MicroNet SP6008P Manuel utilisateur

Communicate via

P/N 2300-0748

Quick Installation Guide

Model No.: SP6008P

8-Port 10/100M PoE Switch

Specifications

SP6008P

Model No.

CE Mark Warning

This equipment complies with the requirements relating to

electromagnetic compatibility of the essential protection requirement

of Council Directive 89/336/EEC on the approximation of the laws of

the Member States. Company has an on-going policy of upgrading

its products and it may be possible that information in this document

is not up-to-date. Please check with your local distributors for the

latest information. No part of this document can be copied or

reproduced in any form without written consent from the company.

WEEE Directive & Product Disposal

At the end its serviceable life ,this product should not be treated

as household or general waste. It should be handed over to the

applicable collection point for the recycling of electrical and

electronic equipment, or returned to the supplier for disposal.

www.micronet.com.tw

Standards

Features

Pin Assignment

and Polarity

PoE Power

Budge

LED Indicators

PoE Power

Output

Power

Adaptor

Dimension

Weight

Reliability MTBF

Environment

IEEE 802.3af/at PoE

IEEE 802.3 10 BaseT

IEEE 802.3u 100 BaseTX

IEEE 802.3x Flow Control

Number of Ports: 8 PoE/PSE ports

Transmission Method: Store and Forward

1/2 (+), 3/6 (-)

120W

Per Port: Link/Act, PoE Act/Status

Per Unit: Power

48V/DC Per Port Output,

15.4 Watts (Up to 30W)

Input: 100~240V/AC, 47~63 Hz

Output: DC56V/2.15A

188 mm x 119 mm x 39mm

0.69 Kg

60 k.hrs. at 25 C

Operating: -10~45 C.

Humidity Operating: 10~90%

LED indicators

For definitions of LED indicators, please refer to the following table:

Introduction

The SP6008P supports IEEE 802.3af/at standard for Power over

Ethernet (PoE) with the maximum power delivery up to 120 Watts.

That makes it suitable to various applications that demand for

remote power feeding and meet high level requirement for power.

SP6008P is totally equipped with 15.4Watts or 30 Watts per PoE

port, which effectively helps allocate power for connected multiple

devices and enhances network management.

Key Features

8 Port 10/100M Nway (Auto-negotiation) Switch

8 PSE/PoE function ports

Supporting the power 15.4 or 30 W for each PoE port

Auto-learn of networking configuration

Auto-detect full/half-duplex modes for any port

Dedicated full-duplex 200Mbps bandwidth

Store-and-Forward switching methods

IEEE 802.3x flow control for full-duplex and back-pressure flow

control for half-duplex

Non-blocking & Non-head-of-line blocking full wire speed

forwarding

Auto-MDI/MDI-X function for any port

1 2

LED Status

Power

Indication

Off

Network Speed Cable Type

10M

100M

Max. Length

Cat. 3,4,5,5e UTP/STP

Cat. 5,5e UTP/STP

100 meters

Note: To prevent costly equipment damage and downtime, please

consider installing a surge suppression device or a UPS

(Un-interrupted Power Supply).

Note:

For cable selection, refer to the following table:

Package Contents

Before you start installing SP6008P, please verify the following

package contents:

SP6008P 10/100M PoE Switch

Quick Installation Guide

Power Cord

Tour of the System

Front Panel

LED indicators

Back Panel

Power Switch and Power Cord Connector

Power in ON

Off power

10M

100M

Port is linked to Power Device

No Power Device is connected

10/100M

PoE

Hardware Installation

The setup of the switch can be performed using the following steps:

Step 1: Connect the Power Cord to SP6008P and then to a

power outlet.

Step 2: Connect a RJ-45 Ethernet cable from IEEE802.3af/802.3at

compliant devices (PD) to an available PoE port

of SP6008P.

Note:

Port 1 to Port 8 are used for connecting to PD or PoE splitter for

end devices.

Step 1:
