eddyfi Technologies Floormap X Manuel utilisateur

Faselase

Faselase F6 Manuel utilisateur

Fujitsu

Fujitsu CardMinder Manuel utilisateur

Uniden

Uniden BC340CRS Manuel utilisateur

Infinite Peripherals

Infinite Peripherals INFINEA TAB M Manuel utilisateur

Mustek

Mustek PageExpress 4800 Pro Manuel utilisateur

Optex

Optex 750830 Manuel utilisateur
