Maxtor OneTouch II Manuel utilisateur

EXTERNAL HARD DRIVE

Maxtor OneTouchTM II QuickStart Guide

For Windows

1Insert the Install CD into your

CD-ROM drive

To install the Maxtor OneTouch II software

and Dantz Retrospect Express HD:

1. Insert the Install CD.

2. Wait for the Maxtor

screen to appear.

3. Follow the on-screen instructions to install

the software. For details, refer to Chapter 2 in

the User’s Guide, on the Install CD.

4. After completing installation, eject the CD.

Do not remove the CD until all steps of the

installation are complete.

Fir

Wir

USB

394

USB

Maxtor OneTouch

Button

*The USB model does not support the 1394/FireWire interface. The combo model

may be connected with either the 1394/FireWire or the USB interface.

3Set up the OneTouch feature

1. Push the button on the front of your drive.

The Retrospect Express HD registration

screen will appear.

2Connect the drive to your computer*

Plug in the power adapter, turn the power switch

on and plug in either the USB cable or the

1394/FireWire cable (depending on which model

you have). For details, refer to the Connecting the

Drive section

Allow up to 2 minutes for your computer to

recognize the drive.

This Installation describes the Full Installation with Retrospect™ Express

HD. If you wish to install your drive without Retrospect Express HD, choose

the ‘Install Drivers’ option to install the Maxtor software only. For more

information, go to Chapter 2 of the User’s Guide on the Install CD.

The Maxtor OneTouch feature will not work unless you install

Retrospect Express HD.

If you did not install Retrospect Express HD,

you may skip this step.

2. Complete the registration form.

Note: In order to register, you must be

connected to the internet.

3. After you complete the registration, the

Retrospect Express HD welcome screen

will appear, displaying the automated backup

settings for your computer.

You may back up your computer immediately

by clicking Back up now, let Retrospect

Express HD do it automatically at the next

scheduled backup time, or do it at any time

by pressing the button on the front of your

drive and clicking Back up now.

Your installation is complete!

Windows 2000 and XP

A window will appear, giving you the opportunity to format

your drive with the NTFS format. To do so, click Format.

Windows 2000 and XP

You must have Administrative Privileges, refer to chapter 2 of

the User’s Guide, on the Install CD for more information.

Windows 98SE and 1394/FireWire* interface

You must install Microsoft’s 98SE Storage Supplement. For

details, refer to chapter 2 of the User’s Guide. You must have

Microsoft Internet Explorer 5.01 or later to install the software.

trademark of Maxtor Corporation. Dantz and Retrospect are either registered trademarks or trademarks of Dantz

Development Corporation. Specifications subject to change without notice.

Maxtor P/N: 20259900

EXTERNAL HARD DRIVE

www.maxtor.com

Maxtor P/N: 20259900

To restore your Windows system

1. Prepare your hard drive.

Partition, if necessary, and format.

Note: Do not partition or reformat the Maxtor OneTouch II drive that

your system is stored on.

2. Install your operating system.

The following services packs need to be installed:

• Windows XP: Service Pack 1 or later.

• Windows 2000: Service Pack 3 or later.

Microsoft Internet Explorer 5.01 or later is required for all Windows

operating systems.

3. Re-install the Maxtor OneTouch II software including Retrospect

Express HD.

4. Open Retrospect Express HD.

5. Set up the Restore.

Click Restore.

A calendar window will appear showing all of your restore points.

6. Select your restore point.

Click the restore point that you wish to restore and click Next.

Note: For more information about restore points and using

Retrospect Express HD, see ‘Using Retrospect Express HD’ in

chapter 3 of the User’s Guide on the Install CD.

You are now asked which files and folders you would like to restore.

7. Select your entire computer for restore.

Place a check next to My Computer and click Next.

8. Select the location of your restore.

You will now select where you want to restore your files.

Select To Their Original Location On, to restore them to the exact

location from which they were originally copied.

Note: All data will be replaced at the location you have chosen to

restore with the files and folders you have chosen to restore.

9. Start the Restore.

Click Restore.

Retrospect Express HD will start restoring files on your computer.

A status bar will show the progress until the restore is finished.

10. Exit Retrospect Express HD.

If your system restore was successful, you can exit Retrospect

Express HD. Click the red ‘X’ in the upper right corner of

the window.

11. Finishing the restore.

Restart your computer.

Your system may require more than one restart. Follow any

additional on-screen instructions, if necessary, to complete your

system restore.

Restoring your System

Windows 2000, XP, 98SE, ME

If your system is damaged and you need to restore it from your

backup copy, follow the steps below:
