CALIBRATION PROCEDURE

SCXI -1503

This document contains information for verifying and adjusting the SCXI-1503 module using

NI-DAQmx 8.1 or later. For more information about calibration, visit ni.com/calibration.

Contents

Software Requirements........................................................................................................................ 1

Documentation Requirements.............................................................................................................. 2

Calibration Interval .............................................................................................................................. 2

Test Equipment .................................................................................................................................... 3

Test Conditions .................................................................................................................................... 3

Calibration Procedures......................................................................................................................... 4

Initial Setup.................................................................................................................................. 5

Self-Calibration............................................................................................................................ 8

MAX .................................................................................................................................... 8

Verification .................................................................................................................................. 8

Verifying the Analog Input.................................................................................................. 8

Verifying the Excitation Current ......................................................................................... 11

Adjustment................................................................................................................................... 11

Adjusting the Analog Input.................................................................................................. 12

Adjusting the Excitation Current ......................................................................................... 14

Where to Go for Support ..................................................................................................................... 15

Software Requirements

Calibrating the SCXI-1503 requires installing NI-DAQmx 8.1 or later on the calibration system.

You can download NI-DAQmx from ni.com/downloads. NI-DAQmx 8.1 or later supports

self-calibration and external calibration in the LabVIEW, LabWindows/CVI, C/C++, C#, and

Visual Basic .NET application development environments (ADEs). When you install NI-DAQmx 8.1 or

later, you only need to install support for the ADE that you intend to use.

™

ni.com/manuals

DeutschFrançais

SCXI-1503 Calibration Procedure 2 ni.com

Documentation Requirements

For information about NI-DAQmx, and the SCXI-1503 module and SCXI-1306 terminal block, consult

the following documents:

•SCXI Quick Start Guide—provides instructions for installing and configuring SCXI chassis and

modules.

•SCXI-1503 User Manual (includes specifications)—includes detailed information and published

specifications for the SCXI-1503.

•SCXI-1306 Terminal Block Installation Guide—includes detailed information and published

specifications for the SCXI-1306.

•NI-DAQmx Help—includes information about creating applications that use NI-DAQmx.

•NI-DAQmx C Reference Help—includes information about the functions in the driver.

You can find the latest versions of the documentation at ni.com/manuals.

Calibration Interval

National Instruments recommends a calibration interval of one year for the SCXI-1503. You should

adjust the recommended calibration interval based on the measurement accuracy demands of your

application.

©National Instruments 3 SCXI-1503 Calibration Procedure

Test Equipment

National Instruments recommends using the equipment in Table 1 for adjusting and verifying the

SCXI-1503.

Test Conditions

The following setup and environmental conditions are required to ensure the SCXI-1503 meets

published specifications.

• Keep connections to the module as short as possible. Long cables and wires act as antennae, which

can pick up extra noise that affects measurements.

• Verify that all connections to the calibration system are secure.

• Maintain an ambient temperature of 25 ±10 °C. The SCXI-1503 module temperature will be

greater than the ambient temperature. If you plan to operate the SCXI-1503 at a specific

temperature outside this range, calibrate the module at that temperature.

• Keep relative humidity below 80%.

Table 1. Recommended Equipment

Equipment

Recommended

Model

Parameter

Measured Minimum Requirements

Calibrator Fluke 5500A* Analog Input If this instrument is

unavailable, use a

calibrator that is accurate to

10 ppm (5 digits).

DMM PXI-4071 Excitation Current

Analog Input

If this instrument is

unavailable, use a

multiranging 7½ digit

DMM.

SCXI Chassis SCXI-1000 — —

DAQ Device NI PCI(e)/PXI(e) E, M

or X Series Device

—16-bit DAQ device

that is supported by

NI-DAQmx 8.1 or later.

Terminal Block Connection

Accessory

SCXI-1306 — —

Rear Connection Accessory SCXI-1349 — —

Terminal Accessory, 50-pin CB-50 — —

Ribbon Cable, 50-Pin NB1 — —

Cable between SCXI-1349

and E Series DAQ devices

SH68-68-EP — —

Cable between SCXI-1349

and M Series or X Series

DAQ devices

SHC68-68-EPM — —

* If using the Fluke 5500A calibrator, you must have the Fluke Fl5xmcal driver installed on the test computer.

