MELICONI TLC02 Manuel utilisateur

TLC02

Thank you for choosing a Meliconi remote control.

The TLC02 remote control is designed to command a LG digital television sets.

The MELICONI remote control reproduces infrared signals corresponding to the original; the functions that operate in radio

frequency (e.g. voice commands and pointers) are not supported.

The remote control has a permanent memory, so it does not lose its settings even if there are no batteries in it.

The remote control requires 2 new 1.5V AAA/LR03 alkaline batteries, not included in the

package. Insert with the correct polarity as shown in figure.

DO NOT use rechargeable batteries.

BATTERIES TEST: Press and hold the 5button and check that the LED remains on

continuously until the button is released. If the light is off or blinks, the inserted batteries are low,

therefore they need replacement.

If necessary it is possible to completely reset the remote control and bring it back to the initial conditions.

WARNING : All user settings will be lost. Operate as follows:

•On the MELICONI remote control press and hold the button until the LED lights up; release.

•Enter the code 0100.

•Three final flashes indicate that the operation has been completed successfully.

RESET THE REMOTE CONTROL

Do not leave exhausted batteries inserted, as liquid may leak and damage the remote control

INSERTING THE BATTERIES

SAFETY WARNINGS

The remote control and batteries should not be exposed to excessive heat such as sunlight, fire

or the like.

The product is not a toy. Keep out of reach of children or domestic animals.

This remote control, after inserting the batteries, is normally ready for use as it is already set at the

factory with a specific code.

Keep this booklet for future reference

Remote control for TV sets LG ready to use

The functions of the buttons on the MELICONI remote control are only available if the original device is equipped with it.

Sometimes some functions of the original remote control are not directly present on the MELICONI remote control keypad.

To enable them, connect to the www.cme.it page, use the on-line tool BUTTONS AND FUNCTIONS and continue until you

see the list matching buttons between the original remote control and the MELICONI remote control.

To obtain some functions, press and hold the button and press the corresponding key indicated in the table.

If the function you want to play is matched with an number in orange color, operate as follows:

•On the MELICONI remote control press and hold the button.

•When the LED turn on, without releasing the button, point the remote control towards the device

and enter the previously identified number corresponding to the function you want to get. (at the last digit

pressure, the remote control already transmits this function)

• Release the buttons; to match the function obtained to a MELICONI remote control button, within 30

seconds, press and hold the desired button.

• Wait three flashes indicate that storage; release the button. (the used button loses the original function

that will be called by the REMOTE CONTROL RESET procedure)

●IF THE REMOTE CONTROL IS NEW AND YOU CAN NOT MAKE IT WORK

Check that you have carried out all the settings procedures correctly. If necessary repeat them, following all the steps

indicated carefully, or contact the ASSISTANCE.

●IF THE REMOTE CONTROL IS NO LONGER ABLE TO CONTROL THE DEVICE

Disconnect the device from the electric socket and leave it without power for a few minutes; switch the device on again.

Remove the batteries from the remote control, press the ON/OFF button twice and insert NEW batteries.

Make sure that the remote control is pointing at the device without any obstacles between them.

If necessary try to the RESET THE REMOTE CONTROL.

●IF SOME FUNCTIONS ARE NOT AVAILABLE ON THE REMOTE CONTROL

Sometimes some functions of the original remote control are not directly present on the MELICONI remote control keypad.

To enable them, operate as described in the BUTTONS AND FUNCTIONS chapter.

●HOW TO CHECK IF THE REMOTE CONTROL SENDS INFRARED SIGNALS

The human eye is not able to detect infrared signals; use a camera (even that of the mobile phone).

Aim the infrared LED located in front of the remote control (not the red LED above) and press and hold on the remote control

the 5button.

If you see through the camera, the LED light with short white / light blue flashes means that the remote control works and

emits infrared.

ATTENTION!

Most problems are caused by using insufficiently charged batteries.

We recommend checking and replace them as shown in the INSERTING THE BATTERIES chapter.

TROUBLESHOOTING (F.A.Q.)

BUTTONS AND FUNCTIONS

If you want to delete the function in combination with a single button, operate as follows:

•On the MELICONI remote control press and hold the button.

•When the LED turn on, without releasing the button, enter the code 1600; release the buttons.

• Within 30 seconds, press and hold the button of which you want to delete the function; wait three flashes indicating the end

of the operation, release the button. (to recall the original function RESET THE REMOTE CONTROL)

web: www.cme.it e-mail: [email protected]

IMPORTANT! To obtain technical assistance, it is essential to indicate the BRAND and MODEL of the appliance you intend

to control and the name of the MELICONI remote control you are using.

WARRANTY: 2 year Always keep your sales receipt as proof of the validity of the product’s warranty. The warranty is

voided if the product is tampered with or used improperly.

Meliconi SpA, Via Minghetti 10 - 40057 Cadriano di Granarolo Emilia, (BO) Italy

web: www.meliconi.com email: telecomandi@meliconi.com

The symbol showing a wheelie bin with a cross through it which appears on the device indicates that at the

end of its useful life the product must be collected separately from other waste. Therefore, at the end of the

device’s life, you must take it to appropriate centres for the differentiated collection of electrical and electronic

waste, or return it to the retailer when purchasing a new device of equivalent type. Suitable differentiated

collection to allow subsequent recycling of the decommissioned device, with environmentally-compatible

treatment and disposal, help to prevent any negative effects on the environment and health and to promote

the recycling of the materials of which the device is made.

CAUTION: Batteries must not be disassembled, thrown into fire or released into the environment. Improper

use can cause damage to the environment and health. The symbol of the bins, indicating that the batteries

should be disposed of according to current regulations; inquire on collection of spent batteries and

accumulators in force in your country.

ASSISTANCE

DELETE FUNCTION BY SINGLE BUTTON
