Moxa Technologies EtherDevice EDS-P510A-8PoE Series Manuel

P/N: 1802005100020

Moxa EtherDeviceTM Switch

EDS-P510A-8PoE Series

Hardware Installation Guide

First Edition, January 2013

- 2 -

Overview

The Moxa EDS-P510A-8PoE series switches are Gigabit managed PoE+

Ethernet switches that come standard with eight 10/100BaseT(X),

802.3af (PoE) and 802.3at (PoE+) compliant Ethernet ports and two

combo Gigabit Ethernet ports. The EDS-P510A-8PoE Ethernet switches

provide up to 30 watts of power per PoE+ port in standard mode, and

allow high power output of up to 36 watts for industrial heavy-duty PoE

devices, such as weather-proof IP surveillance cameras with

wipers/heaters, high-performance wireless access points, and rugged IP

phones. The EDS-P510A-8PoE Ethernet switches are highly versatile, and

the SFP fiber ports can transmit data up to 120 km from the device to the

control center with high EMI immunity. The Ethernet switches support a

variety of management functions, including STP/RSTP, TurboRing, Turbo

Chain, PoE power management, PoE device auto-checking, PoE power

scheduling, IGMP, VLAN, QoS, RMON, bandwidth management, and port

mirroring. The EDS-P510A-8PoE series is designed especially for outdoor

harsh environment applications with 3KV surge resistance to keep

continuous reliability of the PoE systems.

Package Checklist

The EDS-P510A-PoE is shipped with the following items. If any of these

items are missing or damaged, please contact your customer service

representative for assistance.

•1 EDS-P510A-8PoE EtherDevice Switch

•Hardware Installation Guide

•CD-ROM with user’s manual and Windows utility

•Moxa product warranty statement

•RJ45 to DB9 console port cable

•Protective caps for unused SFP ports

•DIN-Rail mounting kit (attached to the EDS-P510A-8PoE’s rear panel

by default)

- 3 -

Panel Views of EDS-P510A-8PoE

Front Panel View

Top Panel View

Rear Panel View

1. Power input PWR1 LED

2. Power input PWR2 LED

3. Fault LED

4. MSTR/HEAD LED

5. CPLR/TAIL LED

6. 1000Mbps copper port of the

combo port

7. 100/1000Mbps SFP port of the

combo port

8. Gigabit port speed LED

9. Model name

10.

SmartPoE LED indicator of PoE+

ports

11.

Fast Ethernet port speed LED

12.

10/100Mbps IEEE 802.3af/at

port

13.

Terminal block for digital input

14.

Terminal block for relay output

15.

RS-232 serial console port

16.

DIP switches

17.

Grounding screw

18.

Terminal block for power input 1

19.

Terminal block for power input 2

20.

Screw holes f

or wall mounting kit

21.

DIN rail mounting kit

22.

Heat dissipation vents

- 4 -

Mounting Dimensions (unit = mm)

DIN-Rail Mounting

The aluminum DIN-Rail attachment plate should already be fixed to the

back panel of the EDS-P510A-8PoE when you take it out of the box. If you

need to reattach the DIN-Rail attachment plate to the EDS-P510A-8PoE,

make sure the stiff metal spring is situated towards the top, as shown by

the following figures.

STEP 1

—Insert the top of the

DIN

-Rail into the slot just below

the

stiff metal spring.

STEP 2

—The DIN-Rail attachment

unit will snap into place as shown in

the following illustration.

To remove the EDS-P510A-8PoE from the DIN-Rail, simply reverse Steps

1 and 2 above.

- 5 -

Wall Mounting (Optional)

For some applications, you will find it convenient to mount Moxa

EDS-P510A-8PoE on the wall, as shown in the following illustrations:

STEP 1—Remove the

aluminum DIN

-Rail

attachment plate from the

rear panel

of the

EDS

-P510A -8PoE, and

then attach the wall

mount plates

with M3

screws

, as shown in the

figure

at the right.