SCXI-1503 Calibration Procedure 4 ni.com

• Allow a warm-up time of at least 30 minutes to ensure that the measurement circuitry is at a stable

operating temperature.

• Use shielded copper wire for all cable connections to the SCXI-1306 terminal block. Use

twisted-pair wire to eliminate noise and thermal offsets.

• Ensure that the SCXI chassis empty slots contain front and rear filler panels.

• Plug the SCXI chassis, computer, and the instrument standard into the same power strip to avoid

ground loops.

Calibration Procedures

The calibration process includes the following steps:

1. Initial Setup—Install the module and configure it in Measurement & Automation Explorer (MAX).

2. Self-Calibration—Adjust the self-calibration constants of the module.

3. Verification—Verify the existing operation of the module. This step confirms whether the module

is operating within the published specifications prior to adjustment.

4. Adjustment—Adjust the calibration constants of the module. The adjustment procedure

automatically stores the calibration date on the EEPROM. Go to ni.com/calibration for

information about returning a module to NI for a factory calibration.

5. Reverification—Repeat the verification procedure to ensure that the module is operating within the

published specifications after adjustment.

These procedures are described in more detail in the following sections.

©National Instruments 5 SCXI-1503 Calibration Procedure

Initial Setup

Refer to the DAQ Getting Started Guides and the SCXI Quick Start guide for information about how to

install the software and hardware, and how to configure the module in MAX. Figure 1 shows a typical

SCXI setup for calibration using an NI PCI(e) DAQ device.

Figure 1. Typical Setup for Verification and Adjustment Using an NI PCI(e) DAQ Device

1 SCXI-1306 Terminal Block

2 SCXI-1503 Module

3 SCXI-1000 Chassis

4 SCXI-1349 Adapter

5 SH68-68 EP Cable (for E Series DAQ Device)

SHC68-68 EPM Cable (for M or X Series DAQ Device)

6 Test Computer, with NI PCI(e) DAQ Device

7DMM

8Calibrator

9 Calibrator to SCXI-1306 Wiring

10 CB-50 to DMM Wiring

11 CB-50 Terminal Accessory

12 NB1 Ribbon Cable

+10.0000208 V

+10.0000001 V DC

DCV ACVOHM DCI ACI FREQ

Local



Auto

Cal

Auto

Zero

Trig

Recall

State

NPLC

Offset

Comp

NRdg/

Trig

Store

State

Off

7.000

kHz

SCXI 1100

2468 1012 14 16 18 20 20 24 26 28 30 32 34 36 38 40 42 44 46 48 50

13 5 7 911131517 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49

ADDRESS

SCXI-1503 Calibration Procedure 6 ni.com

Figure 2 shows a typical SCXI setup for calibration using the NI PXI(e) DAQ device.

Figure 2. Typical Setup for Verification and Adjustment Using an NI PXI(e) DAQ Device

1. Power off the SCXI-1000 chassis.

2. Insert the SCXI-1503 into any available SCXI-1000 chassis slot.

Note If you are using an NI PCI(e) DAQ device, connect the SCXI-1349 to the NI PCI(e) DAQ

device using an SHC68-68 cable.

Note If you are using an NI PXI(e) DAQ device rather than an NI PCI(e) DAQ device, refer to

Figure 2 to make your connections.

1 SCXI-1306 Terminal Block

2 SCXI-1503 Module

3 SCXI-1000 Chassis

4 SCXI-1349 Adapter

5 SHC68-68 EPM Cable

6 PXI Chassis

7DMM

8 Calibrator

9 Calibrator to SCXI-1306 Wiring

10 CB-50 to DMM Wiring

11 CB-50 Terminal Accessory

12 NB1 Ribbon Cable

+10.0000208 V

+10.0000001 V DC

DCVACV OHMDCIACIFREQ

Local



Auto

Cal

Auto

Zero

Trig

Recall

State

NPLC

Offset

Comp

NRdg/

Trig

Store

State

Off

7.000

kHz

SCXI 1100

2468101214 16 18 20 20 24 26 28 30 32 34 36 38 40 42 44 46 48 50

13 5 7 911 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49

NI PXIe-1062Q

ADDRESS

NATIONAL

INSTRUMENTS

©National Instruments 7 SCXI-1503 Calibration Procedure

3. Ensure that all of the SCXI-1306 configuration switches are switched to the off position, as shown

in Figure 3.

