METROLOGIC INSTRUMENTS, INC.

MS6130 Hand Held Laser Scanner

and MX003 Scanner Interfaces

Installation and User’s Guide

LOCATIONS

North America Headquarters

Metrologic Instruments, Inc. Customer Service: 1-800-ID-METRO

90 Coles Road Tel: 856-228-8100

Blackwood, NJ 08012-4683 Email: [email protected]

Website: www.metrologic.com

Germany

Metrologic Instruments GmbH Tel: 49-89-89019-0

Dornierstrasse 2 Fax: 49-89-89019-200

82178 Puchheim b. Email: [email protected]

Munich, Germany

South America

Metrologic South America Tel: 5511-5505-6568

Rua Flórida 1821 - 5° Andar Fax: 5511-5505-1681

São Paulo, SP, Brasil Email: [email protected]

CEP: 04571-090

Brazil

Metrologic do Brasil Ltda Tel: 5511-5505-2396

Rua Flórida 1821 - 5° Andar Fax: 5511-5507-2301

São Paulo, SP, Brasil Email: [email protected]

CEP: 04571-090

Asia

Metrologic Asia (Pte) Ltd Tel: 65-842-7155

31, Kaki Bukit Road 3 Fax: 65-842-7166

#05-08 Techlink Email: [email protected]

Singapore 417818

work may be reproduced, transmitted, or stored in any form or by any means

without prior written consent, except by reviewer, who may quote brief

passages in a review, or provided for in the Copyright Act of 1976.

Products and brand names mentioned in this document are trademarks of

their respective companies.

MLPN 2212

Printed in USA

February 2000

iii

TABLE OF CONTENTS

MS6130 Hand Held Bar Code Scanner.....................................................1

MX003 Series Scanner Interfaces.............................................................2

Unpacking List.........................................................................................3

Connections of the “MX” Interface to the Host Device................................4

Connections of the Keyboard Wedge “MX” Interface to the PC..................5

Connections of the MS700i/MS720i with “MX” to the Host Device..............6

Configuration of the MS700i/MS720i with “MX”..........................................7

Configuration of the MS700i/MS720i with “MX” to the Host System............8

Configuration of the “MX” to the ScanPal®Data Collector..........................9

Configuration of the “MX” to the RS-232 Light Pen or Keyboard Wedge

Host System.............................................................................10

Keyboard Wedge (KB) Interface .............................................................11

Configuration of the MS6130 Hand-Held.................................................15

Enabling the MS700i/MS720i Scanner’s RF Low Speed Option...............16

Changing the ID.....................................................................................17

Matching Procedure...............................................................................18

Parts of the MS6130 Hand-Held Bar Code Scanner ................................19

Components of the MS6130 Series Stand...............................................20

Installation of the MS6130 Series Stand..................................................21

Installation of the 6000 Series Universal Charging Stand.........................22

NiCd Battery Charger with Reconditioning Feature..................................23

Visual Indicators.....................................................................................24

Audible Indicators...................................................................................25

Labels....................................................................................................27

TABLE OF CONTENTS (CONTINUED)

Maintenance..........................................................................................27

Troubleshooting.....................................................................................28

Appendix A

Specifications ...........................................................................29

Appendix B

Default Settings of the MS6130 and “MX” Interface ...................32

Appendix C

MX003 Series Scanner Interface Pin Assignments.....................36

Appendix D

Warranty and Disclaimer...........................................................37

Appendix E

Notices.....................................................................................38

Appendix F

Patents.....................................................................................39

Index .....................................................................................................40

THE MS6130 HAND HELD BAR CODE SCANNER

MS6130 Hand Held Bar Code Scanners are wireless scanners with a

mobility range of up to 30 feet from the receiver. When not in use, the

scanner rests in a universal-charging stand. The scanner will be fully

charged in 2 hours when not scanning in the stand. A fully charged MS6130

can provide up to 8 hours of wireless, hand-held scanning. After dormant

periods, the scanner is programmed to enter a timeout mode that will extend

the battery life. There is a reactivation switch conveniently located on the

side of the scanner to turn the unit back on. The scanner has a replaceable

battery pack for added reliability and convenience for your scanning

application.

Metrologic’s scanner uses wireless data communication to transfer

information to the host. The MS6130 may be used with Metrologic’s MX003

Series Scanner Interfaces to provide the short range, one-way

communication link between the scanner and an RS-232, Keyboard Wedge

or Light Pen host device.

The MS6130 uses Metrologic’s patented Infrared Object Sensor for

triggerless operation. The scanner, after a specified time, will enter a

standby mode where the VLD and motor will shut off. Simply present an

object in front of the scanner window, the Infrared Sensor will reactivate the

scanner and the unit will be ready to scan.

