NetUP Streamer 16xC Manuel utilisateur

1/7, Ulofa Palme str., Moscow, Russia

+7 (495)510-1025 |info@netup.tv |http://netup.tv

NetUP Streamer 16xC

User manual

9 April 2019

NetUP Streamer 16xC. User manual

Contents

Introduction ............................................................................ 3

Appearance and illustration................................................................................................... 3

Specifications ......................................................................................................................... 4

Installation guide..................................................................... 5

Device’s installation flow chart.............................................................................................. 5

Packing list check ................................................................................................................... 5

Safety instructions ................................................................................................................. 5

Environment requirement ..................................................................................................... 6

Grounding requirement ......................................................................................................... 6

WEB NMS Operation ............................................................... 7

Login ....................................................................................................................................... 7

Summary → Status................................................................................................................. 8

Parameters → TS Config ........................................................................................................ 8

Parameters → Scrambler..................................................................................................... 11

Parameters → Modulator .................................................................................................... 11

Parameters → IP Stream...................................................................................................... 12

System → Network .............................................................................................................. 13

System → Password............................................................................................................. 14

System → Configuration ...................................................................................................... 14

System → Firmware............................................................................................................. 14

System → Log....................................................................................................................... 15

Troubleshooting.........................................................................................16

NetUP Streamer 16xC. User manual

Introduction

NetUP Streamer 16xC – is the latest generation Mux-scrambling-modulating all-in-one device

developed by NetUP. It has 16 multiplexing channels, 16 scrambling channels and 16 QAM (DVB-C)

modulating channels, and supports maximum 1024 IP input through the GE port and 16 non-adjacent

carriers (50MHz~960MHz) output through the RF output interface.

Appearance and illustration

NMS/CAS: network management port and CA data port

RF output port

Reset IP: reset the device’s IP address to its default value

Link/Act Indicators

Data Input / Output 1/2 (SFP)

Power switch

Power socket

Grounding pole

NetUP Streamer 16xC. User manual

Specifications

Input stream

Input

512×2 IP input, 2 100/1000M Ethernet Port (SFP)

Transport Protocol

TS over UDP/RTP/RTSP, unicast and multicast, IGMP

V2/V3

Transmission Rate

Max 840Mbps for each GE input

Mux

Input Channels

1024

Output Channels

Max PIDs

180 per channel

Functions

PID remapping (auto/manual, optional)

Scrambling

Max simulscrypt CA

Scrambling Standard

ETR289, ETSI 101 197, ETSI 103 197

Connection

Local/remote connection

Modulation

QAM Channel

16 non-adjacent carrier

Modulation Standard

EN300 429/ITU-T J.83A/B

Symbol Rate

5.0~7.0Msps, 1ksps stepping

Constellation

16, 32, 64, 128, 256QAM

FEC

RS (204, 188)

RF output

Interface

1 F type output port for 16 carriers, 75Ω impedance

RF Range

50~960MHz, 1kHz stepping

Output Level

-20dBm~+10dBm(87~117dbµV), 0.1dB stepping

MER

≥ 40dB

ACLR

-60 dBc

TS output

16×IP output over UDP/RTP/RTSP, unicast/multicast, 2 100/1000M Ethernet

Ports

System

Network management software (NMS) support

Other parameters

Dimension (W×L×H)

420 mm × 440 mm × 44,5 mm

Approx. weight

3kg

Temperature

0~45℃(operation), -20~80℃(storage)

Power requirements

AC 100V±10%, 50/60Hz or AC 220V±10%, 50/60Hz

Power consumption

15.4W

NetUP Streamer 16xC. User manual

Installation guide

Device’s installation flow chart

Before installing and connecting the device, carefully read the environment and

grounding requirements, as well as safety instructions for the sake of your safety and for

the safety of the device

Packing list check

Check items according to packing list. Normally it should include the following items:

•NetUP Streamer 16xC

•Power Cord

Safety instructions

•Before installing and connecting the device make sure that the device was damaged during

delivery.

•Install the device in an appropriate place. The device is designed to work in a clean and dry room.

