Mazda 1982 RX-7 Guide de démarrage rapide

This document is brought to you through the kind services of

Kevin Wright

[email protected]

http://www.wankel.net/~krwright

who laboriously scanned, post-processed, Distilled, and organized the original 1982 (May 1981

printing) wiring diagram provided by Michael DeVantier (Thanks!).

There are several ways to get around in the document. I have provided Bookmarks to all the

sections and subsections, and thumbnails are also provided in the Thumbnails side bar.

Only a few of the pages in the original document were of the fold-out variety, and only one really

needsto be split into multiple documents. This page hasbeen provided in full sheet and

segmented versions, as indicated in the Bookmarks. These pages probably should be printed out

on 11” x 17” paper if available, but are still readable on 8.5” x 11” paper. You could also print out

the segmented versions and attach them together, if so desired (or not. Whatever you want, eh?)

I have also included a label for the spine of a binder, for those who wish to print out all the pages

and keep a dead-tree edition handy. J

The original document is © 1981Toyo Kogyo Co., Ltd., and remains so.

This version is provided as a service for owners of first generation Mazda RX-7s who are having a

devil of a time locating the factory wiring guide for a reasonable price.

If you really want to send me money, email me and I’ll tell you where to send it, but it’s not

necessary. Consider this payback for all the good advice and information gleaned from the various

RX-7 email lists!

Subscribe to the Early Mazda Rotaries email list:

Send an email with “subscribe” (without the quotes) to [email protected]

See http://www.dfw-rx7.com for information on the DFW-RX7 email list.

05/31/02