Figure 3. SCXI-1306 Switch Diagram

4. Install the SCXI-1306 on the SCXI-1503 DUT.

5. Power on the SCXI-1000 chassis.

1 Configuration Switches (shown in Off position) 2 Switch Legends 3 Ground Lug

1 2 1 1 2 1

ON = Closed

IEX+/AI+

IEX–/AI–

Ch X

IEX+

AI+

AI–

IEX–

IEX+

AI+

AI–

IEX–

CH 0CH 1

CH 2CH 3

CH 4CH 5

CH 6CH 7

CH 9CH 8

CH 11CH 10

CH 13CH 12

CH 15CH 14

1 2 34 5 6 7 81 2 34 5 6 7 8

CH 4 CH 5 CH 6 CH 7CH 0 CH 1 CH 2 CH 3CH 12 CH 13CH 14 CH 15

CH 8CH 9 CH 10 CH 11

ON ON

SW 1 SW 2 ON ON

SW 3SW 4

1 2 34 5 6 7 81 2 34 5 6 7 8

1 2 34 5 6 7 8

CH 0 CH 1 CH 2 CH 3

SCXI-1503 Calibration Procedure 8 ni.com

Self-Calibration

The SCXI-1503 includes precise internal circuits and references used during self-calibration to adjust

for any errors caused by short-term fluctuations in the environment.

Note Allow a 30 minute warm-up period before you begin self-calibration.

You can initiate self-calibration from MAX.

MAX

To initiate self-calibration from MAX, complete the following steps:

1. Launch MAX.

2. Select My System»Devices and Interfaces»NI-DAQmx Devices.

Note NI-DAQmx Devices is not displayed when using NI-DAQmx 9.0 or later.

3. Select the DAQ device you are using to digitize the SCXI-1503.

4. Initiate self-calibration in one of the following ways:

•ClickSelf-Calibrate in the upper right corner of the window. If the Self-Calibrate button is

not displayed, click the »button.

• Right-click the module and select Self-Calibrate from the context menu.

5. Select the chassis containing the module you want to calibrate.

6. Select the module that you want to calibrate.

7. Initialize a self-calibration of the module you want to calibrate.

Verification

This section provides instructions for verifying the following SCXI-1503 specifications:

• Analog input.

• Excitation current.

Note Limits in Table 2 are based on the March 2007 edition of the SCXI-1503 User Manual, which

includes the specifications. Refer to ni.com/manuals to determine if there is a more recent edition

of the specifications. If a more recent edition of the specifications is available, recalculate the limits

based upon the latest specifications.

Verifying the Analog Input

Complete the following steps to verify the analog input of the SCXI-1503:

1. Connect the calibrator ± output to all of the SCXI-1306 AI± input channels.

Note Ensure that all switches on the SCXI-1306 are in the off position as shown in Figure 3.

2. Insert the NB1 ribbon cable into the breakout connector on the SCXI-1349.

3. Insert the SCXI-1349 into the SCXI-1503 rear connector.

4. Insert the other end of the NB1 ribbon cable into the CB-50 ribbon cable connector.

©National Instruments 9 SCXI-1503 Calibration Procedure

5. Connect the DMM V+ to pin 3 and DMM V- to pin 4 of the CB-50 terminal accessory. Refer to

Figure 4 for pin locations.

Figure 4. CB-50 Terminal Accessory Wiring Diagram for Connection to DMM

6. Configure an AI voltage channel with an input range of ±10 V for channel ai0 on the

NI PCI(e)/PXI(e) DAQ device.

7. Use DAQmx properties to read the AI dev scaling coefficients of the DAQ device. E Series have

two scaling coefficients while M Series and X Series have four scaling coefficients. Record the

first two scaling coefficients and save the values as a0and a1.

