Nauticam NA-D850 Manuel utilisateur
1
2
F
ORWARD
Thank you for your purchase of a NAUTICAM housing.
At NAUTICAM, we pride oursel es in the ability to recognise the requirements of professional
as well as amateur underwater photographers and fulfill them through the inno ati e designs
of our products. We stri e to achie e a high le el of user-friendliness by allowing stress-free
installation and easy operation of all important functions of the camera.
Each housing is indi idually inspected and water pressure tested to ensure optimum quality.
Please read this manual carefully before using the housing, this will maximise its performance
as well as its lifetime.
The illustrations in this manual may differ from the actual product.
3
T
ABLE OF
C
ONTENTS
Warranty ……………………………………………………………………………………………………………. 4
Precautions ………………………………………………………………………………………………………… 5
Package Contents ………………………………………………………………………………………………. 7
Specifications …………………………………………………………………………………………………….. 8
Identification of Parts ………………………………………………………………………………………… 9
Opening and Locking the Housing ……………………………………………………………………… 14
Preparation of the Housing ………………………………………………………………………………… 16
Installing the Camera …………………………………………………………………………………………. 23
Shooting Tips …………………………………………………………………………………………………….. 27
Mounting the Port ……………………………………………………………………………………………… 28
Changing the Viewfinder ……………………………………………………………………………………. 31
Care and Maintenance ………………………………………………………………………………………. 33
Optional Accessories ………………………………………………………………………………………….. 34
4
W
ARRANTY
All NAUTICAM Products are warranted against any material and manufacturing defects for two years from
the date of purchase for consumer use. Please fill in the warranty cards shipped with our housings and
iewfinders at the time of sale and return them to your point of purchase within a month. If we do not
recei e the completed warranty card for a particular product, the warranty period would be assumed to
begin from the day that the product is shipped from our facility. This warranty only applies to products
purchased from authorised NAUTICAM dealers and does not extend beyond the original retail purchaser.
To return your product for ser ice, please contact your regional authorized ser ice centre(s). Please note
that this warranty only applies when the product is purchased in the territory where the ser ice centre is
located.
NAUTICAM accepts no liability for any damage to and defects in the housing caused by improper use and/or
poor maintenance; it is the responsibility of the owner to carefully follow the instructions in our manuals.
NAUTICAM does not hold responsibility for damage, of any nature, to any equipment used with and/or
placed within our products.
NAUTICAM accepts no liability for any loss of captured images or the inability to capture images e en if it is
due to the malfunctioning of our products.
Unauthorised modifications and/or repairs of our products will automatically in alidate the warranty.
5
P
RECAUTIONS
•A water-tight test without the camera inside the housing is highly recommended when
using the system for the first time and after the changing of port and O-ring(s).
•Do not use lubricants from other brands with the silicone rubber O-ring on this housing,
only use the lubricant pro ided by NAUTICAM.
•Discontinue use immediately should you notice any leakage.
•Store the housing in a robust, shock-proof container during transportation; a oid
transporting with any equipment, such as a camera, inside the housing.
•When tra elling by air, do not close the housing as this may lead to a pressure difference
between the atmosphere and inside the housing.
•Care must be taken when opening the housing, as pressure may build up inside the
housing which increases the opening force.
6
•Do not open the product in a wet or sandy en ironment. Protect the interior from
moisture and debris in order to pre ent malfunction or leakage.
•Do not store the product in an en ironment of high humidity.
•Do not lea e the housing and the monitor in direct sunlight for prolonged periods.
•Keep out of reach of children, failure to do so could result in injury.
•Defecti e products should be shipped to our distributors for ser ice, unauthorized
disassembling and/or modifications could result in malfunction or leakage.
7
P
ACKAGE
C
ONTENTS
•NA-D850 housing
•Spare silicone rubber O-ring for housing
•O-ring remo er
•CR2032 battery
•Lubricant
•Set of Allen keys
•Instruction manual
8
I
DENTIFICATION OF
P
ARTS
Construction
Housing body: Aluminium alloy
Surface treatment: Hard anodised
Display window: Abrasion resistant polycarbonate
Dimensions
Width: 360mm
Height: 195mm
Depth: 135mm
Weight Approx. 3.07kg
Buoyancy Slightly negati e
Depth rating 100 metres
Port mount N120
Compatible camera Nikon D850 Camera
Vacuum system battery CR 2032 x1pc (operating time: approx. 350hrs)
Flash trigger battery CR 2032 x2pcs (operating time: approx. 50000 flashes)
Compatible strobes
(Manual triggering only)
INON: Z240 type 4, D2000 type 4, S2000
Sea&Sea: YS-D2, YS-D1, YS-01
9
I
DENTIFICATION OF
P
ARTS
Port alignment index
Optical bulkhead
Lens release button
Port lock le er
Port lock safety button
On/off switch
10
Focus mode selector
Release mode dial
Flash up/Flash mode/Flash
compensation button
AF mode le er
*
Handle
s
are
not displayed
Zoom/focus knob
M16 accessory port
Zoom/ focus gear
disengagement le er
M5/M10 threaded hole
Fn2 le er
Playback le er
Housing lo
ck
safety button
See P.13
