NEC P474W Manuel utilisateur

NEC Display Solutions of America, Inc.

P474W/P474U/P554W/P554U Installation Guide

Desktop and Ceiling Mount Rev 1.0

www.necdisplay.com P474W/P474U/P554W/P554U Page 1 of 9

Contents

Product Description, Lens Specs, Screen/Aspect Ratio

Notes Pg 1

Distance Charts and Formulas Pg 2-3

Ceiling Mount/Desktop Installation Pg 4

Lens Shift Adjustable Range Pg 5

Cabinet Dimensions Pg 6-7

Ceiling Mount Dimensions and Input Panel Pg 8

Control Codes Pg 9

Product Description

Type: 3 panel LCD projector, Dimensions: 16.52”(W) x 5.54”(H) x 12.95”(D)

0.64 p-Si TFT w/MLA Weight: 10.6 lbs

Resolution: P474W: 1280 x 768 (16:10) Brightness: P474W: 4700 Lumens

P474U: 1920 x 1200 (16:10) P474U: 4700 Lumens

P554W: 1280 x 800 (16:10) P554W: 5500 Lumens

P554U: 1920 x 1200 (16:10) P554U: 5500 Lumens

Fan Noise: 39 dB / 33dB @ 1 meter

Power Consumption: P474W: 418W (max) BTU’s: P474W: 1426.3 BTU/hour (max)

P474U: 424W (max) P474U: 1446.7 BTU/hour (max)

P554W: 448W (max) P554W: 1528.6 BTU/hour (max)

P554U: 460W (max) P554U: 1559.3 BTU/hour (max)

Network Ready, integrated wired and wireless adapter

Manual: Lens Shift, Horizontal & Vertical /Zoom/ Focus

Lens Specifications

Throw Ratio: P474W/P554W: 1.2 –2.1:1 (for 100” diagonal) Focal Length: 17.4mm –29.0mm

P474U/P554U: 1.2 –2.0:1 (for 100” diagonal) 17.2mm –27.7mm

Offset Angle: 4.8° - 8.0° (for 100” diagonal) F/#: 1.7 –2.2

1.5 –2.1

Screen Sizes: 30” - 300” diagonal Manual Focus/Manual Zoom/Manual Lens Shift

Screen/Aspect Ratio

4:3, 16:9 and 16:10 screens are fully supported with proper aspect ratio control for both type sources using NEC developed scaling

technology. Menu selections have settings for each screen type and aspect ratio control for each source type.

Notes

For screen sizes not indicated on the projection tables, use the formulas below.

If the figures on the tables do not match the results of formulas, use the figures in the table..

Distances are in inches, for millimeters multiply by 25.4.

Distances may vary 5%.

NEC Display Solutions of America, Inc.

P474W/P474U/P554W/P554U Installation Guide

Desktop and Ceiling Mount Rev 1.0

www.necdisplay.com P474W/P474U/P554W/P554U Page 2 of 9

Formulas: 16:10 Aspect Ratio (P474W/P554W—WXGA)

The Projection Formulas use the image width for calculation. Image width is the same for all aspect ratios, only vertical image size

varies. For proper projector placement, determine the image width for a desired screen size. Use the Screen Formulas below to

calculate all screen dimensions. Plug in the image width for “W” in the Projection Formulas.

Refer to the diagrams and charts for popular screen sizes on page 4:

16:10 Screen Formulas:

W = H x 16/10

H = W x 10/16

Screen Diagonal = W x 18.868/16

Projection Formulas:

B(max) = 0.347W

B (min) = 0

C(wide) = 1.263W –3.138

C (tele) = 2.264W –3.138

D (max) = -0.053W

D (min) = 0.313W

α(wide) = tanˉ¹ (B/C(wide))

α(tele) = tanˉ¹ (B/C(tele))

Lens Shift Max (Right) = 0.15W

Lens Shift Max (Left) = 0.-15W

Note: For screen sizes not indicated on the projection

tables, use the formulas on page 1.

Distance Charts

The following shows the proper relative positions of the projector and screen. Refer to the table to determine the position of installation.

