Motorola HPD 1000 Manuel utilisateur

HPD

MODEM

HPD™ 1000 Modem

Quick Reference Card

Product Safety and RF Exposure Compliance

ATTENTION!

This modem is restricted to occupational use only to satisfy

FCC RF energy exposure requirements. Before using this

product, read the RF energy awareness information and

operating instructions in the Product Safety and RF

Exposure booklet enclosed with your radio (Motorola

Publication part number 6881095C99) to ensure

compliance with RF energy exposure limits.

BASIC OPERATION

Reset Modem

Change IP Address

LED INDICATIONS

Before using this product, read the operating instructions

for safe usage contained in the Product Safety and RF

Exposure booklet enclosed with your radio.

Caution

Accessory

Connector

Power

Button

GPS

Connector

Ethernet

Connector

LED

Indicators

Click this button on the status applet to restart the HPD

Modem.

1 Click Change.

2 Key in new IP address and click Change once more.

Action LED Condition

Power OFF - -

GPS OFF - -

Power ON LED 1 FLASHING GREEN

Programming test LED 1 FLASHING AMBER

Insufficient

voltage/current

LED 1 RED

Power ON - Self

Test failure

LED 1- 4 RED

Channel - Tx LED 2 FLASHING GREEN

Out of range LED 2 & 3 RED

Searching for

Data Channel

LED 2 & 3 FLASHING RED

Channel - Rx LED 3 FLASHING GREEN

GPS ON LED 4 GREEN

GPS ON -

Assisted Mode

LED 4 AMBER

GPS ON -

Searching for

signal

LED 4 FLASHING RED

GPS Error/Failure LED 4 RED

96C67_Text.book Page 1 Monday, February 20, 2006 5:19 PM

HPD™ 1000 Modem ii

Product Safety and RF Exposure Compliance

ATTENTION!

This radio is restricted to occupational use only to satisfy FCC RF energy

exposure requirements. Before using this product, read the RF energy

awareness information and operating instructions in the Product Safety and RF

Exposure booklet enclosed with your radio (Motorola Publication part number

6881095C99) to ensure compliance with RF energy exposure limits.

Computer Software Copyrights

The Motorola products described in this manual may include copyrighted Motorola

computer programs stored in semiconductor memories or other media. Laws in the

United States and other countries preserve for Motorola certain exclusive rights for

copyrighted computer programs, including, but not limited to, the exclusive right to copy

or reproduce in any form the copyrighted computer program. Accordingly, any

copyrighted Motorola computer programs contained in the Motorola products described

in this manual may not be copied, reproduced, modified, reverse-engineered, or

distributed in any manner without the express written permission of Motorola.

Furthermore, the purchase of Motorola products shall not be deemed to grant either

directly or by implication, estoppel, or otherwise, any license under the copyrights,

patents or patent applications of Motorola, except for the normal non-exclusive license

to use that arises by operation of law in the sale of a product.

Documentation Copyrights

No duplication or distribution of this document or any portion thereof shall take place

without the express written permission of Motorola. No part of this manual may be

reproduced, distributed, or transmitted in any form or by any means, electronic or

mechanical, for any purpose without the express written permission of Motorola.

Disclaimer

The information in this document is carefully examined, and is believed to be entirely

reliable. However, no responsibility is assumed for inaccuracies. Furthermore, Motorola

reserves the right to make changes to any products herein to improve readability,

function, or design. Motorola does not assume any liability arising out of the

applications or use of any product or circuit described herein; nor does it cover any

license under its patent rights, nor the rights of others.

MOTOROLA, the Stylized M Logo, HPD and FLASHport are registered in the U.S.

Patent & Trademark Office. All other product or service names are the property of their

respective owners. P25 radios contain technology patented by Digital Voice Systems,

Inc.

Before using this product, read the operating instructions for safe

usage contained in the Product Safety and RF Exposure booklet

enclosed with your radio.

Caution

96C67_Text.book Page ii Monday, February 20, 2006 5:19 PM

iii

Notations Used in This Manual

Throughout the text in this publication, you will notice the use of WARNINGS,

CAUTIONS, and Notes. These notations are used to emphasize that safety

hazards exist, and care that must be taken or observed.