STEP 2—Mounting the EDS-P510A-8PoE on the wall

requires 4 screws. Use the EDS

-P510A-8PoE, with wall

mount plates attached, as a guide to mark the correct

locations of the 4 screws. The

heads of the screws

should be less than 6.0 mm in diameter, and the shafts

should be less than 3.5 mm in diameter, as shown in the

figure on at right.

NOTE

Before tightening the screws into the wall, make sure the screw

head and shank size are suitable

by inserting the screw through

one of the keyhole-shaped apertures of the Wall Mounting Plates.

Do not screw the screws in all the way—leave about 2 mm to allow room

for sliding the wall mount panel between the wall and the screws.

STEP 3—Once the screws are

fixed

to the wall, insert the four

screw heads through the wide

parts of the keyhole

-shaped

apertures, and then slide

the

EDS

-P510A-8PoE downwards, as

indicated

in the figure at

the right.

Tighten the four screws for

stability.

- 6 -

Wiring Requirements

WARNING

Do not disconnect modules or wires unless power has been

switched off or the area is known to be non

-hazardous. The

devices may only be connected to the supply voltage shown on

the type plate. The

devices are designed for operation with a

Safety Extra

Low Voltage. Thus, they may only be connected to

the supply voltage connections and to the signal contact with the

Safety Extra

-Low Voltages (SELV) in compliance with

IEC60950-1/EN60950-1.

ATTENTION

This unit is a built

-in type. When the unit is installed in another

piece of equipment, the equipment enclosing the unit must

comply with fire enclosure regulation IEC60950

-1/EN60950-

1 (or

similar regulation).

ATTENTION

Safety First!

Be sure to disconnect the power cord before installing and/or

wiring your Moxa EtherDevice Switch.

Calculate the maximum possible current in each power wire and

common wire. Observe all electrical code

s dictating the

maximum current allowable for each wire size.

If the current goes above the maximum ratings, the wiring could

overheat, causing serious damage to your equipment.

Please read and follow these guidelines:

•Use separate paths to route wiring for power and devices. If power

wiring and device wiring paths must cross, make sure the wires are

perpendicular at the intersection point.

NOTE

Do not run signal or communications wiring and power wiring

through the same wire conduit. To avoid interference, wires with

different signal characteristics should be routed separately.

•You can use the type of signal transmitted through a wire to

determine which wires should be kept separate. The rule of thumb is

that wiring that shares similar electrical characteristics can be

bundled together.

•You should separate input wiring from output wiring.

•We advise that you label the wiring to all devices in the system.

- 7 -

Grounding the Moxa EDS-P510A-8PoE

Grounding and wire routing help limit the effects of noise due to

electromagnetic interference (EMI). Run the ground connection from the

ground screw to the grounding surface prior to connecting devices.

ATTENTION

This product is intended to be mounted to a well

-grounded

mounting surface such as a metal panel.

Wiring the Relay Contact

The EDS-P510A-8PoE has one relay output. The relay contact uses two

contacts of the terminal block on the EDS-P510A-8PoE’s top panel. Refer

to the next section for detailed instructions on how to connect the wires to

the terminal block connector, and how to attach the terminal block

connector to the terminal block receptor.

In this section, we illustrate the meaning of the two contacts used to

connect the relay contact.

FAULT:

The relay contacts

of the 2-pin terminal block

connector are used to detect user

-configured events.

The two wires attached to the

fault contacts form an

open circuit when a user

configured event is triggered.

If a user

-configured event does not occur, the fault

circuit remai

ns closed.

Wiring the Redundant Power Inputs

The EDS-P510A-8PoE has two sets of power inputs—power input 1 and

power input 2. The two terminal block connectors on the top-left of the

EDS-P510A-8PoE's top panel are used for the two power inputs. The top

and front views of one of the terminal block connectors are shown here.

STEP 1: Insert the negative/positive DC wires into the

-/V+ terminals, respectively.

STEP 2: To keep the DC wires from pulling loose, use a

small flat

-blade screwdriver to tighten the wire-

clamp

screws on the front of the terminal block connector.