Distances are in inches. For millimeters multiply by 25.4.

Diagonal Width(W) Height (H)

Max

(Right)

Max

(Left)

inches inches inches

57 48 30 17 - 0 57 -106 -2 -15 16.2 - 9.0 7.2 - -7.2

66 56 35 19 - 0 68 -124 -2 -18 16.0 - 8.9 8 - -8

68 58 36 20 - 0 70 -127 -2 -18 16.0 - 8.9 9 - -9

75 64 40 22 - 0 78 -142 -2 -20 16.0 - 8.9 10 - -10

79 67 42 23 - 0 82 -149 -2 -21 15.9 - 8.9 10 - -10

85 72 45 25 - 0 88 -160 -3 -23 15.9 - 8.9 11 - -11

92 78 49 27 - 0 96 -174 -3 -25 15.8 - 8.9 12 - -12

98 83 52 29 - 0 102 -185 -3 -26 15.8 - 8.9 12 - -12

102 86 54 30 - 0 106 -192 -3 -27 15.8 - 8.9 13 - -13

111 94 59 33 - 0 116 -211 -3 -30 15.8 - 8.8 14 - -14

113 96 60 33 - 0 118 -214 -3 -30 15.8 - 8.8 14 - -14

123 104 65 36 - 0 128 -232 -4 -33 15.7 - 8.8 16 - -16

125 106 66 37 - 0 130 -236 -4 -33 15.7 - 8.8 16 - -16

147 125 78 43 - 0 154 -279 -4 -39 15.7 - 8.8 19 - -19

149 126 79 44 - 0 157 -283 -4 -40 15.7 - 8.8 19 - -19

213 181 113 63 - 0 225 -406 -6 -57 15.6 - 8.8 27 - -27

255 216 135 75 - 0 270 -486 -8 -68 15.5 - 8.8 32 - -32

270 229 143 79 - 0 286 -515 -8 -72 15.5 - 8.8 34 - -34

300 254 159 88 - 0 318 -573 -9 -80 15.5 - 8.8 38 - -38

max - min

inches

Screen Size (16:10)

inches

wide - tele

inches

degrees

inches

max - min

Lens Shift

wide - tele

NEC Display Solutions of America, Inc.

P474W/P474U/P554W/P554U Installation Guide

Desktop and Ceiling Mount Rev 1.0

www.necdisplay.com P474W/P474U/P554W/P554U Page 3 of 9

Formulas: 16:10 Aspect Ratio (P474U/P554U—WUXGA)

The Projection Formulas use the image width for calculation. Image width is the same for all aspect ratios, only vertical image size

varies. For proper projector placement, determine the image width for a desired screen size. Use the Screen Formulas below to

calculate all screen dimensions. Plug in the image width for “W” in the Projection Formulas.

Refer to the diagrams and charts for popular screen sizes on page 4:

16:10 Screen Formulas:

W = H x 16/10

H = W x 10/16

Screen Diagonal = W x 18.868/16

Projection Formulas:

B(max) = 0.347W

B (min) = 0

C(wide) = 1.238W –1.818

C (tele) = 1.999W –1.727

D (max) = -0.053W

D (min) = 0.313W

α(wide) = tanˉ¹ (B/C(wide))

α(tele) = tanˉ¹ (B/C(tele))

Lens Shift Max (Right) = 0.15W

Lens Shift Max (Left) = 0.-15W

Note: For screen sizes not indicated on the projection

tables, use the formulas on page 1.

Distance Charts

The following shows the proper relative positions of the projector and screen. Refer to the table to determine the position of installation.

Distances are in inches. For millimeters multiply by 25.4.

Diagonal Width(W) Height (H)

Max

(Right)

Max

(Left)

inches inches inches

57 48 30 17 - 0 58 -94 -2 -15 16.1 - 10.0 7.2 - -7.2

66 56 35 19 - 0 68 -110 -2 -18 16.1 - 10.0 8 - -8

68 58 36 20 - 0 69 -113 -2 -18 16.0 - 10.0 9 - -9

75 64 40 22 - 0 77 -126 -2 -20 16.0 - 10.0 10 - -10

79 67 42 23 - 0 81 -133 -2 -21 16.0 - 10.0 10 - -10

85 72 45 25 - 0 87 -142 -3 -23 16.0 - 10.0 11 - -11

92 78 49 27 - 0 95 -155 -3 -25 15.9 - 10.0 12 - -12

98 83 52 29 - 0 101 -165 -3 -26 15.9 - 9.9 12 - -12

102 86 54 30 - 0 105 -171 -3 -27 15.9 - 9.9 13 - -13

111 94 59 33 - 0 115 -187 -3 -30 15.9 - 9.9 14 - -14

113 96 60 33 - 0 117 -190 -3 -30 15.9 - 9.9 14 - -14

123 104 65 36 - 0 127 -206 -4 -33 15.9 - 9.9 16 - -16

125 106 66 37 - 0 129 -209 -4 -33 15.9 - 9.9 16 - -16

147 125 78 43 - 0 153 -248 -4 -39 15.8 - 9.9 19 - -19

149 126 79 44 - 0 155 -251 -4 -40 15.8 - 9.9 19 - -19

213 181 113 63 - 0 222 -360 -6 -57 15.8 - 9.9 27 - -27

255 216 135 75 - 0 266 -430 -8 -68 15.8 - 9.9 32 - -32

270 229 143 79 - 0 281 -456 -8 -72 15.8 - 9.9 34 - -34

300 254 159 88 - 0 313 -507 -9 -80 15.7 - 9.9 38 - -38

degrees

inches

max - min

Lens Shift

wide - tele

max - min

inches

Screen Size (16:10)

inches

wide - tele

inches

NEC Display Solutions of America, Inc.

P474W/P474U/P554W/P554U Installation Guide

Desktop and Ceiling Mount Rev 1.0

www.necdisplay.com P474W/P474U/P554W/P554U Page 4 of 9

Ceiling Mounted

Desktop

Shift Range

Screen Center

0.1H

Lens Offset From Mount Pipe

6.25

5.34

2.48

Shift Range

Screen Center

NEC Display Solutions of America, Inc.

P474W/P474U/P554W/P554U Installation Guide

Desktop and Ceiling Mount Rev 1.0

www.necdisplay.com P474W/P474U/P554W/P554U Page 5 of 9

Lens Shift Adjustable Range

Lens Shift Range for Desktop and Ceiling Mount Application

The diagram below shows the location of the image position in the lens for the P474W/P555W. The P474W/P554W has a maximum

horizontal lens shift range of +/- 15% and a maximum vertical lens shift of + 55%. The lens can be shifted within the shaded area

as shown using the normal projection position as a starting point.

Lens Shift Range for Desktop and Ceiling Mount Application

The diagram below shows the location of the image position in the lens for the P474U/P554U. The P474U/P554U has a maximum

horizontal lens shift range of +/- 25% and a maximum vertical lens shift of + 62%. The lens can be shifted within the shaded area

as shown using the normal projection position as a starting point.

Note: Projector is set out of the box at center position, which is how it is depicted above.

(H: width of projected image, V: height of projected image)

NEC Display Solutions of America, Inc.

P474W/P474UU/P554W/P554U Installation Guide

Desktop and Ceiling Mount Rev 1.0

www.necdisplay.com P474W/P474U/P554W/P554U Page 6 of 14

Cabinet Dimensions

The following diagrams show the cabinet dimensions for the P474W/ P474U/P554W/P554U.

Dimensions are in inches. For millimeters multiply by 25.4.

12.67

12.95

16.52

2.49

2.69

5.23

5.54

2.8

Intake Filter

Speaker

Exhaust

Lamp

NEC Display Solutions of America, Inc.

P474W/P474UU/P554W/P554U Installation Guide

Desktop and Ceiling Mount Rev 1.0

www.necdisplay.com P474W/P474U/P554W/P554U Page 7 of 14

Cabinet Dimensions

5.11

7.67

6.88

7.26 7.26

0.2

For CeilingMount

(4) M4 x 8mm

1.86

5.93

NEC Display Solutions of America, Inc.

