Multitech MultiMobile MT56128ZLX-NT Manuel utilisateur
Owner’sManual
MultiMobileTM
Model#MT56128ZLX-NT&MT56128ZLX-ST
P/N82076503
This publication may not be reproduced, in whole or in part, without prior expressed
written permission from Multi-Tech Systems, Inc. All rights reserved.
Copyright © 1998 by Multi Tech Systems, Inc.
Multi-Tech Systems, Inc. makes no representations or warranties with respect to the
content hereof and specifically disclaims any implied warranties of merchantability or
fitness for any particular purpose. Furthermore, Multi-Tech Systems, Inc. reserves the
right to revise this publication and to make changes from time to time in the content
hereof without obligation of Multi-Tech Systems, Inc. to notify any person or
organization of such revisions or changes.
Record of Revisions
Revision Description
A Manual released at revision level A.
(2/5/98)
B Dial-Up Networking v.1.2 product update added
(4/ 6/98) ISDN CAPI 2.0 product update added
Manual format size changed
Minor editorial, technical, and format changes
C V.90 support, S-Registers and Result Codes added; minor
(7/17/98) editorial and format changes
D Manual revised and reorganized to reflect software/driver changes.
(1/15/99)
TRADEMARKS
Trademarks of Multi-Tech Systems, Inc. are as follows: MultiMobile, Multi-Tech, and
the Multi-Tech logo. All other trademarks are owned by their respective companies.
Multi-Tech Systems, Inc.
2205 Woodale Drive
Mounds View, Minnesota 55112 U.S.A.
(612) 785-3500 or (800) 328-9717
U. S. FAX 612-785-9874
Fax-Back Service 612-717-5888
Technical Support (800) 972-2439
BBS (612) 785-3702 or (800) 392-2432
Internet Address: http://www.multitech.com
C
C
C
C
C
Contents
Chapter1—Introduction/Description
Features ..................................................................................................... 6
Technical Specifications ............................................................................ 7
Shipping Kit Contents ............................................................................... 9
About This Manual ................................................................................... 9
Chapter2—Hardware/DriverInstallation
Installing PC Card and Drivers/Software ..................................................12
Safety Warnings .......................................................................................12
Windows 95/98 InstallationVCOMM & CAPI ......................................13
Windows 95/98 InstallationNDIS ..........................................................15
Windows NT Installation ..........................................................................16
Customizing the TerminalAdapter (Optional) ...........................................18
Chapter 3—Application Program Interfaces (APIs)
Introduction ..............................................................................................20
VCOMM (Virtual Communications Port) ...................................................21
NDIS (Network Driver Interface Specification) .........................................31
CAPI (Common ISDNApplication Programming Interface) ......................36
Chapter4—Troubleshooting
How can I make sure MultiMobile hardware functions properly? ............54
COM Port and IRQ Conflicts ....................................................................55
Windows 95 COM Port and IRQ Conflicts................................................56
Chapter5—Service,Warranty,Technical Support
Introduction ..............................................................................................58
Limited Warranty ......................................................................................58
On-line Warranty Registration ..................................................................58
Software User LicenseAgreement ............................................................59
Tech Support ............................................................................................60
Service ......................................................................................................61
About the Multi-Tech BBS .......................................................................62
About CompuServe ..................................................................................64
About the Internet ....................................................................................64
About the Multi-Tech Fax-Back System ...................................................64
Appendix
Appendix A: Pin Assignments ..................................................................66
Appendix B: AT Command Summary, S-Register Summary, and Result
Codes Summary ........................................................................................67
Appendix C: Upgrade Procedures ............................................................79
Appendix D: RegulatoryAgency Information ..........................................85
Index
..................................................................................................................94
Chapter 1—Introduction/Description
6 MultiMobile
Chapter 1—Introduction/Description
ongratulations
on your purchase of the MultiMobile ISDN/Modem
PC Card. The MultiMobile (models MT56128ZLX-NT and
MT56128ZLX-ST) is the only multifunction PC Card in the world that
offers seamless connection between digital ISDN lines and analog
telephone lines (PSTN) within one single PC Card.