It must be operated and maintained free of dust.

•Before switching on the device make sure that it is adjusted to the mains voltage you intend to

use. Make sure that you keep within the specifications – AC 100V-220V±10%, 50/60Hz.

•Check that all the cables are connected properly. Connect cables only to a device that is turned

off.

Packing list

check

Connecting

grounding

wire and

power cord

Installing

device

Connecting

signal cable

Setting

parameter

Running

device

NetUP Streamer 16xC. User manual

Environment requirement

Item

Requirement

Room space

When installing a rack in the room, make sure the distance between two

rows of racks is 1.2~1.5m and the distance to the wall is at least 0.8m.

Room floor

Electric isolation. Dust free. The volume resistivity of ground anti-static

material: 1×107~1×1010 Ω. Grounding current limiting resistance: 1M (Floor

bearing should be greater than 450Kg/m2).

Environment

temperature

5~40℃(sustainable), 0~45℃(short time).

Installing air-conditioning is recommended.

Relative temperature

20%~80% (sustainable); 10%~90% (short time).

Pressure

86~105KPa

Door & window

Install rubber strip for sealing door-gaps and dual level glasses for windows

Walls

Can be covered with wallpaper or dark paint.

Fire protection

Fire alarm system and extinguisher.

Power

The device requires AC 100V-220V±10%, 50/60Hz.

Please carefully check before running.

Grounding requirement

•Connect the ground wire to the grounding hardware on the device. Ground resistance should be

no more than 1 Ω

Grounding is essential for device’s functionality, surge and electronic interference

protection

•Keep proper contact with the metal housing of the device

•Grounding wire must be made out of copper and as thick and short as possible

•Make sure the two ends of grounding wire conduct electricity and are not rusty

•It is prohibited to use any other devices as a part of grounding electric circuit

•All racks should be connected with a protective copper strip. Ground loops should be avoided

•Grounding wire’s contact area with the rack should be no less than 25mm2

NetUP Streamer 16xC. User manual

WEB NMS Operation

Use the Web interface to control NetUP Streamer 16xC.

Connect a personal computer and the device with net cable, and use ping command to confirm they

are on the same network segment.

Make sure that the computer’s IP address is different from the device’s IP address;

otherwise, it would cause an IP conflict

The default IP address of NetUP Streamer 16xC is 192.168.0.136 or 10.0.0.103. Thus, set the

computer’s IP address to 192.168.0.X or 10.0.0.X, where X can be from 0 to 255, except 136 or 103.

Open a web browser, enter the device’s IP address in the browser address bar and press Enter. If the

network is configured correctly, you will see the login interface (Figure 1).

Enter username and password and click LOGIN to enter the web interface. Default username is

“admin”, default password is “admin”.

Figure-1

NetUP Streamer 16xC. User manual

Summary →Status

After login, you will get the Status page which displays the current system status (Figure-2).

Figure-2

Parameters → TS Config

Use the TS Config page to configure the TS output parameters and select one of the following tabs:

Output TS, Stream Select, General, PID Bypass.

Output TS

Select the Output TS X tab, to open the list of available TS channels. Click one of the channels to

select it (Figure-3).

Figure-3

Use this menu to

navigate between

the interface pages

System information

Select a channel

NetUP Streamer 16xC. User manual

Stream Select

Select the Stream Select tab to select streams that should be sent to Mux out (Figure-4).

Figure-4

Figure-5

Operation area:

CA Filter filter or not filter the source CA information

PID Remap enable or disable PID remapping

Refresh input / output refresh an input or an output

===> / <=== move programs between the input and the output areas

All input / output select all input or output programs

Input area

Output area

Operation area

Change the

channel

information

(Figure-5)

Parse programs

Confirm

changes

NetUP Streamer 16xC. User manual

General

Select the General tab to edit common parameter for output streams (Figure-6).

Figure-6

Figure-7

PID Bypass

Select the PID Bypass tab to edit the list of PIDs that should pass through (Figure-8).

Figure-8

Add an NIT

descriptor
