NETGEAR D6400 Manuel utilisateur

Quick Start

AC1600 WiFi VDSL/ADSL

Modem Router

Model D6400

Support

Thank you for purchasing this NETGEAR product.

After installing your device, locate the serial number on the label of your product and use it

to register your product at https://my.netgear.com.

You must register your product before you can use NETGEAR telephone support. NETGEAR

recommends registering your product through the NETGEAR website.

For product updates and web support, visit http://support.netgear.com.

NETGEAR recommends that you use only the official NETGEAR support resources.

You can get the user manual online at http://downloadcenter.netgear.com or through a link in

the product’s user interface.

Trademarks

Any non‑NETGEAR trademarks are used for reference purposes only.

Compliance

For the current EU Declaration of Conformity, visit

http://support.netgear.com/app/answers/detail/a_id/11621/.

For regulatory compliance information, visit

http://www.netgear.com/about/regulatory/.

See the regulatory compliance document before connecting the power supply.

Package Contents

The box contains the following items.

In some regions, a resource CD is included in the package.

NETGEAR, Inc.

350 East Plumeria Drive

San Jose, CA 95134 USA

May 2015

Modem router

Ethernet cable

Power adapter

(varies by region)

Phone cable

DSL splitter

(varies by region)

1. Connect the modem router to a

DSL service or a cable or fiber

modem.

To connect to a DSL service (ADSL

or VDSL):

Install the DSL splitter and connect it

to the DSL port on the modem router.

To connect to a cable or fiber

modem:

Prepare your cable or fiber modem and

connect it to the red Internet port on

the modem router.

2. Power on the modem router.

Wait for the Power LED to light

green.

If the Power LED does not light, press

the Power On/Off button.

Wait for the WiFi LED to light blue.

3. Check the DSL LED.

If the modem router is connected to

a DSL service, the DSL LED lights

green.

4. Connect a computer.

You can use an Ethernet cable or connect with

WiFi.

To connect with WiFi, use the WiFi network name

and password on the product label.

Note: If the computer is set to a static or fixed

IP address (this setting is uncommon), make sure

to change the computer to obtain an IP address

automatically from the modem router through DHCP,

or change the IP address of the computer to a static or

fixed IP address in the 192.168.0.2–192.168.0.254

range.

5. Log in to the modem router.

Launch a web browser.

NETGEAR genie displays.

If you do not see genie, enter

www.routerlogin.net in the address

field of the web browser. When

prompted, enter admin for the user

name and password for the password.

NETGEAR genie determines

your Internet connection. If the

modem router successfully connects to

the Internet, the Internet LED lights

green.

6. Get the genie app.

Download the free genie app from

www.NETGEAR.com/genie.

Easily share media, files, and printers

on the network from your smartphone,

tablet, or laptop.

7. Get the user manual.

You can get the user manual online at

http://downloadcenter.netgear.com

or through a link in the product’s user

interface.

Ethernet cable

ADSL or VDSL

Internet

Cable or ﬁber modem

Power adapter

You can use this diagram to connect your modem router or follow the detailed instructions in this booklet.

DSL splitter

Ethernet cable

(not included)

Modem router

Cable or ﬁber

Internet

Phone cable

(not included)

Front and Side Panels

The status LEDs and buttons on the modem router are shown in the

following figure.

Back Panel

The connections and buttons on the rear panel of the

modem router are shown in the following figure.

WPS button

WiFi button

USB 2.0 port

Power LED

Internet LED

WiFi LED

USB port LED

DSL LED

Internet port

Reset

button Power On/O

button

Power connector

USB 2.0 port

DSL port

Ethernet ports 1–4

Additional Information for DSL Service

Make sure that your DSL service (ADSL or VDSL) is active before

you install the modem router. You need the following information to

install your modem router and connect to the Internet:

• DSL user name and password. This information is included

in the welcome letter your DSL Internet service provider (ISP)

sent you when you signed up for your service.

• Your telephone number or DSL account number. If you do

not use voice service, you can use your DSL account number

instead.