WARNING: An operational procedure, practice, or other

condition, which might result in injury or death if not carefully

observed.

CAUTION: An operational procedure, practice, or other

condition, which might result in damage to the equipment if not

carefully observed.

Note: Note: An operational procedure, practice, or other condition,

which is essential to emphasize.

WARNING

CAUTION

96C67_Text.book Page iii Monday, February 20, 2006 5:19 PM

ASTRO XTL 1500 Digital Mobile Radio with Control Head iv

Contents

Computer Software Copyrights ......................................................... ii

Documentation Copyrights ................................................................ ii

Disclaimer ......................................................................................... ii

Notations Used in This Manual .........................................................iii

Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Software Installation and Setup ........................................................ 2

Important Installation Information for HPD Status Applet ........... 2

HPD Status Applet Installation ................................................... 3

Finishing the installation ............................................................. 4

Status Applet and Features . . . . . . . . . . . . . . . . . . . . . 5

Status Applet Window ....................................................................... 5

Features ............................................................................................ 6

MSU IP Address ............................................................................... 6

Indicator lights description ................................................................. 7

Out of range ...................................................................................... 9

Power Management ........................................................................ 10

General Modem Features . . . . . . . . . . . . . . . . . . . . . . 13

Location Services Offered ............................................................... 13

GPS Functionality ........................................................................... 14

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Antennas ......................................................................................... 17

Cables ............................................................................................. 17

Trunnion Kits ................................................................................... 18

Glossary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Commercial Warranty and Service . . . . . . . . . . . . . . 21

Limited Warranty ............................................................................. 21

Service ............................................................................................ 25

96C67_Text.book Page iv Monday, February 20, 2006 5:19 PM

Notes

96C67_Text.book Page v Monday, February 20, 2006 5:19 PM

HPD™ 1000 Modem 1

Getting Started

The Motorola HPD 1000 Modem is a sophisticated, mobile modem

pioneering the latest technology in radio electronics.

The HPD 1000 Modem provides connectivity between a vehicle-

mounted data device and a host computer through Motorola's High

Performance Data (HPD) radio network. The modem connects to a

data device via USB or Ethernet and is designed to support data

transfer speeds of 32 kbps, 64kbps or 96 kbps within the 700/800

MHz frequency bands. The modem’s integrated GPS receiver allows

the user to determine the current location of a mobile HPD modem

when used in conjunction with a GPS location application. Location

alone, or combined with other information about the environment (e.g.

a map), enables value-added applications such as tracking of

resources.

96C67_Text.book Page 1 Monday, February 20, 2006 5:19 PM

Getting Started

Software Installation and Setup

Important Installation Information for HPD Status

Applet

Do not plug in the modem before installing the HPD Status

Applet. If this is done, the HPD modem will fail to install

properly.

System Requirements: Windows XP Service Pack 1 or Windows

2000 Service Pack 3.

Installation criteria:

1Install .Net 1.1 Common Language Runtime (CLR). If this

is not installed, the HPD Status Applet Installation will

install it on your machine automatically.

2Microsoft .NET Framework 1.1 Service Pack 1

(NDP1.1sp1-KB867460-X86.exe) must be installed, which

is included on the CD. This can only be installed AFTER

.Net 1.1 CLR is installed. If the Service Pack is not

installed when you attempt to install the Status Applet, the

installation will stop and inform the user to install the

Service Pack.

3Ensure SNMP is installed and running:

• Open "Services" (found under Administrative Tools) to

make sure SNMP Trap Services installed properly and is

running with "Automatic" startup type.

• If SNMP Trap Service is not installed, it must be installed

using Add/Remove Windows Components. The actual

component that the user needs to install is the Simple

Network Management Protocol, which can be found

under “Management and Monitoring Tools. This will

usually prompt the user to insert a Windows XP CD.

96C67_Text.book Page 2 Monday, February 20, 2006 5:19 PM

HPD™ 1000 Modem 3

Getting Started

HPD Status Applet Installation

1Double-click setup

2Welcome Screen appears. Click Next.

