Your two year guarantee

It is important to retain the retailers

receipt as proof of purchase. Staple your

receipt to this back cover for future reference.

Please quote the following information if the

product develops a fault. These numbers can

be found on the base of the product.

Model no. Serial no.

All Morphy richards products are individually

tested before leaving the factory. In the unlikely

event of any appliance proving to be faulty

within 28 days of purchase it should be returned

to the place of purchase for it to be replaced.

If the fault develops after 28 days and within

24 months of original purchase, you should

contact the Helpline number quoting Model

number and Serial number on the product, or

write to Morphy richards at the address shown.

You will be asked to return the product (in

secure, adequate packaging) to the address

below along with a copy of proof of purchase.

Subject to the exclusions set out below (1-5) the

faulty appliance will then be repaired or

replaced and dispatched usually within 7

working days of receipt.

If you suspect a fault, follow the simple

checks detailed below before returning the

appliance or calling the helpline.

• Check the filters for blockages.

• Check the tools / tubes for blockages.

• Check the plug is firmly in the socket and the

supply is switched on.

• Make sure the socket is working by trying

another appliance.

• Check the fuse in the plug.

If for any reason this item is replaced during

the 2 year guarantee period, the guarantee on

the new item will be calculated from original

purchase date. Therefore it is vital to retain your

original till receipt or invoice to indicate the date

of initial purchase.

To qualify for the 2 year guarantee the

appliance must have been used according to

the manufacturers instructions. For example, the

filter must be cleaned regularly.

EXCLUSIONS

Morphy richards shall not be liable to replace

or repair the goods under the terms of the

guarantee where:

1The fault has been caused or is attributable

to accidental use, misuse, negligent use or

used contrary to the manufacturers

recommendations or where the fault has

been caused by power surges or damage

caused in transit.

2The appliance has been used on a voltage

supply other than that stamped on the

products.

3Repairs have been attempted by persons

other than our service staff (or authorised

dealer).

4Where the appliance has been used for hire

purposes or non domestic use.

5The guarantee excludes consumables such

as filters.

This guarantee does not confer any rights

other than those expressly set out above and

does not cover any claims for consequential

loss or damage. This guarantee is offered as an

additional benefit and does not affect your

statutory rights as a consumer.

• This guarantee is valid in the UK and Ireland

only.

Morphy richards products are intended for

household use only.

Morphy richards has a policy of continuous

improvement in product quality and design.

The company, therefore reserves the right

to change the specification of its models at

any time.

The After Sales Division

Morphy richards Ltd, Mexborough

South Yorkshire, England, S64 8AJ

Helpline (office hours)

UK 0870 060 2604

Republic of Ireland 1800 409119

VC71050M Rev 2

Cyclonic vac VC71050M Rev 2 19/6/03 5.02 PM Page 1

Cyclonic vacuum cleaner

Please read and keep these instructions

www.morphyrichards.co.uk

getting the best from your

new cleaner...

If your cleaner is not picking up as well as it

should, please check

• Filters

It is important to clean the motor protection filter every time you

empty the dust container, otherwise the performance of the

cleaner will be impaired. See page 5 - Cleaning the filter. A spare

is provided.

• Blockages

Check the nozzle, tubes and hose for blockages.

Cyclonic vac VC71050M Rev 2 19/6/03 5.02 PM Page 2

Important safety

instructions

The use of any electrical appliance

requires the following common sense safety

rules.

Primarily there is danger of injury or

death and secondly the danger of damage

to the appliance. These are indicated in the

text by the following two conventions:

WARNING: Danger to the person!

IMPORTANT: Damage to the appliance! In

addition we offer the following safety advice.

Location

• Do not use or keep this product outside

when it is raining.

• Do not store the appliance near hot

ovens or heating appliances.

Mains lead

• Do not allow the mains lead to become

strained or run this appliance over it.

• If the electrical cable becomes damaged

the complete cable assembly must be

replaced. Do not attempt this task

yourself, contact Morphy Richards using

the replacement parts number on the

front of this leaflet.

Children

• Children do not understand the dangers

associated with operating electrical

appliances. Never allow children to use

this appliance.

Personal safety

• The plug must be removed from the wall

socket before cleaning or maintaining

the appliance.

• Never modify the cleaner in any way.

• Never use in the presence of explosive

liquids or vapours.

• Never pick up inflammable or poisonous

liquids such as petrol, copier toner or

other volatile substances. Never pick up

acids, asbestos or asbestos dust.

• Repairs to electrical appliances are only

to be undertaken by trained personnel.

Unprofessional repairs can be

dangerous for users.

• Use only genuine Morphy Richards

spare parts and accessories.

• The appliance must never be left running

when unsupervised.

• This vacuum cleaner is intended for

domestic use only. Misuse or use for

commercial or any other purpose will

render the guarantee invalid.

Product safety

• Never use the appliance without the

filters being installed.

• Never use the appliance to vacuum hot

ashes, broken glass, sharp objects or

liquids.

• To protect against fire, electric shock and

personal injury do not immerse cord,

plug or cleaner in water or other liquid.

