Operating Manual
Digital Temperature Transmitter
Digital Temperature Transmitter Page-1
DTW- Digital Temperature Transmitter
DTW-M
1 General (Information, Signs and Abbreviations) 3
2 Transport, Packaging, Storage 3
3 Safety Instructions 4
4 Start-Up, Operation 7
4.1 Function 7
4.2 Before Mounting 7
4.3 Product Label 7
4.4 Mounting 8
5 Electrical Connection 13
5.1 Information 13
5.2 Tools 13
5.3 Auxiliary Power 14
5.4 Maximum Values 14
5.5 Load 14
5.6 Wiring Terminals Assignment 15
6 Configuration 16
7 Troubleshooting 17
8 Maintenance, Dismounting, Return, Cleaning, Disposal 19
9 Technical Data 20
10 Dimensions 26
11 Accessories 27
11.1 Available Accessories 27
11.2 Connection Programming Unit 28
11.3 Configsoft DT 28
11.4 Software Configuration 29
Content
Digital Temperature Transmitter Page-2
DTW-M
Check the device for any damage that may have been caused during transportation.
Report obvious damage immediately!
- These operation instructions contain important information on handling the DTW transmitter.
Working safely requires that all safety instructions and work instructions are observed.
- Skilled personnel must have carefully read and understood the operating instructions prior to beginning
a ny work.
3
-The operating instructions are part of the product and must be kept in the immediate vicinity of the DTW and
readily accessible to skilled personnel at any time.
- Observe the relevant local accident prevention regulations and general safety regulations for the DTW
temperature transmitter range of use.
- If the serial number gets illegible (e. g. by mechanical damage), the retraceability of the device becomes
impossible.
- The temperature transmitters described in this operating manual are carefully designed and manufactured using
state-of-the-art technology. Every component undergoes strict quality inspection in all stages of manufacture.
- The manufacturer's liability is void in the case of any damage caused by using the product contrary to its
intended use, non-compliance with these operating instructions, unauthorised modifications to the DTW or
assignment of insufficiently qualified skilled personnel.
- Norms applied for Ex-protection: EN 60079-0:2012+A11:2013 General Requirements
and EN 60079-11:2012 Intrinsic Safety „i“
- Our company is certified according to ISO 9001:2015
- More information is available under www.mueller-ie.com
- Relevant data sheet: DTW
1 General
Digital Temperature Transmitter Page-3
1.1 For Your Information
1.2 Signs and Abbreviations
!
i
!
Warning!
Noncompliance can cause injuries to persons and/or the demolition of the device. There can be a
danger to life.
Attention!
Noncompliance can cause a faulty operation of the device or lead to property damage.
Information!
Noncompliance can have influence on the operation of the device or cause unintentional reactions of
the device.
Danger!
There is a risk of serious or fatal injury caused by electrical power if the safety instructions are not
complied with.
Danger!
Potential dangerous situation in an area exposed to explosion hazards. Noncompliance can lead to
death or heavy injuries!
Warning!
There is a potential for dangerous situations resulting in burns from hot surfaces or liquids. Please
avoid!
Warning
Danger
Warning
!
Attention!
Damages caused by incorrect handling
Incorrect handling can cause property damage and light injuries.
- Do not use DTW transmitters with visible damage!
Danger
2 Transport, Packaging, Storage
2.1 Transport
DTW-M
Digital Temperature Transmitter Page-4
3 Safety Instructions
3.1 Intended Use of the Product
!
Before installation, commissioning and operation select the appropriate digital DTW temperature
transmitter in terms of function and equipment.
Warning
The device has been designed and built solely for the intended use described here and may only be used
accordingly.
The technical specifications contained in these operating instructions must be observed. Improper handling or
operation of the device outside of its technical specifications requires the device to be taken out of service immediately
and an inspection by the manufacturer.
When the device is transported from a cold into a warm environment, the formation of condensation may cause the
device to malfunction. Before putting it back into operation, wait for the device temperature and the room temperature
to equalise.
The manufacturer shall not be liable for claims of any type based on operation contrary to the intended use.
!
Warning
3.2 Personnel Qualification
For installation and start-up of the DTW the personnel has to be familiar with the relevant regulations and directives of
the country and must have the required qualification. They must have knowledge of measurement and control
technology, have to be acquainted with electric circuits, are capable of carrying out the work described and can
independently recognise potential hazards.
The personnel needs to have the proper training for their work environment and has to comply with the current
regulations for safety at work as prescribed by law!
Working with devices for areas exposed to explosion hazards requires specialist knowledge!
The personnel needs to have knowledge about types of ignition protection, regulations and directives for equipment in
areas exposed to explosion hazards. Depending on operating conditions they need to have the corresponding
knowledge, e. g. of corrosive media.
Risk of injury if qualification is insufficient
Improper handling can result in considerable injuries and damage to equipment.
- The activities described in these operating instructions may only be carried out by skilled personnel who
have the qualifications described below.
- Keep unqualified personnel away from hazardous areas.
iMore safety instructions can be found in the individual chapters.
