8
Environment
Working Environment:
Temperature: 0 ~ 50 ( 32 ~ 122 ). Humidity: 10% ~ 90%
(non-condense).
Storage Environment:
Temperature: -20 ~ 60 ( -4 ~140 ). Humidity: 5% ~ 95%
(non-condense).
℃ ℃ ℉ ℉
℃ ℃ ℉ ℉
Technical Specifications
NEW8210
Product manual
NEW POS Technology limited
Processor:
Memory:
Display：
Keypad：
Magnetic Card Reader:
IC Card Reader:
PSAM Slots:
Contactless Card Reader:
(Optional)
Internal PIN PAD:
Internal wireless(optional):
Internal Modem:
(optional)
Other module(Optional):
Remote download：
Peripheral Ports：
Printer:
Language：
Dimensions:
Weight:
Power Supply:
Battery:
Optional:
Identification:
32 bit secure ARM11 CPU, 400MHz.
128MB FLASH, 64MB SDRAM.
2.8 inch , 320*240 TFT LCD. Optional signature capture function.
10 alphanumeric keys, 8 functional keys, 1 power switch key.
Compliant with ISO78I1, ISO7812; Track1/2/3, bi-directional
swipe, supports smart error correcting.
1 user card(EMV4.3), supports SLE4442/SLE4428 memory card.
2(optional 3)PSAM slots, compliant with ISO7816. Supports PPS
protocol.
Supports Mifare classic, Mifare Ultralight, Mifare DESFire,ISO
14443A&B, SONY Felica, Compatible with the Top tapping.
Supports MK/SK, Fixed, DUKPT, Supports dual and triple length
TDES. Supports RSA,AES.
GPRS/CDMA/Wi-Fi, GPRS/CDMA&Wi-Fi/3G, supports SSLv2/3
TLSv1.
Synchronous: V.22bis, V.29, Supports 1200/2400/9600bps.
Asynchronous: V.92, up to 56kbps.
GPS, 1D or 2D scanner.
Supports NewTMS remote download.
1 RS-232(up to 2), output:5VDC, 500mA, 1 mini USB OTG.
Easy-load stlye.
Supports Chinese(GB2312/GB18030), English, French, German,
Latin, Russian, Aranbic, Vietname etc.
190mm*89.5mm*56mm(L*W*H).
495g.
Input: 100~240VAC, 50Hz/60Hz. Output: 9.5VDC, 2.5A.
2600mAh, 7.4V, more than 72 hours standby time, supports 400
transactions.
Leather case, backup battery, car jack charger, dock charger.
CCC, CE, RoHS, PCI PTS5.X, EMV4.3 level 1&2, PBOC3.0.
Terminal characteristics
11. Insert user smart card
* Insert smart card with the gold-colored contact surface facing up into the card slot.
View LCD Icc card icon to determine if IC card is inserted into its place. If the IC card icon is
switched on, it indicates OK. While the icon is off, please confirm whether gold-colored
contact surface of card is facing up and IC card is inserted into its place.
12. Battery Charge
* Remove the back cover of the device . Insert the rechargeable battery.Slide the back cover
into its place.(If the rechargeable battery is in the device, the step is unnecessary.)
* Connect the power supply to the power port on the side of the device. And connect the AC
plug of power supply to the wall socket. LED indicator on the side of device shows red
indicating that battery is in charging status. If the LED indicator shows green, it indicates
battery charge completes.
Note
If the device is in powered-off state, Only LED indicator on the side of device shows battery
charge status. While the device is in powered-on state, Battery icon on the LCD display also
indicates the battery charge status.
NEW8210
NEW POS Technology limited
Insert user smart card
7
Product manual
13. How to connect the stylus to the terminal
* Take out the cable from the bag with specification,and connect the stylus and terminal with
the cable to prevent the loss of stylus.