If you do not know or cannot locate your DSL user name and

password, call your DSL ISP.

Note: If your provider says that they do not support NETGEAR

services, tell them that you need only your DSL user name and

password; you do not need support.

Install Your Modem Router

Make sure that your Internet service is active before you install

your modem router.

¾To install your modem router:

1. Connect the modem router to a DSL service (ADSL or VDSL) or

a cable or fiber modem.

To connect the modem router to a DSL service (ADSL or VDSL):

a. Install the DSL splitter between your phone line and a

phone.

b. Use the phone cable to connect the DSL splitter to the DSL

port on the modem router.

ADSL or VDSL

Internet

DSL splitter

Phone cable

Modem router

Phone cable

(not included)

To connect the modem router to a cable or fiber modem:

a. Unplug your modem’s power, leaving the modem connected

to the wall jack for your Internet service.

If your modem uses a battery backup, remove the battery.

b. Plug in and turn on your modem.

If your modem uses a battery backup, put the battery back

in.

c. With an Ethernet cable, connect your modem to the red

Internet port on your modem router.

2. Add power to the modem router:

a. Connect the power adapter to the modem router and plug

the power adapter into an outlet.

b. Wait for the Power LED to light green.

If the Power LED does not light, press the Power On/Off

button.

Ethernet cable

(not included)

Modem router

Cable or ﬁber

Internet

Cable or ﬁber modem

Power

adapter

Modem router

c. Wait for the WiFi LED to light blue.

If the WiFi LED does not light, press the WiFi On/Off

button .

3. Check the DSL LED.

If the modem router is connected to a DSL service, the DSL

LED lights green.

4. Connect a computer.

You can use an Ethernet cable or connect with WiFi:

• For a wired connection, use the Ethernet cable that came

with the modem router to connect your computer to an

Ethernet port on your modem router.

• To connect with WiFi, use the WiFi settings on the product

label.

Note: If the computer is set to a static or fixed IP address (this

setting is uncommon), either change the computer to obtain an

IP address automatically from the modem router through DHCP,

or change the IP address of the computer to a static or fixed IP

address in the 192.168.0.2–192.168.0.254 range.

Modem router

Cable or ﬁber modem

Ethernet cable

(not included)

Power

adapter

ADSL or VDSL

Internet

DSL splitter

Cable or ﬁber

Internet

Phone cable

Ethernet

cable

5. Launch a web browser.

The first time that you connect to the modem router, the

genie screen displays. Follow the genie steps to connect to the

Internet.

If the genie screen does not display, try the following:

• Close and reopen the browser.

• Make sure that your computer is connected to one of the

four Ethernet ports on the modem router, or that you are

connected to your WiFi network.

• Make sure that the modem router is receiving full power

and that its Power LED is lit.

• If your computer is set to a static or fixed IP address (this

is uncommon), change it to obtain an IP address from the

modem router automatically.

If you still do not see the genie screen, log in to the

modem router so that genie can detect your Internet

connection.

¾To log in to the modem router:

1. Launch a web browser.

2. Enter www.routerlogin.net in the address field of the

browser.

A login screen displays.

3. Enter admin for the user name and password for the

password.

The BASIC Home screen displays. If your Internet connection

is not set up yet, genie automatically detects your Internet

connection.

WiFi Network Name and Password

The preset WiFi network name (SSID) and password (network key)

are unique to your modem router, like a serial number. Because the

modem router automatically uses WiFi security, you don’t need to

set it up. The WiFi settings are on the product label.

NETGEAR recommends that you use the preset WiFi settings

because you can check the product label if you forget them.

NETGEAR genie lets you change these settings. If you do so, write

down the new WiFi settings and store them in a safe place.

You can write the WiFi settings from your product label in this space

for easy reference.

WiFi network name (SSID):

Network key (password):

If you change the WiFi settings, write the new settings here for

easy reference and store this booklet in a safe place.

WiFi network name (SSID):

Network key (password):

Join the WiFi Network

You can either use Wi‑Fi Protected Setup (WPS) or select your WiFi

network and type its password. For help with the WPS button on

your computer or WiFi device, check the instructions or online help

that came with that computer or device. Some older equipment

cannot use WPS.