Note The DAQ device scaling coefficients, a0and a1, are the same for each channel on the SCXI

module since the DAQ device multiplexes all SCXI channels to channel ai0 on the DAQ device.

8. Clear the task.

1 To DMM V+

2 To DMM V-

3 NB1 Ribbon Cable Connector

4 CB-50 Top View

5 CB-50 Side View

5048464442403836343230282624222018161412108642

494745434139373533312927252321191715131197531

SCXI-1503 Calibration Procedure 10 ni.com

9. Configure the calibrator to output a DC voltage. Table 2 shows the test point values.

10. Create an AI voltage channel with an input range of ±10 V for one channel on the SCXI-1503.

11. Configure the SCXI-1503 input channel for a finite acquisition with a sample rate of 1000 Hz and

1000 samples per channel.

12. Use DAQmx properties to set a gain of 1.

13. Use DAQmx properties to read the DAQ device scaling coefficients. E Series have two scaling

coefficients while M Series and X Series have four scaling coefficients. Record the first two scaling

coefficients and save the values as b0and b1.

14. Start the task to set the channel MUX to the specified channel.

15. Use the saved device scaling coefficients from the DAQ device, a0and a1from step 7, and the

combined DAQ device and SCXI-1503 module, b0and b1from step 13, to compute the device

scaling coefficients for just the SCXI-1503, c0and c1.

16. Configure the DMM to measure voltage at the CB-50 outputs and take a measurement.

Table 2. Test Point and Limit

SCXI-1503 Gain Test Point Level (V) Lower Limit (V) Upper Limit (V)

1 9 8.991680513 9.008319487

65.993900513 6.006099487

32.996120513 3.003879487

0-0.001659487 0.001659487

-3 -3.003879487 -2.996120513

-6 -6.006099487 -5.993900513

-9 -9.008319487 -8.991680513

100 0.09 0.089898305 0.090101695

0.06 0.059920505 0.060079495

0.03 0.029942705 0.030057295

0-0.0000350949 0.0000350949

-0.03 -0.030057295 -0.029942705

-0.06 -0.060079495 -0.059920505

-0.09 -0.090101695 -0.089898305

c0b0b1

-----– a0

=

c1b1

-----=

Autres manuels pour Module SCXI-1503

Table des matières

Autres manuels National Instruments Unité de contrôle

National Instruments

National Instruments NI 6013 Guide de démarrage rapide

National Instruments

National Instruments Phase Matrix PXI-1420 Manuel utilisateur

National Instruments

National Instruments SLSC-12251 Manuel utilisateur

National Instruments

National Instruments NI 9425 Manuel utilisateur

National Instruments

National Instruments PXIe-8522 Manuel utilisateur

National Instruments

National Instruments Isolated Current Output Module SCC-CO20 Manuel utilisateur

National Instruments

National Instruments 9225 Manuel

National Instruments

National Instruments NI PXIe-4140 Manuel utilisateur

National Instruments

National Instruments NI 9870 Manuel utilisateur

National Instruments

National Instruments NI USB-9201 Manuel utilisateur

National Instruments

National Instruments NI 9205 Manuel utilisateur

National Instruments

National Instruments NI PCIe-1430 Manuel utilisateur

National Instruments

National Instruments NI 9262 Manuel utilisateur

National Instruments

National Instruments SCXI-1104 Manuel utilisateur

National Instruments

National Instruments PXIe-4357 Manuel

National Instruments

National Instruments SCXI-1313 Manuel utilisateur

National Instruments

National Instruments PXIe-8245 Manuel utilisateur

National Instruments

National Instruments CFP-TC-120 Manuel utilisateur

National Instruments

National Instruments SCC-LP Series Manuel utilisateur

National Instruments

National Instruments SCC-AI Series Manuel utilisateur

National Instruments

National Instruments SCXI SCXI-1102 Manuel utilisateur

National Instruments

National Instruments NI 9242 Manuel utilisateur

National Instruments

National Instruments NI 9401 Manuel utilisateur

National Instruments

National Instruments SCC-A10 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