Allowed storage conditions:
- Storage temperature: -40...+85 °C
- Humidity: 95 % r. h. (condensation allowed)
For longer term storage avoid the following influences:
- Direct sunlight or proximity to hot objects
- Mechanical vibration, mechanical shock (rough deployment)
- Soot, vapour, dust and corrosive gases
If possible, store the device in its original package or an equivalent one
2.3 Storage
Do not remove packaging until just before mounting. Keep the packaging as it will provide optimum protection during
transport (e. g. change in installation site, returns).
2.2 Packaging
2 Transport, Packaging, Storage (Continued)
DTW-M
3 Safety Instructions (Continued)
Digital Temperature Transmitter Page-5
!
!
3.3 Special Hazards
In addition to all standard regulations, the appropriate existing codes or regulations must also be
followed.
If you do not comply with the appropriate regulations, serious injuries and/or damage can occur!
A protection from electrostatic discharge (ESD) is required.
The proper use of grounded work surfaces and personal wrist straps is required when working with
exposed circuitry (PCB, printed circuit boards), in order to prevent static discharge from damaging
sensitive electronic components.
Do not use this instrument in safety or emergency stop devices. Incorrect use of the device can result in
injury.
There is a danger of death caused by electric current.
Upon contact with live parts, there is a direct danger of death.
Electrical instruments may only be installed and connected by skilled electrical personnel.
Operation using a defective power supply unit (e.g. short circuit from the mains voltage to the voltage
output) can result in life-threatening voltages at the device.
Warning
Warning
!
Warning
Danger
3.4 Responsibility of the Operating Body
There is danger to life caused by areas exposed to explosion hazards. Situations leading to death or
heavy injuries are possible.
The instrument is used in the industrial sector. The operatoring body is therefore responsible for legal obligations
regarding safety at work.
The safety instructions within these operating instructions, as well as the safety, accident prevention and
environmental protection regulations for the application area must be maintained.
The operatoring body is obliged to maintain the product label in a legible condition.
The responsibility for classification of zones lies with the operatoring body and not the manufacturer/supplier of the
equipment.
Danger
DTW-M
BVS 15 ATEX E 139 X
IECEx BVS 15.0112X
3 Safety Instructions (Continued)
Digital Temperature Transmitter Page-6
3.5 Ex-Marking and Approval
Danger!
Danger to life caused by loss of explosion protection
Non-compliance with these instructions and their contents can lead to loss of explosion protection.
- Observe the safety instructions and further explosion instructions in these operating instructions.
- Follow the requirements of the ATEX-directive.
- Observe the information given in the applicable type examination certificate and the relevant
country-specific regulations for installation and use in hazardous areas (e.g. IEC 60079-14, NEC,
CEC).
Please make sure to read the operating manual before mounting and start-up of the DTW-transmitter!
Check whether the classification is suitable for the application. Comply with the relevant national regulations.
Model Overview of European Approvals
Danger
II 1G Ex ia IIC T6...T4 Ga
II 1D Ex ia IIIC T135 °C Da
II 2(1)G Ex ia [ia Ga] IIC T6...T4 Gb
II 2(1)D Ex ia [ia Da] IIIC T135 °C Db
For an explanation of the type code,
see data sheet, section Order Code.
Type
Ex-Marking
Ignition Protection Type
DTW head version
DX00XXX01
Intrinsically safe equipment
DTW rail version
DX11XXX01
Intrinsically safe equipment
DTW-M
i
Müller Industrie-Elektronik GmbH - D-31535 Neustadt
Made in Germany
Art.Nr.: 600-00548 DX11XXX01
Tel.: +49 5032 /9672-0
SN.: 0000.11/17-1.0- 000
Input : Pt 100 DIN (3 w)
Range : 0...150 °C PN.: 1A00KOR7U3B
Output : 4...20 mA Tamb: -40...85/70/55 °C / T4/T5/T6
Tamb: 550/650/750 mW / -40...85/70/40 °C
Supply : 10...35 VDC Date : 2017-11
BVS 18 ATEX E012X
II 2(1)G Ex ia [ia Ga] IIC T6...T4 Gb
II 2(1)D Ex ia [ia Da] IIIC T135 °C Db
Next Calibration : 11 / 18 0044
Made in Germany
Art.Nr.: 600-00999
DTW - DX0000001
Tel.: ++49 5032 /9672-0
SN.: 1A00KOR7U3B
2017-11 DC 10...35 V Tamb: -40...85/70/55 °C / T4/T5/T6 II 1G Ex ia IIC T6...T4 Ga
31535 Neustadt am Rübenberge Tamb: 550/650/750 mW / -40...85/70/40 °C II 1D Ex ia IIIC T135 °C Da
Next Cal.: 11 / 18
BVS 18 ATEX E012X
0044
- Check if the DTW transmitter was delivered in complete assembly.
- Inspect the DTW for possible damage during transportation. Should there be any obvious
damage, inform the transport company and supplier immediately.
- Keep the packaging, as it offers optimal protection during transportation.
- Make sure to protect the connecting contacts from damage.
The digital temperature transmitter DTW is a universal measuring transmitter for resistance thermometers and
potentiometers. It is configurable via PC. The device transforms resistance values or relations (potentiometer)
into a proportional current signal. At the same time the sensors are constantly tested to ensure faultless operation.
The temperature transmitter complies with the requirements of:
- Explosion protection (varies with version)
- Electromagnetic compatibility according to NAMUR-recommendation NE21
- Signaling at analog output according to NAMUR-recommendation NE43
- Sensor break signaling according to NAMUR-recommendation NE89 (Corrosion monitoring of sensor
connection)
4 Start-Up, Operation
Digital Temperature Transmitter Page-7
4.1 Function
4.2 Before Mounting
4.3 Product Label (Example)
Art.Nr. : Item number
SN : Serial number
PN : Part number
Rail version DX11XXXXX
Head version DX00XXXXX
iThe product labels as
depicted here are
subject to change and
do not necessarily
represent the final form.
Note: Ex-markings and
type code are always
included.
DTW-M
4 Start-Up, Operation (Continued)
Digital Temperature Transmitter Page-8
4.4 Mounting
i- Check the delivery immediately for completeness and obvious faults.
- If parts are missing or if there are faults, contact the transport company and supplier immediately.
4.4.1 Special Conditions for Safe Use (Ex ia)
Installation in Secure Area
- Mount the transmitter in casing with at least protection level IP20, according to EN/IEC 60529.
- The electrical connections of the casing have to comply to the relevant parts of EN/IEC 60079-11.
- Connection parts or connectors with breaking capability for the intrinsically safe current circuits have to be
arrayed according to the relevant parts of EN/IEC 60079-11.
Installation in Areas Requiring an EPL of Ga (Zone 0), Gb (Zone 1) or Gc (Zone 2)
- Mount the transmitter in casing suitable for mounting in zone 0 or zone 1. The transmitter casing has to
provide at least protection level IP20 according to EN/IEC 60529. Additionally, the casing has to eliminate
electrostatic discharges.
- The electrical connections of the casing have to comply to the relevant parts of EN/IEC 60079-11.
- Connection parts or connectors with breaking capability for the intrinsically safe current circuits have to be
arrayed according to the relevant parts of EN/IEC 60079-11.
Installation in Areas Requiring an EPL of Da (Zone 20) or Db (Zone 21)
- Mount the transmitter in casing suitable for mounting in zone 20 or 21. The transmitter casing has to provide at
least protection level IP6x according to EN/IEC 60079-0. Additionally, the casing has to eliminate electrostatic
discharges.
- The electrical connections of the casing have to comply to the relevant parts of EN/IEC 60079-11.
- Connection parts or connectors with breaking capability for the intrinsically safe current circuits have to be
arrayed according to the relevant parts of EN/IEC 60079-11.
Danger!
Danger to life by explosion!
Working in flammable atmospheres can cause explosion hazards, which may lead to death.
- Conduct set-up work only in areas without explosion hazards!
- In areas with explosion hazards only use DTW-transmitters approved for this specific type of
hazardous area.
Please comply with the approval on the product label!
Gefahr
DTW-M
4 Start-Up, Operation (Continued)
Digital Temperature Transmitter Page-9
4.4.1 Special Conditions for Safe Use (Ex ia, Continued)
Transmitters with ia-marking may also be used in supply circuits of type ib with the same connection parameters.
With this, the entire measuring circuit (including the sensor circuit) is an ib circuit.
DTW-transmitters which were operated with supply circuits of type ib may not be re-used with supply
circuits of type ia.
The external wiring has to be suitable for the temperature range of the end-use application! (max. 85 °C)
The conductor cross section has to be a minimum of 0.14 mm²!
DTW-M
4 Start-Up, Operation (Continued)
Digital Temperature Transmitter Page-10
!
i
4.4.2 Grounding
Property damage by electrostatic charge!
Please observe safety measures according to DIN EN 61340-51/-3 to avoid a electrostatic charge!
During running operation electrostatic charges can occur. Please take actions to avoid electrostatic
discharges on wiring terminals. The discharges can lead to temporary corruption of measurement
values.
- Install DTW head version only in grounded thermometer-heads!
- The connection of a resistance sensor (e. g. Pt100) to the DTW rail version is made with shielded
wiring
- The shielding has to be bonded with the casing of the grounded thermometer.
Only qualified personnel is allowed to work on the electronics.
Grounding DTW Head Version
Install the temperature-transmitter
DTW only in grounded
thermometers!
looped circuit
Connecting Head BSZ
grounded
Table des matières
Autres manuels Muller Émetteur
Manuels Émetteur populaires d'autres marques
Dejero
Dejero EnGo 3x Manuel utilisateur
Rosemount
Rosemount 4600 Manuel utilisateur
Speaka Professional
Speaka Professional 2342740 Manuel utilisateur
trubomat
trubomat GAB 1000 Manuel utilisateur
Teledyne Analytical Instruments
Teledyne Analytical Instruments LXT-380 Manuel utilisateur
Rondish
Rondish UT-11 Manuel utilisateur
