Moxa Technologies EtherDevice EDS-30 Manuel

P/N: 1802003083011

EDS-308/309

Hardware Installation Guide

Moxa EtherDevice Switch

Ninth Edition, April 2014

- 2 -

Overview

Moxa EtherDevice™ EDS-308/309 Series, which consists of 9-,and 8-port

smart Ethernet switches, provides an economical solution for your

Ethernet connections. As an added bonus, the built-in smart alarm

function helps system maintainers monitor the health of your Ethernet

network.

EDS-308/309 switches have a wide operating temperature range of -40

to 75°C, and are designed to withstand a high degree of vibration and

shock. The rugged hardware design makes EDS-308/309 Series perfect

for ensuring that your Ethernet equipment can withstand critical

industrial applications, and complies with FCC and CE Standards.

NOTE

Throughout this Hardware Installation Guide, we use EDS as an

abbreviation for Moxa EtherDevice Switch:

EDS = Moxa EtherDevice Switch

Package Checklist

Moxa EDS-308/309 is shipped with the following items. If any of these

items is missing or damaged, please contact your customer service

representative for assistance.

•Moxa EtherDevice™ Switch

•Hardware Installation Guide

•Moxa Product Warranty booklet

•Protective caps for unused ports

Features

High Performance Network Switching Technology

•10/100BaseT(X) (RJ45), 100BaseFX (SC/ST-type, Multi/Single

mode)

•IEEE802.3/802.3u/802.3x

•Store and Forward switching process type, with 1024 address entries

•10/100M, Full/Half-Duplex, MDI/MDIX auto-sensing

Industrial Grade Reliablity

•Power failure, port break alarm by relay output

•Redundant dual DC power inputs

Rugged Design

•Operating temperature range from 0 to 60°C, or extended operating

temperature from -40 to 75°C for “-T” models

•IP30, rugged high-strength case

•DIN-rail or panel mounting ability

WARNING

The

power for this product is intended to be supplied by a Listed

Power Supply, with output marked LPS, and rated to deliver 12 to

48 VDC at a maximum of 0.6A.

The DC

jack should be used with an LPS unit that is rated to

deliver 12 to 48 VDC at a minimum of 1.1A. The product should

not be disassembled by operators or service people.

- 3 -

EDS-308 Panel Layout

1. Grounding screw

2. Terminal block for power inputs

PWR1/PWR2 and relay output

3. Heat dissipation orifices

4. DIP switches

5. Power input PWR1 LED

6. Power input PWR2 LED

7. Fault LED

8. 10/100BaseT(X) Port

9. TP port’s 100 Mbps LED

10.

TP port’s 10 Mbps LED

11.

Model Name

12.

Screw holes for wall mounting kit

13.

DIN-Rail Kit

- 4 -

EDS-308 Panel Layout (SC-type)

NOTE: The appearance of EDS-308-S-SC is

identical to EDS

-308-M-SC, and the

appearance of EDS

-308-SS-SC is identical to

EDS

-308-MM-SC.

1. Grounding screw

2. Terminal block for power inputs

PWR1/PWR2 and relay output

3. Heat dissipation orifices

4. DIP switches

5. Power input PWR1 LED

6. Power input PWR2 LED

7. Fault LED

8. 10/100BaseT(X) Port

9. TP port’s 100 Mbps LED

10.

TP port’s 10 Mbps LED

11.

Model Name

12.

100BaseFX Port

13.

FX port’s 100 Mbps LED

14.

Screw holes for wall mounting kit

15.

DIN-Rail Kit

- 5 -

EDS-309 Panel Layout (SC-type)

1. Grounding screw

2. Terminal block for power inputs

PWR1/PWR2 and relay output

3. Heat dissipation orifices

4. DIP switches

5. Power input PWR1 LED

6. Power input PWR2 LED

7. Fault LED

8. 10/100BaseT(X) Port

9. TP port’s 100 Mbps LED

10.

TP port’s 10 Mbps LED

11.

Model Name

12.

100BaseFX Port

13.

Screw holes for wall mounting kit

14.

DIN-Rail Kit

15.

100 Mbps LED for FX port 7

16.

100 Mbps LED for FX port 8

17.

100 Mbps LED for FX port 9

- 6 -

EDS-308/309 Panel Layout (ST-type)

1. Grounding screw

2. Terminal block for power input

PWR1/PWR2 and relay output

3. Heat dissipation orifices

4. DIP switches

5. Power input PWR1 LED

6. Power input PWR2 LED

7. Fault LED

8. 10/100BaseT(X) Port

9. TP port’s 100 Mbps LED

10.

TP port’s 10 Mbps LED

11.

Model Name

12.

100BaseFX Port

13.

100 Mbps LED for FX port

14.

Screw hole for wall mounting kit

15.

DIN-Rail Kit

16.

100 Mbps LED for FX port 7

17.

100 Mbps LED for FX port 8

18.

100 Mbps LED for FX port 9

- 7 -

Mounting Dimensions

Unit = mm (inch)

- 8 -

DIN-Rail Mounting

The aluminum DIN-Rail attachment plate should already be fixed to the

back panel of EDS-308/309 when you take it out of the box. If you need

to reattach the DIN-Rail attachment plate, make sure the stiff metal

spring is situated towards the top, as shown in the figures below.

STEP 1:

Insert the top of the DIN

-Rail into

the slot just

below the stiff metal

spring.

STEP 2:

The DIN

-Rail attachment unit will

snap into place as shown below.

To remove Moxa EtherDevice Switch from the DIN-Rail, simply reverse

Steps 1 and 2 above.

Wall Mounting (optional)

For some applications, you will find it convenient to mount EDS-308/309

on the wall, as illustrated below.

STEP 1:

Remove the aluminum

DIN

-Rail attachment plate

from EDS

-308/309’s rear

panel, and then attach the

wall mount plates, as shown

in the diagram below.

STEP 2:

Mounting

EDS-308/309

on the wall requires 4 screws.

Use the switch, with wall mount plates attached, as a

guide to mark the correct locations of the 4 screws.

The heads of the screws should be less than 6.0 mm in

diameter, and the shafts should be less than 3.5 mm

diameter, as shown in the figure at the right.

NOTE

Before tightening screws into the wall, make sure the screw head

and shank size are suitable by inserting the screw into one of the

keyhole-shaped apertures of the Wall Mounting Plates.

Do not screw the screws in all the way—leave about 2 mm to allow room

for sliding the wall mount panel between the wall and the screws.

- 9 -

STEP 3:

Once the screws are fixed in the

wall, insert the four screw heads

through the large parts of the

keyhole

-shaped apertures, and

then slide EDS

-308/309

downwards, as indicated. Tighten

the four screws for added

stability.

ATEX Information

1. Certificate number DEMKO 08 ATEX 0812123x

2. Ambient range (-40°C ≤Tamb ≤75°C)

3. Certification string (Ex nA nC IIC T4 Gc)

4. Standards covered ( EN 60079-0:2012, EN 60079-15:2010)

5. The conditions of safe usage:

•

The Ethernet Communication Devices are to be mounted in an

IP54 enclosure and used in an area of not more than pollution

degree 2 as defined by IEC 60664-1.

•A 4 mm2conductor must be used when connection to the

external grounding screw is utilized.

•Conductors suitable for use in an ambient temperature of 93°

must be used for the Power Supply Terminal.

Provisions shall be

made to prevent the rated voltage being exceeded by the

transient disturbances of more than 40%.

Wiring Requirements

WARNING

Do not disconnect modules or wires unless the power supply has

been switched off or the area is known to be non

-hazardous.

The

devices may only be

connected to the supply voltage shown on

the type plate.

The devices are designed for operation with a

Safety Extra-Low

Voltage. Thus, they may only be connected to the supply voltage

connections and to the signal contact with the

Safety Extra-L

Voltages (SELV) in compliance with IEC950/ EN60950/ VDE0805.

WARNING

Substitution of components may impair suitability for Class

Division 2

, and Zone 2. These devices must be supplied by an

SELV source as defined in Low Voltag

e Directive 73/23/EEC and

93/68/EEC.

- 10 -

WARNING

This unit is a built

-in type. When the unit is installed in another

piece of equipment, the equipment enclosing the unit must

comply with fire enclosure regulation IEC

60950/EN60950 (or

similar regulation).

WARNING

Safety First!

Be sure to disconnect the power cord before installing and/or

wiring your

Moxa EtherDevice Switch.

Calculate the maximum possible current in each power wire and

common wire. Observe all electrical codes dictating the

maximum current allowable for each wire size.

If the current goes above the maximum ratings, the wiring could

overheat, causing serious damage to your equipment.

You should also pay attention to the following items:

•Use separate paths to route wiring for power and devices. If power

wiring and device wiring paths must cross, make sure the wires are

perpendicular at the intersection point.

NOTE: Do not run signal or communications wiring and power wiring

in the same wire conduit. To avoid interference, wires with different

signal characteristics should be routed separately.

•You can use the type of signal transmitted through a wire to

determine which wires should be kept separate. The rule of thumb is

that wiring that shares similar electrical characteristics can be

bundled together.

•Keep input wiring and output wiring separated.

•It is strongly advised that you label wiring to all devices in the system

when necessary.

Grounding Moxa EtherDevice Switch

Grounding and wire routing help limit the effects of noise due to

electromagnetic interference (EMI). Run the ground connection from the

ground screw to the grounding surface prior to connecting devices.

ATTENTION

This pro

duct is intended to be mounted to a well-grounded

mounting surface, such as a metal panel.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Moxa Technologies Changer

Moxa Technologies

Moxa Technologies ICS-G7828A-T Series Manuel utilisateur

Moxa Technologies

Moxa Technologies EtherDevice Switch EDS-G205 Manuel

Moxa Technologies

Moxa Technologies UPORT 1200 series Manuel utilisateur

Moxa Technologies

Moxa Technologies EDS-508A Series Manuel utilisateur

Moxa Technologies

Moxa Technologies MDS-G4000 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies PowerTrans PT-7728-PTP Manuel

Moxa Technologies

Moxa Technologies EtherDevice EDS-4012 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies PowerTrans PT-508-MM-ST-48 Manuel utilisateur

Moxa Technologies

Moxa Technologies EDS-508 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies EDS-208 series Manuel utilisateur

Moxa Technologies

Moxa Technologies NPort S8000 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies PowerTransPT-7528 Series Manuel

Moxa Technologies

Moxa Technologies EtherDevice EDS-518A Series Manuel utilisateur

Moxa Technologies

Moxa Technologies TN-5308 Manuel utilisateur

Moxa Technologies

Moxa Technologies ToughNet TN-4500A Series Manuel utilisateur

Moxa Technologies

Moxa Technologies PowerTrans PT-7528-24TX-WV Manuel utilisateur

Moxa Technologies

Moxa Technologies EtherDevice EDS-G205A-4PoE-1GSFP Manuel

Moxa Technologies

Moxa Technologies EDS-316 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies EtherDevice EDS-518A Series Manuel

Moxa Technologies

Moxa Technologies TN-G4516-8GPoE-4XGPoE-WV-T Manuel utilisateur

Moxa Technologies

Moxa Technologies EtherDevice EDS-P510 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies ToughNet TN-5524-8PoE Manuel

Moxa Technologies

Moxa Technologies NPort S8000 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies EtherDevice EDS-4012 Series Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