3Release Notes Screen is accessed. Click Yes to progress

or No to exit installation.

4Destination Directory Screen appears. You can configure

the location where the files will be installed. Select the path

of where the Application Framework (the exe. file) will be

installed. The default path is C:\Program

Files\Motorola\HPD\Status Applet. Once path has been

configured, click Next.

5Configuration Screen appears.

You need to key in Modem IP Address

(Default: 192.168.128.1).

Choose either PPP or PPPoE (Default: PPP).

The PPPoE is only available to Windows XP users.

Click the checkered box if you want the Status Applet to

automatically start whenever Windows starts up.

Click Next.

7Installation Complete.

96C67_Text.book Page 3 Monday, February 20, 2006 5:19 PM

Getting Started

Finishing the installation

1Plug in the HPD Modem

2The Found New Hardware Wizard will appear. Select

Install the software automatically.

3A message box appears stating that the hardware “has not

passed Windows Logo testing”.

Click Continue Anyway.

96C67_Text.book Page 4 Monday, February 20, 2006 5:19 PM

Table des matières

Autres manuels Motorola Modem

Motorola

Motorola SB5100 - SURFboard - 38 Mbps Cable Modem Manuel utilisateur

Motorola

Motorola SURFboard SBV5222v2 Manuel utilisateur

Motorola

Motorola iDEN iO1500R Manuel utilisateur

Motorola

Motorola SURFBOARD SBG1000 Manuel utilisateur

Motorola

Motorola SURFboard SBV5120 Manuel utilisateur

Motorola

Motorola SURFboard SB4101 Manuel utilisateur

Motorola

Motorola SBV5322 SURFBOARD DIGITAL VOICE MODEM - annexe... Manuel de la liste des pièces

Motorola

Motorola SURFboard SB3500 Manuel utilisateur

Motorola

Motorola SURFboard SB5102 Manuel utilisateur

Motorola

Motorola SURFboard SBV5322 Manuel utilisateur

Motorola

Motorola VMM6300 Manuel utilisateur

Motorola

Motorola SURFboard SBV6220 Manuel utilisateur

Motorola

Motorola SBG1000 Manuel utilisateur

Motorola

Motorola SURFboard SBV5222 Manuel de formation

Motorola

Motorola SBV6220 DOCSIS Manuel utilisateur

Motorola

Motorola SB5120 - SURFboard - 38 Mbps Cable Modem Manuel utilisateur

Motorola

Motorola SURFboard SB6121 Guide de dépannage

Motorola

Motorola SURFboard SB4000 Manuel utilisateur

Motorola

Motorola 3360 Manuel utilisateur

Motorola

Motorola SURFboard SB6180 Manuel utilisateur

Motorola

Motorola MG7550 Manuel utilisateur

Motorola

Motorola LA-5137 Manuel utilisateur

Motorola

Motorola SBV5220 Manuel utilisateur

Motorola

Motorola SB6100 Manuel utilisateur

Manuels Modem populaires d'autres marques

Davicom

Davicom DM562AP Manuel utilisateur

EpiValley

EpiValley TATA indicom SXC-1080 Manuel utilisateur

Zte

Zte WiMAX Manuel utilisateur

Intelimax

Intelimax MA-2060 Manuel utilisateur

SMC Networks

SMC Networks D3CM1604V Manuel d'utilisation et d'entretien

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuel utilisateur

Samsung

Samsung AceLink SAM-335A Manuel utilisateur

Enfora

Enfora Enabler-G Guide de configuration rapide

iRZ

iRZ ATM2-232 Manuel utilisateur

Zhone

Zhone 6310 Manuel utilisateur

Paradyne

Paradyne Hotwire 7976 Manuel utilisateur

US Robotics

US Robotics 3453C Manuel utilisateur

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur

Zte

Zte MF823 Manuel utilisateur

Four-Faith

Four-Faith F1403 Manuel utilisateur

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manuel utilisateur

Gemtek

Gemtek WiMAX WIXFBR-103 Manuel utilisateur