P474W/P474UU/P554W/P554U Installation Guide

Desktop and Ceiling Mount Rev 1.0

www.necdisplay.com P474W/P474U/P554W/P554U Page 8 of 14

Input Panel

Control Panel

NEC Display Solutions of America, Inc.

P474W/P474UU/P554W/P554U Installation Guide

Desktop and Ceiling Mount Rev 1.0

www.necdisplay.com P474W/P474U/P554W/P554U Page 9 of 14

PC Control Codes

Function Code Data

POWER ON 02H 00H 00H 00H 00H 02H

POWER OFF 02H 01H 00H 00H 00H 03H

INPUT SELECT Computer 02H 03H 00H 00H 02H 01H 01H 09H

INPUT SELECT HDMI1 02H 03H 00H 00H 02H 01H A1H A9H

INPUT SELECT HDMI2 02H 03H 00H 00H 02H 01H A2H AAH

INPUT SELECT Video 02H 03H 00H 00H 02H 01H 06H 0EH

INPUT SELECT Computer 02H 03H 00H 00H 02H 01H 01H 09H

INPUT SELECT HDBaseT 02H 03H 00H 00H 02H 01H BFH C7H

PICTURE MUTE ON 02H 10H 00H 00H 00H 12H

PICTURE MUTE OFF 02H 11H 00H 00H 00H 13H

SOUND MUTE ON 02H 12H 00H 00H 00H 14H

SOUND MUTE OFF 02H 13H 00H 00H 00H 15H

AUTO ADJUST 02H 0FH 00H 00H 02H 05H 00H 18H

Cable Connection

Communication Protocol:

Baud Rate: 38400 bps (for cable lengths longer than 20’, it is recommended changing to 9600 bps in setup menu)

Data Length: 8 bits

Parity: No Parity

Stop Bit: One bit

X on/off: None

Communications: Full duplex

PC Control Connector (D-Sub 9P)

NOTE 1 : Pins 1, 4, 6, and 9 are used inside the projector.

NOTE 2: For long cable runs it is recommended to set communication speed within the projector to 9600 bps.

NOTE 3: Jumper “Request to Send” and “Clear to Send” together on both ends of the cable to simplify cable connection.

1 2 3 4 5

6 7 8 9

To GND of PC

To RxD of PC

To TxD of PC

To CTS of PC

To RTS of PC

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels NEC Projecteur

NEC

NEC NP41 - TECHNISCHE DATEN Manuel utilisateur

NEC

NEC GT1150 Series Manuel utilisateur

NEC

NEC V230X Manuel utilisateur

NEC

NEC NEC PH1400U Manuel utilisateur

NEC

NEC NP1250 Series Manuel utilisateur

NEC

NEC Nighthawk SX 4000D Manuel utilisateur

NEC

NEC WT610 Series Manuel utilisateur

NEC

NEC M403W Manuel utilisateur

NEC

NEC MT1065 - MultiSync XGA LCD Projector Manuel utilisateur

NEC

NEC NP60 - CEILING PLATE Manuel utilisateur

NEC

NEC VT45 Manuel utilisateur

NEC

NEC VT695 Mode d'emploi

NEC

NEC NP-PX700W Manuel utilisateur

NEC

NEC VT37 Manuel utilisateur

NEC

NEC VT660K Manuel utilisateur

NEC

NEC WT600 Series Manuel utilisateur

NEC

NEC NP500W Manuel utilisateur

NEC

NEC NC900C-A Manuel utilisateur

NEC

NEC NP215 Series Manuel utilisateur

NEC

NEC NP100 - SVGA DLP Projector Manuel utilisateur

NEC

NEC M402W Manuel utilisateur

NEC

NEC V311X Manuel utilisateur

NEC

NEC NP-UM352W Manuel utilisateur

NEC

NEC NP-UM330W Series Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur

Asus

Asus ZenBeam Latte Manuel utilisateur