Electrical requirements

Check that the voltage on the rating

plate corresponds with your house

electricity supply which must be A.C.

(alternating current).

If the socket outlets in your home are not

suitable for the plug supplied with this

appliance the plug should be removed and

the appropriate one fitted.

If you cut off the plug and let go of the

cable it will rewind into the machine.

Therefore you must pull out a length of

cable and secure it before cutting off the

plug and refitting a new one.

IMPORTANT: The plug removed from

the mains lead, if severed, must be

destroyed as a plug with a bared flexible

cord is hazardous if engaged into a live

socket outlet.

Should the fuse in the 13 amp plug

require changing a 13 amp BS1362 fuse

must be fitted.

Cyclonic vac VC71050M Rev 2 19/6/03 5.02 PM Page 3

Features

⁄ Hose inlet

¤ Cable rewind pedal

‹ Carrying handle

› On/off power foot pedal

ﬁVariable power switch

ﬂDust container release button

‡ Pleated, washable motor protection filter

· Dust collection container

‚ Tool storage drawer

„ Parking slot

‰ Exhaust filter cover

Â Airflow regulator

⁄

¤‹

›

ﬁ

ﬂ

‡

‚

‰

„

Illustration

Accessories you should have

Ê Hose handle

Á Flexible hose

Ë Telescopic tube (length adjustable)

È Filter cleaning brush

Í Crevice tool

Î Upholstery nozzle

Ï Clip on brush (attaches to Î)

Ì Wheeled floor nozzle

Ó Stair cleaning stretch hose

(not shown)

Note: È,Í,Îand Ïare stored in

the tool storage drawer ‚.

Cyclonic vac VC71050M Rev 2 19/6/03 5.02 PM Page 4

Quick start

1Assemble the nozzle, telescopic tube

and hose as shown A.

2Pull out the mains cable to it’s full length

and plug into the mains supply.

3Switch on by pressing the foot pedal ›.

Accessories

1Fit the hose to the cleaner by inserting

the hose end into the hose inlet ⁄.

When removing, squeeze the clips either

side and pull.

2Attach the telescopic tube to the handle

end of the hose. Extend to the required

length by pressing down the slider

release and pulling out the tube B.

The hose handle features an airflow

regulator Âwhich allows suction to be

reduced as required.

3Attach the wheeled floor nozzle Ìto the

tube.

The crevice tool Í (for awkward places,

behind radiators etc) and the upholstery

nozzle Î with clip on brush Ï (for curtains

and upholstery) are stored in the tool

drawer ‚. The crevice tool is used for hard

surfaces, pelmets, delicate objects etc C.

Stair cleaning hose Ó

An additional stretch hose is also

provided for use on stairs. Fit the hose to

the cleaner by inserting the hose end into

the hose inlet. When removing squeeze the

clips either side and pull.

WARNING: For safety, always leave

the cleaner at the bottom of the stairs

and clean upwards.

Controls

Power

The on/off control is operated by the foot

pedal ›.

Variable power

A sliding switch ﬁ varies the suction

power as required. For example, maximum

suction can be used for cleaning carpets,

hard floors etc. and reduced suction for

cleaning upholstery and curtains.

Suction can also be controlled using the

airflow regulator on the handle Â. Closed

for maximum suction, open for reduced

suction.

Automatic cable rewind

After use, unplug and press the cable

rewind button ¤ to retract the cable.

WARNING: When using the cable

rewind, always hold the plug as the cable

will rewind quickly.

Cyclonic vac VC71050M Rev 2 19/6/03 5.02 PM Page 5

Dust disposal

To obtain the best results from your

cleaner empty the dust container regularly,

otherwise the airflow and cleaning power

will be reduced.

1Remove the dust container from the

product by pressing the dust container

release button ﬂand pulling the dust

container away from the product. D

2Holding the dust container over a

dustbin press the dust release button as

shown E, the bottom of the dust

container will drop down to release the

dirt.

3Close the bottom of the dust container

by pressing the base upwards until it

clicks into place.

4Push the dust container back onto the

product to refit.

Cleaning the motor

protection filter

1Remove the dust container from the

product by pressing the dust container

release button ﬂand pulling the

container away from the product. After

emptying any dirt into the dustbin as

detailed in E.

2Remove the motor protection filter ‡

from the top of the dust container by

pushing the filter release switch to

release the filter and lift the filter out of

the container from the top.F. The filter

can be gently knocked against the side

of the dustbin to remove excess dust.

Use the filter cleaning brush Èto

remove dirt from between the pleats.

3To re-fit the filter, drop the cartridge into

the hole in the top of the dust container.

Ensure the top of the filter is located

under the lug and push the filter release

switch to allow the filter to drop into

place. The filter release switch will then

automatically flick back when released to

lock the filter in place.

The filter should be regularly washed in

cold water and left to air dry before

inserting back into the machine.

IMPORTANT: Do not use detergents to

clean the filter. The filter must be thoroughly

dry before the machine is used.

A spare filter is provided.

