USER MANUALT

TOTAL CHLORINE

MODEL: MW11

ISTMW11 08/10

WARRANTY:

This instrument is warranted from all defects in materials and manufacturing for

a period of two years from the date of purchase.

If during this period, the repair or replacement of parts is required, where the

damage is not due to negligence or erroneous operation by the user, please return

the parts to either dealer or our office and the repair will be effected free of charge.

Note:We reserve the right to modify the design, construction and appearance

of our products without advance notice.

SPECIFICATIONS:

MW 11

RANGE 0.00 to 3.50 ppm

RESOLUTION 0.01 ppm

ACCURACY ±0.03 ppm ±3% of reading @ 25 °C

TYPICAL EMC DEV. ±0.01 ppm

LIGHT SOURCE Light Emitting Diode @ 525 nm

LIGHT DETECTOR Silicon Photocell

METHOD Adaptation of USEPA method 330.5. The reaction

between total chlorine and the DPD reagent

causes a pink tint in the sample.

ENVIRONMENT 0 to 50°C (32 to 122 °F)

max. 95% RH non-condensing

BATTERY TYPE 1 x 1.5V AAA

AUTO-SHUT OFF After 2 minutes of non-use

DIMENSIONS 81.5 x 61 x 37.5 mm (3.2 x 2.4 x 1.5”)

WEIGHT 64 g (2.25 oz.)

OPTIONAL ACCESSORIES:

Reagent Sets

2720216 Total Chlorine powder reagent, 25 pcs.

Other Accessories

3000100 Glass cuvettes with caps (2 pcs)

3000200 Tissue fow wiping cuvettes (2 pcs)

3000300 1.5V AAA batteries (4 pcs)

Milwaukee

PRELIMINARY EXAMINATION:

Please examine this product carefully. Make sure that the

instrument is not damaged. If any damage occured during

shipment, please notify your Dealer.

Each MW 11 meter is supplied complete with:

• Two Sample Cuvettes and Caps

• Six powder reagents for Total Chlorine

• 1 x 1.5V AAA Battery

• Instruction Manual

FUNCTIONAL DESCRIPTION:

1. Dust cover

2. Cuvette with cap

3. Cuvette holder

4. Liquid Crystal Display

5. Button

OPERATION:

•Turn the meter on by pressing the

button. After all the segments are dis-

played, “C.1”, “Add” appears with

“Press” blinking, the meter is ready.

•Fill the cuvette with 10 mL of unre-

acted sample and replace the cap.

Place the cuvette into the meter and

close the meter’s cap.

•Press the button. When the display

shows “Add”, “C.2” with “Press” blink-

ing the meter is zeroed.

•Remove the cuvette, open it and add

the content of one packet of 2720216

reagent. Replace the cap and shake

gently for 20 seconds. Replace the

cuvette into the meter.

•Wait for 2 minutes and 30 seconds

and then press the button or press

and hold the button until the timer is

displayed on the LCD.

•The instrument directly displays the

concentration of total chlorine in ppm.

The meter automatically turns off after

2 minutes.

BATTERY REPLACEMENT:

To save the battery, the instrument shuts down after 2 minutes

of non-use. One fresh battery lasts for a minimum of 5000

measurements, depending on the light level. When the battery

capacity is under 10 % “bAt” appears on the LCD at start-up.

If the battery is empty and accurate measurements can’t be

taken any more, the instrument shows “bAd” then ”bAt” each

for 1 second and turns off. To restart the instrument, the

battery must be replaced with a fresh one.

To replace the instrument’s battery, follow the steps:

•Turn the instrument off by holding the button until the meter

shuts off.

•Turn the instrument

upside down and

remove the battery cover

with a screwdriver.

•Remove the battery from

its location and replace

it with a fresh one.

•Insert the battery cover

and replace the screw

with a screwdriver.

10 mL