To indicate the status of the scanner, the MS6130 uses a green and red

LED located on the top of the scanner. By understanding the flashes of the

LED, you can determine a successful read, laser status, low battery power,

sleep mode, and program mode. There are audible indicators on the

scanner as well. The scanner will beep; one, two or three times to indicate

successful power up or scan, low battery, or program mode, respectively, or

give a razzberry tone; which indicates the scanner has failed diagnostics

upon power up.

In this manual, the MS6130 may be referred to as the scanner or transmitter.

MX003 SERIES SCANNER INTERFACES

Metrologic’s MX003 Series Scanner Interfaces provide a short range, one-

way wireless data communication link between a remote portable scanner

and an RS-232 or light pen host device. Specifically, Metrologic’s MS6130

Hand-Held Laser Scanners include a Liberty®RF transmitter board.

Metrologic’s MS700i/MS720i series scanners, TECH series scanners may

be connected to a MX Series scanner interface. The “MX” scanner interface

includes a RF receiver and a digital interface board.

The MS6130 scanner provides two functions:

•Scans and decodes bar codes

•Transmits scanned data to the RF receiver or “MX”

When the “MX” interface is connected to a ScanPal®or host device such as

a portable data terminal (PDT), it provides two functions

(For example, refer to Figure 1):

•Performs the RF receiver function; for example, beeps to show it has

received data from the transmitter

•Communicates with the host device

In this manual, MX003 series scanner interfaces may be referred to as the

“MX”, “MX” interface or receiver. Suffix of the MX003 model designation will

vary due to country of usage.

Figure 1

Any RS-232C or

Light Pen Device with

MX003 RF Receiver

MS6130 with Liberty

Scanner Interface (Transmitter)

Up to 30 Ft.

(conditions permitting)

UNPACKING LIST

Your shipment will contain a set of items from the two groups listed below:

Transmitter Group:

•MS6130 Hand-Held Scanner

•Stand #45880 (optional)

•Stand #45558, 45559 and 45560 (optional)

•MS4120 Programming Guide

Receiver Group:

•“MX” Scanner Interface

•MCA951 adapter or adapter cable (if required)

•Regulated 5V power supply, MLPN: 6090/6091

(115/220 VAC)(optional)

•“MX” Scanner Interface

•MS700i with Liberty®RF Receiver option cable

•Power supply (optional)

•Communication cable with connection for power

supply (optional) or communication cable only

•Stand #45483 (optional)

•MS700i and MS720i Installation and User’s Guide

•ScanSelect™ Scanner Programming Guide (#2186)

•ScanPal®Data Collector

•“MX” Scanner Interface

•Upload cable, MLPN: 51061 and 51236

•MCA951 adapter

•Regulated 5V power supply, MLPN: 6090/6091 (115/220 VAC)

•ScanPal Data Collector Installation and User’s Guide

CONNECTIONS OF THE “MX” INTERFACE TO THE HOST DEVICE

Except version 17

1. Turn off the host system.

2. Connect the MCA to the host device. Connect the “MX” interface to

the MCA.

3. Check the AC input requirements of the transformer to make sure the

voltage matches the AC outlet. The socket outlet should be near the

equipment and easily accessible.

4. Plug the transformer into the side of the MCA and the AC outlet.

5. Power up the host system.

Figure 2: Connecting the “MX” (through the MCA) to a host device

To maintain compliance with applicable standards, all circuits connected

to the unit must meet the requirements for SELV (Safety Extra Low

Voltage) according to EN 60950.

Transformer

“MX” Scanner Interface

MCA

Host System

MS6130 with Liberty

Scanner Interface

(Transmitter)

CONNECTIONS OF THE KEYBOARD WEDGE

“MX” INTERFACE TO THE PC

Version 17 only

MX003 Scanner Interfaces with a suffix of “17" are Keyboard Wedge

versions used to interface with a PC and keyboard.

1. Turn off the PC.

2. Plug the “MX” receiver adapter cable to the PC keyboard port.

3. Plug the keyboard into the “MX” receiver adapter cable.

4. Power up the PC.

Figure 3: Connecting the “MX” to a PC and keyboard

To maintain compliance with applicable standards, all circuits connected

to the unit must meet the requirements for SELV (Safety Extra Low

Voltage) according to EN 60950.

The following statement is applicable if the scanner will receive power

from a host device such as a computer system.

Caution: To maintain compliance with standards CSA C22.2 No. 950/UL

1950 and norm EN60950, the power source must meet

applicable performance requirements for a limited power

source.

“MX” Receiver adapter Cable

Optional Adapter

Host System

MS6130 with Liberty

Scanner Interface

(Transmitter)

CONNECTIONS OF THE MS700I/MS720I

WITH “MX” TO THE HOST DEVICE

To avoid potential problems, do not power up the scanner until the

communication cable is secured to the host.