IMPORTANT: The dust container will not

lock back onto the machine unless the filter

is fitted correctly

Filter

release

switch locating

lug

Cyclonic vac VC71050M Rev 2 19/6/03 5.02 PM Page 6

Cleaning the exhaust

filter

The exhaust filter ‰is located at the side

of the cleaner. To remove, push the catch

and pull the cover away. GTake out the filter.

Wash regularly in warm water, but do not use

detergent. Allow to dry naturally and ensure it

is totally dry before replacing it.

IMPORTANT

• All filters should be checked regularly for

signs of damage, preferably after each

cleaning task. The filters must be replaced

immediately if they become damaged.

• Always disconnect the cleaner from the

mains when checking filters.

• Always make sure all filters are fitted

before use. Failure to do so may result in

damage to your product.

Storage position

When finished you can store the tubes

and accessories by locating the tube storage

clip into the slot on the side of the cleaner as

shown H.

Cyclonic vac VC71050M Rev 2 19/6/03 5.02 PM Page 7

Care and maintenance

Your cleaner is manufactured to withstand

normal day-to-day use, but an occasional

wipe over with a damp cloth will help

maintain its good looks. Abrasive cleaners

should not be used.

Purchasing filters

Use original Morphy Richards spares &

consumables. These can be purchased by

telephoning the Morphy Richards

replacement parts line.

Helpline

If you have any difficulty with your

appliance do not hesitate to call us. We are

likely to be more help than the store from

where it was bought.

Please have the following information

ready to enable our staff to help you.

• Name of product

• Model number as shown on the underside

of the appliance.

Cyclonic vac VC71050M Rev 2 19/6/03 5.02 PM Page 8

Table des matières

Autres manuels Morphy Richards Aspirateur

Morphy Richards

Morphy Richards Vacuum Cleaner Manuel utilisateur

Morphy Richards

Morphy Richards IB73100 Manuel utilisateur

Morphy Richards

Morphy Richards Pod vacuum cleaner Manuel utilisateur

Morphy Richards

Morphy Richards PremAir Cyclonic 70035 Manuel utilisateur

Morphy Richards

Morphy Richards PerformAir Upright Vacuum Manuel utilisateur

Morphy Richards

Morphy Richards IB73180 Manuel utilisateur

Morphy Richards

Morphy Richards 73281 Manuel utilisateur

Morphy Richards

Morphy Richards IB71061 Manuel utilisateur

Morphy Richards

Morphy Richards 70316 Manuel utilisateur

Morphy Richards

Morphy Richards 73313 Manuel utilisateur

Morphy Richards

Morphy Richards SpillMaster Manuel utilisateur

Morphy Richards

Morphy Richards Orb vacuum cleaner Manuel utilisateur

Morphy Richards

Morphy Richards 73270 Manuel utilisateur

Morphy Richards

Morphy Richards Bagless Cylinder Vacuum Cleaner Manuel utilisateur

Morphy Richards

Morphy Richards POD COMPACT BAGLESS VACUUM CLEANER - REV 2 Manuel utilisateur

Morphy Richards

Morphy Richards IB70313 Manuel utilisateur

Morphy Richards

Morphy Richards VC73270MUK Manuel utilisateur

Morphy Richards

Morphy Richards VC73240MUK Manuel utilisateur

Morphy Richards

Morphy Richards STORM CYCLONIC vacuum cleaner Manuel utilisateur

Morphy Richards

Morphy Richards IB71051 Manuel utilisateur

Morphy Richards

Morphy Richards Upright Bagless Vacuum Cleaner Manuel utilisateur

Morphy Richards

Morphy Richards IB70240 Manuel utilisateur

Morphy Richards

Morphy Richards PERFORMAIR CYCLONIC VACUUM CLEANER 71062 Manuel utilisateur

Morphy Richards

Morphy Richards PERFORMAIR CYCLONIC VACUUM CLEANER Manuel utilisateur

Manuels Aspirateur populaires d'autres marques

Bissell

Bissell LittleGreen Proheat 1425 Series Manuel utilisateur

Panasonic

Panasonic MC-YL637S147-AE Manuel utilisateur

NEFF

NEFF N17XH10 0 Series Manuel utilisateur

LG A9 Series Manuel utilisateur

Oreck

Oreck Cordless Captura BK51700 Series Manuel utilisateur

Kogan

Kogan KAVACROBVWA Manuel utilisateur

Kränzle

Kränzle VENTOS 50 ID Guide de l'utilisateur

EVVO

EVVO Ai35 Manuel utilisateur

DeWalt

DeWalt DWH200D Manuel utilisateur

Pontec

Pontec Pondomatic Vacuum Cleaner Manuel utilisateur

Cleanmaxx

Cleanmaxx PC-P007E Manuel utilisateur

Exido

Exido 240-114 Manuel utilisateur

RIDGID

RIDGID WD1685AU0 Manuel utilisateur

Ezviz

Ezviz RE4P Manuel utilisateur

STG global

STG global TANVAC HDV3000 Manuel utilisateur

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuel utilisateur

Factory

Factory M3340 Manuel utilisateur

Shop-Vac

Shop-Vac VN92 SERIES Manuel utilisateur
