Mercedes-Benz Series 176 Manuel de référence

Introduction of the New A-Class

Model Series 176

Introduction into Service Manual

Daimler AG, GSP/OR, HPC R 822, 70546 Stuttgart

Order No. 6516 1393 02 – HLI 000 000 08 06 – Printed in Germany – 06/12

Introduction of the New A-Class

• Model Series 176

– This printout will not be recorded by the update service. Status: 06 / 2012 –

Mercedes-Benz Service

Daimler AG · Technical Information and Workshop Equipment (GSP/OR) · 70546 Stuttgart

Introduction of the New A-Class

Model Series 176

– This printout will not be recorded by the update service. Status: 06 / 2012 –

Information and copyright

Product Portfolio

You can find out all you need to know about our entire product

portfolio in our Internet portal:

Link: http://aftersales.mercedes-benz.com

Questions and suggestions

If you have any questions or suggestions concerning this product, please write

to us.

Email: [email protected]

Fax: +49-(0)18 05/0 10-79 78

This document, including all its parts, is protected by copyright.

Any further processing or use requires the previous written consent of

Daimler AG, Department GSP/ORS, HPC R822, W002, 70546 Stuttgart.

This applies in particular to reproduction, distribution, alteration, translation,

microfilming and storage and/or processing in electronic systems, including

databases and online services.

Image no. of title image: P00.01-4255-00

Image no. of poster: P00.00-4817-00

Order no. of this publication: 6516 1393 02 – HLI 000 000 08 06

06/12

– This printout will not be recorded by the update service. Status: 06 / 2012 –

Contents

Introduction of the New A-Class, Model Series 176

Preface 7

Overview

Models and major assemblies 8

Brief description 9

Equipment 15

Overall vehicle

Exterior 24

Dimensions 25

Technical data 27

Panoramic sliding sunroof 29

Interior 30

Maintenance

ASSYST PLUS 34

– This printout will not be recorded by the update service. Status: 06 / 2012 –

Contents

4bIntroduction of the New A-Class, Model Series 176

Drive

Engine data for gasoline engines 36

Engine data for diesel engines 37

Description of engine M 270 38

Description of engine OM 651 41

Description of engine OM 607 43

Exhaust system 61

Fuel system 63

Transmission

Manual transmission FSG 310 64

Automatic transmission 7G-DCT 65

Suspension

Steering 66

Axles and suspension 67

Brake system 68

Wheels and tires 70

– This printout will not be recorded by the update service. Status: 06 / 2012 –

Contents

Introduction of the New A-Class, Model Series 176

Networking

Overall network 72

Battery and alternator 76

Energy management 77

Lights

Exterior lights 78

Safety

Active safety 80

Passive safety 81

Driving assistance systems

Active Parking Assist 83

Comfort

Climate control 84

Audio and communication

Telematics 85

– This printout will not be recorded by the update service. Status: 06 / 2012 –

Contents

6bIntroduction of the New A-Class, Model Series 176

Bodywork

Bodyshell 88

Force progression during an accident 90

Aftersales Information

CO2 Efficiency Classes 91

Special tools

Bodywork 92

Engine OM 607 93

Workshop equipment

Body repair systems 101

Annex

Abbreviations 102

Index 104

– This printout will not be recorded by the update service. Status: 06 / 2012 –

Preface

Introduction of the New A-Class, Model Series 176

Dear Reader,

With this Introduction into Service Manual we are

introducing the new A-Class, model series 176.

The purpose of this brochure is to acquaint you with

the technical highlights of this new vehicle in advance

of its market launch. This brochure is intended to

provide information for people employed in service,

maintenance/repair and for aftersales staff. It is

assumed here that the reader is already familiar with

the Mercedes-Benz model series currently on the

market.

In terms of the contents, the emphasis in this Intro-

duction into Service manual is on presenting new and

modified components and systems.

This Introduction into Service Manual is not intended

as an aid for repairs or for the diagnosis of technical

problems. For such needs, more extensive information

is available in the Workshop Information System (WIS)

and Xentry Diagnostics.

WIS is updated continuously. Therefore, the informa-

tion available there reflects the latest technical status

of our vehicles.

The Introduction into Service Manual provides initial

information on the on the new A-Class, model series

176. The Introduction into Service Manual is not

stored in this form in WIS. The contents of this

brochure are not updated. No provision is made for

supplements.

We will publicize modifications and new features in the

relevant WIS documents. The information presented in

this Introduction into Service Manual may therefore

differ from the more up-to-date information found in

WIS.

All information relating to technical data, equipment

and options is valid as of the copy deadline in April

2012 and may therefore differ from the current

production configuration.

Daimler AG

Technical Information

and Workshop Equipment (GSP/OR)

iNote

Information about the vehicles and about oper-

ating the vehicle functions can also be found in the

interactive owner's manual on the Internet at:

www.mercedes-benz.de/betriebsanleitung

– This printout will not be recorded by the update service. Status: 06 / 2012 –

Models and major assemblies

Overview

Introduction of the New A-Class, Model Series 176

bd Designation Model

designation

Engine Transmission Market launch

A180CDI

BlueEFFICIENCY 176.000 651.901 724.003 09/12

A180CDI

BlueEFFICIENCY 176.012 607.951 711.642 09/12

A200CDI

BlueEFFICIENCY 176.001 651.901 711.642

724.003 09/12

A220CDI

BlueEFFICIENCY 176.003 651.930 724.003 12/12

A180

BlueEFFICIENCY 176.042

270.910 711.643

724.003

09/12

A200

BlueEFFICIENCY 176.043 09/12

A250

BlueEFFICIENCY 176.044 270.920 724.003 09/12

P00.00-4818-00

A-Class (model 176)

– This printout will not be recorded by the update service. Status: 06 / 2012 –

Brief description

Overview

Introduction of the New A-Class, Model Series 176 b

Vehicle concept

The A-Class in model series 176 is based on a new

concept, which differs fundamentally from the

previous A-Class model series 169.

The transversally installed engine is no longer

mounted above the front axle, but ahead of it. The

multilink rear suspension provides high responsive-

ness with high driving safety and high comfort.

Numerous special equipment options such as

driving assistance systems make the new A-Class

especially comfortable while also enhancing its

safety level.

Dimensional concept

The change in concept is particularly apparent

when the vehicle dimensions are compared with the

predecessor. The vehicle length has been extended

by 409 mm, the wheelbase by 131 mm. The width

of the vehicle has grown by 16 mm while the vehicle

height has been reduced by 160 mm.

Innovations

• New engine mounting concept with improved

NVH characteristics (Noise, Vibration and

Harshness, i.e. minimization of noise and

vibrations)

• New gasoline engines with direct injection

and turbocharging

• New 4-cylinder diesel engine OM 607

• Engine M 270 DEH16 LA with CAMTRONIC

(valve lift adjustment)

• New automatic transmission 7G-DCT

• Cradle for iPhone®(for Audio 5 USB)

• Improved aerodynamics and aeroacoustics of

body

Aerodynamics

• Cd value of 0.27

(0.26 with code (4U3) BlueEFFICIENCY Edition)

• Optimized outside mirror housing design

• Extensive sealing of the entire front spoiler (area

surrounding radiator and headlamps)

• Hubcaps with particularly favorable

aerodynamic properties

•Largerroofspoiler

• Jagged wheel spoilers on front and rear wheel

wells

• Comprehensive paneling of main floor up to rear

wheel arch

• Lowering of body at front and rear axles

• Paneling of suspension parts on rear axle

– This printout will not be recorded by the update service. Status: 06 / 2012 –