Its peerless switchable technology integrates both ISDN terminal adapter
(TA) and todays fastest 56K fax/modem technologies. Users can switch
between digital ISDN or analog PSTN connections simply by plugging in
bundled network connection cables. In addition to its unique switchable
ability, the MultiMobile features an ISDN Phone voice capability.
Features
Switchable ISDN line or analog telephone line (PSTN) connection
56K modem or G3 fax connections over both analog telephone and
ISDN lines
Built-in microphone/speakerphone interface for ISDN Phone voice
applications
Options for ISDN S/T-interface or U-interface
Complies with prevalent ISDN software standards such as ISDN AT
commands, NDIS WAN, and CAPI 2.0
Microsoft Plug-and-Play compatible
Menu-driven configuration utility included
C
MultiMobile 7
Chapter 1—Introduction/Description
Technical Specifications
TradeName
MultiMobileTM
Model Numbers:
MT56128ZLX-NT (U-interface)
MT56128ZLX-ST(S/T-interface)
SystemRequirements
Intel 486, Pentium, or above (Pentium strongly recommended)
30 MB free space
One Type II or Type III PCMCIA slot
Windows 95, OSR2, 98 or Windows NT installed
Fax
G3, send and receive
EIA Class 1/Class 2 Fax command set
Modem
V.90, K56flex, V.34+ (33.6 Kbps), V.34 (28.8 Kbps), V.32bis
(14.4 Kbps)
Note: Though this terminal adapter is capable of 56 Kbps download
performance, line impairments, public telephone infrastructure, and
other external technological factors currently prevent maximum 56 Kbps
connections.
V.42/V.42bis, MNPClass 2 to 5 error correction and data compression
ISDNStandards
Basic RateAccess (2B+D)
U-interface: complies with ANSI T1.601
S/T-interface: complies with ITU-T I.430
Protocol: ITU-T Q.921, Q.931, and ETSI NET3
8 MultiMobile
Chapter 1—Introduction/Description
LineRate
64/56 Kbps on 1 B-channel (ISDN data mode)
128/112 Kbps on 2 B-channel (PPP/MP)
56 Kbps on 1 B-channel (modem mode)
16 Kbps on D-channel for signaling
DTERate
Asynchronous, up to 460.8 Kbps (COM port emulation mode)
ISDN Network & Switch Compatibility
National ISDN-1 (NI-1)
AT&T 5ESS Custom
Northern Telecom DMS-100 Custom
DSS1 (Euro-ISDN)
INS-Net 64
B-ChannelProtocols
X.75
V.120
V.110
PPP and Multi-Link Protocol
Async-to-Sync PPP Conversion
56K modem over B-channel
G3 fax over B-channel
Voice over B-channel
Application Program Interfaces
ISDN AT Command Set
CAPI 2.0
NDIS WAN
Operating System Support
Windows 95, OSR2, and 98
Windows NT 4.0
MultiMobile 9
Chapter 1—Introduction/Description
Shipping Kit Contents
One MultiMobile ISDN + Voice Modem 56K
One ISDN U-interface, or S/T-interface, ISDN network connection
cable
One analog fax/modem DAA connection cable
One ISDN phone kit
One ISDN phone cord with RJ-45 plugs
One analog telephone cord with RJ-11 plugs
One Owners Manual
Four 3.5" software/driver program diskettes
(Note: This manual supports 4.0, or later, drivers only.)
RVS-COM Lite
MultiMobile Global Wizard
About This Manual
This manual explains how to install, configure, and use your
MultiMobileTM Multifunction PC card. Manual chapters and appendixes
are as follows:
Chapter1—Introduction/Description
Chapter2—Hardware/DriverInstallation
Chapter 3—Application Program Interfaces (APIs)
Chapter4—Service,Warranty,Technical Support
Appendix A—Pin Assignments
Appendix B—AT Commands, S-Registers, and Result Codes
AppendixC—UpgradeProcedures
AppendixD—Regulatory Information
Index
10 MultiMobile
Chapter 1—Introduction/Description
