Motic ECO Series Manuel utilisateur

ECO Series Instruction Manual

WWW.MOTIC.COM

MOTIC HONG KONG LIMITED

CONTENTS

1. NOTES ON INSTRUMENT SAFETY 2

1.1 General safety instructions 2

1.2 Instrument safety 2

1.3 Unpacking, transportation & storage 2

1.4 Waste disposal 3

1.5 Operation 3

1.6 Quality Warranty 4

2. INSTRUMENT DESCRIPTION 5

2.1 General Views 5

2.2 Parts names 6

2.3 Application 7

2.4 Instrument and its major features 7

3. FIRST TIME USE AND OPERATION 8

3.1 First time use 8

3.2 Operation of the biological microscope 10

3.2.1 Interpupillary distance adjustment 10

3.2.2 Setting brightfield illumination 10

3.3 Converting the microscope 11

3.3.1 Replace the 12V 20W halogen bulb or the LED illumination 11

3.3.2 Replace the objective 13

4. MAINTENANCE AND TROUBLESHOOTING 14

4.1 Maintenance 14

4.2 Troubleshooting 15

1. NOTES ON INSTRUMENT SAFETY

1.1 General safety instructions

●Please be sure to read these instructions before using the biological

microscope.

●Additional information is available upon request from our maintenance

department or authorized agency.

●To ensure safe operation and guarantee good performance of the

microscope please pay attention to the precautions and warnings specified

in the Operation Instructions.

●In this Operation Instructions manual, the following symbols indicate:

Caution! Electric shock hazard!

Caution! Danger!

1.2 Instrument safety

The ECO microscope has been designed, manufactured and inspected

according to the GB 4793.1-2007 and IEC 61010-1:2001 “Safety

Requirements for Electrical Equipment for Measurement, Control and

Laboratory Use”.

1.3 Unpacking, transportation & storage

●The original shipping container, a foam box in a fiberboard carton, should

be kept for use in long term storage or return shipment.

●When unpacking, please check the components according to the packing

list.

●Please comply with the temperature requirements for transport and storage

specified in the appendix of this manual.

●Set up, use and store the unpacked microscope on a firm and flat

workbench.

●Please do not touch the optical lens surfaces.

1.4 Waste disposal

●Important: Any damaged biological microscope must not be treated as

general waste; it should be disposed of according to relevant regulations.

1.5 Operation

When using the biological microscope, please pay attention to the following

safety instructions:

●If it is used for any purpose other than the specified ones, including any

individual component or part, the manufacturer will not take any

responsibility.

●After-sales service or repair done by unauthorized personnel will void the

warranty.

●Anyone who uses the instrument should receive instruction on the proper

handling of the instrument and safety practices for microscopy. The

biological microscope shall be placed only on a firm, flat workbench for

operation.

●Since the biological microscope is a precision instrument, improper

operation will impair or spoil its performance.

●The power unit is integrated in the main unit of the biological microscope:

the grid supply voltage is within 100-240V~50Hz.

The biological microscope must be connected only to the normal

power socket with a grounding terminal. Any extension cord without

ground protection is not allowed to avoid failure of the protection

function.

If there is any electrical failure (of the fuse system, ground protection

or transformer), turn off and unplug the unit immediately. Make sure

the microscope is set aside so it will not be used again and contact the

Motic service department or a Motic microscope repair agency to have

it repaired.

Please be sure to turn off the power before opening the instrument to

replace LED illuminator or replace the fuse! Only use a fuse for the

rated current.

Safety instructions for the use of immersion oil.

●Immersion oil is irritating to skin; avoid contact with skin, eyes

and clothing.

●Skin contact: wash with soap and plenty of water until the

immersion oil is completely removed.

●Eye contact: flush immediately with plenty of water for at least

5 minutes.

If irritation persists, seek medical advice.

●Dispose of immersion oil properly. Do not discharge into surface

water or sewage.

The biological microscope is not equipped with any special device to protect

against corrosive, latent infective, toxic, radioactive or other hazardous

samples. Therefore, when examining any such sample you must comply with

the relevant laws and regulations, in particular the provisions related to

accident prevention.

1.6 Quality Warranty

The ECO microscope and the attached accessories are only allowed to be

used for microscope examination as described in this manual. The

manufacturer takes no responsibility for any other use.

●The manufacturer guarantees that the product is free from any defect in

material or workmanship on the date of delivery.

●If any defect is found, notify the manufacturer immediately.

●Upon receipt of the Notification of Defect as described above, the

manufacture is responsible to solve the problem either by repairing the

defective instrument or replacing it with a new instrument of the same

model.

●The manufacturer provides no warranty for any failure or defect due to

normal wear and tear or improper use of the product.

●The manufacturer takes no responsibility for any damage caused by

operation error, negligence or unauthorized dismantling of the instrument,

or the use of spare parts from other manufacturers.

2. INSTRUMENT DESCRIPTION

2.1 General Views

2.2 Parts names

2.3 Application

The scope of application of the ECO microscope as follows: medical specimen

microscopic observations in the visible.

2.4 Instrument and its major features

ECO microscope has not only the appearance of classic but also superior

performance, flexible and lightweight.

The major features of the microscope include:

●Binocular siedentopf, inclined at 30 degrees and rotating or Monocular

siedentopf, inclined at 45 degrees and rotating

●Widefield WF10X/18mm eyepieces

●Quadruple nosepiece with parcentric click stops

●Achromatic objectives 4X, 10X, 40X(S), 100X(S, Oil)

●Coaxial coarse and fine focusing with tension adjustment

●Low position coaxial mechanical stage

●Rack & Pinion focusable 1.25NA condenser

●Iris diaphragm with filter holder

●Halogen illumination 12V/20W or LED illumination with intensity control

●External power supply

3. FIRST TIME USE AND OPERATION

3.1 First time use

Before installing and starting up the microscope, be sure to carefully read and

observe the notes on instrument safety (see section 1).

Do not touch optical surfaces when unpacking the microscope to avoid

fingerprints!

●Remove the microscope from the transport case and place it onto the

worktable.

Retain the original packaging for storage of the instrument in longer periods

of non-use or for return to the manufacturer.

●Put the eyepiece into the tube and fix it with the set screw. (Fig.1)

(Fig.1)

●Make sure the microscope input voltage must be consistent with the supply

voltage and then connect the plug-in power unit to a power outlet. (Fig.2)

(Fig.2)

●Switching the microscope ON/OFF switch.

●Tip: Make sure adjust the light intensity control to minimum position and

then turn on or off the ON/OFF switch. (Fig.3)

(Fig.3)

●Adjust the illuminator to the desired intensity. (Fig.4)

(Fig.4)

●After finishing work, switch off the microscope and cover it with the dust

cover.

●The smoothness of the coarse focusing drive is factory-adjusted, but you

can readjust it when required. (Fig.5)