STEP 3:

Insert the plastic terminal block connector

prongs into the terminal block receptor, which is

located on

the EDS-P510A-8PoE’s top panel.

- 8 -

Wiring the Digital Inputs

The EDS-P510A-8PoE has one digital input. The DI consists of two

contacts on the terminal block connector on the EDS-P510A-8PoE’s

top-right panel. The top and front views of one of the terminal block

connectors are shown here.

STEP 1: Insert the negative (ground)/positive DI wires

into the

┴/I terminals, respectively.

STEP 2: To keep the DI wires from pulling loose, use a

small flat

-blade screwdriver to tighten the wire-

clamp

screws on the front of the terminal block connector.

STEP 3:

Insert the plastic terminal block connector

prongs into the terminal block receptor, which is

located on

the EDS-P510A-8PoE’s top panel.

Turbo Ring DIP Switch Settings

EDS-P510A-8PoE series switches are plug-and-play managed redundant

Ethernet switches. The proprietary Turbo Ring protocol was developed by

Moxa to provide better network reliability and faster recovery time. Moxa

Turbo Ring’s recovery time is less than 300 ms (Turbo Ring) or 20 ms

(Turbo Ring V2) —compared to a 3- to 5-minute recovery time for

commercial switches—decreasing the possible loss caused by network

failures in an industrial setting.

There are 4 Hardware DIP Switches for Turbo Ring on the top panel of

EDS-P510A-8PoE that can help set up the Turbo Ring easily within

seconds. If you do not want to use a hardware DIP switch to setup the

Turbo Ring, you can use a web browser, telnet, or console to disable this

function.

NOTE

Please refer to the Turbo Ring DIP Switch section and Using

Communication Redundancy

section in User’s Manual for

more detail informat

ion about the settings and usage of Turbo

Ring and Turbo Ring V2.

EDS-P510A-8PoE Series DIP Switches

The default setting for each DIP Switch is OFF.

The

following table explains the effect of

setting the DIP Switch to the ON position

- 9 -

“Turbo Ring” DIP Switch Settings

DIP 1

DIP 2

DIP 3

DIP 4

Reserved for

future use.

ON: Enables this

EDS as the Ring

Master.

ON: Enables the

default “Ring

Coupling” ports.

ON: Activates DIP

switches 1, 2, 3 to

configure “Turbo

Ring” settings.

OFF: This EDS

will not be the

Ring Master.

OFF: Do not use

this EDS as the

ring coupler.

OFF: DIP

switches 1, 2, 3

will be disabled.

“Turbo Ring V2” DIP Switch Settings

DIP 1

DIP 2

DIP 3

DIP 4

ON: Enables the

default “Ring

Coupling

(backup)” port.

ON: Enables this

EDS as the Ring

Master.

ON: Enables the

default “Ring

Coupling” port.

ON: Activates

DIP switches 1,

2, 3 to configure

“Turbo Ring V2”

settings.

OFF: Enables the

default “Ring

Coupling

(primary)” port.

OFF: This EDS

will not be the

Ring Master.

OFF: Do not use

this EDS as a ring

coupler.

OFF: DIP

switches 1, 2, 3

will be disabled.

NOTE

You must enable the Turbo Ring function first before using the

DIP switch to activate the Master and Coupler functions.

NOTE

If you do not enable any of the EDS

-P510A-8PoE

switches to be

the Ring Master, the Turbo Ring protocol will automatically

choose the EDS

-P510A-8PoE with the smallest MAC address

range to be the Ring Master. If you accidentally enable more than

one EDS

-P510A-8PoE to be the Ring Master, these

EDS

-P510A-8PoE switches will auto-negotiate to determine

which one will be the Ring Master.

LED Indicators

The front panel of the Moxa EDS-P510A-8PoE contains several LED

indicators. The function of each LED is described in the following table:

LED

Color

State

Description

PWR1 AMBER

Power is being supplied to power input

P1.

Off

Power is not being supplied to power

input P1.

PWR2 AMBER

Power is being supplied to power input

P2.

Off

Power is not being supplied to power

input P2.

FAULT RED

When a user-configured event is

triggered.

Off

When a user-configured event is not

triggered.

- 10 -

LED

Color

State

Description

MSTR/HEAD

GREEN

When the switch is set as the Master of

the Turbo Ring, or as the Head of the

Turbo Chain.

Blinking

The switch has become the Ring

Master of the Turbo Ring, or the Head

of the Turbo Chain, after the Turbo

Ring or the Turbo Chain is down.

Off

When the switch is not the Master of

this Turbo Ring or is set as the Member

of the Turbo Chain.

CPLR/TAIL GREEN

When the EDS

-P510A-8PoE coupling

function is enabled to form a back

-up

path, or when it's set as the Tail of the

Turbo Chain.

Blinking

When the Turbo Chain is down.

Off

When the switch disables the coupling

function.

Port 1 to

Port

(10M)

AMBER

TP port’s 10 Mbps link is active.

Blinking

Data is being transmitted at 10 Mbps.

Off

TP port’s 10 Mbps link is inactive.

Port 1 to

Port 8

(100M)

GREEN

TP port’s 100 Mbps link is active.

Blinking

Data is being transmitted at 100 Mbps.

Off

TP port’s 100 Mbps link is inactive.

G1 to G2

(10/100/

1000M)

AMBER

G1 to G2 port’s 10/100Mbps link is

active.

Blinking

Data is being transmitted at

10/100Mbps.

Off

G1 to G2 port’s 10/100Mbps link is

inactive.

G1 to G2

(1000M) GREEN

G1 to G

2 port’s 1000 Mbps link is

active.

Blinking

Data is being transmitted at 1000

Mbps.

Off

G1 to G2 port’s 1000 Mbps link is

inactive.

PoE+

AMBER On

PoE port is connected to PoE device,

using the 802.3af standard

Off

No PoE power output

GREEN On

PoE port is connected to PoE device,

using the 802.3at standard

Off

No PoE power output

RED On

PoE power failure:

Once/second: PoE detection failure

Twice/second: short-circuit,

overloading, or over temperature

Off

Table des matières

Autres manuels Moxa Technologies Changer

Moxa Technologies

Moxa Technologies EtherDevice EDS-4009 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies NPort S8458 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies ToughNet TN-4500A Series Manuel utilisateur

Moxa Technologies

Moxa Technologies MDS-G4000-4XGS Series Manuel utilisateur

Moxa Technologies

Moxa Technologies SDS-3016 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies EtherDevice EDS-305-T Manuel

Moxa Technologies

Moxa Technologies EDS-G308 Manuel

Moxa Technologies

Moxa Technologies PT-7528 Manuel

Moxa Technologies

Moxa Technologies ToughNet TN-5510-2GLSX-ODC Manuel

Moxa Technologies

Moxa Technologies EtherDevice EDS-G205A-4PoE-1GSFP Manuel

Moxa Technologies

Moxa Technologies EDS-726 Series Manuel

Moxa Technologies

Moxa Technologies PT-7528 Manuel utilisateur

Moxa Technologies

Moxa Technologies IKS-6728 Series Manuel

Moxa Technologies

Moxa Technologies NPort S8000 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies ToughNet TN-5516 Series Manuel

Moxa Technologies

Moxa Technologies ToughNet TN-G4500 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies EDS-G308 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies MDS-G4000 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies EDS-528E Series Manuel utilisateur

Moxa Technologies

Moxa Technologies EtherDevice EDS-P206A-4PoE Series Manuel utilisateur

Moxa Technologies

Moxa Technologies PowerTrans PT-508-MM-ST-48 Manuel utilisateur

Moxa Technologies

Moxa Technologies TN-G4516-8GPoE-4XGPoE-WV-T Manuel utilisateur

Moxa Technologies

Moxa Technologies NE-4100 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies EtherDevice EDS-G205A-4POE-1GSFP-T Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
