NetUP Streamer HDMI 1x

User manual

20 March 2019

NetUP Streamer HDMI 1x. User manual

Contents

Introduction ............................................................................ 3

Specifications ......................................................................................................................... 3

Installation guide..................................................................... 4

Device’s installation flow chart.............................................................................................. 4

Packing list check ................................................................................................................... 4

Safety instructions ................................................................................................................. 4

Grounding requirement ......................................................................................................... 5

WEB NMS Operation ............................................................... 6

Login ....................................................................................................................................... 6

Status information ................................................................................................................. 7

Param setting ......................................................................................................................... 7

Save/Restore config ............................................................................................................... 8

Backup/Load config................................................................................................................ 8

System → Upgrade................................................................................................................. 9

System → Usrinfo................................................................................................................... 9

System → Setting ................................................................................................................... 9

System → Network .............................................................................................................. 10

System → RTMP Flash Player............................................................................................... 10

Usage examples......................................................................11

To record TS files on USB ..................................................................................................... 11

To play from recorded TS files ............................................................................................. 11

Connect device over LAN ..................................................................................................... 11

Set up to receive video and audio on phones, tablets or computers.................................. 12

Troubleshooting.........................................................................................14

NetUP Streamer HDMI 1x. User manual

Introduction

NetUP Streamer HDMI 1x – is an encoding device for IP broadcasting. It can receive signal from an

STB, PC, TV, etc., and broadcast a live stream through the Internet or LAN. The live stream then can be

received on a PC, phone, tablet, etc. NetUP Streamer HDMI 1x lets one access an IP STB, PC or TV

anywhere, whether in the same building or across the globe. You will never miss a game or a favorite

show.

The device accepts signal from HDMI sources and encodes it to MPEG 4 AVC/H.264, it broadcasts the

output signal over UDP (unicast/multicast), RTMP or HLS. NetUP Streamer HDMI 1x is also capable of

writing output stream to a USB drive as TS files and broadcasting from those files later.

Specifications

Input 1 HDMI

Video

Resolution

1920x1080_60p, 1920x1080_60i

1920x1080_50p,1920x1080_50i

1280x720_60p ,1280x720_50p

720x576_60i ,720x576_50i

Bitrate

1~15 Mbps

Format

MPEG-4 AVC/H.264

Audio

Bitrate

48, 64, 96, 128 kbps

Format

MPEG1 Layer II, MPEG2-AAC, MPEG4-AAC

Sample rate

48 KHz, 44.1 KHz (RTMP)

Output

UDP (unicast/multicast), RTMP, HLS (100/1000 Mbps)

System

Web-based management

USB update

Other

parameters

Dimension (W×L×H)

183 mm × 110 mm × 45 mm

Approx. weight

1 kg

Temperature

0~45℃ (work)

Power requirements

DC12V

NetUP Streamer HDMI 1x. User manual

Installation guide

Device’s installation flow chart

Before installing and connecting the device, carefully read the grounding requirements, as

well as safety instructions for the sake of your safety and for the safety of the device

Packing list check

Check items according to packing list. Normally it should include the following items:

•NetUP Streamer HDMI 1x

•Power Cord

•HDMI cable

•Network cable

Safety instructions

NetUP Streamer HDMI 1x power supply voltage should be DC12V

•Before installing and connecting the device make sure that the device was not damaged during

delivery.

•Install the device in an appropriate place. The device is designed to work in a clean and dry room.

It must be operated and maintained free of dust.

•Before switching on the device make sure that it is adjusted to the mains voltage you intend to

use. Make sure that you keep within the specifications – AC 100V-220V±10%, 50/60Hz.

•Check that all the cables are connected properly. Connect cables only to a device that is turned

off.

Packing list

check

Connecting

grounding

wire and

power cord

Installing

device

Connecting

signal cable

Setting

parameter

Running

device

NetUP Streamer HDMI 1x. User manual

Grounding requirement

•Connect the ground wire to the grounding hardware on the device. Ground resistance should be

no more than 1 Ω.

Grounding is essential for device’s functionality, surge and electronic interference

protection

•Keep proper contact with the metal housing of the device

•Grounding wire must be made out of copper and as thick and short as possible

•Make sure the two ends of grounding wire conduct electricity and are not rusty

•It is prohibited to use any other devices as a part of grounding electric circuit

•All racks should be connected with a protective copper strip. Ground loops should be avoided

•Grounding wire’s contact area with the rack should be no less than 25mm2

NetUP Streamer HDMI 1x. User manual

WEB NMS Operation

Use the Web interface to control NetUP Streamer HDMI 1x.

Connect a personal computer and the device with net cable, and use ping command to confirm they

are on the same network segment.

Make sure that the computer’s IP address is different from the device’s IP address;

otherwise, it would cause an IP conflict

The default IP address of NetUP Streamer HDMI 1x is 192.168.200.64. Thus, set the computer’s IP

address to 192.168.200.X, where X can be from 0 to 255, except 64. Open a web browser, enter the

device’s IP address in the browser address bar and press Enter. If the network is configured correctly,

you will see the login interface (Figure 1).

Enter username and password and click LOGIN to enter the web interface. Default username is

“admin”, default password is “admin”.

Figure-1

NetUP Streamer HDMI 1x. User manual

Status information

After login, you will get the Status page which displays the current system status (Figure-2).

Figure-2

Param setting

NetUP Streamer HDMI 1x supports up to three output streams simultaneously (different bitrate,

resolution, protocol, etc.). Use the Param setting page to access the encoding and broadcasting

settings of each of the three available output streams (Figure-3).

Figure-3

Select UDP (unicast/multicast),

RTMP, HLS or USB

Select a channel

System information

Use this menu to navigate

between the interface pages

Status area.

Green light

indicates normal

status, grey

indicates error

Version information

To stop USB device

recording or playing TS

NetUP Streamer HDMI 1x. User manual

Save/Restore config

Use the Save/Restore config page to save current settings or restore from saved ones or from factory

settings. The encoder applies saved settings after each reboot, therefore discarding any unsaved

changes (Figure-4).

Figure-4

Backup/Load config

Use the Backup/Load config page to download current configuration and save it on a local storage

device. It also allows you to restore settings from a local file (Figure-5).

Figure-5

NetUP Streamer HDMI 1x. User manual

System →Upgrade

Use the Upgrade page to upgrade device’s firmware (Figure-6).

Figure-6

System →Usrinfo

Use the Usrinfo page to change current password and username (Figure-7).

Figure-7

System →Setting

Use the Setting page to setup port and channel name for http output (CH1, CH2, CH3).

Confirm

changes

NetUP Streamer HDMI 1x. User manual

System →Network

Use the Network page to setup device’s network adapter (Figure-8).

Figure-8

System →RTMP Flash Player

Use the RTMP Flash Player page to open the built-in RTMP player (Figure-9).

Figure-9

Replace “localhost” with the IP address of the server, “my

stream” with the value of the path name parameter and

then click

Start

to start playing