¾To join the network using WPS:

1. Press the WPS button on the modem router for 3–5 seconds.

The WiFi LED on the modem router blinks blue.

2. Within two minutes, on your computer or WiFi device, press its

WPS button or click its onscreen WPS button.

The WiFi LED on the modem router lights solid blue when the

computer or WiFi device connects to your modem router.

3. Repeat this process to add other computers or WiFi devices.

¾To select your network and enter its password:

1. Open the software utility that manages your WiFi connections

on the computer or WiFi device that you want to connect to

your modem router.

This utility scans for WiFi networks in your area.

2. Find and select your modem router’s WiFi network name (SSID).

The SSID is on the product label.

3. Enter the modem router’s password (or your custom password

if you changed it) and click the Connect button.

The password is on the product label.

4. Repeat Step 1 through Step 3 to add other computers or WiFi

devices.

Autres manuels pour D6400

Table des matières

Autres manuels NETGEAR Modem

NETGEAR

NETGEAR LM1200 Manuel utilisateur

NETGEAR

NETGEAR CM1000 Manuel utilisateur

NETGEAR

NETGEAR CM500V Manuel utilisateur

NETGEAR

NETGEAR C6250 Manuel utilisateur

NETGEAR

NETGEAR CM400 Manuel utilisateur

NETGEAR

NETGEAR DG834GV Guide de l'utilisateur

NETGEAR

NETGEAR MBM621 - 3G HSDPA Ethernet Modem Manuel utilisateur

NETGEAR

NETGEAR LB1121 Manuel utilisateur

NETGEAR

NETGEAR Nighthawk CM1200 Manuel utilisateur

NETGEAR

NETGEAR ATT-340U Manuel utilisateur

NETGEAR

NETGEAR CM500 Manuel utilisateur

NETGEAR

NETGEAR A6200 Manuel utilisateur

NETGEAR

NETGEAR CM600 Manuel utilisateur

NETGEAR

NETGEAR LB2120 Series Manuel utilisateur

NETGEAR

NETGEAR CG834WG Manuel utilisateur

NETGEAR

NETGEAR FVL328 - Cable/DSL ProSafe VPN Firewall... Manuel utilisateur

NETGEAR

NETGEAR XM128U Manuel utilisateur

NETGEAR

NETGEAR LM1200 Manuel utilisateur

NETGEAR

NETGEAR CGD24G Manuel utilisateur

NETGEAR

NETGEAR DG834PN - RangeMax ADSL Modem Wireless... Guide de l'utilisateur

NETGEAR

NETGEAR XM128S Manuel utilisateur

NETGEAR

NETGEAR AC327U Manuel utilisateur

NETGEAR

NETGEAR CM212 Manuel utilisateur

NETGEAR

NETGEAR MBM621 - 3G HSDPA Ethernet Modem Manuel utilisateur

Manuels Modem populaires d'autres marques

Davicom

Davicom DM562AP Manuel utilisateur

EpiValley

EpiValley TATA indicom SXC-1080 Manuel utilisateur

Zte

Zte WiMAX Manuel utilisateur

Intelimax

Intelimax MA-2060 Manuel utilisateur

SMC Networks

SMC Networks D3CM1604V Manuel d'utilisation et d'entretien

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuel utilisateur

Samsung

Samsung AceLink SAM-335A Manuel utilisateur

Enfora

Enfora Enabler-G Guide de configuration rapide

iRZ

iRZ ATM2-232 Manuel utilisateur

Zhone

Zhone 6310 Manuel utilisateur

Paradyne

Paradyne Hotwire 7976 Manuel utilisateur

US Robotics

US Robotics 3453C Manuel utilisateur

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur

Zte

Zte MF823 Manuel utilisateur

Four-Faith

Four-Faith F1403 Manuel utilisateur

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manuel utilisateur

Gemtek

Gemtek WiMAX WIXFBR-103 Manuel utilisateur