1. Turn off the host system.

2. Connect the 25-pin D-type connector on the MS700i/MS720i scanner’s

head cable to the communication cable. Connect the other end of the

communication cable to the host device. If the scanner will not receive

power from a transformer, skip to Step 5.

3. If the scanner will receive power from an external power source, check

the AC input requirements of the transformer to make sure the voltage

matches the AC outlet. The socket-outlet should be near the equipment

and easily accessible.

4. Plug the transformer into the side of the female D-type connector

located on the communication cable. Plug the transformer into the AC

outlet to supply power to the scanner.

5. Power up the host system.

6. Attach the “MX” to the MS700i/MS720i scanner via the LSO cable that

terminates to a 10-pin modular connector.

Note: When the MS700i/MS720i scanner first receives power, the

LEDs will flash and then the scanner will beep once. After the

scanner performs this startup sequence, the green LED will remain

on for a specified time showing that the laser is on.

Refer to the MS700i and MS720i Laser Bar Code Projection

Scanner Installation and User’s Guide for information on how to

operate the scanner.

To maintain compliance with applicable standards, all circuits connected

to the unit must meet the requirements for SELV (Safety Extra Low

Voltage) according to EN 60950.

The following statement is applicable if the scanner will receive power

from a host device such as a computer system.

Caution: To maintain compliance with standards CSA C22.2 No. 950/UL

1950 and norm EN60950, the power source must meet

applicable performance requirements for a limited power

source.

Autres manuels pour MS6130

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Metrologic Lecteur de codes-barres

Metrologic

Metrologic MS 1690 Focus Series Manuel utilisateur

Metrologic

Metrologic MS7600 Manuel utilisateur

Metrologic

Metrologic 160 Guide de l'utilisateur

Metrologic

Metrologic MK5145-31A38 Manuel utilisateur

Metrologic

Metrologic MS7820 Solaris Manuel utilisateur

Metrologic

Metrologic MS 1690 Focus Series Manuel utilisateur

Metrologic

Metrologic MS9520 Voyager Manuel utilisateur

Metrologic

Metrologic MS6720 Manuel utilisateur

Metrologic

Metrologic MS6720 Manuel utilisateur

Metrologic

Metrologic MS7120 Orbit Manuel utilisateur

Metrologic

Metrologic Hand-Held Scanner Manuel utilisateur

Metrologic

Metrologic IS1000 Series Manuel utilisateur

Metrologic

Metrologic S4800 microQuest Series Manuel utilisateur

Metrologic

Metrologic MS1633 FocusBT Manuel utilisateur

Metrologic

Metrologic MS9590 VOYAGERGS series Manuel utilisateur

Metrologic

Metrologic MS700i Manuel utilisateur

Metrologic

Metrologic MS7320 InVista Series Manuel utilisateur

Metrologic

Metrologic MS9530 Series Manuel utilisateur

Metrologic

Metrologic MK3780-31A62 Manuel utilisateur

Metrologic

Metrologic IS3480-00 Manuel utilisateur

Metrologic

Metrologic IS421X ScanGlove Manuel utilisateur

Metrologic

Metrologic MS5100 Eclipse Series Manuel utilisateur

Metrologic

Metrologic Cubit IS6520 Series Manuel utilisateur

Metrologic

Metrologic MS1633 FocusBT Manuel utilisateur

Manuels Lecteur de codes-barres populaires d'autres marques

POSMicro

POSMicro Datalogic PowerScan D7100 Manuel utilisateur

Marson

Marson MT780 Guide de configuration rapide

NCR

NCR RealPOS Manuel utilisateur

Motorola

Motorola SE3300 Guide de configuration rapide

Element

Element P130BT Manuel utilisateur

Motorola

Motorola Symbol LS3008 Manuel d'installation et d'exploitation

Meec tools

Meec tools OBD-II / VAG Manuel utilisateur

SICK

SICK CLP 100 Manuel utilisateur

Royal Tag SA

Royal Tag SA I-Read Manuel utilisateur

Welch Allyn

Welch Allyn IMAGETEAM 3800 Manuel utilisateur

Meteor

Meteor 8310 Manuel utilisateur

Denso

Denso BHT-500B Manuel utilisateur

Datalogic

Datalogic Heron HD3130 Manuel utilisateur

Motorola

Motorola MP6000 Instructions de montage

Newland

Newland NLS-HR15-BT Manuel utilisateur

ARTDEV

ARTDEV AS-1310 Manuel utilisateur

Aopos

Aopos AS290 Manuel utilisateur

ENS

ENS 367-5455 Manuel utilisateur
